2006 NISSAN VERSA check engine light

AT-3
D
E
F
G
H
I
J
K
L
MA
B
AT
Revision: June 20062007 Versa Diagnostic Procedure ........................................... 172
Component Inspection ......................................... 175
DTC TURBINE REVOLUTION SENSOR ............... 176
Description ........................................................... 176
CONSULT-II Reference Value .............................. 176
On Board Diagnosis Logic ................................... 176
Possible Cause .................................................... 176
DTC Confirmation Procedure ............................... 176
Wiring Diagram — AT — PT/SEN ........................ 177
Diagnostic Procedure ........................................... 178
CONTROL UNIT (RAM), CONTROL UNIT (ROM) . 182
Description ........................................................... 182
On Board Diagnosis Logic ................................... 182
Possible Cause .................................................... 182
DTC Confirmation Procedure ............................... 182
Diagnostic Procedure ........................................... 182
MAIN POWER SUPPLY AND GROUND CIRCUIT . 183
Wiring Diagram — AT — MAIN ............................ 183
Diagnostic Procedure ........................................... 184
PNP, OD SWITCH AND CLOSED THROTTLE,
WIDE OPEN THROTTLE POSITION SIGNAL CIR-
CUIT ........................................................................ 186
CONSULT-II Reference Value .............................. 186
TCM Terminals and Reference Value ................... 186
Diagnostic Procedure ........................................... 187
Component Inspection ......................................... 191
SHIFT POSITION INDICATOR CIRCUIT ............... 192
Description ........................................................... 192
CONSULT-II Reference Value .............................. 192
Diagnostic Procedure ........................................... 192
TROUBLE DIAGNOSIS FOR SYMPTOMS ............ 193
Wiring Diagram — AT — NONDTC ...................... 193
OD OFF Indicator Lamp Does Not Come On ...... 198
Engine Cannot Be Started in “P” and “N” Position . 200
In “P” Position, Vehicle Moves Forward or Backward
When Pushed ....................................................... 201
In “N” Position, Vehicle Moves ............................. 201
Large Shock “N” → “R” Position ........................... 202
Vehicle Does Not Creep Backward in “R” Position . 203
Vehicle Does Not Creep Forward in “D”, “2” or “1”
Position ................................................................ 205
Vehicle Cannot Be Started from D
1 ...................... 206
A/T Does Not Shift: D
1 → D2 or Does Not Kickdown:
D
4 → D2 ............................................................... 208
A/T Does Not Shift: D
2 → D3 ............................... 210
A/T Does Not Shift: D
3 → D4 ............................... 212
A/T Does Not Perform Lock-up ............................ 214
A/T Does Not Hold Lock-up Condition ................. 215
Lock-up Is Not Released ...................................... 216
Engine Speed Does Not Return to Idle (Light Brak-
ing D
4 → D3 ) ....................................................... 217
A/T Does Not Shift: D
4 → D3 , When OD OFF .... 218
A/T Does Not Shift: D
3 → 22 , When Selector Lever
“D” → “2” Position ................................................ 219
A/T Does Not Shift: 2
2 → 11 , When Selector Lever
“2” → “1” Position ................................................. 221
Vehicle Does Not Decelerate by Engine Brake .... 223
TCM Self-diagnosis Does Not Activate ................ 227TRANSMISSION CONTROL MODULE ..................228
Removal and Installation ......................................228
SHIFT CONTROL SYSTEM ....................................229
Control Device Removal and Installation ..............229
Control Device Disassembly and Assembly .........232
Selector Lever Knob Removal and Installation .....233
Adjustment of A/T Position ...................................233
Checking of A/T Position ......................................234
A/T SHIFT LOCK SYSTEM ....................................235
Description ............................................................235
Shift Lock System Parts Location .........................235
Wiring Diagram — AT — SHIFT ...........................236
Diagnostic Procedure ...........................................237
KEY INTERLOCK CABLE ......................................239
Removal and Installation ......................................239
ON-VEHICLE SERVICE ..........................................242
Control Valve Assembly and Accumulators ..........242
Park/Neutral Position (PNP) Switch .....................246
Revolution Sensor ................................................247
Turbine Revolution Sensor (Power Train Revolution
Sensor) .................................................................248
Differential Side Oil Seal .......................................250
AIR BREATHER HOSE ..........................................252
Removal and Installation ......................................252
TRANSAXLE ASSEMBLY ......................................253
Removal and Installation ......................................253
OVERHAUL ............................................................257
Components .........................................................257
Oil Channel ...........................................................265
Locations of Adjusting Shims, Needle Bearings and
Thrust Washers ....................................................266
Locations of Snap Rings .......................................267
DISASSEMBLY .......................................................268
Disassembly .........................................................268
REPAIR FOR COMPONENT PARTS .....................285
Manual Shaft ........................................................285
Oil Pump ...............................................................289
Control Valve Assembly ........................................293
Control Valve Upper Body ....................................302
Control Valve Lower Body ....................................306
Reverse Clutch .....................................................309
High Clutch ...........................................................314
Forward and Overrun Clutches ............................320
Low & Reverse Brake ...........................................327
Rear Internal Gear and Forward Clutch Hub ........332
Output Shaft, Output Gear, Idler Gear, Reduction
Pinion Gear and Bearing Retainer ........................336
Band Servo Piston Assembly ...............................343
Final Drive ............................................................349
ASSEMBLY .............................................................354
Assembly (1) .........................................................354
Adjustment (1) ......................................................355
Assembly (2) .........................................................361
Adjustment (2) ......................................................366
Assembly (3) .........................................................369
SERVICE DATA AND SPECIFICATIONS (SDS) ....378
General Specifications ..........................................378
Vehicle Speed at Which Gear Shifting Occurs .....378
Vehicle Speed at When Lock-up Occurs/Releases .378

