2006 MERCEDES-BENZ SPRINTER Marker

8W-50 FRONT LIGHTING
Component Page
Beam Select Switch................ 8W-50-4, 6
D+ Relay No. 1........... 8W-50-7, 8, 12, 14, 15
Daytime Running Lamp Relay-Left Side . . 8W-50-7
Daytime Running Lamp Relay-Right
Side.......................... 8W-50-6, 8
Daytime Running Lamps Relay...... 8W-50-3, 13
Fog Lamp Relay................ 8W-50-6, 9, 10
Fog Lamp Switch.................... 8W-50-9
Fuse 1........................ 8W-50-3, 4, 13
Fuse 2.......................... 8W-50-6, 8
Fuse 3........................ 8W-50-6, 7, 12
Fuse 4....................... 8W-50-3, 14, 15
Fuse 5............................ 8W-50-9
Fuse 6............................ 8W-50-2
Fuse 9................... 8W-50-12, 13, 14, 15
Fuse 10........................ 8W-50-3, 4, 8
Fuse 11........................ 8W-50-3, 4, 7
Fuse 12........................ 8W-50-4, 6, 8
Fuse 13........................ 8W-50-6, 7, 8
Fuse 14......................... 8W-50-6, 10
Fuse Block No. 1............... 8W-50-2, 4, 5, 6
Fuse Block No. 2..... 8W-50-3, 7, 8, 12, 13, 14, 15
Fuse Block No. 3.................... 8W-50-9
G100........................... 8W-50-7, 10
G102........................... 8W-50-8, 10
G200.............................. 8W-50-2
G202............. 8W-50-7, 8, 10, 11, 13, 14, 15
G203.............................. 8W-50-9Component Page
Hazard Warning Switch............... 8W-50-2
Headlamp Adjust Switch.......... 8W-50-7, 8, 9
Headlamp Assembly-Left.......... 8W-50-3, 6, 7,
9, 10, 11, 13, 14
Headlamp Assembly-Right......... 8W-50-3, 6, 8,
9, 10, 11, 13, 15
Headlamp Switch................ 8W-50-4, 5, 6
Lamp Relay-Left.................. 8W-50-3, 14
Lamp Relay-Right................. 8W-50-3, 15
Marker Lamp Connector.............. 8W-50-11
Marker Lamp No. 1-Left Front......... 8W-50-11
Marker Lamp No. 1-Right Front........ 8W-50-11
Marker Lamp No. 2-Left Front......... 8W-50-11
Marker Lamp No. 2-Right Front........ 8W-50-11
Marker Lamp-Left Center............ 8W-50-11
Marker Lamp-Left Rear.............. 8W-50-11
Marker Lamp-Right Center........... 8W-50-11
Marker Lamp-Right Rear............. 8W-50-11
Multi-Function Switch.......... 8W-50-2, 4, 5, 6
Power Distribution Center............ 8W-50-12
Tail Lamp Assembly-Left............. 8W-50-14
Tail Lamp Assembly-Right............ 8W-50-15
Turn Signal Relay.................. 8W-50-2, 5
Turn Signal Switch................. 8W-50-4, 5
Wiper/Turn Signal/Engine Start Control
Module........................ 8W-50-2, 5
VA8W-50 FRONT LIGHTING 8W - 50 - 1

8W-51 REAR LIGHTING
Component Page
Brake Lamp Switch.................. 8W-51-6
Center High Mounted Stop Lamp...... 8W-51-6, 8
Daytime Running Lamps Relay......... 8W-51-2
Fuse 1............................ 8W-51-4
Fuse 8............................ 8W-51-5
Fuse 11............................ 8W-51-4
Fuse Block No. 1.................. 8W-51-4, 5
G200............................ 8W-51-6, 8
G202.............................. 8W-51-2
G300...................... 8W-51-3, 6, 7, 8, 9
Headlamp Switch.................... 8W-51-4
License Plate Lamp No. 1............. 8W-51-3Component Page
License Plate Lamp No. 2............. 8W-51-3
