2006 KIA AMANTI jump start

417
1
2
3
4
5
6
7
8
910
Driving your vehicle
✽ ✽NOTICEWhen you jump start your vehicle
because of a drained battery, the
engine may not run as smoothly and
the ABS warning light may turn on
at the same time. This happens
because of the low battery voltage. It
does not mean your ABS is malfunc-
tioning.
• Do not pump your brakes!
• Have the battery recharged before
driving the vehicle.

59
Driving tips
 Driving too fast through large pud-dles can affect your brakes. If you
must go through puddles, try to
drive through them slowly.
 If you believe you may have gotten your brakes wet, apply them lightly
while driving until normal braking
operation returns.
Winter driving We recommend that you carryemergency equipment, including
tire chains, a window scraper,
windshield de-icer, a bag of sand
or salt, flares, a small shovel and
jumper cables.
 Make sure you have sufficient eth- ylene-glycol coolant in the radiator.
 Check the battery condition and cables. Cold temperatures reduce
the capacity of any battery, so it
must be in excellent condition to
provide enough winter starting
power.
 Make sure the engine oil viscosity is suitable for cold weather.
 Check the ignition system for loose connections and damage.  Use antifreeze-formulated wind-
shield washer fluid. (Do not use
engine coolant antifreeze.)
 Do not use the parking brake if it might freeze. When parking, shift
to P (Park) with an automatic
transaxle and block the rear
wheels.
1
2
3
4
5
6
7
8
910

In case of an emergency46EMERGENCY STARTING Jump starting Jump starting can be dangerous if
done incorrectly. Therefore, to avoid
harm to yourself or damage to your
vehicle or battery, follow the jump
starting procedures listed on page
6-6. If in doubt, we strongly recom-
mend that you have a competent
technician or towing service jump
start your vehicle.
✽ ✽NOTICEUse only a 12-volt jumper system.
You can damage a 12-volt starting
motor, ignition system, and other
electrical parts beyond repair by use
of a 24-volt power supply (either two
12-volt batteries in series or a 24-
volt motor generator set).
1
2
3
4
5
6
7
8
910
WARNING
- Battery
• Keep all flames or sparks away from the battery. The bat-
tery produces hydrogen gas
which may explode if exposed
to flame or sparks.
 Do not attempt to jump start the vehicle if the discharged
battery is frozen or if the elec-
trolyte level is low; the battery
may rupture or explode.
WARNING
- Battery
Never attempt to check the elec-
trolyte level of the battery as
this may cause the battery to
rupture or explode causing seri-
ous injury.

In case of an emergency66Jump starting procedure 1. Make sure the booster battery is12-volt and that its negative termi-
nal is grounded.
2. If the booster battery is in another vehicle, do not allow the vehicles
to touch.
3. Turn off all unnecessary electrical loads.
4. Connect the jumper cables in the exact sequence shown in the pre-
vious illustration. First connect one
end of a jumper cable to the posi-
tive terminal of the discharged bat-
tery (
➀), then connect the other
end to the positive terminal on the
booster battery (
➁). Proceed to
connect one end of the other
jumper cable to the negative ter-
minal of the booster battery (
➂),
then the other end to a solid, sta-
tionary, metallic point (for exam-
ple, the engine lifting bracket)
away from the battery (
➃). Do not
connect it to or near any part that
moves when the engine is
cranked. Do not connect the
jumper cable from the negative
terminal of the booster battery to
the negative terminal of the dis-
charged battery. Do not allow the jumper cables to
contact anything except the cor-
rect battery terminals or the cor-
rect ground. Do not lean over the
battery when making connections.
5. Start the engine of the vehicle with the booster battery and let it run at
2,000 rpm, then start the engine of
the vehicle with the discharged
battery.
If the cause of your battery discharg-ing is not apparent, you should haveyour vehicle checked by anAuthorized Kia Dealer.
Refer to illustration on page 6-5.
Push-starting Vehicles equipped with automatic
transaxle cannot be push-started.
Follow the directions in this section
for jump-starting.
1
2
3
4
5
6
7
8
910
CAUTION
Never tow a vehicle to start itbecause the sudden surge for-ward when the engine startscould cause a collision with thetow vehicle.