AT-42
ON BOARD DIAGNOSTIC (OBD) SYSTEM
Revision: June 20062007 Versa
HOW TO ERASE DTC (NO TOOLS)
The OD OFF indicator lamp is located on the combination meter.
1. If the ignition switch stays ON after repair work, be sure to turn ignition switch OFF once. Wait at least 10
seconds and then turn it ON (engine stopped) again.
2. Perform “TCM SELF-DIAGNOSTIC PROCEDURE (No Tools)”. Refer to AT-90, "
Diagnostic Procedure
Without CONSULT-II" . (The engine warm-up step can be skipped when performing the diagnosis only to
erase the DTC.)
3. Perform “OBD-II SELF-DIAGNOSTIC PROCEDURE (No tools)”. Refer to EC-60, "
How to Erase DTC" .
Malfunction Indicator Lamp (MIL)UCS005N7
DESCRIPTION
The MIL is located on the instrument panel.
1. The MIL will light up when the ignition switch is turned ON with-
out the engine running. This is a bulb check.

If the MIL does not light up, refer to DI-24, "WARNING
LAMPS" , or see EC-592, "MIL AND DATA LINK CONNEC-
TOR" .
2. When the engine is started, the MIL should go off.

If the MIL remains on, the on board diagnostic system has
detected an engine system malfunction.
SEF 2 17 U