Marker Lamp Connector.............. 8W-51-2
Marker Lamp-Left Rear............... 8W-51-3
Marker Lamp-Right Rear.............. 8W-51-3
Multi-Function Switch................ 8W-51-4
Tail Lamp Assembly-Left.... 8W-51-4, 5, 6, 7, 8, 9
Tail Lamp Assembly-Right . . . 8W-51-4, 5, 6, 7, 8, 9
Turn Signal/Anti-Theft Alarm Relay-Left . . 8W-51-5
Turn Signal/Anti-Theft Alarm Relay-
Right........................... 8W-51-5
VA8W-51 REAR LIGHTING 8W - 51 - 1

Component Page
Interior Lamp-Right................. 8W-80-58
Interior Light Switch................ 8W-80-59
Interior Light Switch-Driver........... 8W-80-59
Interior Light Switch-Passenger........ 8W-80-59
Interior Light Switch-Rear............ 8W-80-60
Interior Lighting Connector........... 8W-80-60
Intrusion Sensor No. 1............... 8W-80-60
Intrusion Sensor No. 2............... 8W-80-60
Intrusion Sensor No. 3............... 8W-80-61
Kick Down Switch.................. 8W-80-61
Lateral Acceleration Sensor........... 8W-80-61
License Plate Lamp No. 1............. 8W-80-61
License Plate Lamp No. 2............. 8W-80-61
Locker Switch No. 1................. 8W-80-62
Locker Switch No. 2................. 8W-80-62
Low Fuel Pressure Sensor............ 8W-80-62
Map/Reading Lamp Switch............ 8W-80-62
Marker Lamp Connector............. 8W-80-63
Marker Lamp No. 1-Left Front......... 8W-80-63
Marker Lamp No. 1-Right Front....... 8W-80-63
Marker Lamp No. 2-Left Front......... 8W-80-63
Marker Lamp No. 2-Right Front....... 8W-80-64
Marker Lamp-Left Center............ 8W-80-64
Marker Lamp-Left Rear.............. 8W-80-64
Marker Lamp-Right Center........... 8W-80-64
Marker Lamp-Right Rear............. 8W-80-64
Mass Air Flow Sensor................ 8W-80-65
Master Door Lock Switch............. 8W-80-65
Metering Pump..................... 8W-80-65
Microphone Connector............... 8W-80-65
Oxygen Sensor (OBD)................ 8W-80-66
Panic Alarm Switch................. 8W-80-66
Parking Brake Switch............... 8W-80-66
Power Mirror Motor-Driver........... 8W-80-67
Power Mirror Motor-Passenger......... 8W-80-67
Power Mirror Switch................ 8W-80-67
Power Window Motor-Driver.......... 8W-80-67
Power Window Motor-Passenger........ 8W-80-68
Power Window Switch-Driver.......... 8W-80-68
Power Window Switch-master......... 8W-80-68
Power Window Switch-Passenger....... 8W-80-68
Radio Antenna..................... 8W-80-69
Radio C1.......................... 8W-80-69
Radio C2.......................... 8W-80-69
Radio/Cellular Antenna.............. 8W-80-69
Rain Sensor....................... 8W-80-70
Rain Sensor Control Module........... 8W-80-70
Reading Lamp Connector............. 8W-80-71
Recirculated Air Solenoid Valve........ 8W-80-71
Refrigerant Pressure Sensor........... 8W-80-71
Remote Keyless Entry Antenna........ 8W-80-71
Rollover Switch Assembly............. 8W-80-71
Roof A/C Control Module............. 8W-80-72
Roof A/C Switch.................... 8W-80-72Component Page
Roof A/C Temperature Setting Control . . . 8W-80-72
Roof Fan Motor..................... 8W-80-73
Roof Fan Switch.................... 8W-80-73
Roof Thermotronic Control Module...... 8W-80-73
