2007.5 Peugeot 807 Dag Owner's Manual

Parking assistance
IN-CAR TECHNOLOGY129
4
signal becomes continuous and the "Danger"
symbol appears depending on the display.
The volume of the audio equipment decreases
during the transmission of the parking
assistance bleeps.
Switching the system off
Change to neutral, the system is again
inactive.
REAR PARKING
ASSISTANCE
If fitted on your vehicle, the system is
audible and/or visual and consists of four
proximity sensors, located in the rear
bumper.
The sensors detect any obstacle: person,
vehicle, tree, gate, behind the vehicle during
the manoeuvre.
Objects the size or thickness of which is
detected at the beginning of the manoeuvre,
may no longer be detected at the end of
the manoeuvre due to blind spots between
and below the sensors. Examples: stake,
roadworks cone, kerbstone. Switching the system on
The system is activated as soon as reverse
gear is engaged.
This is accompanied by an audible signal and
displaying of the vehicle, depending on the
display.
The proximity information is given by:
- an audible signal, which becomes more rapid
as the vehicle approaches the obstacle,
- a graphic on the display, with blocks which become progressively closer to the vehicle.
Depending on the display, the audible signal is
transmitted by a buzzer or by the rear speakers
which transmit:
- on the right if an obstacle is detected on the right,
- on the left if an obstacle is detected on the left,
- on the right and on the left if an obstacle is detected in the centre.
When the distance between the rear of
the vehicle and the obstacle is less than
approximately thirty centimetres, the audible
Activation/Deactivation
The system can be activated
or deactivated from the display
configuration menu.
The activation and deactivation of
the system are memorised when the engine
is switched off.
This function will be deactivated
automatically when the vehicle is towing
a trailer or when a bicycle carrier is fitted
(vehicle fitted with towing attachment or
bicycle carrier recommended by PEUGEOT).
In bad or wintry weather, ensure that the
sensors are not covered with mud, frost or
snow.
If there is an operating fault (e.g.
sensors dirty), when reverse gear is
engaged, the service warning light
comes on, accompanied by an audible signal
(short bleep or long bleep if the sensors are
dirty) and a message on the display.
Contact a PEUGEOT dealer.

Improved safety and security
130
IMPROVED SAFETY AND SECURITYIn the event of a front impact, the retractable
steering column limits the backwards
movement of the steering wheel and the
risks of intrusion of the engine and gearbox
into the passenger compartment are
reduced.
In the event of a side impact, you are inside
a cell armed with solid side strengtheners.
With 5 stars in the Euro
NCAP ADULT OCCUPANT
PROTECTION tests,
the 807 protects you in
several ways. Its structure
absorbs a large proportion
of the energy connected with impacts.
Tests carried out on an 807 fitted with the
2.0 HDi engine.
Details of the other components are given in
the content of this chapter.

Driving safety
SAFETY131
5
HANDBRAKE
Applying
When parking, pull the handbrake to
immobilize your vehicle. When parking on
a slope, direct your wheels towards the
pavement and pull the handbrake.
Releasing
Pull on the handle and press the button to
release the handbrake.
Disengaging
Apply the handbrake.
Pull the button located at the end of the
handbrake forwards.
The handbrake lever lowers.
You can now pivot the seat.
To return to normal operation, pull the lever
upwards until a click is heard.
If the handbrake is still on or has not been
released properly, this is indicated by:
HAZARD WARNING LIGHTS
Press the button, the direction indicators
flash.
They can operate with the ignition off.
Automatic lighting of hazard
warning lights
Equipment conditioned according to country:
when braking in an emergency, depending
on the deceleration, the hazard warning
lights come on automatically. They switch off
automatically the first time you accelerate.
It is also possible to switch them off by
pressing the button.
DRIVING SAFETY
 a warning light which comes on
on the instrument panel,
 an audible signal,
 a message on the display.

