2006 INFINITI QX56 warning

PRECAUTIONSGW-3
C
DE
F
G H
J
K L
M A
B
GW
Revision: November 2009 2006 QX56
PRECAUTIONSPFP:00001
Precautions for Supplemental Restraint System (SRS) “AIR BAG” and “SEAT
BELT PRE-TENSIONER”
EIS004TI
The Supplemental Restraint System such as “AIR BAG” and “SEAT BELT PRE-TENSIONER ”, used along
with a front seat belt, helps to reduce the risk or severity of injury to the driver and front passenger for certain
types of collision. This system includes seat belt switch inputs and dual stage front air bag modules. The SRS
system uses the seat belt switches to determine the front air bag deployment, and may only deploy one front
air bag, depending on the severity of a collision and whether the front occupants are belted or unbelted.
Information necessary to service the system safely is included in the SRS and SB section of this Service Man-
ual.
WARNING:

To avoid rendering the SRS inoperative, which could increase the risk of personal injury or death
in the event of a collision which would result in air bag inflation, all maintenance must be per-
formed by an authorized NISSAN/INFINITI dealer.

Improper maintenance, including incorrect removal and installation of the SRS, can lead to per-
sonal injury caused by unintentional activation of the system. For removal of Spiral Cable and Air
Bag Module, see the SRS section.

Do not use electrical test equipment on any circuit related to the SRS unless instructed to in this
Service Manual. SRS wiring harnesses can be identified by yellow and/or orange harnesses or
harness connectors.
Handling for Adhesive and PrimerEIS004TJ

Do not use an adhesive which is past its usable date. Shelf life of this product is limited to six months after
the date of manufacture. Carefully adhere to the expiration or manufacture date printed on the box.

Keep primers and adhesive in a cool, dry place. Ideally, they should be stored in a refrigerator.

Open the seal of the primer and adhesive just before application. Discard the remainder.

Before application, be sure to shake the primer container to stir the contents. If any floating material is
found, do not use it.

If any primer or adhesive contacts the skin, wipe it off with gasoline or equivalent and wash the skin with
soap.

When using primer and adhesive, always observe the precautions in the instruction manual.

WINDSHIELD GLASSGW-11
C
DE
F
G H
J
K L
M A
B
GW
Revision: November 2009 2006 QX56
WINDSHIELD GLASSPFP:72712
Removal and InstallationEIS004TQ
REMOVAL
1. Remove inside mirror. Refer to GW-73, "Removal and Installation" .
2. Partially remove the headlining (front edge). Refer to EI-38, "
HEADLINING" .
3. Remove cowl top cover. Refer to EI-18, "
Removal and Installation" .
4. Apply a protective tape around the windshield glass to protect the painted surface from damage.

Remove glass using piano wire or power cutting tool and an inflatable pump bag.

If the windshield glass is to be reused, mark the body and the glass with mating marks.
WARNING:
When cutting the glass from the vehicle, always wear safety glasses and heavy gloves to help prevent
glass splinters from entering your eyes or cutting your hands.
CAUTION:

When the windshield glass is to be reused, do not use a cutting knife or power cutting tool.

Be careful not to scratch the glass when removing.

Do not set or stand glass on its edge. Small chips may develop into cracks.
INSTALLATION

Use a genuine NISSAN Urethane Adhesive Kit (if available) or equivalent and follow the instructions fur-
nished with it.

While the urethane adhesive is curing, open a door window. This will prevent the glass from being forced
out by passenger compartment air pressure when a door is closed.

The molding must be installed securely so that it is in position and leaves no gap.
LIIA0652E
PIIA0186E

GW-12
WINDSHIELD GLASS
Revision: November 20092006 QX56

Inform the customer that the vehicle should remain stationary until the urethane adhesive has completely
cured (preferably 24 hours). Curing time varies with temperature and humidity.

Install parts removed.
WARNING:

Keep heat and open flames away as primers and adhesive are flammable.

