2007 BUICK LACROSSE Owner's Manual

There are three important considerations have to
do with weight:
The weight of the trailer
The weight of the trailer tongue
The total weight on the vehicle’s tires
Weight of the Trailer
How heavy can a trailer safely be?
It should never weigh more than 1,000 lbs
(450 kg). But even that can be too heavy.
It depends on how you plan to use your rig. For
example, speed, altitude, road grades, outside
temperature and how much the vehicle is used to
pull a trailer are all important. It can also depend
on any special equipment that is on the vehicle,
and the amount of tongue weight the vehicle can
carry. See “Weight of the Trailer Tongue” later
in this section for more information.Maximum trailer weight is calculated assuming
only the driver is in the tow vehicle and it has all
the required trailering equipment. The weight
of additional optional equipment, passengers and
cargo must be subtracted from the maximum
trailer weight.
Ask your dealer for our trailering information or
advice, or you can write us at:
Buick Customer Assistance Center
P.O. Box 33136
Detroit, MI 48232-5136
In Canada, write to:
General Motors of Canada Limited
Customer Communication Centre, 163-005
1908 Colonel Sam Drive
Oshawa, Ontario L1H 8P7
329

Weight of the Trailer Tongue
The tongue load (A) of any trailer is an important
weight to measure because it affects the total
or gross weight of the vehicle. The Gross Vehicle
Weight (GVW) includes the curb weight of the
vehicle, any cargo in it, and the people who will be
riding in the vehicle. If there are a lot of options,
equipment, passengers or cargo in the vehicle,
it will reduce the tongue weight the vehicle
can carry, which will also reduce the trailer weight
the vehicle can tow. And if you tow a trailer,
you must add the tongue load to the GVW
because the vehicle will be carrying that weight,
too. SeeLoading Your Vehicle on page 319
for more information about the vehicle’s maximum
load capacity.When using a weight-carrying hitch, the trailer
tongue (A) should weigh 10 percent to 15 percent
of the total loaded trailer weight (B).
After the trailer is loaded, weigh the trailer and the
tongue, separately, to see if the weights are
proper. The correct weight could be achieved
simply by moving some items around in the trailer.
330

Total Weight on Your Vehicle’s Tires
Be sure the vehicle’s tires are inated to the upper
limit for cold tires. These numbers can be found
on the Tire-Loading Information label. SeeLoading
Your Vehicle on page 319. Be sure not to go
over the GVW limit for the vehicle, or the GAWR,
including the weight of the trailer tongue. If a
weight distribution hitch is used, make sure not to
go over the rear axle limit before applying the
weight distribution spring bars.
Hitches
It is important to have the correct hitch equipment.
Crosswinds, large trucks going by and rough
roads are a few reasons why the right hitch
is needed. Here are some rules to follow:
The rear bumper on the vehicle is not intended
for hitches. Do not attach rental hitches or
other bumper-type hitches to it. Use only
a frame-mounted hitch that does not attach to
the bumper.
If holes need to be made in the body of the
vehicle to install a trailer hitch, then be sure
to seal the holes later when the hitch is
removed. If the holes are not sealed, deadly
carbon monoxide (CO) from the exhaust
can get into the vehicle. SeeEngine Exhaust
on page 122. Dirt and water can, too.
Safety Chains
Chains should always be attached between the
vehicle and the trailer. Cross the safety chains
under the tongue of the trailer so that the tongue
will not drop to the road if it becomes separated
from the hitch. Instructions about safety chains
may be provided by the hitch manufacturer or by
the trailer manufacturer. Follow the manufacturer’s
recommendation for attaching safety chains
and do not attach them to the bumper. Always
leave just enough slack so the rig can be turned.
And, never allow safety chains to drag on the
ground.
331

