2006 INFINITI QX56 steering

LAN-116
[CAN]
CAN SYSTEM (TYPE 4)
Revision: November 20092006 QX56
Case 15
Check steering angle sensor circuit. Refer to LAN-133, "Steering Angle Sensor Circuit Inspection" .
PKIC3554E
PKIC3049E

TROUBLE DIAGNOSIS FOR SYSTEMLAN-133
[CAN]
C
DE
F
G H
I
J
L
M A
B
LAN
Revision: November 2009 2006 QX56
2. CHECK HARNESS FOR OPEN CIRCUIT
Check resistance between data link connector terminals.
OK or NG
OK >> Diagnose again. Refer to LAN-5, "TROUBLE DIAG-
NOSES WORK FLOW" .
NG >> Repair harness between data link connector and combi-
nation meter.
Steering Angle Sensor Circuit InspectionUKS004TQ
1. CHECK CONNECTOR
1. Turn ignition switch OFF.
2. Disconnect the battery cable from the negative terminal.
3. Check terminals and connector of steering angle sensor for damage, bend and loose connection (sensor side and harness side).
OK or NG
OK >> GO TO 2.
NG >> Repair terminal or connector.
2. CHECK HARNESS FOR OPEN CIRCUIT
1. Disconnect steering angle sensor connector.
2. Check resistance between steering angle sensor harness con- nector terminals.
OK or NG
OK >> Replace steering angle sensor.
NG >> Repair harness between steering angle sensor and data link connector.
Front Air Control Circuit InspectionUKS004TR
1. CHECK CONNECTOR
1. Turn ignition switch OFF.
2. Disconnect the battery cable from the negative terminal.
3. Check terminals and connector of front air control for damage, bend and loose connection (unit side and harness side).
OK or NG
OK >> GO TO 2.
NG >> Repair terminal or connector.
Data link
connector TerminalResistance
(Approx.)
M22 614 54 – 66 Ω
PKIA9865E
Steering angle
sensor connector TerminalResistance
(Approx.)
M47 3454 – 66 Ω
PKIA6838E

LT-98
LIGHTING AND TURN SIGNAL SWITCH
Revision: November 20092006 QX56
LIGHTING AND TURN SIGNAL SWITCHPFP:25540
Removal and InstallationEKS00BA5
REMOVAL
1. Remove steering column cover.
2. While pressing tabs, pull lighting and turn signal switch toward
driver door and disconnect from the base.
INSTALLATION
Installation is in the reverse order of removal.
LKIA0013E

LT-126
TRAILER TOW
Revision: November 20092006 QX56
TRAILER TOWPFP:93020
Component Parts and Harness Connector LocationEKS00BB1
System DescriptionEKS00BB2
Power is supplied at all times

to ignition relay, located in the IPDM E/R (intelligent power distribution module engine room), and

through 50A fusible link (letter f , located in the fuse and fusible link box)

to BCM (body control module) terminal 70, and

through 10A fuse (No. 32, located in the IPDM E/R)
1. Fuse and fusible link box2. IPDM E/R fuse layout 3. Fuse and relay box
4. IPDM E/R E118, E119, E120, E121, E122, E123, E124 5. A. Steering column
B. Data link connector M22
C. BCM M18, M19, M20
(View with instrument lower panel
LH removed) 6. A. Trailer turn relay LH E156
B. Battery
C. Trailer tow relay 2 E140
D. Trailer turn relay RH E157
7. A. Trailer tow relay 1 M51 B. Electric brake (pre-wiring) M76
(View with instrument lower panel
LH removed) 8. Trailer connector C2
9. Combination switch (lighting switch)
M28
WKIA4616E