The materials contained in the kit are harmful if swallowed, and may irritate skin and eyes. Avoid
contact with the skin and eyes.

Use in an open, well ventilated location. Avoid breathing the vapors. They can be harmful if
inhaled. If affected by vapor inhalation, immediately move to an area with fresh air.

Driving the vehicle before the urethane adhesive has completely cured may affect the perfor-
mance of the windshield in case of an accident.
CAUTION:

Do not use an adhesive which is past its usable term. Shelf life of this product is limited to six
months after the date of manufacture. Carefully adhere to the expiration or manufacture date
printed on the box.

Keep primers and adhesive in a cool, dry place. Ideally, they should be stored in a refrigerator.

Do not leave primers or adhesive cartridge unattended with their caps open or off.

The vehicle should not be driven for at least 24 hours or until the urethane adhesive has com-
pletely cured. Curing time varies depending on temperature and humidity. The curing time will
increase under lower temperature and lower humidity.
Repairing Water Leaks for Windshield
Leaks can be repaired without removing and reinstalling glass.
If water is leaking between the urethane adhesive material and body or glass, determine the extent of leakage.
This can be done by applying water to the windshield area while pushing glass outward.
To stop the leak, apply primer (if necessary) and then urethane adhesive to the leak point.
LIIA1115E

IDX-5
A
C
D E
F
G H
I
J
K L
B
IDX
ALPHABETICAL INDEX
H
H/AIM - Wiring diagram ...................................... LT-66
H/LAMP - Wiring diagram .................................... LT-9
Handling precautions for plastics ..................... BL-187
Harness connector ............................................ PG-68
Harness layout .................................................. PG-41
Hazard warning lamp ......................................... LT-80
Headlamp ............................................................. LT-5
Headlamp aiming control ................................... LT-66
Headlamp leveler - See Headlamp aiming control . LT-
66
Headlamp removal and installation .................... LT-31
Heated oxygen sensor 2 (bank 1) .... EC-253, EC-264,
EC-277
Heated oxygen sensor 2 (bank 2) .... EC-253, EC-264,
EC-277
Heated oxygen sensor 2 heater (bank 1) ........ EC-163
Heated oxygen sensor 2 heater (bank 2) ........ EC-163
Heated seat ....................................................... SE-84
Heater and cooling unit (Heater core) . ATC-153, ATC-
156
Heater unit (heater core) ............... ATC-153, ATC-156
Height (Dimensions) ........................................... GI-50
HFC134a (R134a) system identification ........... ATC-6
HFC134a (R134a) system precaution ............... ATC-5
HFC134a (R134a) system service procedure ATC-171
HFC134a (R134a) system service tools ......... ATC-14
HFC134a system service equipment precaution ATC-
11
High and low reverse clutch solenoid valve .... AT-151,
AT-153
Homelink universal transceiver ........................ BL-156
Horn ................................................................ WW-55
HORN - Wiring diagram .................................. WW-55
How to erase DTC for OBD system .................. EC-61
HSEAT - Wiring diagram ................................... SE-86
I
IATS - Wiring diagram ..................................... EC-189
ICC - Wiring diagram ....................................... ACS-20
ICC/BS - Wiring diagram ................................. EC-504
ICC/SW - Wiring diagram ................................ EC-489
ICCBOF - Wiring diagram ............................... EC-611
Identification plate .............................................. GI-48