Seat Belt Switch.................... 8W-80-74
Seat Belt Tensioner-Driver............ 8W-80-74
Seat Belt Tensioner-Passenger......... 8W-80-74
Security System Module C1........... 8W-80-75
Security System Module C2........... 8W-80-75
Sentry Key Remote Entry Module
(SKREEM)...................... 8W-80-76
Shifter Assembly................... 8W-80-76
Siren............................. 8W-80-76
SKREEM Transponder............... 8W-80-77
Speaker-Left Front Door Assembly C1 . . . 8W-80-77
Speaker-Left Front Door Assembly C2 . . . 8W-80-77
Speaker-Left Rear.................. 8W-80-77
Speaker-Right Front Door............ 8W-80-77
Speaker-Right Rear................. 8W-80-78
Speed Control Switch................ 8W-80-78
Steering Angle Sensor............... 8W-80-78
Tail Lamp Assembly-Left............. 8W-80-78
Tail Lamp Assembly-Right............ 8W-80-79
TCS Switch (ASR).................. 8W-80-79
Towing/intrusion Sensor On/Off Switch . . 8W-80-79
Trailer Tow Connector............... 8W-80-80
Trailer Tow Control Module C1 (Except
Retrofit)........................ 8W-80-80
Trailer Tow Control Module C1 (retrofit) . 8W-80-80
Trailer Tow Control Module C2 (Except
Retrofit)........................ 8W-80-81
Transmission Control Module C1....... 8W-80-81
Transmission Control Module C2....... 8W-80-81
Turn Signal No. 1-Left Front.......... 8W-80-82
Turn Signal No. 1-Right Front......... 8W-80-82
Turn Signal No. 2-Left Front.......... 8W-80-82
Turn Signal No. 2-Right Front......... 8W-80-82
Warm Air Auxiliary Heater Assembly
C1............................. 8W-80-83
Warm Air Auxiliary Heater Assembly
C2............................. 8W-80-83
Washer Pump Motor-Front............ 8W-80-83
Water Cycle Valve................... 8W-80-83
Water In Fuel Sensor................ 8W-80-84
Wheel Speed Sensor-Left Front........ 8W-80-84
Wheel Speed Sensor-Left Rear......... 8W-80-84
Wheel Speed Sensor-Right Front....... 8W-80-84
Wheel Speed Sensor-Right Rear........ 8W-80-84
Window Defogger Module-Rear......... 8W-80-85
Window Defogger Switch-Rear......... 8W-80-85
Window Defogger-Left Rear........... 8W-80-86
Window Defogger-Right Rear.......... 8W-80-86
Wiper Motor-Front.................. 8W-80-86
VA8W-80 CONNECTOR PIN-OUTS 8W - 80 - 3

MARKER LAMP CONNECTOR
CAV CIRCUIT FUNCTION
1 16GY/RD LAMP DRIVER
2 16BR GROUND
MARKER LAMP NO. 1-LEFT FRONT
CAV CIRCUIT FUNCTION
1 16GY/BK LAMP DRIVER
2 16BR GROUND
MARKER LAMP NO. 1-RIGHT FRONT
CAV CIRCUIT FUNCTION
1 16GY/RD LAMP DRIVER
2 16BR GROUND
MARKER LAMP NO. 2-LEFT FRONT
CAV CIRCUIT FUNCTION
1 16GY/BK LAMP DRIVER
2 16BR GROUND
VA8W-80 CONNECTOR PIN-OUTS 8W - 80 - 63

MARKER LAMP NO. 2-RIGHT FRONT
CAV CIRCUIT FUNCTION
1 16GY/RD LAMP DRIVER
2 16BR GROUND
MARKER LAMP-LEFT CENTER
CAV CIRCUIT FUNCTION
1 16GY/BK LAMP DRIVER
2 16BR GROUND
MARKER LAMP-LEFT REAR
CAV CIRCUIT FUNCTION
1 16GY/BK LAMP DRIVER
2 16BR GROUND
MARKER LAMP-RIGHT CENTER
CAV CIRCUIT FUNCTION
1 16GY/RD LAMP DRIVER
2 16BR GROUND
MARKER LAMP-RIGHT REAR
CAV CIRCUIT FUNCTION
1 16GY/RD/WT LAMP DRIVER
2 16BR GROUND
8W - 80 - 64 8W-80 CONNECTOR PIN-OUTSVA

CONNECTOR NAME/NUMBER COLOR LOCATION FIG.