TROUBLE DIAGNOSIS
AT-49
D
E
F
G
H
I
J
K
L
MA
B
AT
Revision: June 20062007 Versa
4. 4-3. “Cruise Test”AT-6 1
Part 1
❏ AT-206, "
Vehicle Cannot Be Started from D1" .
❏ AT-208, "
A/T Does Not Shift: D1 → D2 or Does Not Kickdown: D4 → D2" .
❏ AT-210, "
A/T Does Not Shift: D2 → D3" .
❏ AT-212, "
A/T Does Not Shift: D3 → D4" .
❏ AT-214, "
A/T Does Not Perform Lock-up" .
❏ AT-215, "
A/T Does Not Hold Lock-up Condition" .
❏ AT-216, "
Lock-up Is Not Released" .
❏ AT-217, "
Engine Speed Does Not Return to Idle (Light Braking D4 → D3 )" .
Part 2AT-6 4
❏ AT-206, "Vehicle Cannot Be Started from D1" .
❏ AT-208, "
A/T Does Not Shift: D1 → D2 or Does Not Kickdown: D4 → D2" .
❏ AT-210, "
A/T Does Not Shift: D2 → D3" .
❏ AT-212, "
A/T Does Not Shift: D3 → D4" .
Part 3AT-6 5
❏ AT-218, "A/T Does Not Shift: D4 → D3 , When OD OFF" .
❏ AT-219, "
A/T Does Not Shift: D3 → 22 , When Selector Lever “D” → “2” Position" .
❏ AT-221, "
A/T Does Not Shift: 22 → 11 , When Selector Lever “2” → “1” Position" .
❏ AT-223, "
Vehicle Does Not Decelerate by Engine Brake" .
❏ Perform self-diagnosis. Enter checks for detected items. AT-8 2
, AT-9 0 .
❏ AT - 9 4 , "
DTC U1000 CAN COMMUNICATION LINE" .
❏ AT - 9 7 , "
DTC P0705 PARK/NEUTRAL POSITION (PNP) SWITCH" .
❏ AT-102, "
DTC P0710 A/T FLUID TEMPERATURE SENSOR CIRCUIT" .
❏ AT-107, "
DTC P0720 VEHICLE SPEED SENSOR·A/T (REVOLUTION SENSOR)" .
❏ AT - 11 3 , "
DTC P0725 ENGINE SPEED SIGNAL" .
❏ AT - 11 7 , "
DTC P0731 A/T 1ST GEAR FUNCTION"
❏ AT-121, "DTC P0732 A/T 2ND GEAR FUNCTION" .
❏ AT-124, "
DTC P0733 A/T 3RD GEAR FUNCTION" .
❏ AT-128, "
DTC P0734 A/T 4TH GEAR FUNCTION" .
❏ AT-134, "
DTC P0740 TORQUE CONVERTER CLUTCH SOLENOID VALVE" .
❏ AT-139, "
DTC P0744 A/T TCC S/V FUNCTION (LOCK-UP)" .
❏ AT-145, "
DTC P0745 LINE PRESSURE SOLENOID VALVE" .
❏ AT-151, "
DTC P0750 SHIFT SOLENOID VALVE A" .
❏ AT-156, "
DTC P0755 SHIFT SOLENOID VALVE B" .
❏ AT-161, "
DTC P1760 OVERRUN CLUTCH SOLENOID VALVE" .
❏ AT-166, "
DTC VEHICLE SPEED SENSOR MTR" .
❏ AT-170, "
DTC BATT/FLUID TEMP SEN (A/T FLUID TEMP SENSOR CIRCUIT AND TCM
POWER SOURCE)" .
❏ AT-176, "
DTC TURBINE REVOLUTION SENSOR" .
❏ AT-182, "
CONTROL UNIT (RAM), CONTROL UNIT (ROM)" .
❏ AT-183, "
MAIN POWER SUPPLY AND GROUND CIRCUIT" .
5.❏ For self-diagnosis NG items, inspect each component. Repair or replace the damaged parts.AT-8 2
,
AT-9 1
6.❏ Perform “Road Test”.AT-5 8
7.❏ Perform the Diagnostic Procedures for all remaining items marked NG. Repair or replace the damaged parts.
Refer to the Symptom Chart when you perform the procedures. (The chart also shows some other possible
symptoms and the component inspection orders.)AT-6 8
8.❏ Erase DTC from TCM and ECM memories.AT-8 3,
AT-9 3

TROUBLE DIAGNOSIS
AT-63
D
E
F
G
H
I
J
K
L
MA
B
AT
Revision: June 20062007 Versa
5. CHECK LOCK-UP (D4 TO D4 L/U)
Check lock-up (D
4 to D4 L/U).
Specified speed when lock-up occurs. Refer to AT-67, "
Vehicle Speed at Which Lock-up Occurs/Releases" .
Read vehicle speed, throttle opening when lock-up duty
becomes 94%. Refer to AT- 8 4 , "
DATA MONITOR MODE" .
Does A/T perform lock-up at the specified speed?
YES >> GO TO 6.
NO >>

Mark the box on the AT-47, "DIAGNOSTIC WORK-
SHEET" .