Idle air volume learning ..................................... EC-78
Idle speed .............................................. EC-71, EC-76
Idle speed control (ISC) .................... EC-444, EC-446
Ignition coil .......................................... EM-28, EC-618
Ignition control system .................................... EC-618
Ignition key hole illumination ............................ LT-134
Ignition timing ........................................ EC-71, EC-76
IGNSYS - Wiring diagram ............................... EC-619
ILL - Wiring diagram ......................................... LT-163
Illumination ....................................................... LT-157
In vehicle sensor ........................... ATC-137, ATC-146
In-cabin Microfilter ............................................. MA-21
INJECT - Wiring diagram ................................ EC-599
Injector ............................................................. EC-598
Input clutch solenoid valve ................. AT-139, AT-141
Instrument panel .................................................. IP-10
Intake air temperature sensor ............ EC-188, EC-208
Intake door control linkage adjustment . ATC-85, ATC-
88
Intake door motor ........................... ATC-83, ATC-160
Intake manifold .................................................. EM-17
Intake sensor ................................ ATC-142, ATC-148
Integrated homelink transmitter - See Homelink univer-
sal tranceiver .................................................... BL-156
Intelligent cruise control (ICC) system ............... ACS-6
Interior ................................................................. EI-35
Interior lamp ...................................................... LT-134
Interior lamp on-off control ................................ LT-135
Internal gear (Transfer) ....................... TF-149, TF-176
IPDM (Intelligent power distribution module engine
room) ................................................................. PG-18
IVIS (Infiniti vehicle immobilizer system) .......... BL-137
IVIS (Infiniti vehicle immobilizer system) precautions ...
GI-3
J
Jacking points ..................................................... GI-41
Junction box (J/B) .............................................. PG-76
K
Key illumination ................................................ LT-135
KEYLES - Wiring diagram .................................. BL-49
Knock sensor (KS) ........................................... EC-335
KS - Wiring diagram ........................................ EC-336
L
Laser beam aiming adjustment ....................... ACS-12
Length (Dimensions) .......................................... GI-50
License lamp .................................................... LT-111
Lifting points ....................................................... GI-42
Line pressure solenoid valve ........................... AT-122
Line pressure switch (Transfer) .......... TF-154, TF-167
Line pressure test (A/T) ..................................... AT-52
Location of electrical units ................................. PG-65
Low coast brake solenoid valve .......... AT-155, AT-157
Low tire pressure warning system ...................... WT-8
Low tire pressure warning system - trouble diagnoses
WT-11
Low tire pressure warning system - Wiring diagram .....
WT-11
Lubricant (R134a) A/C ..................................... ATC-22
Lubricants .......................................................... MA-11
Lubrication circuit (engine) .................................. LU-5
Lubrication oil A/C ........................................... ATC-22
Lubrication-locks, hinges and hood latches ....... MA-31
M
MAFS - Wiring diagram ..................... EC-174
, EC-182