License Plate Lamp No. 2 On Rear Of Vehicle 53
Locker Switch No. 1 BK Under Body-Front N/S
Locker Switch No. 2 BK Under Body-Rear 51
Low Fuel Pressure Sensor BK Engine Compartment 12,14
Low Pressure Switch Roof A/C Unit 39
Map/Reading Lamp Switch BK Instrument Panel N/S
Marker Lamp Connector K NS
Marker Lamp No.1-Left Front BK Front Of Vehicle-Left Side N/S
Marker Lamp No.1-Right Front BK Front Of Vehicle-Left Side N/S
Marker Lamp No.2-Left Front BK 5
Marker Lamp No.2-Right Front BK 5
Marker Lamp-Left Center BK Front Of Vehicle-Center Left
Side53
Marker Lamp-Left Rear BK Rear Of Vehicle-Left Side 53
Marker Lamp-Right Center BK Front Of Vehicle-Center
Right Side53
Marker Lamp-Right Rear BK Rear Of Vehicle -Right Side 53
Mass Air Flow Sensor BK Engine Compartment 11
Master Door Lock Switch BK Center Of Instrument Panel 20
Metering Pump BK Instrument Panel 27
Microphone Connector Instrument Panel N/S
Multi-Function Switch Steering Wheel 24
Optional Equipment Relay (Relay Block) Under Driver Seat 23
Oxygen Sensor (OBD) BK 6
Panic Alarm Switch BK Instrument Panel 20
Parking Brake Switch BK Under Instrument Panel N/S
Power Mirror Motor-Driver BK In Driver Door 27
Power Mirror Motor-Passenger BK In Passenger Door 27
Power Mirror Switch BK 23
Power Window Motor-Driver BK 44
Power Window Motor-Passenger BK 44
Power Window Switch-Driver BK 23
Power Window Switch-Master BK 23
Power Window Switch-Passenger BK 6
Radio Antenna Behind Radio 48
Radio C1 BK Behind Radio 20
Radio C2 BK Behind Radio 20
Radio/Cellular Antenna Behind Radio 48
Rain Sensor Front Center Roof 25
Reading Lamp Connector WT Instrument Panel N/S
Recirculated Air Solenoid Valve BK Underhood Right (To The
Instrument Panel)10
Refrigerant Pressure Sensor Engine Compartment-Left
Front8,10
VA8W-91 CONNECTOR/GROUND/SPLICE LOCATION 8W - 91 - 7

SPLICE NUMBER LOCATION FIG.
S306 Near Locker Switch No.2 18
S307 Near Fuse/Relay Block 18
S308 Near Interior Lamp No.3 50
S309 Near Interior Lamp-Right 50
S310 Near Fuse Block No.2 18, 21
S311 Under Drivers Seat 18
S312 Near Wheel Speed Sensor-Left Rear 47
S313 Near Wheel Speed Sensor-Left Rear 47
S314 Near Wheel Speed Sensor-Right Rear 47
S315 Near Wheel Speed Sensor-Right Rear 47
S316 Near Headlamp Assembly-Left 18
S317 Under Drivers Seat 18
S318 Near Marker Lamp-Left Rear 7
S319 Near Tail Lamp Assembly-Left 7
S320 Under Body-Rear Center 7
S321 Near Power Window Switch-Passenger 23, 25
S322 Instrument Panel 18
S323 Near Brake Wear Sensor-Left Rear 47
S324 Near Interior Lamp No.3 N/S
S325 Near Map/Reading Lamp Switch 21
S326 Top Body- Front Center 42
S327 Near Security System Module 18
S328 Near Central Timer Module 18
S329 Near Central Timer Module 18
S330 Near Security System Module 18
S331 Near Security System Module 18
S332 Near Brake Wear Sensor-Left Rear 47
S333 Instrument Panel 18
S350 Near Trailer Tow Connector 18
S351 Near Trailer Tow Control Module 18
S352 Near Trailer Tow Control Module 18
S353 Near Dome Lamp 21
S354 Body-Upper Right Center 42, 50
S355 Near Window Defogger Module-Rear 18, 23
S356 Near Headlamp Assembly-Left 18
S357 Near Central Timer Module 23
S358 Near Trailer Tow Control Module 18
S359 Near Interior Light Switch-Passenger 9
S360 Near Interior Light Switch-Rear 9
S361 Near Time Delay Relay 18
S362 Near Circulation Pump Diode 18
S363 Near Heated Seat Module-Passenger 47
S364 Near CTEL Connector 21
8W - 91 - 12 8W-91 CONNECTOR/GROUND/SPLICE LOCATIONVA

INDEX
ABS INDICATOR.......................8J-9ACCELERATOR PEDAL POSITION SENSOR. . . 14-32