MA-1
MAINTENANCE
L MAINTENANCE
CONTENTS
C
DE
F
G H
I
J
K
M
SECTION
A
B
MA
Revision: November 2009 2006 QX56
PRECAUTIONS .....................................................
..... 3
Precautions for Supplemental Restraint System
(SRS) “AIR BAG” and “SEAT BELT PRE-TEN-
SIONER” ............................................................. ..... 3
PREPARATION ...................................................... ..... 4
Special Service Tools .......................................... ..... 4
Commercial Service Tool .................................... ..... 4
GENERAL MAINTENANCE .................................. ..... 5
General Maintenance .......................................... ..... 5
PERIODIC MAINTENANCE .................................. ..... 7
Introduction of Periodic Maintenance .................. ..... 7
Maintenance For Off-road Driving (4WD only) .... ..... 7
Schedule 1 .......................................................... ..... 7
EMISSION CONTROL SYSTEM MAINTE-
NANCE ............................................................. ..... 7
CHASSIS AND BODY MAINTENANCE .......... ..... 8
Schedule 2 .......................................................... ..... 9
EMISSION CONTROL SYSTEM MAINTE-
NANCE ............................................................. ..... 9
CHASSIS AND BODY MAINTENANCE .......... ... 10
RECOMMENDED FLUIDS AND LUBRICANTS ... ....11
Fluids and Lubricants .......................................... .... 11
SAE Viscosity Number ........................................ ... 12
GASOLINE ENGINE OIL ................................. ... 12
ANTI-FREEZE COOLANT MIXTURE RATIO .. ... 12
ENGINE MAINTENANCE ...................................... ... 13
Checking Drive Belts ........................................... ... 13
DRIVE BELT TENSION ................................... ... 13
Changing Engine Coolant ................................... ... 13
DRAINING ENGINE COOLANT ...................... ... 13
REFILLING ENGINE COOLANT ..................... ... 14
FLUSHING COOLING SYSTEM ...................... ... 15
Checking Fuel Lines ............................................ ... 16
Changing Fuel Filter ............................................ ... 16
Changing Engine Air Cleaner Filter ..................... ... 16
VISCOUS PAPER TYPE .................................. ... 16
Changing Engine Oil ........................................... ... 17
Changing Oil Filter .............................................. ... 17
REMOVAL ........................................................ ... 17
INSTALLATION ................................................ ... 17INSPECTION AFTER INSTALLATION .............
... 18
Changing Spark Plugs ......................................... ... 18
REMOVAL ........................................................ ... 19
INSPECTION AFTER REMOVAL .................... ... 19
INSTALLATION ................................................ ... 19
Checking EVAP Vapor Lines ............................... ... 20
CHASSIS AND BODY MAINTENANCE ................ ... 21
Changing In-cabin Microfilter ............................... ... 21
Checking Exhaust System ................................... ... 22
Checking Automatic Transmission Fluid (ATF) .... ... 22
Changing Automatic Transmission Fluid (ATF) ... ... 24
Changing Transfer Fluid ...................................... ... 24
DRAINING ........................................................ ... 24
FILLING ............................................................ ... 25
Checking Transfer Fluid ...................................... ... 25
FLUID LEAKAGE AND FLUID LEVEL ............. ... 25
Checking Propeller Shaft ..................................... ... 25
Checking Final Drive Oil ...................................... ... 25
Changing Final Drive Oil ...................................... ... 26
Balancing Wheels ................................................ ... 26
REMOVAL ........................................................ ... 26
WHEEL BALANCE ADJUSTMENT .................. ... 26
Tire Rotation ........................................................ ... 28
Checking Brake Fluid Level and Leaks ............... ... 28
Checking Brake Lines and Cables ...................... ... 28
Checking Disc Brake ........................................... ... 28
ROTOR ............................................................. ... 28
CALIPER .......................................................... ... 29
PAD .................................................................. ... 29
Checking Steering Gear and Linkage .................. ... 29
STEERING GEAR ............................................... 29
STEERING LINKAGE ......................................... 29
Checking Power Steering Fluid and Lines ........... ... 29
CHECKING FLUID LEVEL ............................... ... 29
CHECKING LINES ........................................... ... 30
Checking Axle and Suspension Parts ................. ... 30
FRONT AND REAR AXLE AND SUSPENSION
PARTS .............................................................. ... 30
DRIVE SHAFT .................................................. ... 30

