The vehicle stability assist (VSA)
system helps to stabilize the vehicle
during cornering if the vehicle turns
more or less than desired. It also
assists you in maintaining traction
while accelerating on loose or
slippery road surfaces. It does this
by regulating the engine’s output,
and by selectively applying the
brakes.
When VSA activates, you may notice
that the engine does not respond to
the accelerator in the same way it
does at other times.
The VSA system cannot enhance the
vehicle’s driving stability in all
situations and does not control your
vehicle’s entire braking system. It is
still your responsibility to drive and
corner at reasonable speeds and to
leave a sufficient margin of safety. If
the indicator does not come on
when the ignition switch is turned to
the ON (II) position, there may be a
problem with the VSA system. Have
your dealer inspect your vehic le as
soon as possible.
If this indicator comes on while
driving, pull to the side of the road
when it is safe, and turn off the
engine. Reset the system by
restarting the engine. If the VSA
system indicator stays on, or comes
back on while driving, have the VSA
system inspected by your dealer. When VSA activates, you will see the
VSA activation indicator blink (see
page ). On manual transmission models, if
the VSA system is of f and you
accelerate f rom a stop, the vehicle
may pull, and it may take extra effort
to return the steering wheel to
center.
Without VSA, your vehicle will have
normal braking and cornering ability,
but it will not have VSA traction and
stability enhancement.
61
VSA System Indicator VSA A ctivation Indicator
Vehicle Stability Assist (VSA) System
264
——
y

y
(%yy

Driving with varying tire or wheel
sizes may cause the VSA to
malfunction. When replacing tires,
make sure they are the same size
and type as your original tires (see
page ).
If you install winter tires, make sure
they are the same size as those that
were originally supplied with your
vehicle. Exercise the same caution
during winter driving as you would if
your vehicle was not equipped with
VSA.
This switch is under the lef t vent.
Press it to turn the VSA system on
and off.
When VSA is off, the VSA activation
indicator comes on as a reminder.
VSA is turned on every time you
start the engine, even if you turned it
off the last time you drove the
vehicle.
In certain unusual conditions when
your vehicle gets stuck in shallow
mud or f resh snow, it may be easier
to free it with the VSA temporarily
switched of f . When the VSA system
is of f , the traction control system is
alsooff.Youshouldonlyattemptto
f ree your vehicle with the VSA of f if
you are not able to f ree it when the
VSA is on.
Immediately af ter f reeing your
vehicle, be sure to switch the VSA on
again. We do not recommend driving
your vehicle with the VSA and
traction control systems switched off.
306
VSA Of f Switch
VSA and Tire Sizes
Vehicle Stability Assist (VSA) System
Driving
265
VSA OFF SWITCH
——
y

y
(%yy

Your vehicle is equipped with a tire
pressure monitoring system (TPMS)
that turns on every time you start the
engine and monitors the pressure in
your tires while driving.
Each tire has its own pressure
sensor. If the air pressure of a tire
becomes signif icantly low, the
sensor in that tire immediately sends
a signal that causes the low tire
pressure indicator in the instrument
panel to come on. If this happens,
you will see which tire is losing
pressure on the multi-inf ormation
display along with a ‘‘CHECK TIRE
PRESSURE’’ message.When the low tire pressure indicator
is on, one or more of your tires is
signif icantly underinf lated. You
should stop and check your tires as
soon as possible, and inf late them to
the proper pressure as indicated on
the vehicle’s tire inf ormation placard.
It is possible that the pressures
shown on the multi-inf ormation
display and the pressures you
manually measure are slightly
dif f erent.
If the dif f erence is signif icant or you
cannot make the low tire pressure
indicator and message on the multi-
inf ormation display go out af ter
inf lating the tires to the specif ied
values, have your dealer check the
system as soon as possible.If the tire is f lat, or if the tire
pressure is too low to continue
driving, replace the tire with the
compact spare tire.
Driving on a signif icantly under-
inf lated tire causes the tire to
overheat and can lead to tire failure.
Under-inf lation also reduces f uel
efficiency and tire tread life, and may
af f ect the vehicle’s handling and
stopping ability.
Becausetirepressurevariesby
temperature and other conditions,
the low tire pressure indicator may
come on unexpectedly. After inflating the tire(s) to the
proper pressure, the low tire
pressure indicator will remain on
until the vehicle is driven at a speed
more than 25 mph (40 km/h).
Low Tire Pressure
Indicator
Tire Pressure Monitoring System (TPMS)
266
——
y
y
(%y
y

This section explains why it is
important to keep your vehicle well
maintained and how to follow basic
maintenance safety precautions.
If you have the skills and tools to
perform more complex maintenance
tasks on your vehicle, you may want
to purchase the service manual. See
page f or inf ormation on how to
obtain a copy, or see your dealer. This section also includes
instructions on how to read the
maintenance messages on the multi-
inf ormation display, a maintenance
record, and instructions f or simple
maintenance tasks you may want to
take care of yourself . ......................
Maintenance Saf ety .272
....................
Maintenance Minder . 273
....................
Maintenance Record .279
..............................
Fluid Locations .281
......
Engine Compartment Covers . 282
........................
Adding Engine Oil .283
.........
Changing the Oil and Filter . 284
..............................
Engine Coolant .286
....................
Windshield Washers .287
....
Automatic Transmission Fluid . 288
........
Manual Transmission Fluid . 290
................
Brake and Clutch Fluid . 291
....................
Power Steering Fluid . 292
.............................................
Lights .293
................
Cleaning the Seat Belts . 299
.....................................
Floor Mats .300
.................................
Wiper Blades .300
...............................................
Tires .302
...................
Checking the Battery . 308
.............................
Vehicle Storage .309
355
Maintenance
Maint enance
271
——
y
y
(%yy