IDX-7
A
C
D E
F
G H
I
J
K L
B
IDX
ALPHABETICAL INDEX
Rear combination lamp removal and installation ... LT-
125
Rear cover packing replacement diff. ..............
RFD-28
Rear door ........................................... BL-128, GW-68
Rear seat belt ...................................................... SB-6
Rear suspension ............................................. RSU-26
Rear view monitor ............................................... DI-73
Rear washer .................................................... WW-32
Rear window defogger ..................................... GW-74
Rear wiper ....................................................... WW-32
Refrigerant connection precaution .................... ATC-7
Refrigerant discharging evacuating charging ATC-171
Refrigerant general precaution .......................... ATC-6
Refrigerant lines ........... ATC-171, ATC-179, ATC-180
Refrigerant pressure sensor ............ EC-630, ATC-182
Relay box .......................................................... PG-78
Remote keyless entry system ............................ BL-44
Removal and installation (A/T) ........... AT-243, AT-246
Removal and installation (Transfer) ................. TF-145
Ring gear diff. inspection ................................. RFD-18
Road wheel size ................................................. GI-50
Rocker cover ..................................................... EM-35
Room lamp ....................................................... LT-134
Room lamp - See Interior lamp ........................ LT-134
ROOM/L - Wiring diagram ................................ LT-140
RP/SEN - Wiring diagram ............................... EC-631
S
SAE J1979 - Service $01 - 09 ........................... EC-48
SEAT - Wiring diagram ..................................... SE-83
Seat belt inspection ............................... SB-11, MA-32
Seat belt pre-tensioner .................................... SRS-57
Seat belt, front ..................................................... SB-3
Seat belt, rear ...................................................... SB-6
Seat, front .......................................................... SE-91
Self-diagnosis (Transfer) .................................... TF-50
SEN/PW - Wiring diagram ............................... EC-461
SHIFT - Wiring diagram ................................... AT-222
Shift control (Transfer) ....................... TF-149, TF-176
Shift lock system .............................................. AT-221
Shock absorber (front) .................................... FSU-11
Shock absorber (rear) ..................................... RSU-35
Side air bag (satellite) sensor .......................... SRS-56
Side curtain air bag ......................................... SRS-53
Side trim .............................................................. EI-35
SMJ (super multiple junction) ............................ PG-74
SONAR - Wiring diagram .................................... DI-63
Spare tire size .................................................... GI-50
Spark plug ......................................................... EM-29
Spark plug replacement .................................... MA-18
Specification value .......................................... EC-134
Speedometer ......................................................... DI-5
Spiral cable ..................................................... SRS-48
SROOF - Wiring diagram .................................. RF-13
SRS - See Supplemental Restraint System ...... SRS-5
SRS - Wiring diagram ..................................... SRS-12
SRS Trouble diagnoses .................................... SRS-8
Stabilizer bar (front) ......................................... FSU-12
Stabilizer bar (rear) ......................................... RSU-42
Stall test (A/T) .................................................... AT-51
Standardized relay ............................................. PG-72
START - Wiring diagram ................................... SC-11
Starting system .................................................. SC-10
Steering gear, linkage and transfer gear inspection .....
MA-29
Steering linkage ................................................. PS-15
Steering wheel and column ................................. PS-7
Step lamp ......................................................... LT-135
Stop lamp ......................................................... LT-106
Stop lamp switch ................. EC-511, EC-523, EC-586
STOP/L - Wiring diagram ................................. LT-107
Strut (front) ...................................................... FSU-10
STSIG - Wiring diagram .................................. AT-101
Sub-oil pump (Transfer) ...................... TF-154, TF-167
Sun gear (Transfer) ............................ TF-149, TF-176
Sun roof, electric ................................................ RF-10
Sunload sensor .............................................. ATC-140
Sunroof .............................................................. RF-24
Supplemental Restraint System ........................ SRS-5
Supplemental restraint system - Wiring diagram . SRS-
12
Symbols and abbreviations ..................... GI-10, GI-23
Symptom matrix chart ........................................ EC-92
System readiness test (SRT) code .................... EC-54
T
Tachometer .......................................................... DI-5
Tail lamp ........................................................... LT-111
TAIL/L - Wiring diagram .................................... LT-113
TCM circuit diagram .......................................... AT-50
TCM inspection table ......................................... AT-83
TCS - Wiring diagram ..................................... BRC-16
TCS (traction control system) ........................... BRC-7
TCS component parts and connector location BRC-14
TCS wheel sensors ........................................ BRC-14
Telephone .......................................................... AV-64
Theft warning system - See Vehicle security (Theft warn-
ing) system ......................................................... BL-75
Thermometer ...................................................... DI-26
Three way catalyst ............................................. EM-21
Three way catalyst function (Bank 1) .............. EC-354
Three way catalyst function (Bank 2) .............. EC-354
Three way catalyst precautions ............................ GI-5
Throttle control motor ...................................... EC-540
Throttle control motor relay .............................. EC-528
Throttle position sensor (TPS) ... EC-198, EC-320, EC-
483, EC-485, EC-560
Throttle valve closed position learning .............. EC-78
Tie-rod ............................................................... PS-15
Timing chain ...................................................... EM-37
Tire rotation ....................................................... MA-28
Tire size .............................................................. GI-50
Torque converter installation AT-244, AT-245, AT-248,
AT-249
Torque convertor clutch solenoid valve .... AT-118, AT-
120