GENERAL MAINTENANCEMA-5
C
DE
F
G H
I
J
K
M A
B
MA
Revision: November 2009 2006 QX56
GENERAL MAINTENANCEPFP:00000
General MaintenanceELS001BI
General maintenance includes those items which should be checked during the normal day-to-day operation
of the vehicle. They are essential if the vehicle is to continue operating properly. The owner can perform these
checks and inspections or have their INFINITI dealers perform them.
OUTSIDE THE VEHICLE
The maintenance items listed here should be performed from time to time, unless otherwise specified.
INSIDE THE VEHICLE
The maintenance items listed here should be checked on a regular basis, such as when performing periodic maintenance, cleaning the
vehicle, etc. Item
Reference page
Tires Check the pressure with a gauge at least once a month and always prior to a
long distance trip. Adjust to the specified pressure if necessary. Check carefully
for damage, cuts or excessive wear. —
Wheel lug nuts When checking the tires, make sure no nuts are missing, and check for any
loose nuts. Tighten if necessary. WT-7, "
Rotation"
Windshield
Clean the windshield on a regular basis. Check the windshield at least every six
months for cracks or other damage. Repair as necessary. —
Tire rotation Tires should be rotated every 12,000 km (7,500 miles). WT-7, "
Rotation"
Wheel alignment and
balanceIf the vehicle pulls to either side while driving on a straight and level road, or if
you detect uneven or abnormal tire wear, there may be a need for wheel align-
ment. If the steering wheel or seat vibrates at normal highway speeds, wheel
balancing may be needed. WT-6, "Balancing
Wheels", FSU-6, "Front
Wheel Alignment"
Windshield wiper
blades
Check for cracks or wear if they do not wipe properly.
—
Doors and engine
hood Check that all doors and the engine hood operate smoothly as well as the back
hatch. Also make sure that all latches lock securely. Lubricate if necessary.
Make sure that the secondary latch keeps the hood from opening when the pri-
mary latch is released.
When driving in areas using road salt or other corrosive materials, check lubri-
cation frequently. MA-31, "
Lubricating
Locks, Hinges and Hood
Latches"
Lamps
Make sure that the head lamps, stop lamps, tail lamps, turn signal lamps, and
other lamps are all operating properly and installed securely. Also check head
lamp aim. Clean the head lamps on a regular basis. LT-29, "Aiming Adjust-
ment" for US, LT-46,
"Aiming Adjustment" for
Canada
Item Reference page
Warning lamps and
buzzers/chimes Make sure that all warning lamps and buzzers/chimes are operating properly.
DI-25, "
Electrical Com-
ponents Inspection"
Windshield wiper and
washerCheck that the wipers and washer operate properly and that the wipers do not
streak.
—
Windshield defroster Check that the air comes out of the defroster outlets properly and in sufficient
quantity when operating the heater or air conditioner. —
Steering wheel Check that it has the specified play. Be sure to check for changes in the steering
condition, such as excessive play, hard steering or strange noises. PS-7, "
CHECKING
STEERING WHEEL
PLAY"
Seats
Check seat position controls such as seat adjusters, seat back recliner, etc. to
make sure they operate smoothly and that all latches lock securely in every
position. Check that the head restraints move up and down smoothly and that
the locks (if equipped) hold securely in all latched positions. Check that the
latches lock securely for folding-down rear seat backs. —
Seat belts Check that all parts of the seat belt system (e.g. buckles, anchors, adjusters and
retractors) operate properly and smoothly and are installed securely. Check the
belt webbing for cuts, fraying, wear or damage. SB-11, "
Seat Belt
Inspection", MA-32,
"Checking Seat Belts,
Buckles, Retractors,
Anchors and Adjusters"
Accelerator pedal
Check the pedal for smooth operation. Keep the floor mats away from the pedal. —

