GAUGES, METERS AND SERVICE REMINDER INDICATORS
73
LIGHT SENSITIVE OPTITRONMETER
Light sensitive optitron meter reduces unwanted glare of
the instrument cluster to provide a fine view for the driver.
The meter is originally set to “AUTONorm” mode, so the
reflection of the instrument cluster is adjusted
automatically by tinting the cluster glass depending on
the lighting condition of your surroundings.
There are “AUTO” and “MANUAL” modes. To change the
mode as you like, follow the procedure below.
The reflection control switch is located in the switch box.
G13044
Push the button to use the switch box. When you push the
“MODE” switch, the present setting appears on the
multiinformation display. Push the “MODE” switch once
and then again within 6
seconds. Each time you push the button, the mode changes
in the following order:
1. “AUTO−Norm” Recommended mode . . . .
2. “AUTO−Lo” The cluster glass is tinted with the . . . . . .
surroundings darker than in “AUTO −Norm” mode.
3. “AUTO−Hi” The cluster glass is tinted with the . . . . . . .
surroundings brighter than in “AUTO −Norm” mode.
4. “MANUAL−1” The cluster glass is adjusted in deep . . . . .
tints.
5. “MANUAL−2” The cluster glass is adjusted in neutral . . . . .
tints.
6. “MANUAL−3” The cluster glass is adjusted in light . . . . .
tints.
7. “MANUAL−4” The cluster glass is not tinted, . . . . .
however, if the surroundings are very bright, it is automatically
adjusted in light tints.
The setting display goes off automatically about 6 seconds
after the “MODE” switch is pushed. The mode shown last is
set.
The cluster glass may not be tinted in “MANUAL−1”,
“MANUAL−2” or “MANUAL− 3” mode in the night or cloudy dark
day.
When the ambient temperature in the vehicle interior is low, it
may take time for the cluster glass to be tinted.
After operation, be sure to close the switch box to its original
position.

GAUGES, METERS AND SERVICE REMINDER INDICATORS
74
CAUTION
To reduce the chance of injury in case of an accident or
a sudden stop, keep the switch box closed when not in
use while driving.
G13106
The light sensitive optitron meter sensor is located under the
high mounted stoplight.
NOTICE
Do not apply window tint or a sticker on the rear
window. Otherwise the light sensitive optitron meter
may not operate properly.
 If snow, mud, frost or the like is attached to the rear
window just behind the sensor, remove it soon, or the
light sensitive optitron meter may not operate
properly.
SERVICE REMINDER INDICATORS AND WARNING BUZZERS
IF THIS INDICATOR OR
BUZZER COMES ON ...DO THIS.
(a)or
(Red indicator and buzzer)If parking brake is off,
stop immediately and
contact Lexus dealer.
(b)
(Yellow indicator)
Take vehicle to Lexus
dealer. If brake
system warning light
(red) is also on, stop
immediately and
contact Lexus dealer.
(c)
(Indicator and buzzer)
Fasten driver’s seat
belt.
(d)WG5Fasten front
passenger’s seat belt.

GAUGES, METERS AND SERVICE REMINDER INDICATORS
75
IF THIS INDICATOR OR
BUZZER COMES ON ...
DO THIS.
(e)Take vehicle to Lexus
dealer immediately.
(f)Stop immediately and
contact Lexus dealer.
(g)orTake vehicle to Lexus
dealer.
(h)See multi− information
display.
(i)or
Take vehicle to Lexus
dealer.
If brake system
warning light (red) is
also on, stop
immediately and
contact Lexus dealer.
IF THIS INDICATOR OR BUZZER COMES ON ...DO THIS.
(j)Close all doors.
(k)WG10If flashing, take vehicle
to Lexus dealer.
(l)WG6
Adjust tire inflation
pressure.
If light remains on,
contact Lexus dealer.
(m)WG8Take vehicle to Lexus
dealer.
(n)WG7Take vehicle to Lexus
dealer.
(o)Low fuel level
warning lightFill up tank.