10 5
Index
Hazard Warning Flasher . . . . . . . . . . . . . . . . . . . 4-53,6-2
Hazardous Driving conditions . . . . . . . . . . . . . . . . . . . 5-7
HeadlightHigh Beam Indicator . . . . . . . . . . . . . . . . . . . . . . . 4-40
Replacement . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-44
Headrest adjustment Driver’s seat . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-24
Front passenger seat . . . . . . . . . . . . . . . . . . . . . . . . 3-28
Rear seat . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-32
HLA (Hydraulic Lash Adjustment) Noise . . . . . . . . . 5-12
Homelink® Wireless Control System . . . . . . . . . . . . 5-23
Hood . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
. 3-88
Horn . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
. 4-20
How To Use This Manual . . . . . . . . . . . . . . . . . . . . . . 1-2
If You Have a Flat Tire . . . . . . . . . . . . . . . . . . . . . . 6-20
Ignition Switch . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-2 And Anti-Theft Steering Column Lock . . . . . . . . . . 4-2
Illumination, Instrument Panel . . . . . . . . . . . . . . . . . 4-35
Immobilizer system . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-7
Indicators, Warnings and . . . . . . . . . . . . . . . . . . . . . . 4-36
Infants and Small Children, Restraint of . . . . . . . . . . 3-48
Inflation Pressures (Tire) . . . . . . . . . . . . . . . . . . . . . . 7-37
Inspections, Necessary . . . . . . . . . . . . . . . . . . . . . . . . 5-5
Installation of a mobile two-way radio system . . . . . . 9-4 Instrument
Cluster . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-32, 4-33
Panel Vents . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-62
Panel Illumination . . . . . . . . . . . . . . . . . . . . . . . . . 4-35
Panel Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-5
Interior Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-4
Care . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
7-57
Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-102
General Precautions . . . . . . . . . . . . . . . . . . . . . . . . 7-57
Lights . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-97
Trim, Cleaning the Upholstery and . . . . . . . . . . . . 7-57
Window Glass, Cleaning the . . . . . . . . . . . . . . . . . 7-57
Intermittent Wipers, Variable . . . . . . . . . . . . . . . . . . . 4-50
Jacking Instructions . . . . . . . . . . . . . . . . . . . . . . . . . 6-20
Jump Starting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-4
Keyless Entry, remote . . . . . . . . . . . . . . . . . . . . . . . . . 3-4
Key Reminder Warning Chime . . . . . . . . . . . . . . . . . 4-43
Keys . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
. . 3-2
Knowing Your Vehicle . . . . . . . . . . . . . . . . . . . . . . . . 3-1
1
2
3
4
5
6
7
8
910
HI
JK

Index8
10Roadside Assistance, Emergency . . . . . . . . . . . . . . . . 9-2
Road Warning . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-2
Rocking the Vehicle . . . . . . . . . . . . . . . . . . . . . . . . . . 5-7
Rotation, Tire . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-38
Safety Belt . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-36
Into the auto lock mode . . . . . . . . . . . . . . . . . . . . . 3-53
Restraint System . . . . . . . . . . . . . . . . . . . . . . . . . . 3-39
System, Proper Use and Care of . . . . . . . . . . . . . . . 3-47
Warning Light and Chime . . . . . . . . . . . . . . . . . . . 3-42
Into the Auto Lock mode, placing a passenger . . . . 3-53
Safety Chains . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-16
Schedule 1- Normal Maintenance . . . . . . . . . . . . . . . . 7-5
Schedule 2- Service Maintenance . . . . . . . . . . . . . . . . 7-8
Scheduled Maintenance Service . . . . . . . . . . . . . . . . . 7-4
Seat . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
. . 3-18 Adjustment, Driver’s . . . . . . . . . . . . . . . . . . . . . . . 3-20
Adjusting the front passenger seat . . . . . . . . . . . . . 3-25
Rear . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
3-30
Severe maintenance schedule . . . . . . . . . . . . . . . . . . . 7-8
Snow Tires . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-10
Spare Tire Removing the . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-20
Special Driving Conditions . . . . . . . . . . . . . . . . . . . . . 5-7
Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-2 Lubricant . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-51
Speedometer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-34 Starting
Emergency . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-4
Jump . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
6-4
The Engine . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-4
Steering Column Lock, Ignition Switch and Anti-Theft . . . . . 4-2
Power . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-18, 7-24
Wheel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-18, 7-25
Tilt . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
. 4-19
Storage Compartment . . . . . . . . . . . . . . . . . . . . . . . . 3-99
Suggestions for Economical Operation . . . . . . . . . . . . 5-6
Sunglass Holder . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-101
Sunroof . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-108
Sunvisor . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-104
Switch, Ignition . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-2
Tachometer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-34
Temperature Control Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-56
Gauge, Engine . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-35
Tie-down Hook . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-16
Tilt Steering . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-19
Tips On Driving Your Vehicle . . . . . . . . . . . . . . . . . . . . . 5-4
For Towing a Stuck Vehicle . . . . . . . . . . . . . . . . . . 6-19
Tire Balance, Wheel Alignment and . . . . . . . . . . . . . . . 7-39
Care . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
7-37
Chains . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-10
1
2
3
4
5
6
7
8
910
S
T
