TROUBLE DIAGNOSISTF-47
CE F
G H
I
J
K L
M A
B
TF
Revision: November 2009 2006 QX56
How to Erase Self-diagnostic Results
1. Perform applicable inspection of malfunctioning item and then repair or replace.
2. Start engine and select “SELF-DIAG RESULTS” mode for “ALL MODE AWD/4WD ” with CONSULT-II.
3. Touch “ERASE” on CONSULT-II screen to erase DTC memory.
CAUTION:
If memory cannot be erased, perform applicable diagnosis.
DATA MONITOR MODE
Operation Procedure
1. Perform “CONSULT-II SETTING PROCEDURE ”. Refer to TF-44, "CONSULT-II SETTING PROCEDURE"
.
2. Touch “DATA MONITOR ”.
3. Select from “SELECT MONITOR ITEM ”, screen of data monitor mode is displayed.
NOTE:
When malfunction is detected, CONSULT-II performs REAL-TIME DIAGNOSIS.
Also, any malfunction detected while in this mode will be displayed at real time.
Display Item List
× : Standard –: Not applicable
Monitored item (Unit) Monitor item selection
Remarks
ECU INPUT
SIGNALS MAIN
SIGNALS SELEC-
TION FROM
MENU
VHCL/S SEN ·FR [km/h] or [mph] ×–×Wheel speed calculated by ABS actuator and
electric unit (control unit).
Signal input with CAN communication line.
VHCL/S SEN ·RR [km/h] or [mph] ×–×Wheel speed calculated by TCM.
Signal input with CAN communication line.
ENGINE SPEED [rpm] ×–×Engine speed calculated by ECM.
Signal input with CAN communication line.
THRTL POS SEN [V] ×–×Accelerator pedal position (APP) sensor sig-
nal voltage is displayed.
Signal input with CAN communication line.
FLUID TEMP SE [V] ×–×Transfer fluid temperature sensor signal volt-
age is displayed.
BATTERY VOLT [V] ×–×Power supply voltage for transfer control unit.
2WD SWITCH [ON/OFF] ×–×4WD shift switch status is displayed.
AUTO SWITCH [ON/OFF] ×–×4WD shift switch status is displayed.
LOCK SWITCH [ON/OFF] ×–×4WD shift switch status is displayed.
(LOCK means 4H of 4WD shift switch.)
4L SW [ON/OFF] ×–×4WD shift switch status is displayed.
(4L means 4LO of 4WD shift switch.)
N POSI SW TF [ON/OFF] ×–×Neutral-4LO switch signal status is displayed.
ATP SWITCH [ON/OFF] ×–×ATP switch signal status is displayed.
WAIT DETCT SW [ON/OFF] ×–×Wait detection switch status is displayed.
LINE PRES SW [ON/OFF] ×–×Line pressure switch status is displayed.
CL PRES SW [ON / OFF] ×–×Clutch pressure switch status is displayed.
N POSI SW AT [ON/OFF] זד
N ” position signal of A/T PNP switch status
is displayed.
Signal input with CAN communication line.
R POSI SW AT [ON/OFF] זד
R ” position signal of A/T PNP switch status
is displayed.
Signal input with CAN communication line.
Page 3154 of 3383
TROUBLE DIAGNOSISTF-49
CE F
G H
I
J
K L
M A
B
TF
Revision: November 2009 2006 QX56
WORK SUPPORT
When there is no problem with transfer and 4WD system, following symptom in “AUTO” mode may be claimed
by a customer.
Vibration when accelerating on a low µ road (snow-covered or icy road)
It is possible to deal with these symptoms by changing “CLUTCH FORCE RELEASE LIMIT VALUE”.
However, be careful when changing the values because it may adversely affect driving performance.
NOTE:
A slight shock is felt at a few hertz as if it were being pushed lightly from behind.
Operation Procedure
1. Perform “CONSULT-II SETTING PROCEDURE ”. Refer to TF-44, "CONSULT-II SETTING PROCEDURE"
.
2. Touch “WORK SUPPORT ”.
3. Select from “CLUTCH/F RLS LIM ADJ ”, screen of data monitor mode is displayed.
T/F F SPEED [km/h] or [mph] ×–×Displayed, but do not use.
A/T R SPEED [km/h] or [mph] ×–×Output shaft revolution signal (Revolution
sensor) calculated by TCM.
Signal input with CAN communication line.
AT GEAR POSI [1/2/3/4/5] ×–×A/T actual gear position is displayed.
Voltage [V] ––×The value measured by the voltage probe is
displayed.
Frequency [Hz] ––×
The value measured by the pulse probe is
displayed.