Trailer Brakes
Does your trailer have its own brakes? Be sure to
read and follow the instructions for the trailer
brakes so you’ll be able to install, adjust
and maintain them properly.
If your vehicle has anti-lock brakes, do not try
to tap into your vehicle’s brake system. If you
do, both brake systems won’t work well, or
at all.
Even if your vehicle doesn’t have anti-lock
brakes, don’t tap into your vehicle’s brake
system if the trailer’s brake system will
use more than 0.02 cubic inch (0.3 cc) of uid
from your vehicle’s master cylinder. If it
does, both braking systems won’t work well.
You could even lose your brakes.
Will the trailer brake parts take 3,000 psi
(20 650 kPa) of pressure? If not, the
trailer brake system must not be used with
your vehicle.
If everything checks out this far, then make
the brake uid tap at the upper rear master
cylinder port. But don’t use copper tubing
for this. If you do, it will bend and break off.
Use steel brake tubing.
Driving with a Trailer
Towing a trailer requires a certain amount of
experience. Before setting out for the open road,
get to know the rig. Acquaint yourself with the
feel of handling and braking with the added weight
of the trailer. And always keep in mind that the
vehicle is now a good deal longer and not nearly
as responsive as the vehicle is by itself.
Before starting, check all trailer hitch parts and
attachments, safety chains, electrical connector,
lamps, tires, and mirror adjustment. If the
trailer has electric brakes, start the vehicle and
trailer moving and then apply the trailer brake
controller by hand to be sure the brakes are
working. This lets you check the electrical
connection at the same time.
During your trip, check occasionally to be sure
that the load is secure, and that the lamps and any
trailer brakes are still working.
332

Following Distance
Stay at least twice as far behind the vehicle ahead
as when driving the vehicle without a trailer.
This can help avoid situations that require heavy
braking and sudden turns.
Passing
More passing distance is needed up ahead when
towing a trailer. And, because the vehicle is a
good deal longer with the trailer, you will need to
go much farther beyond the vehicle you have
passed before you can return to the proper lane.
Backing Up
Hold the bottom of the steering wheel with one
hand. Then, to move the trailer to the left,
move that hand to the left. To move the trailer to
the right, move your hand to the right. Always
back up slowly and, if possible, have someone
guide you.
Making Turns
Notice:Making very sharp turns while
trailering could cause the trailer to come in
contact with the vehicle. Your vehicle could be
damaged. Avoid making very sharp turns while
trailering.
When turning with a trailer, make wider turns than
normal. Do this so the trailer will not strike soft
shoulders, curbs, road signs, trees, or other
objects. Avoid jerky or sudden maneuvers. Signal
well in advance.
Turn Signals When Towing a Trailer
When towing a trailer, the vehicle may need a
different turn signal asher and/or extra wiring.
Check with your dealer. The arrows on the
instrument panel will ash whenever signaling a
turn or lane change. Properly hooked up, the trailer
lamps will also ash, telling other drivers you are
about to turn, change lanes or stop.
When towing a trailer, the arrows on the instrument
panel will ash for turns even if the bulbs on the
trailer are burned out. You may think drivers behind
you are seeing your signal when they are not. It is
important to check occasionally to be sure the
trailer bulbs are still working.
333

Driving On Grades
Reduce speed and shift to a lower gearbefore
starting down a long hill or steep downgrade. If the
vehicle is not shifted down, the brakes might
have to be used so much that they would get hot
and no longer work well.
On a long uphill grade, shift down and reduce the
vehicle’s speed to around 45 mph (70 km/h) to
reduce the possibility of engine and transaxle
overheating.
If towing a trailer, you may want to drive in
THIRD (3) instead of DRIVE (D). Shift to a lower
gear as needed.
Parking on Hills
{CAUTION:
You really should not park your vehicle,
with a trailer attached, on a hill. If
something goes wrong, your rig could
start to move. People can be injured, and
both your vehicle and the trailer can be
damaged.
But if the rig ever has to be parked on a hill, here
is how to do it:
1. Apply the regular brakes, but do not shift into
PARK (P) yet.
2. Have someone place chocks under the
trailer’s wheels.
3. When the wheel chocks are in place, release
the regular brakes until the chocks absorb
the load.
4. Reapply the regular brakes. Then apply the
parking brake, and shift to PARK (P).
5. Release the regular brakes.
334

When You Are Ready to Leave After
Parking on a Hill
1. Apply the regular brakes and hold the pedal
down while you:
Start the engine.
Shift into a gear.
Release the parking brake.
2. Let up on the brake pedal.
3. Drive slowly until the trailer is clear of the
chocks.
4. Stop and have someone pick up and store the
chocks.
Maintenance When Trailer Towing
The vehicle will need service more often when it
pulls a trailer. SeeScheduled Maintenance
on page 462for more information. Things that are
especially important in trailer operation are
automatic transaxle uid; which should not be
overlled; engine oil, drive belt(s), and cooling and
brake systems. Each of these is covered in this
manual, and the Index will help you nd them
quickly. If trailering, it is a good idea to review this
information before starting on a trip.
Check periodically to see that all hitch nuts and
bolts are tight.
Engine Cooling When Trailer Towing
The cooling system may temporarily overheat
during severe operating conditions. SeeEngine
Overheating on page 367.
335
