2006 TOYOTA YARIS Owners Manual

182006 YARIS HATCHBACK from Aug. ’05 Prod. (OM52703U)
QS12016
2. Remove the module from the key case.
QS12017
3. Remove the battery cover of the mod-ule.
NOTICE
Do not bend the terminals.
4. Remove the discharged battery and put
in a new battery with positive (+) side
up.
NOTICE
Make sure the positive side and
negative side of the battery are
faced correctly.
 Do not replace the battery with wet
hands. Water may cause unexpected
rust.
 Do not touch or move any compo-
nents inside the transmitter, or it
may interfere with proper operation.
 Be careful not to bend the electrode
when inserting the battery and that
dust or oils do not adhere to the
case.
 Close the cover securely.
5. Install the battery cover of the module.
6. Install the module into the key case
and secure the cover.
After replacing the battery, check that the
key operates properly. If the key still does
not operate properly, contact your Toyota
dealer.

192006 YARIS HATCHBACK from Aug. ’05 Prod. (OM52703U)
Side doors—
PS12516
LOCKING AND UNLOCKING WITH KEY
Insert the key into the keyhole and turn
it.
To lock: Turn the key forward.
To unlock: Turn the key backward.
Vehicles with the power door lock sys-
tem—All the side doors and back door
lock and unlock simultaneously with the
driver ’s door. In the driver ’s door lock,
turning the key once will unlock the driv-
er’s door and twice in succession will un-
lock all the side doors and back door
simultaneously.When the interior light switch is in the
“DOOR” position and any of the side
doors is opened, the light will come on.
After all the side doors are closed, the
light remains on for about 15 seconds
before fading out. (For further information,
see “Interior light” on page 105 in Section
1
−5.)
Vehicles with the power door lock sys-
tem—When the interior light switch is in
the “DOOR” position, and the driver ’s door
is unlocked using the key, the interior light
will come on and remain on for about 15
seconds before fading out. (For further
information, see “Interior light” on page
105 in Section 1 −5.)
PS12517
LOCKING AND UNLOCKING WITH
INSIDE LOCK KNOB
Move the lock knob.
To lock: Push the knob forward.
To unlock: Pull the knob backward.
The front doors can be opened by pulling
the inside handle even if the lock knobs
are in the locked position.

202006 YARIS HATCHBACK from Aug. ’05 Prod. (OM52703U)
CAUTION
Do not pull the inside handle of the
front doors while driving. The doors
will open and an accident may occur.
Toyota strongly recommends that all
children be placed in the rear seat of
the vehicle.
Closing the door with the lock knob in the
lock position will also lock the door. Be
careful not to lock your keys in the ve-
hicle.
Vehicles with the power door lock sys-
tem—Doors cannot be locked when the
driver’s door is open and the key is in the
ignition.
PS12518
For driver’s use
PS12519
For front passenger’s use
LOCKING AND UNLOCKING WITH
POWER DOOR LOCK SWITCH
Push the switch.
For driver ’s use—
To lock: Push the switch down on the
right side.
To unlock: Push the switch down on the
left side.
For front passenger ’s use—
To lock: Push the switch down on the
“LOCK” side.
To unlock: Push the switch down on the
“UNLOCK” side.
Operating the switch simultaneously locks
or unlocks all the side doors and back
door.
If you do any of the following, no side
door or back door can be unlocked with
the power door lock switch.
Lock all the side doors and back door
with the wireless remote control key.
Set the driver’s door inside lock knob
in the lock position, and close the driv-
er’s door while holding up the outside
door handle.
Lock all the side doors and back door
simultaneously with driver ’s door.

212006 YARIS HATCHBACK from Aug. ’05 Prod. (OM52703U)
The power door lock switch can be reset
in the following ways.
Turn the ignition key to “ON”.
Unlock all the side doors and back
door simultaneously with the driver ’s
door.
Unlock all the side doors and back
door with the wireless remote control
key.
Unlock the driver’s door with the inside
lock knob, and then unlock all the side
doors with the power door lock switch.
PS12520
REAR DOOR CHILDPROTECTORS
(5door models only)
Move the lock lever to the “LOCK”
position as shown on the label.
When the child−protector is locked, you
cannot open the rear door by the inside
door handle. We recommend using this
feature whenever small children are in the
vehicle.
CAUTION
Before driving, be sure that the doors
are closed and locked, especially
when small children are in the ve-
hicle. Along with the proper use of
seat belts, locking the doors helps
prevent the driver and passengers
from being thrown out from the ve-
hicle in an accident. It also helps pre-
vent the doors from being opened
unintentionally.

