2007.5 PEUGEOT 807 Owners Manual

14
Pressing the closed padlock for
more than 2 seconds, in addition
to locking or deadlocking, permits
automatic closing of the windows
and places the sunroofs in the partially open
position, if they were open. To close them
completely, you must press their switch
before leaving the vehicle. Pressing one of the buttons opens
or closes the corresponding rear
door (right or left).
Locating your vehicle
Key in ignition
A buzzer sounds on opening the driver ’s
door, if the key has been left in the ignition.
Folding/opening out the key
Unlocking Press the open padlock to unlock
the vehicle.
This is confirmed by rapid flashing
of the direction indicators.
If the vehicle is locked and unlocking is
activated inadvertently, unless the doors are
opened within 30 seconds, the vehicle will
lock automatically.
This press unlocks the entire vehicle
before opening the sliding door.
Opening/Closing the electric
sliding side doors
To tuck away the key blade, press
the button, then fold it down into
the remote control module.
To open out the key, press the
button.
To locate your vehicle, if you have
locked it, in a car park.
Press the closed padlock, the
courtesy lights come on and the
direction indicators flash for a few seconds.
Accesses

Accesses
13
2
REMOTE CONTROL
Normal locking
Deadlocking
If your vehicle is fitted with
deadlocking, a second press
on the closed padlock within five
seconds of locking changes this
to deadlocking.
This is confirmed by fixed lighting of the
direction indicators for approximately two
seconds.
The key allows you to switch on the ignition
and to mechanically operate the lock on the
fuel filler cap, the glove box, the passenger
air bag disarming switch and the mechanical
child lock.
KEYS
Central locking
From the driver ’s door or passenger door,
the keys allow you to lock, deadlock or
unlock the doors and tailgate, as well as fold
back the exterior mirrors.
If one of the doors or the tailgate is open,
the central locking does not work.
The remote control performs the same
functions at a distance.Deadlocking renders the internal and
external door locking controls inoperative.
Never leave anyone inside the vehicle when
it is deadlocked.
If the deadlocking is operated from inside
the vehicle, it will change to normal locking
when the vehicle is started.
ACCESSES Press the closed padlock to lock
the vehicle.
This is confirmed by fixed lighting
of the direction indicators for
approximately two seconds.
READY TO SET OFF

14
Pressing the closed padlock for
more than 2 seconds, in addition
to locking or deadlocking, permits
automatic closing of the windows
and places the sunroofs in the partially open
position, if they were open. To close them
completely, you must press their switch
before leaving the vehicle. Pressing one of the buttons opens
or closes the corresponding rear
door (right or left).
Locating your vehicle
Key in ignition
A buzzer sounds on opening the driver ’s
door, if the key has been left in the ignition.
Folding/opening out the key
Unlocking Press the open padlock to unlock
the vehicle.
This is confirmed by rapid flashing
of the direction indicators.
If the vehicle is locked and unlocking is
activated inadvertently, unless the doors are
opened within 30 seconds, the vehicle will
lock automatically.
This press unlocks the entire vehicle
before opening the sliding door.
Opening/Closing the electric
sliding side doors
To tuck away the key blade, press
the button, then fold it down into
the remote control module.
To open out the key, press the
button.
To locate your vehicle, if you have
locked it, in a car park.
Press the closed padlock, the
courtesy lights come on and the
direction indicators flash for a few seconds.
Accesses

Accesses
15
2
Changing the battery of the remote
control
Battery ref.: CR1620/3 volts.
The information "battery flat" is given by an
audible signal, accompanied by a message
on the multifunction display.
To replace the battery, unclip the casing
using a coin at the ring.
If the remote control does not work after the
battery has been changed, re-programme
the remote control. Programming the remote control
Following changing of the remote
control battery or disconnection
of the vehicle battery, the remote
control must be reprogrammed.
Wait at least one minute before
using the remote control.
Switch on the ignition.
Press one of the two padlocks
for at least five seconds within the next ten
seconds.
Switch off the ignition.
Wait at least one minute before using the
remote control.
The remote control is now working again.
Do not discard the remote control batteries,
they contain metals which are harmful to the
environment.
Take them to a PEUGEOT dealership, or to
any other approved collection point. CONFIDENTIAL CARD
This is given to you on delivery of your
vehicle with the duplicate keys.
It contains the identification code necessary
for any work carried out by a PEUGEOT
dealer on the electronic immobiliser system.
This code is hidden by a film, which should
be removed only if necessary.
Keep your card in a safe place, never inside
the vehicle.

When undertaking a long trip or journey,
however, it is advisable to take it with you
along with your personal papers.
READY TO SET OFF

Accesses
15
2
Changing the battery of the remote
control
Battery ref.: CR1620/3 volts.
The information "battery flat" is given by an
audible signal, accompanied by a message
on the multifunction display.
To replace the battery, unclip the casing
using a coin at the ring.
If the remote control does not work after the
battery has been changed, re-programme
the remote control. Programming the remote control
Following changing of the remote
control battery or disconnection
of the vehicle battery, the remote
control must be reprogrammed.
Wait at least one minute before
using the remote control.
Switch on the ignition.
Press one of the two padlocks
for at least five seconds within the next ten
seconds.
Switch off the ignition.
Wait at least one minute before using the
remote control.
The remote control is now working again.
Do not discard the remote control batteries,
they contain metals which are harmful to the
environment.
Take them to a PEUGEOT dealership, or to
any other approved collection point. CONFIDENTIAL CARD
This is given to you on delivery of your
vehicle with the duplicate keys.
It contains the identification code necessary
for any work carried out by a PEUGEOT
dealer on the electronic immobiliser system.
This code is hidden by a film, which should
be removed only if necessary.
Keep your card in a safe place, never inside
the vehicle.