MA-6
GENERAL MAINTENANCE
Revision: November 20092006 QX56
UNDER THE HOOD AND VEHICLE
The maintenance items listed here should be checked periodically (e.g. each time you check the engine oil or refuel).Brakes
Check that the brake does not pull the vehicle to one side when applied. —
Brake pedal and
booster Check the pedal for smooth operation and make sure it has the proper distance
under it when depressed fully. Check the brake booster function. Keep the floor
mats away from the pedal. ACC-5, "
ADJUSTABLE
ACCELERATOR
PEDAL",
BR-17, "On-
Vehicle Service"
Parking brake Check that the parking brake control has the proper travel and make sure that
the vehicle is held securely on a fairly steep hill when only the parking brake is
applied. PB-9, "Parking Brake
Control"
Automatic transmis-
sion “Park” mecha-
nismOn a fairly steep hill check that the vehicle is held securely with the selector
lever in the P position without applying the brakes.
—
Item
Reference page
Item Reference page
Windshield washer
fluid Check that there is adequate fluid in the tank.
—
Engine coolant level Check the coolant level when the engine is cold. —
Radiator and hoses Check the front of the radiator and clean off any dirt, insects, leaves, etc., that
may have accumulated. Make sure the hoses have no cracks, deformation,
deterioration or loose connections. —
Brake fluid level Make sure that the brake fluid level is between the “MAX ” and “ MIN” lines on the
reservoirs MA-28
Battery
Check the fluid level in each cell. It should be between the “MAX ” and “MIN ”
lines. Vehicles operated in high temperatures or under severe conditions require
frequent checks of the battery fluid level. —
Engine drive belt Make sure that no belt is frayed, worn, cracked or oily. MA-13
Engine oil levelCheck the level on the dipstick after parking the vehicle on a level spot and turn-
ing off the engine. —
Power steering fluid
level and lines Check the level on the reservoir with the engine off. Check the lines for improper
attachment, leaks, cracks, etc.
MA-29
Automatic transmis-
sion fluid levelCheck the level on the dipstick after putting the selector lever in
“P ” with the
engine idling. MA-22
Exhaust system
Make sure there are no loose supports, cracks or holes. If the sound of the
exhaust seems unusual or there is a smell of exhaust fumes, immediately locate
the trouble and correct it. MA-22
Underbody
The underbody is frequently exposed to corrosive substances such as those
used on icy roads or to control dust. It is very important to remove these sub-
stances, otherwise rust will form on the floor pan, frame, fuel lines and around
the exhaust system. At the end of winter, the underbody should be thoroughly
flushed with plain water, being careful to clean those areas where mud and dirt
can easily accumulate. —
Fluid leaks Check under the vehicle for fuel, oil, water or other fluid leaks after the vehicle
has been parked for a while. Water dripping from the air conditioner after use is
normal. If you should notice any leaks or gasoline fumes are evident, check for
the cause and correct it immediately. —

PERIODIC MAINTENANCEMA-7
C
DE
F
G H
I
J
K
M A
B
MA
Revision: November 2009 2006 QX56
PERIODIC MAINTENANCEPFP:00026
Introduction of Periodic MaintenanceELS001BJ
Two different maintenance schedules are provided, and should be used, depending upon the conditions in
which the vehicle is mainly operated. After 60,000 miles (96,000 km) or 48 months, continue the periodic
maintenance at the same mileage or time intervals, whichever comes first.
Maintenance For Off-road Driving (4WD only)ELS001BK
After driving the vehicle off-road through sand, mud, or water; more frequent maintenance may be required for
the following items:
Brake pads and rotors
Brake lines and hoses
Rear final drive oil, transmission fluid, and transfer fluid
Steering linkage
Drive shafts
Engine air cleaner filter
In-cabin microfilters
Schedule 1ELS001BL
EMISSION CONTROL SYSTEM MAINTENANCE
Abbreviations: R = Replace. I = Inspect. Correct or replace if necessary. [ ]: At the mileage intervals only
Schedule 1
Follow Periodic Maintenance Schedule 1 if your driving habits frequently includes
one or more of the following driving conditions:

Repeated short trips of less than 5 miles (8 km).

Repeated short trips of less than 10 miles (16 km) with outside temperatures
remaining below freezing.

Operating in hot weather in stop-and-go
“rush hour ” traffic.

Extensive idling and/or low speed driving for long distances, such as police,
taxi or door-to-door delivery use.

Driving in dusty conditions.

Driving on rough, muddy, or salt spread roads.

Towing a trailer or using a car-top carrier. Emission Control Sys-
tem Maintenance
MA-7
Chassis and Body
MaintenanceMA-8
Schedule 2Follow Periodic Maintenance Schedule 2 if none of the driving conditions shown
in Schedule 1 apply to the driving habits.
Emission Control Sys-
tem MaintenanceMA-7Chassis and Body
MaintenanceMA-8
MAINTENANCE OPERATION
MAINTENANCE INTERVAL
Reference
Section -
Page or -
Content Title
Perform at number of miles, kilo-
meters or months, whichever
comes first. Miles x 1,000
(km x 1,000)
Months 3.75
(6)
3 7.50
(12)
6 11 . 2 5
(18)
9 15
(24)
12 18.75
(30)
15 22.5
(36)
18 26.25
(42)
21 30
(48)
24
Drive belts NOTE (1) MA-13
Air cleaner filterNOTE (2) [R]MA-16
EVAP vapor lines I*MA-20
Fuel lines I*MA-16
Fuel filter NOTE (3) —
Engine coolant NOTE (4) MA-13
Engine oilR R R R R R R R MA-17
Engine oil filterR R R R R R R R MA-17
Spark plugs (double PLATINUM-
TIPPED type)Replace every 105,000 miles (169,000 km).
MA-18
Intake and exhaust valve clear-
ance*NOTE (5)
EM-105