ACCESSORY SWITCH BEZEL............23-56
ADR INDICATOR.....................8J-10
AIR CLEANER ELEMENT................9-21
AIR CLEANER HOUSING................9-21
AIR FILTER ....................24-45, 24-58
AIR OUTLET TEMPERATURE SENSOR....24-16
AIR OUTLETS.......................24-45
AIRBAG CONTROL MODULE.............8O-8
AIRBAG INDICATOR...................8J-11
ALB CONTROLLER....................5-16
ALB LEVER..........................5-16
AMBIENT TEMPERATURE INDICATOR.....8J-11
AMBIENT TEMPERATURE SENSOR.......24-17
ANTENNA BODY & CABLE..............8A-1
ARMREST..........................23-79
ASH RECEIVER......................23-57
ASH RECEIVER / CIGAR LIGHTER LAMP
UNIT..............................8L-30
ASSIST HANDLE.....................23-71
AUDIO..............................8A-1
AUTOMATIC TRANSMISSION NAG1 -
SERVICE INFORMATION................21-3
A - PILLAR TRIM.....................23-70
A / C CLUTCH RELAY.................24-24
A / C COMPRESSOR CLUTCH COIL.......24-12
A / C COMPRESSOR CLUTCH............24-8
A / C COMPRESSOR..................24-66
A / C CONDENSER COVER.............24-52
A / C CONDENSER FAN RELAY..........24-26
A / C CONDENSER HOUSING...........24-52
A / C CONDENSER....................24-69
A / C CONTROL MODULE..............24-28
A / C DISCHARGE LINE................24-71
A / C EVAPORATOR COVER.............24-55
A / C EVAPORATOR HOUSING...........24-55
A / C EVAPORATOR...................24-72
A / C EXPANSION VALVE...............24-73
A / C HEATER CONTROL...............24-12
A / C HIGH PRESSURE SWITCH.........24-30
A / C LOW PRESSURE SWITCH.........24-32
A / C PRESSURE TRANSDUCER.........24-14
BACKLITE - BULKHEAD TRIM PANEL.....23-84
BACKUP LAMP BULB..................8L-5
BASECOAT / CLEARCOAT FINISH........23-77
BATTERY CABLES....................8F-14
BATTERY HOLDDOWN.................8F-13
BATTERY SYSTEM.....................8F-1
BATTERY TRAY......................8F-16
BATTERY............................8F-6
BEARINGS - DIFFERENTIAL CASE.........3-38
BEARING / SEAL - AXLE HUB............3-28
BEARING / SEAL - AXLE................3-24
BELT TENSIONERS.....................7-5
BLOWER MOTOR RELAY...............24-33
BLOWER MOTOR RESISTOR............24-17
BLOWER MOTOR SWITCH........24-19, 24-35
BLOWER MOTOR...............24-47, 24-58
BODY...............................23-1
BOOST PRESSURE SENSOR............14-33
BRAKE INDICATOR...................8J-12
BRAKE LAMP SWITCH.................8L-6
BRAKE LINES.........................5-8
BRAKE PADS / SHOES...................5-8
BRAKE WEAR INDICATOR..............8J-13
BRAKES - ABS........................5-30
BRAKES - BASE........................5-2
BRAKE / PARK LAMP BULB.............8L-7
BULKHEAD TRIM PANEL...............23-72
BUMPERS...........................13-1
BUSHINGS............................2-3
B - PILLAR TRIM.....................23-71
CABIN HEATER.....................24-104
CABLE TENSIONER....................5-24
CABLE..............................8P-2
CABLES.............................5-24
CAMSHAFT POSITION SENSOR..........14-33
CAMSHAFT(S)........................9-28
CARGO LAMP SWITCH................8L-31
CARGO / DOME LAMP BULB............8L-30
CARGO / DOME LAMP UNIT............8L-31
CARPETS AND FLOOR MATS...........23-72
CATALYTIC CONVERTER
................11-3
CENTER BEARING
......................3-9
CENTER HIGH MOUNTED STOP LAMP BULB. . . 8L-8CENTER HIGH MOUNTED STOP LAMP UN.....8L-8
CENTER ROLLER ARM
................23-36CENTER TRACK......................23-37
