2006 MERCEDES-BENZ C-Class Comand Manual

95 Telephone*
Telephone operation
TDMA or CDMA mobile phone
Entering the unlock code
Use the number keys 1 through 0
to enter the four-digit unlock code.
Asterisks instead of digits will appear in
the input line.
Press the OK soft key.
If entered code is correct and the pho-
ne is registered in a network, the phone
is ready for use and the Telephone
menu will appear.GSM mobile phone
Entering the PIN code
Enter the four-digit PIN code at the
COMAND using the number keys 1
through 0. Please refer to the mobile
phone operator’s manual on how to en-
ter the code from the mobile phone.
If no SIM card is in the telephone, the
message
Please insert SIM card
(Emergency Call 911 only pos-
sible with phone)
appears.
Insert a SIM card. Refer to the mo-
bile phone operator’s manual.
Entering codesi
Your unlock code prevents unauthori-
zed persons from using your telephone.
B e s u re t o m em o ri z e t hi s c o d e , a f o u r d i -
git number, carefully.
If you enter an incorrect code, the sys-
tem returns to the menu for entering the
unlock code.
i
You must always enter the unlock code
when you switch on the telephone the
first time (if phone is in locked mode).

96 Telephone*
Telephone operation
Entry incorrect:
You will hear a warning sound. The mes-
sage
PIN-Code incorrect will appear.
You need to re-enter your PIN code.Entering the PUK
If you enter your PIN incorrectly three
times in a row, you need to enter the PUK
number.
The PUK can only be entered at the mobile
phone. Refer to the mobile phone
operator’s manual.When the COMAND is switched on, you
can switch to telephone operation from
any other system (e.g. radio):
Press a.
The Telephone menu will appear.
Telephone menu
!
If the PIN is entered incorrectly three
times in a row, the SIM card will be
blocked. The message
SIM-card
blocked
is displayed briefly. After that
the message
PIN blocked. Please
enter PUK on cell phone
is
displayed.
i
The PUK number is provided by your
telephone service provider.
Switching to telephone operation

97 Telephone*
Telephone operation
The telephone is ready for operation
Message
Ready and the reception
strength Ö are shown on the status bar.
Other messages
ROAMING
The telephone is using a non home type
system
No Serv
The telephone is not logged into a net-
workFull screen messages:
Telephone not inserted
Plug the mobile phone into the mobile
phone cradle*. Refer to the separate
mobile phone operator’s manual.
Telephone not available
Your vehicle may not have a mobile phone
cradle* installed and/or the telephone
control unit may not be coded properly.
Contact an authorized Mercedes-Benz
Center.

98 Telephone*
Telephone operation
The system detects an incoming call, the
phone rings.
Incoming calls are indicated in a window in
any system (e.g. radio).
The window shows:
the caller’s number if it is transmitted
or
the caller’s name if her or his name and
number are saved in the phone book or
Unknown.Accepting a call
Press k.
or
Press E to confirm accept.
The display will change to the
call menu (
page 103). In the status
bar, the off-hook symbol will appear.
An active audio source will be muted.
You talk over the hands-free set.
Rejecting a call
Press K.
or
Push the joystick to H to highlight
reject and than press E.Setting the volume for hands-free ope-
ration
Raising the volume
Turn the rotary control on the e but-
ton to the right.
Lowering the volume
Turn the rotary control on the e but-
ton to the left.
Ending a call
Press K.
or
Press the End soft key.
Incoming call

99 Telephone*
Telephone operation
You can use the following functions to
make a phone call:
Dialing a telephone number
(
page 99)
Redial (page 100)
Selecting an entry from the Received
calls list (
page 101)
Selecting an entry from the Dialed
numbers list (
page 101)
Use speed-dialing (page 103)
Use quick-dialing (page 103)
Selecting a phone book entry and
dialing the number (
page 107)Dialing a telephone number
Entering a telephone number
Open the Telephone menu
(
page 96).
Use the number keys 1 - 0 to enter
the telephone number.Deleting the last or several digits:
Press the Delete soft key once or se-
veral times.
Deleting all digits:
Press K.
or
Press and hold Delete soft key for
more than 2 seconds.
Outgoing calls

100 Telephone*
Telephone operation
Begin dialing
When you have entered the telephone
number
Press E.
or
Press k.
or
In the Telephone menu, press the Send
soft key.Dialing will begin. If a name is associated
with the phone number saved in the phone
book, the name appears on the screen. In
the status bar, the off-hook symbol will ap-
pear.
COMAND will mute an active audio source.
If the person called answers the call, the
call is active. You talk over the hands-free
set.
The message Call failed may
appear if you place an outgoing call.
Try again later.
Subsequent dialing
Transmitting other dial tones:
During a call you can press the number
keys 1 through 0, # and *.
Ending a call
Press K.
or
Press the End soft key.Redial
Press k.
or
Press the Dialed# soft key.
The Dialed numbers list will appear.
The most recently dialed number is
highlighted.
Push the joystick g or G to select
the desired entry.
To dial the selected number:
Press E.
or
Press k.
or
Press the Send soft key.

101 Telephone*
Telephone operation
Selecting an entry from the Received
calls list
The COMAND automatically generates a
list of the last 10 calls received. The list is
sorted chronologically with the most
recently received call at the top of the list.
Displaying the list
In the Telephone menu (page 96),
press the
Recvd# soft key.
The list is displayed and the most
recently received call is highlighted. Received calls list
The status bar shows:
the caller’s name if her or his name and
number are stored in the phone book
the message Unknown if no entry is
available
the telephone number
You can select the following functions:
Changing the list display
Selecting an entry and begin dialing
Ending a call (page 100)Changing the list display
Press the 123 soft key.
The display changes to numbers.
or
Press the ABC soft key.
The display changes to names.
Selecting an entry and begin dialing
Push the joystick to g or G to
select the desired entry.
Press E.
or
Press k.
or
Press the Send soft key.
The telephone dials the number.

102 Telephone*
Telephone operation
Selecting an entry from the Dialed num-
bers list
The COMAND automatically generates a
list of the last 10 numbers dialed. The list
is sorted chronologically with the most
recently dialed number at the top of the
list.
Displaying the list
In the Telephone menu (page 96),
press the
Dialed# soft key.
The list is displayed and the most
recently dialed number is highlighted. Dialed numbers list
The status bar shows:
the caller’s name if her or his name and
number are stored in the phone book
the message Unknown if no entry is
available
the telephone numberYou can select the following functions:
Changing the list display (page 101)
Selecting an entry and begin dialing
(
page 101)
Ending a call (page 100)
Toggling between lists
Push the joystick to H or h to
select the desired list.
Missed calls
If there are one or more missed calls avai-
lable on the mobile phone, a correspon-
ding message will appear.
Press the Back soft key or press E to
return to the Telephone menu.
