SUPPLEMENTAL RESTRAINT SYSTEM – REAR AIRBAG SENSORRS–387
RS
20. REMOVE RECLINING REMOTE CONTROL LEVER
BEZEL LH (w/o Rear No. 2 Seat)
21. DISCONNECT REAR NO. 1 SEAT OUTER BELT
ASSEMBLY LH (See page SB-48)
22. DISCONNECT REAR NO. 2 SEAT OUTER BELT
ASSEMBLY LH (w/ Rear No. 2 Seat) (See page SB-48)
23. REMOVE DECK TRIM SIDE PANEL ASSEMBLY LH
(w/o Rear No. 2 Seat) (See page IR-32)
24. REMOVE DECK TRIM SIDE PANEL ASSEMBLY LH
(w/ Rear No. 2 Seat) (See page IR-32)
25. REMOVE AIRBAG SENSOR REAR LH
(a) Disconnect the connector.
(b) Remove the bolt and airbag sensor.
B127923E01

RS–388SUPPLEMENTAL RESTRAINT SYSTEM – REAR AIRBAG SENSOR
RS
INSTALLATION
HINT:
• Use the same procedures for the RH side and LH side.
• The procedures listed below are for the LH side.
CAUTION:
Be sure to read the precautionary notices concerning the
SRS airbag system before servicing it (see page RS-1).
1. INSTALL AIRBAG SENSOR REAR LH
(a) Install the airbag sensor with the bolt.
Torque: 9.0 N*m (92 kgf*cm, 80 in.*lbf)
NOTICE:
• If the airbag sensor has been dropped, or
there are any cracks, dents or other defects in
the case, bracket or connector, replace it with
a new one.
• When installing the airbag sensor, be careful
that the SRS wiring does not interfere with
other parts and that it is not pinched between
other parts.
2. INSTALL DECK TRIM SIDE PANEL ASSEMBLY LH (w/
Rear No. 2 Seat) (See page IR-53)
3. INSTALL DECK TRIM SIDE PANEL ASSEMBLY LH (w/
o Rear No. 2 Seat) (See page IR-52)
4. CONNECT REAR NO. 2 SEAT OUTER BELT
ASSEMBLY LH (w/ Rear No. 2 Seat)
5. CONNECT REAR NO. 1 SEAT OUTER BELT
ASSEMBLY LH (See page SB-51)
6. INSTALL RECLINING REMOTE CONTROL LEVER
BEZEL LH (w/o Rear No. 2 Seat)
7. INSTALL REAR FLOOR FINISH PLATE (See page IR-
55)
8. INSTALL REAR NO. 1 FLOOR MAT SUPPORT SIDE
PLATE (See page IR-55)
9. INSTALL REAR FLOOR NO. 3 BOARD
10. INSTALL REAR FLOOR NO. 2 BOARD
11. INSTALL REAR NO. 2 SEAT ASSEMBLY LH (w/ Rear
No. 2 Seat) (See page SE-121)
12. INSTALL REAR NO. 2 SEAT ASSEMBLY RH (w/ Rear
No. 2 Seat) (See page IR-55)
13. INSTALL NO. 2 SEAT LEG COVER LH (w/ Rear No. 2
Seat) (See page SE-123)
14. INSTALL NO. 2 SEAT LEG COVER RH (w/ Rear No. 2
Seat) (See page IR-56)
15. INSTALL NO. 2 SEAT HINGE COVER LH (w/ Rear No.
2 Seat) (See page SE-123)
16. INSTALL NO. 2 SEAT HINGE COVER RH (w/ Rear No.
2 Seat) (See page IR-56)
B127923E01

SUPPLEMENTAL RESTRAINT SYSTEM – REAR AIRBAG SENSORRS–389
RS
17. INSTALL DECK BOARD ASSEMBLY (w/o Rear No. 2
Seat)
18. INSTALL REAR FLOOR NO. 1 BOARD (w/o Rear No.
2 Seat)
19. INSTALL TONNEAU COVER ASSEMBLY (w/o Rear
No. 2 Seat)
20. REMOVE PACKAGE TRAY TRIM POCKET SUB-
ASSEMBLY (w/o Rear No. 2 Seat)
21. INSTALL REAR DOOR OPENING TRIM
WEATHERSTRIP LH
22. INSTALL REAR DOOR SCUFF PLATE LH (See page
IR-57)
23. CONNECT CABLE TO NEGATIVE BATTERY
TERMINAL
24. CHECK SRS WARNING LIGHT
(a) Check the SRS warning light (see page RS-34).

