2007 Hyundai Getz Owner's Manual

FEATURES OF YOUR HYUNDAI 1- 15
HTB025-D
SB070F1-E Seat Cushion Height Adjustment (Driver's seat only)(Not all models)
To raise or lower the front part of the seat cushion, turn the front knob clock-wise or counter-clockwise. To raise or lower the rear part of the seat cushion, turn the rear knob clockwise orcounter-clockwise.HTB027-D
SB070E1-E Lumbar Support Adjustment (Driver's seat only)(Not all models) Some models are fitted with adjustable driver seat lumbar support which may be used to increase the amount oflumbar support offered by the seat back. Adjustment is performed by moving the handle at the side of the backrest in aforward direction to increase the sup- port.
B080G01A-EAT Adjusting Armrest Angle (Driver's side only)
The armrest can be raised or lowered manually. To raise the armrest, pull it up.To lower it, press the armrest down. HTB2049

1- 16 FEATURES OF YOUR HYUNDAI
ZB070A1-E REAR SEAT ENTRY (For 3-door model)
The front passenger seatback should be tilted to enter the rear seat. By pulling up on the recliner controllever (1) at the outside of the front passenger seat, the seatback will tilt forward and the seat will automaticallyslide forward. Rear seat occupants can tilt the front passenger seatback by depressing thefoot lever (2) as shown in the drawing. B080H01FC-EAT REAR SEAT Seat Rake Adjustment
HTB258-D
(1)
(2)
The rear seat rake adjustment is per- formed by raising the lever at the front of the seat back and sliding the seat tothe desired position. At this position the lever should be released and the seat rocked to and fro to ensure that themechanism has locked.HTB028
Seatback folding lever
!WARNING:
Passengers sitting in the rear seat should be careful not to accidentallypress the foot lever (2) whilst the vehicle is moving. As this may cause the seat back to move forward andinjure a front seat occupant.

FEATURES OF YOUR HYUNDAI 1- 17
HTB294
B099A02F-AAT BEFORE FOLDING THE REAR SEATS Outboard Rear Seat Belt
HTB300
!
Rear Seat Centre's 3 Point Type Seat Belt.
In order to prevent the shoulder beltfrom being damaged while folding the rear seat, the shoulder belt must bepassed through the hanger to keep it out of the way. CAUTION:
Seat belts must be removed from the hanger when in use.
B090B01TB-EAT Folding Rear Seatback and Seat Cushion For greater convenience, the entire seatback and seat cushion may be folded down and up.
1. Push the head restraint down to the lowest position.
2. To fold down the seatback , push and hold the seatback folding lever toward the head restraint, then push down the seatback. HTB2006
Seatback folding lever

1- 18 FEATURES OF YOUR HYUNDAI
and no seat belts are available for use when the seatback is folded down. Passengers who are notproperly seated and wearing seat belts could sustain serious inju- ries or death in case of an accidentor a sudden stop.
o Objects should not extend higher
than the top of the front seatbacks.This could allow cargo to slide forward and cause injury or dam- age during sudden stops.
o When you return the folded down seatback to its upright position,always be sure to install the head- rests in their proper positions. Head restraints are important tothe safety of occupants in a rear collision. If the headrests are not installed in their proper position,serious injury or death could re- sult if a rear end collision occurs.
3. Pull the seat cushion release handle
rear ward, then lift up a desired seatcushion.
!WARNING:
o When you return the folded down seatback to its upright position, make sure the seat belts are in position to be accessible and to function properly.
o When you return the folded down seatback to its upright position,be careful not to get your fingersor legs caught in the mechanism.
o The purpose of the fold down
rear seatback and the fold for-ward rear seat cushion is to in- crease cargo space. Do not allow passengers to sit in the cargoarea while the car is moving. This is not a proper seating position
4. To secure the seat, hook the secur-
ing strap under the seat back to the headrest stay of front driver andpassenger seat.
5. To return the seatback and seat
cushion to its normal position, re-verse the above procedure.
o When you return the seatback to its
upright position, always be sure it islocked into position by pulling and pushing on the top of seatback.
HTB030A
Seat cushion release handle
HTB031Securing strap
Securing Strap

FEATURES OF YOUR HYUNDAI 1- 19
B100A01TB-EAT SEAT WARMER (Not all models) The seat warmer is provided to warm the front seats during cold weather. With the ignition key in the "ON" posi-tion, push either of the switches to warm the driver's seat or the passenger's seat.During mild weather or under conditions where the operation of the seat warmer is not needed, keep the switches in the"OFF" position. NOTE:
o The seat warmer will not operate if
ambient temperature is higher than 98.6°F (37°C).
o If the seat warmer doesn't work when ambient temperature islower than 82.4°F(28°C), it must bechecked at authoriseddealer.
HTB194
!WARNING:
Be very careful not to injure by low temperature burn or an attack of fe- ver on the occupants of the frontseats such as: children, elderly per- sons, persons under medication or under the influence of alcohol.
B140A01TB
B140A01B-GAT REAR SEAT WARNING For the safety of all passengers, lug- gage or other cargo should not be piled higher than the top of the seatback.

