Use the mode control button to
select the vents the air flows from.
Some air will flow from the
dashboard vents in all modes.Air flows from the center
and corner vents in the dashboard.
Air f lows f rom the def roster
vents at the base of the windshield. Air f lows f rom the f loor
vents. When you select , the
system automatically switches to
f resh air mode. Airf low is divided between
the vents in the dashboard and the
f loor vents.
Airf low is divided between
the f loor vents and the def roster
vents at the base of the windshield. When you select or ,
the system automatically switches to
f resh air mode and turns on the A/C.
In this case, you cannot turn the A/C
off.
Select and fresh air mode.
Set the f an to the desired speed.
Adjust the warmth of the air with
the temperature control buttons.
The heater uses engine coolant to
warm the air. If the engine is cold, it
will be several minutes bef ore you
f eel warm air coming f rom the
system. Set the temperature to maximum.
Make sure the A/C is of f .
Select and fresh air mode.
Set the f an to the desired speed.
You can set the temperatures and
modes f or the driver’s side and the
passenger’s side separately when
this button is pressed (indicator on).
When the indicator in the DUAL
button is off, you can adjust both
sides to the same temperature and
mode with the driver’s side temperature control buttons and
mode control button.
When is selected, the
passenger’s temperature cannot be
set separately f rom the driver’s. Thedriver’ssidemodeand
passenger’s side mode can be
selected separately when the dual
button is pressed. However, when is selected on the driver’s
side, mode selection on the
passenger’s side is not possible. The f low-through ventilation system
draws in outside air, circulates it
through the interior, then exhausts it
through vents near the rear window.
1.
2.
3.
4.
1.
2.
3.
Vents, Heating, and A/C
Mode Control Button
Using the Heater Ventilation
Dual Button
Features
129
——
y

y
(%y
y

Air conditioning, as it cools, removes
moisture from the air. When used in
combination with the heater, it
makes the interior warm and dry.
Switch the fan on.
Tu rn on the air conditioning.
Select and fresh air mode.
Adjust the temperature to your
preference.
This setting is suitable for all driving
conditions whenever the outside
temperature is above 32°F (0°C).
Air
conditioning places an extra load
on the engine. Watch the engine
coolant temperature gauge (see page ). If it moves near the red zone,
turn of f the A/C until the gauge
reading returns to normal.
To remove f og f rom inside the
windows:Set the f an to the desired speed, or
on high f or f aster def rosting.
Select . When you select , the system automatically
switches to f resh air mode and
turns on the A/C. The A/C ON indicator will not come on, if it was
previously of f .
Adjust the temperature so the
airflow feels warm.
Select to help clear the
rear window.
When you select or ,
the system automatically switches to
f resh air mode and turns on the A/C.
This helps to dehumidif y the air and
to def og the windshield. In either
mode, you cannot turn of f the A/C.
When you switch to another mode,
the A/C returns to its original setting,
either on or of f , as displayed by the
A/C ON or A/C OFF indicator.
Turn on the A/C by pressing the
button.
Set the temperature to the desired
level. For quick cooling set the
temperature to maximum cool.
Select .
If the outside air is humid, select
recirculation mode. If the outside
air is dry, select f resh air mode.
Set the f an to the desired speed.
you can
cool it down more rapidly by partially
opening the windows, turning on the
air conditioning, and setting the f an
to maximum speed in f resh air mode. 1.
2.
3.
4.
1.
2.3.
66 4.
1.
2.
3.
4.
5.
If the interior is very warm,
Vents, Heating, and A/C
Dehumidif y the Interior
Using the A/C
To Def og and Def rost
130
——
y

y
(%y
y

Bef ore you begin driving your
vehicle, you should know what
gasoline to use and how to check the
levels of important f luids. You also
need to know how to properly store
luggage or packages. The
inf ormation in this section will help
you. If you plan to add any
accessories to your vehicle, please
read the information in this section
first..............................
Break-in Period .234
.................
Fuel Recommendation .234
.........
Service Station Procedures .235
....................................
Ref ueling .235
Opening and Closing the .......................................
Hood .237
...................................
Oil Check .238
.............
Engine Coolant Check . 239
...............................
Fuel Economy .239
...
Accessories and Modif ications . 240
.............................
Carrying Cargo .243
Bef ore Driving
Bef ore Driving
233
——
y



y
(%yy

Help assure your vehicle’s f uture
reliability and perf ormance by paying
extra attention to how you drive
during the f irst 600 miles (1,000 km).
During this period:
You should also f ollow these
recommendations with an
overhauled or exchanged engine, or
when the brakes are replaced.Do not change the oil until the
multi-inf ormation display indicates
it is needed. Avoidhardbrakingforthefirst
200 miles (300 km). Avoid full-throttle starts and rapid
acceleration.
Your vehicle is designed to operate
on premium unleaded gasoline with a
pump octane of 91 or higher. If this
octane grade is unavailable, regular
unleaded gasoline with a pump
octane of 87 or higher may be used
temporarily. The use of regular
unleaded gasoline can cause metallic
knocking noises in the engine and
will result in decreased engine
perf ormance. The long-term use of
regular-grade gasoline can lead to
engine damage.
Your vehicle is designed to operate
on premium unleaded gasoline with a
pump octane number of 91 or higher.
Useof aloweroctanegasolinecan
cause occasional metallic knocking
noises in the engine and will result in
decreased engine perf ormance. Use
of a gasoline with a pump octane
number less than 87 can lead to engine damage.
We recommend quality gasolines
containing detergent additives that
help prevent f uel system and engine
deposits.
In addition, in order to maintain good
perf ormance, f uel economy, and
emissions control, we strongly
recommend, in areas where it is
available, the use of gasoline that
does NOT contain manganese-based
f uel additives such as MMT.
Use of gasoline with these additives
may adversely af f ect perf ormance,
and cause the malfunction indicator
lamp on your instrument panel to
come on. If this happens, contact
your dealer f or service.Type S
All models except Type S
Break-in Period Fuel Recommendation
Break-in Period, Fuel Recommendation
234
——
y