When undertaking a long trip or journey,
however, it is advisable to take it with you
along with your personal papers.
READY TO SET OFF

16ELECTRONIC ENGINE
IMMOBILISER
This locks the engine control system as
soon as the ignition has been switched off
and therefore prevents starting of the vehicle
by anyone who does not have the key.
The ignition key has an electronic chip which
has a special code. When the ignition is
switched on, the code must be recognised
for starting to be possible.
If the system does not function correctly, the
central locking button indicator light, situated
on the courtesy light console, flashes rapidly
when the ignition is switched on (2nd notch).
In this case your vehicle will not start.
Contact a PEUGEOT dealer as soon as
possible. Good practice
Key, remote control
Take care not to allow the key to come into
contact with grease, dust, rain or a damp
environment.
A heavy object attached to the key (keyring, ...)
weighing on the shaft of the key in the
switch may cause a malfunction.
The high frequency remote control is a
sensitive system; do not operate it while it is
in your pocket as there is a possibility that it
may unlock your vehicle, without you being
aware of it.
Do not repeatedly press the buttons of your
remote control out of range and out of sight
of your vehicle. You run the risk of stopping
it from working and the remote control would
have to be reprogrammed.
The remote control does not operate
when the key is in the ignition, even when
the ignition is switched off, except for
reprogramming.
Do not make any modifications to the
electronic engine immobiliser system. In the event of loss
A PEUGEOT dealer will carry out his work
more efficiently and quickly if, depending on
the circumstances:
- you give him your confidential card,
- you have made a note of the number
coded on the label when given the keys.
- you have made a note of the code etched on the head of the alloy wheels anti-theft socket.
Safety
Driving with the doors locked may make
access to the passenger compartment by
the emergency services more difficult in an
emergency.
Remove the ignition key when you leave the
vehicle, even for a short time, if there are
children on board.
Purchasing a second-hand vehicle
Ensure that you are given the confidential
card and the anti-theft socket for alloy
wheels.
Have the key codes memorised by a
PEUGEOT dealer, to ensure that the keys
in your possession are the only ones which
can start the vehicle.
Accesses

Accesses
17
2
ALARM
If fitted on your vehicle, this provides two
types of protection:
- exterior protection: it sounds if a door, the tailgate or the bonnet is opened.
- interior protection: it sounds if the volume inside the passenger compartment
changes (breaking of a window or a
movement inside the vehicle).
A red indicator light, located in the centre of
the fascia, indicates the information detailed
below.
Setting the alarm
 Switch off the ignition and get out of the
vehicle.

Set the alarm within five minutes of getting
out of the vehicle, by locking or deadlocking
using the remote control (the red indicator
light flashes once per second).
To lock your vehicle without setting the
alarm, insert the key in the lock then
lock the vehicle (eg. for washing).
When the alarm is triggered, the siren
sounds and the direction indicator lights
flash for thirty seconds.
Warning - alarm triggered: the red indicator
light flashes rapidly, insert the key and switch
on the ignition to switch it off.
When the alarm has been triggered ten
times in succession (on the eleventh time)
the alarm is deactivated. Repeat the rules
for setting the alarm.
Disarming
Unlock the vehicle with the remote control
(the red indicator light goes out).
To set the alarm with exterior
protection only
If, while you are away from the vehicle, you
wish to leave a window partially open or a
pet inside the vehicle, you should choose
exterior protection only.
 Close the sunroofs,
 Switch off the ignition,
 In the next ten seconds, press button A,
located on the left-hand side of the fascia,
until the red indicator light is on
continuously,
 Get out of the vehicle,
 Within the next five minutes, set the alarm by locking or deadlocking using
the remote control (the red indicator light
flashes once a second).
When the alarm is set but the remote
control does not operate:

Unlock the doors with the key and open
the door. The alarm is triggered.
 Switch on the ignition in the next ten
seconds. The alarm is disarmed.
Incorrect operation
When the ignition is switched on, if the red
indicator light remains on for ten seconds,
there is a fault in the siren connection.
Contact a PEUGEOT dealer to have the
system checked.
Automatic setting of the alarm
If fitted on your vehicle, the alarm is set
automatically 2 minutes after the last door or
the tailgate is closed.
To prevent triggering of the alarm when a
door or the tailgate is opened, it is
imperative to press the remote control
unlocking button again.
Do not make any modifications to
the alarm system as this could cause
faults.READY TO SET OFF

18
DOORSAutomatic central locking
The doors can lock automatically when you
are driving (at a speed of more than 6 mph
(10 km/h)).
You can activate or deactivate this function. To deactivate
With the ignition on, press and
hold the padlock.
Deactivation of the function is
accompanied by an audible signal.
"Door open" alert
If a door or the tailgate is not closed
properly:
- when the engine is running , you are
warned by a diagram and a message on
the display for a few seconds,
- when the vehicle is moving (speed above
6 mph (10 km/h)), the service warning light
comes on. It is accompanied by an audible
signal, a message and a diagram on the
display for a few seconds.
Opening the doors from outside Opening the doors from inside
If the vehicle is locked or deadlocked
from the outside, the red warning light
flashes and the padlock does not function. In
this case, use the key or the remote control
to unlock from the outside.
The door opening switches do not function
when the vehicle is deadlocked.
Locking/Unlocking from
the inside
Press the padlock, the red warning
light comes on when the vehicle
is locked and switches off when it is
unlocked.
This locks/unlocks the doors and the tailgate.
To activate
With the ignition on, press and
hold the padlock.
Activation of the function is
accompanied by an audible signal and a
message on the display.
Accesses