DUTY-HI (high) [%]
––×
DUTY-LOW (low) [%] ––×
PLS WIDTH-HI [msec] ––×
PLS WIDTH-LOW [msec] ––×
Monitored item (Unit)
Monitor item selection
Remarks
ECU INPUT
SIGNALS MAIN
SIGNALS SELEC-
TION FROM MENU
Page 3156 of 3383
TROUBLE DIAGNOSISTF-51
CE F
G H
I
J
K L
M A
B
TF
Revision: November 2009 2006 QX56
Diagnostic Procedure
1. Warm up engine.
2. Move A/T selector lever to “P” position.
3. Turn 4WD shift switch to “2WD” position.
4. Turn ignition switch “ON” and “OFF ” at least twice, and then turn ignition switch “OFF”.
5. Turn 4WD shift switch to “AUTO” position.
6. Turn ignition switch “ON”. (Do not start engine.)
7. 4WD warning lamp ON. If 4WD warning lamp does not turn ON, refer to TF-121, "
4WD Warning Lamp Does Not Turn ON" .
8. Move A/T selector lever to “R” position.
9. Turn 4WD shift switch to “2WD”, “AUTO ” and “2WD ” in order.
10. Move A/T selector lever to “D” position.
11. Turn 4WD shift switch to “4H”, “AUTO ” and “4H” in order.
12. Move A/T selector lever to “N” position.
13. Turn 4WD shift switch to “AUTO” position.
14. Move A/T selector lever to “P” position.
15. Read the flickering of 4WD warning lamp. Refer to TF-51, "
Judgement Self-diagnosis" .
Judgement Self-diagnosis
When a malfunction is detected, the malfunction route is indicated by flickering of the 4WD warning lamp.
PDIA0227E
Flickering pattern or
flickering condition Items
Malfunction Check items
2 Output shaft revolution
signal (from TCM)
Malfunction is detected in output shaft revolution signal
that is output from TCM through CAN communication.
Improper signal is input while driving. TF-58, "
Output Shaft
Revolution Signal
(TCM)"
3
Clutch pressure sole-
noid signalProper voltage is not applied to clutch pressure solenoid
valve due to open or short circuit. TF-86, "Clutch Pres-
sure Solenoid"
4
2-4WD solenoid signalProper voltage is not applied to 2-4WD solenoid valve
due to open or short circuit. TF-91, "2-4WD Sole-
noid"
5
Transfer motorMotor does not operate properly due to open or short cir-
cuit in transfer motor or motor relay. TF-95, "Transfer Motor"
6
Vehicle speed signal
(from ABS)
Malfunction is detected in vehicle speed signal that is
output from ABS actuator and electric unit (control unit)
through CAN communication.
Improper signal is input while driving. TF-58, "
Vehicle Speed
Sensor (ABS)"
7
CAN communicationMalfunction has been detected from CAN communica-
tion line. TF-113, "CAN Commu-
nication Line"
8
AD converterAD converter system of transfer control unit is malfunc-
tioning. TF-54, "Power Supply
Circuit For Transfer
Control Unit"
Page 3157 of 3383
TF-52
TROUBLE DIAGNOSIS
Revision: November 20092006 QX56
9Transfer fluid tempera-
ture
Signal voltage from fluid temperature sensor is abnor-
mally high (Transfer fluid temperature is abnormally low)
while driving. TF-102, "Transfer Fluid
Temperature"
10
Neutral-4LO switchImproper signal from neutral-4LO switch is input due to
open or short circuit. TF-59, "Neutral-4LO
Switch"
11
Clutch pressure switch
Improper signal from clutch pressure switch is input due
to open or short circuit.
Malfunction occurs in clutch pressure switch or hydraulic
circuit. TF-105, "
Clutch Pres-
sure Switch"
12
Line pressure switch
Improper signal from line pressure switch is input due to
open or short circuit.
Malfunction occurs in line pressure switch or hydraulic
circuit. TF-108, "
Line Pressure
Switch"
13
Engine speed signal
(from ECM)
Malfunction is detected in engine speed signal that is
output from ECM through CAN communication.
Improper signal is input while driving. TF-85, "
Engine Speed
Signal (ECM)"
14
Throttle position sen-
sor (from ECM)
Malfunction is detected in accelerator pedal position sig-
nal that is output from ECM through CAN communica-
tion.
Signal voltage from accelerator pedal position sensor is
abnormally high or low. TF-111, "
Throttle Posi-
tion Signal (ECM)"
15
Power supplyPower supply voltage for transfer control unit is abnor-
mally low while driving. TF-54, "Power Supply
Circuit For Transfer
Control Unit"
16
4WD shift switchMore than two switch inputs are simultaneously detected
due to short circuit of 4WD shift switch. TF-62, "4WD Shift
Switch"
17
ABS operation signal
(from ABS)
Malfunction is detected in ABS operation signal that is
output from ABS actuator and electric unit (control unit)
through CAN communication. TF-111, "ABS Operation
Signal (ABS)"
18
Wait detection switchImproper signal from wait detection switch is input due to
open or short circuit. TF-66, "Wait Detection
Switch"
19
Actuator motor
Motor does not operate properly due to open or short cir-
cuit in actuator motor.