Go to AT-214, "A/T Does Not Perform Lock-up" .

Continue “Road Test”.
6. CHECK LOCK-UP HOLD
Check lock-up hold.
When lock-up duty becomes 94%. Refer to AT-84, "
DATA MONITOR MODE" .
Does A/T hold lock-up condition for more than 30 seconds?
YES >> GO TO 7.
NO >>

Mark the box on the AT - 4 7 , "DIAGNOSTIC WORKSHEET" .

Go to AT-215, "A/T Does Not Hold Lock-up Condition" .

Continue “Road Test”.
7. CHECK SHIFT-DOWN (D4 L/U TO D4 )
Release accelerator pedal.
When lock-up duty becomes 4%. Refer to AT-8 4, "
DATA MONITOR MODE" .
Is lock-up released when accelerator pedal is released?
YES >> GO TO 8.
NO >>

Mark the box on the AT - 4 7 , "DIAGNOSTIC WORKSHEET" .

Go to AT-216, "Lock-up Is Not Released" .

Continue “Road Test”.
8. CHECK SHIFT-DOWN (D4 TO D3 )
Decelerate vehicle by applying foot brake lightly.
Read gear position and engine speed. Refer to AT- 8 4 , "
DATA
MONITOR MODE" .
Does engine speed return to idle smoothly when A/T is shifted from
D4 to D3 ?
YES >> 1. Stop vehicle.
2. Go to AT- 6 4 , "
Cruise Test — Part 2" .
NO >>

Mark the box on the AT-47, "DIAGNOSTIC WORK-
SHEET" .

Go to AT-217, "Engine Speed Does Not Return to Idle
(Light Braking D4 → D3 )" .

Continue “Road Test”.
SCIA7191E
SAT9 5 9I

AT-80
TROUBLE DIAGNOSIS
Revision: June 20062007 Versa
CONSULT-II Function (A/T)UCS005N1
CONSULT-II can display each diagnostic item using the diagnostic test models shown following.
FUNCTION
CONSULT-II REFERENCE VALUE
NOTICE:
1. The CONSULT-II electrically displays shift timing and lock-up timing (that is, operation timing of each sole-
noid).
Check for time difference between actual shift timing and the CONSULT-II display. If the difference is
noticeable, mechanical parts (except solenoids, sensors, etc.) may be malfunctioning. Check mechanical
parts using applicable diagnostic procedures.
2. Shift schedule (which implies gear position) displayed on CONSULT-II and that indicated in Service Man-
ual may differ slightly. This occurs because of the following reasons:
–Actual shift schedule has more or less tolerance or allowance,
–Shift schedule indicated in Service Manual refers to the point where shifts start, and
–Gear position displayed on CONSULT-II indicates the point where shifts are completed.
3. Shift solenoid valve “A” or “B” is displayed on CONSULT-II at the start of shifting. Gear position is dis-
played upon completion of shifting (which is computed by TCM).
Diagnostic test mode Function Reference page
Work supportThis mode enables a technician to adjust some devices faster and more accurately by
following the indications on CONSULT-II.—
Self-diagnostic results Self-diagnostic results can be read and erased quickly.AT- 8 2
Data monitor Input/Output data in the TCM can be read.AT- 8 4
CAN diagnostic support
monitorThe results of transmit/receive diagnosis of CAN communication can be read.AT- 8 6
Function testPerformed by CONSULT-II instead of a technician to determine whether each system
is “OK” or “NG”.—
DTC work support Select the operating condition to confirm Diagnostic Trouble Codes.AT- 8 6
TCM part number TCM part number can be read. —
Item name Condition Display value (Approx.)
VHCL/S SE-A/T
During drivingApproximately matches the speedometer
reading.
VHCL/S SE-MTR
THROTTLE POSIReleased accelerator pedal. 0.0/8
Fully depressed accelerator pedal. 8.0/8
FLUID TEMP SE When A/T fluid temperature is 20°C (68°F). 1.5 V
When A/T fluid temperature is 80°C (176°F). 0.5 V
BATTERY VOLT When turning ignition switch to “ON”. Battery voltage
ENGINE SPEED Engine runningApproximately matches the tachometer
reading.
TURBINE REV During driving (lock-up ON) Approximately matches the engine speed.
OVERDRIVE SWWhen overdrive control switch is depressed. ON
When overdrive control switch is released. OFF
PN POSI SWWhen setting selector lever to “N” or “P” posi-
tion.ON
When setting selector lever to other positions. OFF
R POSITION SWWhen setting selector lever to “R” position. ON
When setting selector lever to other positions. OFF
D POSITION SWWhen setting selector lever to “D” position. ON
When setting selector lever to other positions. OFF