To eliminate potential hazards, read
the instructions bef ore you begin,
and make sure you have the tools
and skills required.Make sure your vehicle is parked
on level ground, the parking brake
is set, and the engine is of f .
To clean parts, use a commercially
available degreaser or parts
cleaner, not gasoline.
To reduce the possibility of f ire or
explosion, keep cigarettes, sparks,
and flames away from the battery
and all f uel-related parts. Wear eye protection and
protective clothing when working
with the battery or compressed air.
Be sure there is
adequate ventilation whenever you
operate the engine.
Let the
engine and exhaust system cool
down bef ore touching any parts. Do
not run the engine unless
instructed to do so.
Some of the most important saf ety
precautions are given here. However,
we cannot warn you of every
conceivable hazard that can arise in
perf orming maintenance. Only you
can decide whether or not you
should perf orm a given task.
All service items not detailed in this
section should be perf ormed by a
certif ied technician or other qualif ied
mechanic.
Maintenance Saf ety
Important Saf ety Precautions
Potential Vehicle HazardsCarbon Monoxide poison f rom
engine exhaust.
Burns f rom hot parts. Injury f rom moving parts.
272
Improperly maintaining this
vehicle or failing to correct a
problem before driving can
cause a crash in which you can
be seriously hurt or killed.
Always follow the inspection
and maintenance
recommendations in this owner’s
manual.
Failure to properly follow
maintenance instructions and
precautions can cause you to
be seriously hurt or killed.
Always follow the procedures
and precautions in this owner’s
manual.
——
y

y
(%yy

ÛÝ
µ
µ
µ
µ
µ
µ
µ
µ
µ
µ µ
µ
CONTINUED
Displayed
Engine Oil Life (%)
100 %
90 %
80 %
70 %
60 %
50 %
40 %
30 %
20 %
15 %
10 %
5%
0%
Calculated
Engine
Oil Life (%)
100 % 91 %
90 % 81 %
80 % 71 %
70 % 61 %
60 % 51 %
50 % 41 %
40 % 31 %
30 % 21 %
20 % 16 %
15 % 11 %
10 % 6 %
5% 1%
0%
Your vehicle displays engine oil life
and maintenance service items on
the multi-information display to show
youwhenyoushouldhaveyour
dealer perform engine oil
replacement and indicated
maintenance service.
Based on the engine operating
conditions and accumulated engine
revolutions, the onboard computer in
your vehicle calculates the remaining
engine oil life and displays it as a
percentage. To see the current engine oil life,
turn the ignition switch to the ON
(II) position, then push and release
the INFO ( / ) button repeatedly
until the engine oil lif e appears (see
page ). The remaining engine oil lif e is
displayed on the multi-information
display according to this table:
72
Maintenance Minder
Engine Oil L if e Indicator
Maint enance
273
——
y

y
(%yy

Iftheoillifeis15to6percent,you
will see the message ‘‘SERVICE
DUE SOON’’ along with all
maintenance items that are needed
at oil change time (see page ).When
the remaining engine oil life is
5 to 1 percent, you will see the
message ‘‘SERVICE DUE NOW’’
with the same maintenance items
you saw when ‘‘SERVICE DUE
SOON’’ was displayed. When you
see this message, have the indicated
maintenance performed as soon as
possible. If
you still do not perform the
indicated maintenance, you will see
the message ‘‘SERVICE PAST DUE’’
on the display. Immediately have the
service perf ormed, and make sure to
reset the display (see page ). 275
278
Maintenance Minder
274
——
y
y
(%yy

ÛÝÛÝ
All maintenance items displayed in
the information display are in code.
For an explanation of these
maintenance codes, see page .Your dealer will reset the display
af ter completing the required
maintenance service. You will see
‘‘OIL LIFE 100%’’ on the display the
next time you turn the ignition
switch to the ON (II) position.
If maintenance service is done by
someone other than your dealer,
reset the maintenance minder as
f ollows:
Turn the ignition switch to the ON
(II) position.
Press the INFO ( / ) button
repeatedly until the engine oil lif e
is displayed. Press and hold the SEL/RESET
button f or 10 seconds. The multi-
inf ormation display will ask f or a
conf irmation.
If you are sure you want to reset
the display, press the SEL/
RESET button to select ‘‘OK.’’
If you do not want to reset the
display, press the INFO ( / )
button to select ‘‘Cancel.’’
1.
2. 3.
278
Maintenance Minder
Maintenance Main Items and Sub
Items Resetting the Engine Oil Lif e
Indicator
Maint enance
275
MAINTENANCE MAIN ITEM
MAINTENANCE SUB ITEMS
——