GAUGES, METERS AND SERVICE REMINDER INDICATORS
76IF THIS INDICATOR OR
BUZZER COMES ON ...
DO THIS.
(p)Key reminder
buzzerTurn off the engine
switch.
(a) Brake System Warning Light (red) and Buzzer
This light comes on in the following cases when the engine
switch is selected in “IG −ON” mode.
 When the parking brake is applied ...
GS430—This light comes on fo r a few seconds when the
engine is started even after the parking brake is released.
GS300—This light comes on fo r a few seconds when the
engine switch is selected in “IG −ON” mode even after the
parking brake is released.
If you drive your vehicle without releasing the parking brake,
the buzzer sounds and the message “PARK BRAKE” appears
on the multi −information display.
 When the brake fluid level is low ...
CAUTION
It is dangerous to continue driving normally when the
brake fluid level is low.
Have your vehicle checked at your Lexus dealer in the
following case:
The light does not come on even if the parking brake is
applied when the engine is started.
 The light does not come on even if the engine is started with
the parking brake released.

GAUGES, METERS AND SERVICE REMINDER INDICATORS
77
A warning light turning on briefly during operation does not
indicate a problem.
CAUTION
If either of the following conditions occurs, immediately
stop your
vehicle at a safe place and contact your Lexus
dealer.
 The light does not turn off even after the parking
brake is released while the engine is running.
In this case, the brakes may not work properly and
your stopping distance will become longer. Depress
the brake pedal firmly and bring the vehicle to an
immediate stop.
 The brake system warning light remains on together
with the “ABS” warning light.
In this case, not only the antilock brake system will
fail but also the vehicle will become extremely
unstable during braking.
GS430 only—Any of the following conditions may occur,
but do not indicate the malfunction:
The light may stay on for about 60 seconds after the engine
is started. It is normal if it turns off after a while.
 Depressing the brake pedal repeatedly may turn on the
warning light and buzzer. It is normal if the light turns off and
the buzzer stops sounding after a few seconds.
You may hear a small sound in the engine compartment
after the engine is started or the brake pedal is depressed
repeatedly. This is a pump pulsating sound of the brake
system, and it is not a malfunction.
(b) Brake System Warning Light (yellow)
The light comes on when the engine switch is selected in
“IG−ON” mode.
GS430—If the engine is started, and the traction control
system, vehicle stability control system and hill −start assist
control system work properly, the light turns off after a few
seconds. Thereafter, if any part of the system malfunctions,
the light comes on again.
GS300—If the engine switch is selected in “IG −ON” mode, and
the traction control system, vehicle stability control system and
hill −start assist control system work properly, the light turns off
after a few seconds. Thereafter, if any part of the system
malfunctions, the light comes on again.
Although it is no problem to continue driving, have your vehicle
checked by your Lexus dealer as soon as possible.
(c) Driver’s Seat Belt Reminder Light and Buzzer
The light and buzzer act as a reminder to have the driver buckle
up the seat belt.

GAUGES, METERS AND SERVICE REMINDER INDICATORS
78Once the engine switch is selected in “IG
−ON” mode, the
reminder light flashes and buzzer sounds if the driver’s seat
belt is not fastened. Unless the driver fastens the belt, the light
continues flashing and the buzzer stops after about 4 to 8
seconds.
If the vehicle speed exceeds about 15 km/h (10 mph) with the
driver’s seat belt reminder light flashing, beeps sound
intermittently for about 20 seconds.
(d) Front Passenger’s Seat Belt Reminder Light
The light acts as a reminder to have the front passenger buckle
up the seat belt.
Once the engine switch is selected in “IG −ON” mode, the
reminder light flashes if a passenger sits in the front passenger
seat and does not fasten the seat belt. Unless the front
passenger fastens the belt, the light continues flashing.
However, if a front passenger uses an additional seat cushion,
the indicator light may not flash even when the seat belt is not
buckled up.
If luggage or other load is placed on the front passenger seat,
depending on its weight and how it is placed on the seat,
built−in sensors in the seat cushion may detect the pressure,
causing the reminder light to flash.
(e) SRS Warning Light
The indicator comes on when the engine switch is
selected in “IGON” mode. It goes off after about 6
seconds. This means the SRS airbags and seat belt
pretensioners are operating properly.
This warning light system monitors the airbag sensor
assembly, front airbag sensors, side and curtain shield airbag
sensor assemblies, curtain shield airbag sensor assemblies,
driver’s seat position sensor, driver’s seat belt buckle switch,
occupant detection sensor, front passenger’s seat belt buckle
switch, seat belt pretensioner assemblies, inflators, warning
light, interconnecting wiring and power sources.
If any of the following conditions occurs, this indicates a
malfunction of the airbags or seat belt pretensioners. Contact
your Lexus dealer as soon as possible to service the vehicle.
 When the engine switch is selected in “IG−ON” mode, the
light does not come on or remains on for more than 6
seconds.
 The light comes on while driving.
If the light stays on, it indicates that the SRS driver and front
passenger airba gs, SRS side and curtain shield airbags and/or
seat belt pretensioners have a problem.