AT-90
TROUBLE DIAGNOSIS
Revision: June 20062007 Versa
Diagnostic Procedure Without CONSULT-IIUCS005N2
TCM SELF-DIAGNOSTIC PROCEDURE
Description
If a malfunction occurs in electrical system, turning ignition switch ON will illuminate OD OFF indicator lamp for
2 seconds. To detect a malfunction, entering a self-diagnosis start signal retrieves information on malfunctions
from memory and indicates malfunction by blinking OD OFF indicator lamp.
Diagnostic Procedure
1. CHECK OD OFF INDICATOR LAMP
1. Park vehicle on flat surface.
2. Move selector lever to “P” position.
3. Turn ignition switch OFF. Wait at least 5 seconds.
4. Turn ignition switch ON. (Do not start engine.)
Does OD OFF indicator lamp come on about 2 seconds?
YES >> GO TO 2.
NO >> Stop procedure. Perform AT-198, "
OD OFF Indicator
Lamp Does Not Come On" before proceeding.
2. JUDGEMENT PROCEDURE STEP 1
1. Turn ignition switch OFF.
2. Keep pressing shift lock release button.
3. Move selector lever from “P” to “D” position.
4. Turn ignition switch ON. (Do not start engine.)
5. Keep pressing overdrive control switch while OD OFF indicator lamp is lighting up for 2 seconds. (OD
OFF indicator lamp is on.)
6. Keep pressing overdrive control switch and shift selector lever to the “2” position. (OD OFF indicator lamp
is on.)
7. Stop pressing overdrive control switch. (OD OFF indicator lamp is on.)
8. Shift selector lever to the “1” position. (OD OFF indicator lamp is on.)
9. Keep pressing overdrive control switch. (OD OFF indicator lamp is off.)
10. Depress accelerator pedal fully while pressing overdrive control switch.
>> GO TO 3.
SCIA5472E
SCIA7140E