IDX-8
ALPHABETICAL INDEX
Tow truck towing ................................................. GI-43
Towing point ....................................................... GI-44
TPS1 - Wiring diagram .................................... EC-322
TPS2 - Wiring diagram .................................... EC-200
TPS3 - Wiring diagram .................................... EC-562
Traction control system - Wiring diagram ....... BRC-16
Transfer control device ............. TF-76, TF-80, TF-138
Transfer control unit inspection table ................. TF-35
Transfer dropping resistor .................................. TF-90
Transfer fluid temperature sensor TF-104, TF-154, TF-
167
Transfer motor .................................... TF-102, TF-142
Transfer motor relay ........................................ TF-102
Transfer oil replacement ................................... MA-24
Transfer serial number ........................................ GI-49
Transmission serial number ................................ GI-49
Tread-FR&RR (Dimensions) ............................... GI-50
Trim ..................................................................... EI-35
TRNSCV - Wiring diagram .................. BL-140, BL-156
Trouble diagnoses .............................................. GI-10
Turbine revolution sensor ................................ AT-109
TURN - Wiring diagram ...................................... LT-84
Turn signal lamp ................................................. LT-80
Two trip detection logic ...................................... EC-48
Two-pole lift ........................................................ GI-42
V
Vacuum hose (brake system) ............................ BR-20
Vacuum hose drawing (Engine control) ........... EC-102
Valve clearance ................................................ EM-55
Valve guide ....................................................... EM-69
Vanity mirror lamp ............................................. LT-134
VDC (vehicle dynamics control) ........................ BRC-7
VDC -Wiring diagram ...................................... BRC-16
Vehicle identification number .............................. GI-48
Vehicle recovery (freeing a stuck vehicle) .......... GI-44
Vehicle security (theft warning) system ............. BL-75
Vehicle speed sensor (VSS) ............................ EC-442
VEHSEC - Wiring diagram ................................. BL-79
VENT/V - Wiring diagram .................. EC-390, EC-397
VIN registration .................................................. EC-77
Viscosity number (SAE) .................................... MA-12
VSS A/T - Wiring diagram .................. AT-111, AT-113
W
W/ANT - Wiring diagram .................................... AV-61
Wait detection switch ......................................... TF-69
WARN - Wiring diagram ..................................... DI-32
Warning chime .................................................... DI-43
Warning lamps .................................................... DI-31
Washer, front ..................................................... WW-4
Washer, rear .................................................... WW-32
Water pump ...................................................... CO-19
Water temperature gauge ..................................... DI-5
Wheel alignment (front) ..................................... FSU-6
Wheel alignment (rear) ................................... RSU-28
Wheel bearing (front) ......................................... FAX-5
Wheel bearing (rear) ......................................... RAX-5
Wheel hub (rear) ............................................... RAX-5
Wheel size .......................................................... GI-50
Wheelbase (Dimensions) .................................... GI-50
Width (Dimensions) ............................................. GI-50
WINDOW - Wiring diagram .............................. GW-22
Window, door ...................................... GW-65, GW-68
Windshield ....................................................... GW-11
WIP/R - Wiring diagram ................................... WW-36
WIPER - Wiring diagram .................................... WW-8
Wiper, front ........................................................ WW-4
Wiper, rear ....................................................... WW-32
Wiring Diagram (Cell code) list ......................... PG-62
Wiring diagrams .................................................. GI-16
WT-T/WARN - Wiring diagram .......................... WT-11