GAUGES, METERS AND SERVICE REMINDER INDICATORS
79
(f) Charging System Warning Light
This warning light comes on when the engine switch is
selected in “IG−ON” mode, and goes off when the engine is
started.
When there are problems in the charging system while the
engine is running, the warning light comes on.
NOTICE
When the charging system warning light comes on
while the engine is running, malfunctions such as the
engine drive belt being broken may have occurred. If
the warning light comes on, immediately stop the
vehicle in a safe place and contact your Lexus dealer.
(g) Malfunction Indicator Lamp
This lamp comes on when the engine switch is selected in
“IGON” mode and goes off after the engine starts. This
means that the warning light system is operating properly.
If the lamp remains on, or the lamp comes on while
driving, first check the followings:
 Empty fuel tank
If the fuel tank is empty, refuel immediately.
 Loose fuel tank cap
If the fuel tank cap is loose, securely tighten it.
These cases are temporary malfunctions. The malfunction
indicator lamp will go off after taking several driving trips.
If the lamp does not go off even after several trips, contact your
Lexus dealer as soon as possible.
If the fuel tank is not empty or the fuel tank cap is not
loose...
 There is a problem somewhere in the engine, emission
control system, electronic throttle control system, automatic
transmission electrical system or warning light system itself.
Contact your Lexus dealer as soon as possible to service the
vehicle.
If this lamp comes on and engine speed does not increase
when the accelerator pedal is depressed, there may be a
problem somewhere in the electronic throttle control system.

GAUGES, METERS AND SERVICE REMINDER INDICATORS
80At this time, vibration may occur. However, if you depress the
accelerator pedal more firmly and slowly, you can drive your
vehicle at low speeds. Have your vehicle checked by your
Lexus dealer as soon as possible.
Even if the abnormality of the electronic throttle control system
is corrected during low speed driving, the system may not be
recovered until the engine is stopped and the engine switch is
selected in “ACC” or “OFF” mode.
Emissions inspection and maintenance (I/M) programs
Your vehicle may not pass a state emission inspection if the
malfunction indicator lamp remains on. Contact your Lexus
dealer to check your vehicle’s emission control system and
OBD (On
−Board Diagnostics) system before taking your
vehicle for the inspection.
For details, see “Emissions inspection and maintenance (I/M)
programs” on page 505.
(h) Master Warning Light
If any system malfunctions, this warning light comes on or
flashes together with a warning tone, and a warning message
appears on the multi−information display. When the cause of
the problem is eliminated, the warning tone and message on
the display will turn off.
(i) ”ABS” Warning Light
The light comes on when the engine switch is selected in
“IG−ON” mode.
GS430—If the anti−lock brake system and the brake assist
system work properly, the light turns of f in a few seconds after
the engine is started. Thereafter, if either system malfunctions,
the light comes on again.
GS300—If the anti−lock brake system and the brake assist
system work properly, the light turns of f in a few seconds after
the engine switch is selected in “IG−ON” mode. Thereafter, if
either system malfunctions, the light comes on again.
When the “ABS” warning light is on, the anti− lock brake system
and the brake assist system do not operate, but the brake
system still operates conventionally.
If any of the following conditions occur, this indicates a
malfunction somewhere in the components monitored by
the warning light system. Contact your Lexus dealer as
soon as possible to service the vehicle.
 The light does not come on when the engine switch is
selected in “IG −ON” mode.
 The light remains on after the engine is started (GS430), or
remains on after the engine switch is selected in “IG −ON”
mode (GS300).
 The light comes on while you are driving.
A warning light turning on briefly during operation does not
indicate a problem.
