2007 GMC SAVANA Owner's Manual

Outside Camper-Type Mirrors
If your vehicle is
equipped with this style
camper-type mirrors,
they can be adjusted so
you can have a clear
view of any objects
behind you.
1. To adjust the mirrors
when towing a
trailer, turn
the mirror by
pushing the mirror
head toward
the front of the
vehicle.2. Turn the mirror head
so that it swings
further outboard and
adjust the mirror
surface as needed.
If your vehicle is
equipped with this style
camper-type mirrors,
they can be adjusted so
you can have a clear
view of the objects
behind you.
137

Adjust the mirror by rotating it left or right. Once
the mirror is adjusted to the correct position,
tighten the set screw, located at the end of the
arm, to hold the mirror in place. These mirrors can
also be manually folded in.
On the lower portion of each mirror is a convex
mirror. A convex mirror’s surface is curved so you
can see more from the driver’s seat.
Outside Power Mirrors
If the vehicle has power
mirrors, the control is
located on the driver’s
side door.Select each mirror by turning the knob clockwise
for the passenger’s side mirror or counterclockwise
for the driver’s side mirror. The center position
is neutral.
Then, adjust the mirror angle by moving the knob
in the desired direction.
Outside Convex Mirror
Your passenger’s side mirror may be convex.
A convex mirror’s surface is curved so you can see
more from the driver’s seat.
{CAUTION:
A convex mirror can make things (like
other vehicles) look farther away than
they really are. If you cut too sharply into
the right lane, you could hit a vehicle on
your right. Check your inside mirror or
glance over your shoulder before
changing lanes.
138

Outside Heated Mirrors
If your vehicle is
equipped with outside
heated mirrors, they can
be defrosted by
pressing the mirror
button located near the
fan control.
An indicator light in the button will light when the
outside heated mirrors are activated.
Your rear window defogger comes on when the
outside heated mirrors are on. If your vehicle has a
rear window defogger, see “Rear Window
Defogger” inClimate Control System on page 159.
Storage Areas
Your vehicle may have a front storage
compartment. It is located at the center of the
instrument panel extension, by the floor. To open
the compartment, pull up on the latch. The
compartment will open automatically.
Storage compartments may also be included on
the inside of each front door.
139

✍NOTES
140

Instrument Panel Overview........................ 144
Hazard Warning Flashers.......................... 146
Other Warning Devices............................. 146
Horn.......................................................... 146
Tilt Wheel.................................................. 147
Turn Signal/Multifunction Lever.................. 147
Turn and Lane-Change Signals................. 148
Headlamp High/Low-Beam Changer.......... 149
Flash-to-Pass............................................ 149
Windshield Wipers..................................... 149
Windshield Washer.................................... 150
Cruise Control........................................... 151
Exterior Lamps.......................................... 154
Headlamps on Reminder........................... 155
Daytime Running Lamps (DRL)................. 156
Instrument Panel Brightness...................... 156
Dome Lamps............................................. 156
Dome Lamp Override................................ 157
Entry Lighting............................................ 157
Exit Lighting.............................................. 157Reading Lamps......................................... 157
Battery Run-Down Protection..................... 158
Accessory Power Outlet(s)........................ 158
Ashtray(s) and Cigarette Lighter................ 159
Climate Controls......................................... 159
Climate Control System............................. 159
Outlet Adjustment...................................... 162
Rear Heating System................................ 163
Rear Air Conditioning and Heating
System.................................................. 164
Warning Lights, Gages, and Indicators..... 166
Instrument Panel Cluster........................... 167
Speedometer and Odometer...................... 168
Trip Odometer........................................... 168
Safety Belt Reminder Light........................ 168
Passenger Safety Belt Reminder Light....... 169
Airbag Readiness Light............................. 169
Airbag Off Light......................................... 170
Passenger Airbag Status Indicator............. 172
Charging System Light.............................. 174
Section 3 Instrument Panel
141

Voltmeter Gage......................................... 175
Brake System Warning Light..................... 175
Anti-Lock Brake System Warning Light...... 176
StabiliTrak
®Not Ready Light...................... 177
StabiliTrak®Indicator Light......................... 177
Engine Coolant Temperature Gage............ 178
Malfunction Indicator Lamp........................ 178
Oil Pressure Gage..................................... 182
Change Engine Oil Light........................... 183
Security Light............................................ 183
Cruise Control Light.................................. 184
Reduced Engine Power Light.................... 184
Highbeam On Light................................... 185
Daytime Running Lamps (DRL)
Indicator Light........................................ 185
Tow/Haul Mode Light................................ 185
Check Gages Warning Light...................... 185
Fuel Gage................................................. 186Audio System(s)......................................... 187
Setting the Time for Radios without
Radio Data Systems (RDS).................... 188
Setting the Time for Radios with
Radio Data Systems (RDS).................... 189
AM-FM Radio............................................ 189
Radio with CD........................................... 192
Radio with Cassette and CD..................... 198
Radio with Six-Disc CD............................. 211
Theft-Deterrent Feature
(Non-RDS Radios)................................. 223
Theft-Deterrent Feature (RDS Radios)....... 223
Radio Reception........................................ 224
Care of the Cassette Tape Player............. 224
Care of Your CDs..................................... 226
Care of the CD Player.............................. 226
Fixed Mast Antenna.................................. 226
Chime Level Adjustment............................ 226
Section 3 Instrument Panel
142

✍NOTES
143

Instrument Panel Overview