TROUBLE DIAGNOSIS FOR SYMPTOMS
AT-217
D
E
F
G
H
I
J
K
L
MA
B
AT
Revision: June 20062007 Versa
Engine Speed Does Not Return to Idle (Light Braking D4 → D3 )UCS005VA
SYMPTOM:
Engine speed does not smoothly return to idle when A/T shifts from D4 to D3 on “Cruise Test — Part
1”.
DIAGNOSTIC PROCEDURE
1. CHECK SELF-DIAGNOSTIC RESULTS
Perform self-diagnosis. Refer to AT-82, "
SELF-DIAGNOSTIC RESULT MODE" or AT-90, "Diagnostic Proce-
dure Without CONSULT-II" .
Is any malfunction detected by self-diagnostic results?
YES >> Check the malfunctioning system. Refer to AT- 8 2 , "SELF-DIAGNOSTIC RESULT MODE" or AT-
91, "Judgement of Self-diagnosis Code" .
NO >> GO TO 2.
2. CHECK ACCELERATOR PEDAL POSITION SENSOR
Check accelerator pedal position sensor. Refer to EC-532, "
DTC P2138 APP SENSOR" .
OK or NG
OK >> GO TO 3.
NG >> Repair or replace accelerator pedal position sensor.
3. CHECK A/T FLUID CONDITION
1. Remove oil pan. Refer to AT-257, "
Components" .
2. Check A/T fluid condition. Refer to AT-53, "
Fluid Condition Check" .
OK or NG
OK >> GO TO 5.
NG >> GO TO 4.
4. DETECT MALFUNCTIONING ITEM
1. Remove control valve assembly. Refer to AT-242, "
Control Valve Assembly and Accumulators" .
2. Check the following items:
–Overrun clutch control valve
–Overrun clutch reducing valve
–Overrun clutch solenoid valve
3. Disassemble A/T. Refer to AT- 2 6 8 , "
Disassembly" .
4. Check the following items:
–Overrun clutch assembly. Refer to AT-320, "Forward and Overrun Clutches" .
OK or NG
OK >> GO TO 6.
NG >> Repair or replace damaged parts.
5. DETECT MALFUNCTIONING ITEM
1. Remove control valve assembly. Refer to AT-242, "
Control Valve Assembly and Accumulators" .
2. Check the following items:
–Overrun clutch control valve
–Overrun clutch reducing valve
–Overrun clutch solenoid valve
OK or NG
OK >> GO TO 6.
NG >> Repair or replace damaged parts.

AV-24
AUDIO
Revision: June 20062007 Versa
NOTE:
The source of the noise can be found easily by listening to the noise while removing the fuses of electrical
components, one by one.
TYPE OF NOISE AND POSSIBLE CAUSE
Power Supply Circuit InspectionEKS00I9U
1. CHECK FUSE
Check that the following fuses of the subwoofer (premium system) and audio unit are not blown.
OK or NG
OK >> GO TO 2.
NG >> If fuse is blown, be sure to eliminate cause of blown fuse before installing new fuse. Refer to PG-
4, "POWER SUPPLY ROUTING CIRCUIT" .
2. AUDIO UNIT POWER SUPPLY CIRCUIT CHECK
1. Disconnect audio unit connector.
2. Check voltage between the audio unit and ground.
OK or NG
OK >> With premium system, GO TO 3.
NG >>

Check connector housings for disconnected or loose
terminals.

Repair harness or connector.
Occurrence condition Possible cause
Occurs only when engine is ON.A continuous growling noise occurs. The speed of
the noise varies with changes in the engine speed.Ignition components
A whistling noise occurs while the engine speed is
high. A booming noise occurs while the engine is
running and the lighting switch is ON.Generator
Noise only occurs when various
electrical components are oper-
ating.A cracking or snapping sound occurs with the
operation of various switches.Relay malfunction, radio malfunction
The noise occurs when various motors are operat-
ing.

Motor case ground

Motor
The noise occurs constantly, not just under certain conditions.

Rear defogger coil malfunction

Open circuit in printed heater
A cracking or snapping sound occurs while the vehicle is being driven, especially
when it is vibrating excessively.

Ground wire of body parts.

Ground due to improper part installation

Wiring connections or a short circuit
Unit Terminals Signal name Fuse No.
Audio unit19 Battery power 27
7 Ignition switch ACC or ON 20
Subwoofer (with premium audio) 1 Ignition switch ACC or ON 27
UnitTe r m i n a l N o .
OFF ACC ON (+)
(-)
Connector Terminal
Audio unit M4319 GroundBattery
voltageBattery
voltageBattery
voltage
7 Ground 0VBattery
voltageBattery
voltage
WKIA5345E