1- 20 FEATURES OF YOUR HYUNDAI
SB090C1-E Larger Children Larger children should occupy the rear seat and be restrained at all times. Therestraint may take the form of a special safety belt or the original factory fitted seat belt used in conjunction with anapproved booster cushion depending upon the size and weight of the child. Under no circumstances should chil-dren be allowed to travel standing, kneel- ing or lying on the seat. Never allow children to ride in the frontpassenger seat. SB090O1-E Pregnant Women The use of a seat belt is recommended for pregnant women. The seat belt should be worn as low and snugly as possible across the hips, not across the abdo-men. A qualified Medical Practitioner should be consulted for further informa- tion. SB090E1-E Injured Persons A seat belt should be used when an injured person is being transported. Forspecific recommendations, the advice of a qualified Medical Practioner should be sought. SB090F1-E Seat Belt Occupancy The seat belts are designed to be used by one seat occupant only. The use ofa seat belt by more than one person increases the levels of injury which may be sustained in the event of an accident. B150G01A-EAT Do Not Lie Down To ensure that the maximum level of protection may be afforded by the seat belt system, all passengers should besitting in an upright position throughout the journey. The seat belt will be unable to afford maximum protection if thefront seats are at or near the fully reclined position.
SB090A1-E SEAT BELT PRECAUTIONS Seat belts should be worn at all times by all occupants front and rear. Thepossibility of injury or the severity of injuries suffered in the event of an accident will be greatly reduced by thewearing of seat belts. In addition the following recommenda- tions should be observed.
SB090B1-E Babies/Small Children Babies and small children must be restrained using a restraint system spe-cifically designed for this purpose. Un- der no circumstances should a child be carried in the vehicle without the use ofa suitable restraint which meets the regulations in force in the country where the vehicle is in operation.

FEATURES OF YOUR HYUNDAI 1- 21
!WARNING:
Sitting in a reclined position or lying down when your vehicle is in motion can be dangerous. Even if you buckleup, your seat belts can't do their job when you're reclined. The shoulder belt can't do its jobbecause it won't be against your body. Instead, it will be in front of you. In a crash you could go into itwith great force, receiving serious neck or other injuries. The lap belt can't do its job either. Ina crash the belt could go up over your abdomen. The belt forces would be applied there, not at your strongpelvic bones. This could cause seri- ous internal injuries. For proper protection when the ve-hicle is in motion, have the seatback upright. Then sit back in the seat and wear your seat belt properly. Seepage 1-22.
B170A01L
SB090K1-E Replacement of Seat Belts The entire seat belt assembly or as- semblies should be inspected by anauthorized repairer if the vehicle has been involved in an accident even if no damage is evident. Additional ques-tions concerning seat belt operation should be directed to a Hyundai authorised repairer. B170A04A-EAT HEIGHT ADJUSTABLE FRONT SEAT SHOULDER BELT(Not all models)
SB090H1-E CARE OF SEAT BELTS Seat belt assemblies must never be disassembled or modified in any way.In addition, care should be exercised to ensure that the belt assemblies do not become damaged by being trapped inseat mechanisms, door shuts etc. SB090I-E Periodic Inspection It is recommended that all seat belts be inspected periodically for wear or dam-age of any kind. Parts of the system that are damaged should be replaced as soon as possible. Under no circum-stances must any part of the seat belt assemblies be dismantled or repairered. SB090J1-E Keep Belts Clean and Dry Seat belts should be kept clean and dry. If belts become dirty, they can be cleaned using a mild soap solution and warm water. Bleach, dye, strong deter-gents or abrasives should not be used since the fabric may become damaged and weakened.

1- 22 FEATURES OF YOUR HYUNDAI
The buckle should be firmly pressed into the stalk until locked which will be indicated by an audible "click".The length of the seat belt webbing will be automatically adjusted by the seat belt mechanism to allow the wearermaximum freedom of movement whilst the belt is being worn. However, in the event of rapid deceleration or impact,the belt mechanism will automatically lock. The mechanism will also lock if the seatbelt webbing is withdrawn too quickly when the belt is being fastened or if attempts are made to withdraw thewebbing whilst the vehicle is not on level ground. Should the seat belt lock under these conditions, it will be pos-sible to release the mechanism by al- lowing a small amount of webbing to be retracted and the belt withdrawn again.
B180A01A-EAT SEAT BELTS (3-Point Type) To Fasten The Seat Belt
B180A01L-D
The seat belts are fastened by pulling the belt buckle towards the seat belt stalk and inserting the metal tongue of the buckle into the stalk. NOTE: When pulling the seat belt buckle towards the fastening position makesure the webbing is not twisted.
!
You can adjust the height of the shoul- der belt anchor to one of the 4 positions. If the height of the adjusting seat belt istoo near your neck, you will not be getting the most effective protection. The shoulder portion should be ad-justed so that it lies across your chest and midway over your shoulder nearest the door and not your neck.To adjust the height of the seat belt anchor, lower or raise the height ad- juster into an appropriate position. Toraise the height adjuster, pull it up. To lower it, push it down while pressing the height adjuster button.Release the button to lock the anchor into position. Try sliding the release button to make sure that it has lockedinto the position.
WARNING:
o The height adjuster must be in the locked position when the vehicle is moving.
o The misadjustment of height of the shoulder belt could reduce theeffectiveness of the seat belt in a crash.