Driving safety
132
ANTI-LOCK BRAKING SYSTEM
(ABS) AND ELECTRONIC BRAKE
FORCE DISTRIBUTION (EBFD)
The ABS, in conjunction with the electronic
brake force distribution, increases the
stability and manoevrability of your vehicle
on braking, in particular on poor or slippery
road surfaces.
HORN
Press one of the spokes of the steering wheel.
When changing wheels (tyres and
rims), make sure that these are
approved.
The anti-lock braking system comes into
operation automatically when there is a risk
of wheel lock.
When this warning light comes
on, accompanied by a buzzer and
a message, it indicates that there
is a malfunction of the ABS, which
can cause a loss of control of the vehicle
when braking.
When this warning light comes
on, connected to the STOP
warning light, accompanied
by a buzzer and a message, it
indicates that there is a malfunction of the
electronic brake force distribution, which can
cause a loss of control of the vehicle when
braking.
Stop immediately.
In both cases, consult a PEUGEOT dealer.
Normal operation of the ABS may make
itself felt by slight vibrations of the
brake pedal.
In emergency braking, press very firmly
without releasing the pressure.
EMERGENCY BRAKING
ASSISTANCE SYSTEM (EBA)
In an emergency, this system enables the
optimum braking pressure to be reached
more quickly, thus reducing the stopping
distance.
It is triggered by the speed at which the
brake pedal is activated. This alters the
resistance of the brake pedal under your
foot.
To prolong the operation of the emergency
braking assistance system: keep your foot
on the brake pedal.

Driving safety
SAFETY133
5
TRACTION CONTROL (ASR) AND
DYNAMIC STABILITY CONTROL (ESP)
These systems are linked and complement
the ABS.
The ASR system optimises drive to prevent
the wheels skidding, by acting on the brakes
of the drive wheels and on the engine. It
also allows the directional stability of the
vehicle to be improved on acceleration.
If there is a variation between the trajectory
followed by the vehicle and that required by
the driver, the ESP system automatically acts
on the engine and the brake of one or more
wheels, in order to put the vehicle back on
course, within the limits of the laws of physics.
Activation of the ASR and ESP systems
When the ignition is on, the ASR and ESP
systems are always active.Disarming the ASR/ESP systems
In certain conditions (vehicle stuck in mud or
snow, or on loose ground...), it could prove
useful to disarm the ASR and ESP systems
to make the wheels spin and regain grip.
Press the switch, situated under the
steering wheel on the left of the fascia.
The indicator light comes on
accompanied by a message: the
ESP and ASR systems no longer
act on the engine operation, but
continue to act on the brakes. Operating check
When a malfunction of the
systems occurs, the indicator light
comes on, accompanied by an
audible signal and a message on
the display.
Contact a PEUGEOT dealer to have the
system checked.
The ASR/ESP systems offer increased
safety during normal driving, but should
not incite the driver to take risks or to drive
at high speed.
The operation of these systems is ensured
if the recommendations of the manufacturer
regarding the wheels (tyres and rims),
the braking components, the electronic
components and the fitting and repair
procedures within the PEUGEOT network
are observed.
After an impact, have these systems
checked by a PEUGEOT dealer.
They engage again:
 automatically above 30 mph (50 kmh),
 manually by pressing the switch again.
Operation of the ASR and ESP
systems
The warning light flashes if the
ASR or ESP is activated.

Driving safety
134
TYRE UNDER-INFLATION
DETECTION
Sensors check the tyre pressure during
driving, and trigger a warning in the event
of a malfunction (speed greater than
approx.15 mph [25 km/h]) or puncture.
An outline representing one or more wheels
flashing indicates the location of the wheel
or wheels concerned.Flat tyre
The SERVICE warning light
comes on, accompanied by the
message "Tyre(s) deflated" , an
outline on the display, and an audible signal.
Check the tyre pressure as soon as
possible.
If the damaged tyre is temporarily
stored in the boot, it will again emit this
message to remind you of the necessity of
having it repaired. This will prevent another
warning of the same type being displayed.
Sensor(s) not detected
The SERVICE warning light
comes on, accompanied by
the message "X tyre pressure
sensor(s) missing" , an outline on the
display and an audible signal.
Under-inflation detection is absent from one
(or several) tyre(s).
Contact a PEUGEOT dealer to replace the
faulty sensor(s).
This message is also displayed when
one of the tyres is away from the
vehicle (being repaired) or when a wheel
without a sensor is fitted.
All repairs and changing of tyres on a
wheel fitted with this system must be
carried out by a PEUGEOT dealer.
The tyre under-inflation detection system
is a driving aid which does not take the
place of vigilance or the responsibility of
the driver.
This system does not remove the need to
have the tyre pressure checked regularly
(including the spare wheel), to ensure that
the dynamic performance of the vehicle
remains at its best and to avoid premature
wear of the tyres, in particular in the case of
arduous driving (heavy load, high speed).
The system may temporarily be disturbed by
radio broadcasts on a frequency close to it. Puncture
The STOP warning light
comes on, accompanied by
the message "Punctured
tyre(s)" , an outline on the display and an
audible signal.
Stop immediately, avoiding any sudden
movement of the steering wheel and the brakes.
Change the damaged (punctured or very
deflated) tyre, and have the tyre pressure
checked as soon as possible.
Refer to the "Changing a wheel"
section of chapter 8.

