2006 LEXUS RX330 display

AUDIO
277
Push this button on the “
” side to skip backward. Push the
button until “REW” and the number you want to skip appear on
the display.
 If you set “REW 1”, the player will rewind to the beginning
of the current program.
 When counting the number of programs you want to rewind,
remember to count the current program as well. For
example, if you want to rewind to a song that is two before
the song you are listening to, push this button until “REW
3” appears on the display.
When a beginning of the tape is reached, the player
automatically resumes normal play.
There must be at least 3 seconds of blank space between
programs for this feature to work correctly.
“RPT” and “Automatic program selection” features:
These features may not work well with some spoken word, live
or classical recordings.CD player operation
(a) Inserting or ejecting CDs
The ignition switch must be in the “ACC” or “ON” position.
 Setting a CD:
Gently push a CD in with the label faces up. (The player
will automatically eject a CD if the label faces down.)

AUDIO
278
Ejecting a CD:
Push the “
” (eject) button for the CD. (b) Playing a CDPush the “DISC” button if the CD is already loaded in the
player.
“CD” appears on the display.
The CDs set in the player are played continuously. The track
number and the time
from the beginning of the program appear
on the display.
When play of CD ends, the first track starts.

AUDIO
279
(c) Searching for a desired track
Push the “SCAN” button briefly. “SCAN” will appear on the
display.
The CD player will play the next track for 10 seconds,
then scan again. To select a track, push the “SCAN” button a
second time. If the player reaches the end of the CD, it will
continue scanning at track 1.
After all the tracks are scanned in one pass, normal play
resumes. (d) Selecting a desired track“TRACK” button: Use for direct access to a desired track.
Push either
side of the “TRACK” button several times until the
desired track number appears on the display. As you release
the button, the player will start playing the selected track from
the beginning.
Vehicles with rear seat entertainment system —
While the DVD player is in operation, the chapter or track can
be changed by pushing the “ ” or “” side of the “TRACK”
button.
“Fast forward” button: Push the “” button and hold it to
fast forward the CD. When you release the button, the CD
player will resume playing from that position.
“Reverse” button: Push the “ ” button and hold it to
reverse the CD. When you release the button, the CD player
will resume playing.

AUDIO
280(e) Repeating a track
“RPT” button: The repeat feature automatically replays the
current program.
Push the “RPT” button briefly while the track is playing.
“
” will appear on the display. When the track ends, it
will automatically be replayed. This process will be continued
until you push the button again to turn off the repeat feature. (f) Random playing
“RAND” button: Use for listening to the tracks on a CD in
random order.
Push
the “RAND” button briefly. “
” will appear on the
display and play the CD you are listening to in random order.
When a track is skipped or the system is inoperative, push the
button to reset.

AUDIO
281
(g) CD text
When you push the “TEXT” button while the CD with CD
text display function (the logo “CD TEXT” marked on the
CD) is being played, the track number, elapsed time, CD
title and then track title appear on the display.
When you push this button if the CD does not have a text
display function, “NO TITLE” appears on the display.
The display can show up to 12 letters at once. If the CD title
or music title is longer than 12 letters, hold down the button until
you hear a beep. The letters after the 12th one are shown.
However, 24
letters at maximum can be shown on the display. When you push this button until you hear a beep or play no
operation
for about 6 seconds with the letters after the 13th one
on the display, the display returns and shows the first 12 letters.
Even if the CD title or music title is longer than 24 letters, the
display can show up to 24 letters.
(h) If the player malfunctions
If the player or another unit equipped with the player
malfunctions, your audio system will display following error
messages.
If “WAIT” appears on the display: It indicates that the inside
of the player unit may be too hot due to the very high ambient
temperature. Remove the CD from the player and allow the
player to cool down.
If “ERROR 1” appears on the display: It indicates that the CD
is dirty, damaged, or it was inserted up− side down. Clean the
CD or insert it correctly.
If “ERROR 3” or “ERROR 4” appears on the display: It
indicates there is a trouble inside the system. Eject the CD.
If the malfunction is not rectified: Take your vehicle to your
Lexus dealer.

AUDIO
282
AUDIO SYSTEM (with sixCD changer)
Quick reference for your audio system
You can adjust the brightness of the display. See “Instrument panel light control” on page 90 for details.
If a Mark Levinson brand audio system is installed, the “Mark Levinso\
n” logo is shown on the panel.


AUDIO
283
1Radio mode:Scan tuning
(See page 291 for details.)
CD mode: Scan selection
(See page 300 for details.)
2Stopping and ejecting a CD
(See page 297 for details.)
3CD slot
(See page 297 for details.)
4Display of functions in TAPE or CD mode
RAND: Random access
(See page 302 for details.)
RPT: Automatic repeat
(See page 295 or 301 for details.)
:DOLBY NR
(See page 294 for details.)
:CD selection
(See page 299 for details.)
: Side change
(See page 295 for details.)
 : Rewinding or reversing
(See page 295 or 301 for details.)
 : Fast forwarding
(See page 295 or 301 for details.)
5Station selector and function buttons
(See page 290 for details.)
6CD load button
(See page 297 for details.)
7Traffic announcement
(See page 292 for details.)
8Program type
(See page 291 for details.)
9TUNE/AUDIO CONTROL knob
(See page 286 for details.)
10Radio mode: Radio text message
(See page 293 for details.)
CD mode: CD text
(See page 303 for details.)
11Mode selectors
(See page 285 for details.)
12Cassette tape slot
(See page 294 for details.)
13Stopping and ejecting a cassette tape
(See page 294 for details.)
14Turning the system on and adjusting the volume
(See page 284 for details.)
15Radio mode:Seek tuning
(See page 290 for details.)
TAPE mode: Direct access to a desired program
(See page 296 for details.)
CD mode: Direct access to a desired track
(See page 301 for details.)

AUDIO
285
Push the “AM”, “FM”, “TAPE” or “DISC” button to turn on
that mode. The selected mode turns on directly.
Push these buttons if you want to switch from one mode to
another.
If the tape or CD is not set, the cassette player or CD player
does not turn on.
You can turn off each player by ejecting the cassette tape or
CD. If the audio system was previously off, then the entire
audio system will be turned off when you eject the cassette
tape or CD. If the other function was previously playing, it will
come on again. With rear seat entertainment system —
You can play a DVD or CD by pushing the “DISC” button when
a disc is loaded in the DVD player. Each time you push the
“DISC” button, you change between “CD” mode on the front
audio system and the DVD player. When you play the DVD
player, “AUX” appears on the display.