222006 YARIS HATCHBACK from Aug. ’05 Prod. (OM52703U)
Power windows
PS12521
The windows can be operated with the
switch on each side door.
The ignition key must be in the “ON” posi-
tion.
Key off operation: The driver ’s window
works for about 45 seconds even after the
ignition switch is turned off. They stop
working when either of the front door is
opened.
OPERATING THE DRIVER’S WINDOW
Use the switch on the driver’s door.
Normal operation: The window moves as
long as you hold the switch.
To open: Lightly push down the switch.
To close: Pull up the switch.
PS12522
Automatic operation (to open only):
Push the switch completely down and then
release it. The window will fully open. To
stop the window partway, lightly pull the
switch up and then release it.
PS12523
Window lock
switch
OPERATING THE PASSENGERS’
WINDOWS
Use the switches on the each passen-
ger’s door or the switches on the driv-
er ’s door that control each passenger ’s
window.
The window moves as long as you hold
the switch.
To open: Push down the switch.
To close: Pull up the switch.
If you push in the window lock switch on
the driver ’s door, the passenger ’s windows
cannot be operated.

232006 YARIS HATCHBACK from Aug. ’05 Prod. (OM52703U)
PS12524
CAUTION
To avoid serious personal injury, you
must do the following.
Before you close the power win-
dows, always make sure there is
nobody around the power windows.
You must also make sure the
heads, hands and other parts of the
bodies of all occupants are kept
completely inside the vehicle. If
someone’s neck, head or hands get
caught in a closing window, it
could result in death or serious in-
jury. When anyone closes the power
windows, make sure he or she op-
erates the windows safely.
When small children are in the ve-
hicle, never let them use the power
window switches without supervi-
sion. Use the window lock switch to
prevent them from making unex-
pected use of the switches.
Be sure to remove the ignition key
or turn the ignition switch to the
“LOCK” position when you leave
your vehicle.
Never leave anyone (particularly a
small child) alone in your vehicle,
especially with the ignition key still
inserted. Otherwise, he/she could
use the power window switches and
get trapped in a window. Unat-
tended person (particularly a small
child) can be involved in a serious
accident.

242006 YARIS HATCHBACK from Aug. ’05 Prod. (OM52703U)
Back door
PS12525
LOCKING AND UNLOCKING WITH KEY
Insert the key into the keyhole and turn
it.
To lock: Turn the key clockwise.
To unlock: Turn the key counterclockwise.
To open the back door, push the button.
Vehicles with the power door lock sys-
tem—Operating the power door lock
switch or wireless remote control simulta-
neously locks or unlocks the back door
(see “Side doors” on page 19).
When closing the back door, make sure
it is securely closed.See “—Stowage precautions” on page 202
in Section 2 for precautions when loading
luggage.
PS12526
PS12537

252006 YARIS HATCHBACK from Aug. ’05 Prod. (OM52703U)
When closing the back door, the inside
handle can be used to make the reach
easier.
To close the back door, lower it and press
down on it. After closing the back door,
try pulling it up to make sure it is secure-
ly closed.
CAUTION
Keep the back door closed while
driving. This not only keeps the
luggage from being thrown out but
also prevents exhaust gases from
entering the vehicle.
Push the back door shut from the
outside. Using the inside handle to
directly close the back door could
cause hands, arms or head to be
caught in the door, resulting in se-
rious injuries.
Hood
PS12528
To open the hood:1. Pull the hood lock release lever. The hood will spring up slightly.
CAUTION
Before driving, be sure that the hood
is closed and securely locked. Other-
wise, the hood may open unexpected-
ly while driving and an accident may
occur.
PS12040
2. In front of the vehicle, pull up theauxiliary catch l ever and lift the
hood.