y
(%yy

CONT INUED
Park with the driver’s side closest
to the service station pump.
Open the f uel f ill door by pulling
onthehandletotheleftof the
driver’s seat.
For f urther important f uel-related
inf ormation, please ref er to your
.
Stop f illing the tank af ter the f uel
nozzle automatically clicks of f . Do
not try to ‘‘top of f ’’ the tank. Leave
some room f or the f uel to expand
with temperature changes. Remove the f uel f ill cap slowly.
You may hear a hissing sound as
pressure inside the tank escapes.
Place the knob on the cap in the
notch on the f uel f ill door.
If your notice any undesirable
operating symptoms, try another
service station, or switch to another
brand of gasoline.
You may hear a knocking noise from
the engine if you drive the vehicle at
low engine speed (below about 1,000
rpm) in a higher gear. To stop this,
raise the engine speed by shif ting to
a lower gear. Some gasoline today is blended with
oxygenates such as ethanol or
MTBE. Your vehicle is designed to
operate on oxygenated gasoline
containing up to 10 % ethanol by
volume and up to 15 % MTBE by
volume. Do not use gasoline
containing methanol.
1.
2.3.
4.
On TL with manual transmission
Service Station Procedures
Ref ueling
Quick Start Guide
Bef ore Driving
235
Pull
Gasoline is highly flammable
and explosive. You can be
burned or seriously injured
when handling fuel. Stop the engine, and keep
heat, sparks, and flame away.
Handle fuel only outdoors.
Wipe up spills immediately.
——
y


y
(%yy

Your vehicle’s on board diagnostic
system will detect a loose or missing
fuel fill cap as an evaporative system
leak. The first time a leak is detected
a ‘‘TIGHTEN FUEL CAP’’ message
appears on the multi-info rmation
display. Turn the engine off, and
confirm the fuel fill cap is installed. If
it is, loosen it, then retighten it until
it clicks at least once. The message
should go off after several days of
normal driving once you tighten or replace
the fuel fill cap. To scroll to
another message, press the INFO
button. The ‘‘TIGHTEN FUEL CAP’’
message will appear each time you
restart the engine until the system
turns the message off.
even
though the tank is not full, there may
be a problem with your vehicl e’s fuel
vapor recovery system. The system
helps keep fuel vapor from going
into the atmosphere. Try filling at
another pump. If this does not fix the
problem, consult your dealer.
Screw the fuel fill cap back on
until it clicks at least once. If you
do not properly tighten the cap,
you will see a ‘‘TIGHTEN FUEL
CAP’’ message on the multi-
inf ormation display, and the
malf unction indicator lamp may
also come on (see page ).
Push the f uel f ill door closed until
it latches.
5.
6.
68
If the f uel nozzle keeps clicking of fTighten Fuel Cap Message
Service Station Procedure
236
——
y

y
(%y
y

Park the vehicle, and set the
parking brake. Pull the hood
release handle located under the
lower left corner of the dashboard.
The hood will pop up slightly.
Put your fingers between the front
edge of the hood and the front
grille to locate the hood latch
handle. Push this handle up until it
releases the hood. Lift the hood. Lift
the hood up most of the way.
The hydraulic supports will lift it
uptherestofthewayandholdit
up. If the hood latch handle moves
stiffly, or if you can open the hood
without lifting the handle, the
mechanism should be cleaned and
lubricated.
If
the system still detects a leak in
your vehicle’s evaporative
emissions system, the malfunction
indicator lamp (MIL) comes on. If
the fuel fill cap was not already
tightened, turn the engine off, and
check or retighten the fuel fill cap
until it clicks at least once. The
MIL should go off after several
days of normal driving once the
cap is tightened or replaced. If the
MIL does not go of f , have your
vehicle inspected by a dealer. For
more information, see page . 1.
2. 3.
325
CONT INUED
Opening and Closing the Hood
Service Station Procedures
Bef ore Driving
237
HOOD RELEASE HANDLE
LATCH
——
y

y
(%yy

Remove the dipstick again, and
check the level. It should be
between the upper and lower
marks.
Wait
a few minutes after turning the
engine off before you check the oil.
Remove the dipstick (orange loop).
Wipe off the dipstick with a clean
cloth or paper towel.
Insert it all the way back in its tube.
To
close the hood, lower it to about a
foot (30 cm) above the fender, then
press down firmly with your hands.
Make sure the hood is securely
latched. If it is near or below the lower mark,
seeon page .
4.
1.
2.
3. 283
Oil Check
A dding Engine Oil
Service Station Procedures
238
UPPER MARK
LOWER MARK
DIPSTICK
——
y

y
(%yy