CENTRAL TIMER MODULE..............8E-1
CHARGE AIR COOLER AND PLUMBING....11-4
CHARGING INDICATOR................8J-14
CHARGING SYSTEM..................8F-17
CHECK VALVE.......................8R-11
CHECK.......................23-13, 23-23
CHIME / BUZZER......................8B-1
CIGAR LIGHTER OUTLET............8W-97-1
CIRCUIT BREAKER.................8W-97-2
CLEARANCE LAMP BULB...............8L-9
CLEARANCE LAMP UNIT................8L-9
CLOCK.............................8J-14
CLOCKSPRING......................8O-12
CLUSTER BEZEL.....................23-55
COLUMN............................19-4
CONNECTOR.......................Intro.-9
CONNECTOR/GROUND/SPLICE
LOCATION........................8W-91-1
CONTROLLER ANTILOCK BRAKE.........8E-3
COOLANT LEVEL SENSOR...............7-13
COOLANT LOW INDICATOR.............8J-15
COOLANT............................7-9
COOLING.............................7-1
COWL TRIM........................23-73
CRANKCASE VENTILATION BREATHER......25-2
CRANKCASE VENTILATION HEATER.......25-1
CRANKSHAFT OIL SEAL - FRONT.........9-42
CRANKSHAFT OIL SEAL - REAR..........9-41
CRANKSHAFT POSITION SENSOR........14-35
CRANKSHAFT........................9-39
CUP HOLDER........................23-57
CYLINDER HEAD COVER(S).............9-33
CYLINDER HEAD......................9-22
DAYTIME RUNNING LAMP RELAY.......8L-10
DEFROSTER DUCTS..................24-47
DIFFERENTIAL........................3-31
DIODE............................Intro.-9
DISC BRAKE CALIPER ADAPTER.........5-14
DISC BRAKE CALIPERS.................5-11
DOME LAMP / INTRUSION SENSOR
BULB..............................8L-33
DOME LAMP / INTRUSION SENSOR......8L-33
DOME / READING LAMP BULB..........8L-32
DOME / READING LAMP UNIT..........8L-32
DOOR GLASS............23-15, 23-30, 23-46
DOOR JAMB SWITCH.................8L-34
DOOR LOCK MOTOR...................8N-1
DOOR OPENING SEALS................23-90
DOOR........................23-14, 23-23
DRIVE BELTS..........................7-5
DRIVER AIRBAG.....................8O-16
DRIVER HEATED SEAT SWITCH.........8G-11
D - PILLAR TRIM.....................23-73
ELECTRIC COOLANT PUMP.............24-75
ELECTRICAL.........................5-30
ELECTROHYDRAULIC UNIT............21-105
ENGINE BLOCK HEATER................7-14
ENGINE BLOCK.......................9-37
ENGINE CONTROL MODULE.............8E-3
ENGINE COOLANT TEMP SENSOR........7-15
ENGINE COOLANT THERMOSTAT.........7-16
ENGINE CRADLE CROSSMEMBER........13-8
ENGINE TEMPERATURE GAUGE.........8J-15
ENGINE..............................9-2
ENTRY / EXIT LAMP BULB.............8L-34
ENTRY / EXIT LAMP UNIT..............8L-35
ESP INDICATOR......................8J-16
EVAPORATOR TEMPERATURE
SENSOR......................24-19, 24-37
EXHAUST GAS RECIRCULATION..........25-4
EXHAUST MANIFOLD..................9-68
EXHAUST PIPE.......................11-3
EXHAUST SYSTEM....................11-1
EXHAUST TUBE.....................24-105
EXTERIOR HANDLE.......23-16, 23-31, 23-35
FAN DRIVE VISCOUS CLUTCH...........7-17
FASTENER IDENTIFICATION...........Intro.-3
FASTENER USAGE...................Intro.-6
FINESSE SANDING / BUFFING & POLISH . . 23-78
FLOOR DISTRIBUTION DUCTS..........24-47
FLUID AND FILTER..................21-131
FLUID CAPACITIES.....................0-5
FLUID COOLER TUBE
.................19-13
FLUID FILL / CHECK LOCATIONS
..........0-5
FLUID RESERVOIR
....................5-15
FLUID TYPES
..........................0-1
FLYWHEEL
...........................9-43FOG LAMP BULB.....................8L-10