SUPPLEMENTAL RESTRAINT SYSTEM – SEAT POSITION SENSORRS–391
RS
REMOVAL
CAUTION:
Be sure to read the precautionary notices concerning the
SRS airbag system before servicing it (see page RS-1).
1. DISCONNECT CABLE FROM NEGATIVE BATTERY
TERMINAL
CAUTION:
Wait at least 90 seconds after disconnecting the
cable from the negative (-) battery terminal to
prevent airbag and seat belt pretensioner activation.
2. REMOVE FRONT SEAT ASSEMBLY (for Manual Seat)
(See page SE-11)
3. REMOVE FRONT SEAT ASSEMBLY (for Power Seat)
(See page SE-27)
4. REMOVE SEAT POSITION AIRBAG SENSOR
(a) Remove the seat slide position sensor protector
from the seat position sensor.
(b) Using a T30 "torx" socket, remove the "torx" screw
and seat position sensor.
(c) Disconnect the connector.
B127917E01

RS–392SUPPLEMENTAL RESTRAINT SYSTEM – SEAT POSITION SENSOR
RS
INSTALLATION
CAUTION:
Be sure to read the precautionary notices concerning the
SRS airbag system before servicing it (see page RS-1).
1. INSTALL SEAT POSITION AIRBAG SENSOR
(a) Using a 1 mm (0.039 in.) feeler gauge, install the
seat position sensor.
NOTICE:
• If the seat position sensor has been dropped,
or there are any cracks, dents or other
defects in the case or connector, replace the
seat position sensor with a new one.
• When installing the seat position sensor, be
careful that the SRS wiring does not interfere
with other parts and that it is not pinched
between other parts.
HINT:
Be sure that the clearance between the seat
position sensor and the seat rail is within 0.6 mm to
1.4 mm (0.023 to 0.055 in.).
(b) Using a T30 "torx" socket, tighten the "torx" screw to
install the seat position sensor.
Torque: 8.0 N*m (82 kgf*cm, 71 in.*lbf)
(c) Make sure that the clearance between the seat
position sensor and the seat rail is within 0.6 mm to
1.4 mm (0.023 to 0.055 in.).
(d) Connect the connector.

SUPPLEMENTAL RESTRAINT SYSTEM – SEAT POSITION SENSORRS–393
RS
(e) Install the seat slide position sensor protector to the
seat position sensor.
2. INSTALL FRONT SEAT ASSEMBLY (for Manual Seat)
(See page SE-22)
3. INSTALL FRONT SEAT ASSEMBLY (for Power Seat)
(See page SE-37)
4. CONNECT CABLE TO NEGATIVE BATTERY
TERMINAL
5. CHECK SRS WARNING LIGHT
(a) Check the SRS warning light (see page RS-34).
B127917E03

SB–8SEAT BELT – SEAT BELT WARNING SYSTEM
SB
PROBLEM SYMPTOMS TABLE
HINT:
Use the table below to help determine the cause of the
problem symptom. The potential causes of the symptoms are
listed in order of probability in the "Suspected Area" column
of the table. Check each symptom by checking the suspected
areas in the order they are listed. Replace parts as
necessary.
Seat belt warning system
Symptom Suspected area See page
Diver side seat belt warning light does not operate1. Front seat inner belt LHSB-12
2. Center airbag sensor assemblySB-12
3. Combination meterSB-12
4. Wire harnessSB-12
Front passenger side seat belt warning light does not
operate1. Front seat inner belt RHSB-15
2. Combination meterSB-15
3. Occupant detection sensorSB-15
4. Heater control panelSB-15
5. Wire harnessSB-15

SB–12SEAT BELT – SEAT BELT WARNING SYSTEM
SB
DATA LIST / ACTIVE TEST
1. ACTIVE TEST
HINT:
Performing the intelligent tester ACTIVE TEST allows
relay, VSV, actuator and other items to be operated
without removing any parts. Performing the ACTIVE
TEST early in troubleshooting is one way to save time.
The DATA LIST can be displayed during the ACTIVE
TEST.
(a) Connect the intelligent tester to the DLC3.
(b) Turn the ignition switch ON.
(c) Perform the ACTIVE TEST according to the display
on the tester.
Center airbag sensor:
Item Test Details Diagnostic Note
D-BELT REMIND D-SEAT BELT warning light (OFF / ON) Confirm that the vehicle is stopped, engine
idling
P-BELT REMIND P-SEAT BELT warning light (OFF / ON) Confirm that the vehicle is stopped, engine
idling