IP-2
PRECAUTIONS
Revision: November 20092006 QX56
PRECAUTIONSPFP:00001
Precautions for Supplemental Restraint System (SRS) “AIR BAG” and “SEAT
BELT PRE-TENSIONER”
EIS004WW
The Supplemental Restraint System such as “AIR BAG” and “SEAT BELT PRE-TENSIONER ”, used along
with a front seat belt, helps to reduce the risk or severity of injury to the driver and front passenger for certain
types of collision. This system includes seat belt switch inputs and dual stage front air bag modules. The SRS
system uses the seat belt switches to determine the front air bag deployment, and may only deploy one front
air bag, depending on the severity of a collision and whether the front occupants are belted or unbelted.
Information necessary to service the system safely is included in the SRS and SB section of this Service Man-
ual.
WARNING:

To avoid rendering the SRS inoperative, which could increase the risk of personal injury or death
in the event of a collision which would result in air bag inflation, all maintenance must be per-
formed by an authorized NISSAN/INFINITI dealer.

Improper maintenance, including incorrect removal and installation of the SRS, can lead to per-
sonal injury caused by unintentional activation of the system. For removal of Spiral Cable and Air
Bag Module, see the SRS section.

Do not use electrical test equipment on any circuit related to the SRS unless instructed to in this
Service Manual. SRS wiring harnesses can be identified by yellow and/or orange harnesses or
harness connectors.

PRECAUTIONSLAN-3
[CAN]
C
DE
F
G H
I
J
L
M A
B
LAN
Revision: November 2009 2006 QX56
PRECAUTIONSPFP:00001
Precautions for Supplemental Restraint System (SRS) “AIR BAG” and “SEAT
BELT PRE-TENSIONER”
UKS0017I
The Supplemental Restraint System such as “AIR BAG” and “SEAT BELT PRE-TENSIONER ”, used along
with a front seat belt, helps to reduce the risk or severity of injury to the driver and front passenger for certain
types of collision. This system includes seat belt switch inputs and dual stage front air bag modules. The SRS
system uses the seat belt switches to determine the front air bag deployment, and may only deploy one front
air bag, depending on the severity of a collision and whether the front occupants are belted or unbelted.
Information necessary to service the system safely is included in the SRS and SB section of this Service Man-
ual.
WARNING:

To avoid rendering the SRS inoperative, which could increase the risk of personal injury or death
in the event of a collision which would result in air bag inflation, all maintenance must be per-
formed by an authorized NISSAN/INFINITI dealer.

Improper maintenance, including incorrect removal and installation of the SRS, can lead to per-
sonal injury caused by unintentional activation of the system. For removal of Spiral Cable and Air
Bag Module, see the SRS section.

Do not use electrical test equipment on any circuit related to the SRS unless instructed to in this
Service Manual. SRS wiring harnesses can be identified by yellow and/or orange harnesses or
harness connectors.
Precautions When Using CONSULT-IIUKS0017J
When connecting CONSULT-II to data link connector, connect them through CONSULT-II CONVERTER.
CAUTION:
If CONSULT-II is used with no connection of CONSULT-II CONVERTER, malfunctions might be
detected in self-diagnosis depending on control unit which carry out CAN communication.
CHECK POINTS FOR USING CONSULT-II
1. Has CONSULT-II been used without connecting CONSULT-II CONVERTER on this vehicle?
–If YES, GO TO 2.
–If NO, GO TO 5.
2. Is there any indication other than indications relating to CAN communication system in the self-diagnosis results?
–If YES, GO TO 3.
–If NO, GO TO 4.
3. Based on self-diagnosis results unrelated to CAN communication, carry out the inspection.
4. Malfunctions may be detected in self-diagnosis depending on control units carrying out CAN communica- tion. Therefore, erase the self-diagnosis results.
5. Diagnose CAN communication system. Refer to LAN-5, "
TROUBLE DIAGNOSES WORK FLOW" .
Precautions For Trouble DiagnosisUKS0017K
CAN SYSTEM

Do not apply voltage of 7.0 V or higher to the measurement terminals.

Use the tester with its open terminal voltage being 7.0 V or less.

Be sure to turn ignition switch OFF and disconnect the battery cable from the negative terminal before
checking the circuit.