FOG LAMP RELAY....................8L-11
FOG LAMP SWITCH...................8L-12
FRAME..............................13-3
FREEWHEELING CLUTCH.............21-135
FRONT BUMPER - STEPS...............13-2
FRONT DOOR INNER BELT
WEATHERSTRIP.....................23-90
FRONT DOOR OUTER BELT
WEATHERSTRIP.....................23-90
FRONT FASCIA.......................13-2
FRONT LAMP UNIT...................8L-13
FRONT POSITION LAMP BULB..........8L-14
FRONT SEAT BELT & RETRACTOR.......8O-20
FRONT SEAT BELT BUCKLE............8O-23
FRONT TURN / PARK / SIDE MARKER
LAMP BULB.........................8L-15
FRONT WHEEL SPEED SENSOR..........5-31
FRONT...............................2-1
FUEL DELIVERY.......................14-6
FUEL DOSING PUMP.................24-106
FUEL DRAIN TUBES..................14-10
FUEL FILL DOOR.....................23-48
FUEL FILTER CLOGGED INDICATOR......8J-17
FUEL FILTER........................14-10
FUEL GAUGE........................8J-17
FUEL INJECTOR.......................14-35
FUEL LEVEL SENDING UNIT / SENSOR....14-28
FUEL LINE.........................24-107
FUEL LINES.........................14-11
FUEL PRESSURE SENSOR.............14-39
FUEL PRESSURE SOLENOID............14-40
FUEL PUMP MODULE.................14-18
FUEL PUMP.........................14-13
FUEL QUANTITY CONTROL VALVE.......14-21
FUEL RAIL PRESSURE SENSOR.........14-12
FUEL RAIL..........................14-22
FUEL SYSTEM........................14-1
FUEL TANK.........................14-23
FUEL TEMPERATURE SENSOR..........14-42
FUSE BLOCK #1...................8W-97-2
FUSE BLOCK #2...................8W-97-3
GAP AND FLUSH.....................23-91
GEAR SELECTOR INDICATOR...........8J-18
GEAR...............................19-7
GEARSHIFT CABLE..................21-138
GEAR - PINION / RING.................3-41
GENERATOR DECOUPLER PULLEY.......8F-19
GENERATOR........................8F-18
GLOVE BOX.........................23-58
GLOW PLUG RELAY....................8I-1
GLOW PLUG..........................8I-1
GRILLE............................23-48
HCU (HYDRAULIC CONTROL UNIT).......5-36
HEADLAMP LEVELING MOTOR..........8L-16
HEADLAMP LEVELING SWITCH.........8L-17
HEADLINER.........................23-73
HEADREST..........................23-79
HEATED GLASS.......................8G-1
HEATED MIRRORS....................8G-9
HEATED SEAT ELEMENT...............8G-12
HEATED SEAT RELAY.................8G-12
HEATED SEAT SENSOR................8G-13
HEATED SEATS ......................8G-10
HEATER CORE.......................24-76
HEATER UNIT......................24-110
HEATING & AIR CONDITIONING..........24-1
HIGH BEAM HEADLAMP BULB..........8L-18
HIGH BEAM INDICATOR...............8J-19
HINGE..................23-17, 23-32, 23-51
HOISTING............................0-5
HOLDING CLUTCH B1................21-143
HOLDING CLUTCH B2................21-148
HOLDING CLUTCHES.................21-141
HOOD.............................23-51
HORN SWITCH.......................8H-1
HORN..............................8H-1
HOSES.............................19-14
HUB / BEARING........................2-4
HVAC HOUSING......................24-48
HYDRAULIC / MECHANICAL..............5-5
IGNITION CONTROL....................8I-1
INLET HOSE........................24-111
INPUT CLUTCH K1
...................21-92
INPUT CLUTCH K2
...................21-97
INPUT CLUTCH K3
..................21-102
INPUT CLUTCHES
....................21-90
INPUT SPEED SENSORS
..............21-153
VAINDEX 1
Description Group-Page Description Group-Page Description Group-Page