Seat belts
SAFETY135
5
FRONT AND REAR SIDE SEAT
BELTS
The front and row 2 rear side seats are fitted
with pretensioners and force
limiters.
To adjust the height
 To lower the attachment point, squeeze
control and slide it downwards.
 To raise the attachment point, slide
control upwards.
To lock  Pull the strap, then insert the buckle into
the stalk.
 Check that the seat belt is secured
correctly by pulling the strap. The lap strap must be positioned as low as
possible on the pelvis. The chest strap must
pass over the hollow of the shoulder.
Check that the seat belt is fastened correctly
by pulling the strap.
Inertia reel seat belts
These are fitted with a device which locks
the seat belt automatically in the event of an
impact or emergency braking.
Safety in the event of a frontal impact has
been improved by the introduction of pre-
tensioning and force-limiting seat belts.
Depending on the seriousness of the impact,
the pre-tensioning system instantly tightens
the seat belts firmly against the body of the
occupant.
The pre-tensioning seat belts are armed
when the ignition is on. The force-limiting device reduces the
pressure of the seat belt against the chest
of the occupant, so increasing his protection.
A bag placed on the front passenger
seat or a pet sitting on this seat may
trigger the lighting of this warning light.
SEAT BELTS Front seat belt warning
light
If the driver and/or front passenger
has/have not fastened his/their
seat belt, this warning light comes on.
Then, at a speed in excess of approximately
15 mph (25 km/h), it flashes accompanied
by an audible signal of increasing volume
(for approximately 90 seconds) and a
message on the display.
Row 2 rear side seat belts
For your comfort, if you are not using the
seat belt, slide the seat belt loop to the
upper stop to prevent the tongue from
vibrating.
Row 3 rear side seat belts
The row 3 rear side seats are fitted with two
seat belts which are both three-point inertia
reel belts with force limiter.

Seat belts
136
due to the activation of the pyrotechnic
cartridge incorporated in the system.
The force limiter reduces the pressure of the
seat belt against the body of the occupants.
The equipment fitted to these seat belts is
operational when the ignition is switched on.
The inertia reels are fitted with a device
which automatically locks the strap in the
event of a collision, emergency braking or
if the vehicle rolls over. You can release the
seat belt by pulling the strap sharply and
releasing it.
The air bag warning light comes on if the
pretensioners are triggered. Contact a
PEUGEOT dealer.
In order to be effective, a seat belt must:
 restrain one adult person only,
 must not be twisted, check by pulling in
front of you with an even movement,
 be tightened as close to the body as
possible.
The upper part of the seat belt should be
positioned in the hollow of the shoulder.
The lap part should be placed as low as
possible on the pelvis.
Do not invert the seat belt buckles as they
will not fulfil their role completely. If the
seats are fitted with armrests, the lap part of
the seat belt should always pass under the
armrest. Check that the seat belt is fastened correctly
by pulling the strap firmly.
Recommendations for children 
use a suitable child seat if the passenger
is less than 12 years old or shorter than
one metre fifty,
 never allow a child to travel on your lap,
even with the seat belt fastened.
For further information regarding child seats,
refer to the "Children on board" section of
chapter 5.
In accordance with current safety
regulations, your PEUGEOT dealer
guarantees all work or any checks, from
testing to maintenance, on your seat belt
equipment.
Have the seat belts checked regularly
(even after a minor impact) by a PEUGEOT
dealer: they must not show any signs of
wear, cutting or fraying and they must not be
transformed or modified.
Clean the seat belt straps with soapy
water or a textile cleaning product, sold by
PEUGEOT dealers.
Good practice
Wherever you are seated in the
vehicle, always fasten your seat belt, even
for short journeys.
The seat belts are fitted with an inertia reel
which automatically adjusts the length of the
strap to your size. The seat belt is rolled up
automatically when not in use.
Ensure that the seat belt is rolled up
correctly after use.
After folding or moving a rear seat or bench
seat, ensure that the seat belt is rolled up
correctly in its compartment and that the
buckle is ready to accommodate the tongue.
Depending on the nature and seriousness
of any impact, the pretensioning device
may be triggered before and independently
of inflation of the air bags. It instantly
tightens the seat belts against the body
of the occupants. The triggering of the
pretensioners is accompanied by a slight
discharge of harmless smoke and a noise,
To install the seat belt, move the tongue into
position to insert it into the buckle.
Row 2 and 3 rear centre seat belts
The row 2 rear centre seat and the rear
bench seat centre seat have an integrated
three-point inertia reel seat belt.