Malfunction is detected in the actuator motor. (When
4WD shift switch is operated and actuator motor is not
operated)
Malfunction is detected in transfer shift high relay and
transfer shift low relay. TF-70, "
Actuator
Motor", TF-54, "Power
Supply Circuit For
Transfer Control Unit"
20
Actuator position
switch
Improper signal from actuator position switch is input
due to open or short circuit.
Malfunction is detected in the actuator position switch. TF-77, "
Actuator Posi-
tion Switch"
21
Actuator circuit
Transfer control device actuator circuit is shorted or
open. (Malfunctions are detected when motor relay cir-
cuit is open/shorted or relay transfer shift circuit is open/
shorted.)
Malfunction occurs in transfer control device drive circuit. TF-81, "
Transfer Con-
trol Device"
Malfunction is detected in transfer shut off relay.
TF-54, "
Power Supply
Circuit For Transfer
Control Unit"
22
VDC operation signal
(from VDC)
Malfunction is detected in VDC operation signal that is
output from ABS actuator and electric unit (control unit)
through CAN communication. TF-112, "VDC Opera-
tion Signal (ABS)"
23
TCS operation signal
(from TCS)
Malfunction is detected in TCS operation signal that is
output from ABS actuator and electric unit (control unit)
through CAN communication. TF-112, "TCS Opera-
tion Signal (ABS)"
Flickering pattern or
flickering condition Items
Malfunction Check items
Page 3163 of 3383
TF-58
TROUBLE DIAGNOSIS FOR SYSTEM
Revision: November 20092006 QX56
Output Shaft Revolution Signal (TCM)EDS002I6
DIAGNOSTIC PROCEDURE
1. CHECK DTC WITH TCM
Perform self-diagnosis with TCM. Refer to TF-50, "
SELF-DIAGNOSTIC PROCEDURE (WITH CONSULT-II)" .
Is any malfunction detected by self-diagnosis?
YES >> Check the malfunctioning system.
NO >> GO TO 2.
2. CHECK TRANSFER CONTROL UNIT
Check transfer control unit input/output signal. Refer to TF-54, "
TRANSFER CONTROL UNIT TERMINALS
AND REFERENCE VALUE" .
OK or NG
OK >> GO TO 3.
NG >> Check transfer control unit pin terminals for damage or loose connection with harness connector. If any items are damaged, repair or replace damaged parts.
3. CHECK DTC
Perform the self-diagnosis, after driving a vehicle for a while.
OK or NG
OK >> Inspection End.
NG >> Perform self-diagnosis with TCM again. Refer to TF-50, "
SELF-DIAGNOSTIC PROCEDURE
(WITH CONSULT-II)" .
Vehicle Speed Sensor (ABS)EDS002I7
DIAGNOSTIC PROCEDURE
1. CHECK DTC WITH ABS ACTUATOR AND ELECTRIC UNIT (CONTROL UNIT)
Perform self-diagnosis with ABS actuator and electric unit (control unit). Refer to BRC-29, "
SELF-DIAGNO-
SIS" .
Is any malfunction detected by self-diagnosis?
YES >> Check the malfunctioning system.
NO >> GO TO 2.
2. CHECK TRANSFER CONTROL UNIT
Check transfer control unit input/output signal. Refer to TF-54, "
TRANSFER CONTROL UNIT TERMINALS
AND REFERENCE VALUE" .
OK or NG
OK >> GO TO 3.
NG >> Check transfer control unit pin terminals for damage or loose connection with harness connector. If any items are damaged, repair or replace damaged parts.
3. CHECK DTC
Perform the self-diagnosis, after driving a vehicle for a while.
OK or NG
OK >> Inspection End.
NG >> Perform self-diagnosis with ABS actuator and electric unit (control unit) again. Refer to BRC-29,
"SELF-DIAGNOSIS" .
Page 3207 of 3383
TF-102
TROUBLE DIAGNOSIS FOR SYSTEM
Revision: November 20092006 QX56
COMPONENT INSPECTION
Transfer Motor Relay
1. Turn ignition switch “OFF”. (Stay for at least 5 seconds.)
2. Remove transfer motor relay. Refer to TF-22, "
Location of Electrical Parts" .
3. Apply 12V direct current between transfer motor relay terminals 1 and 2.
4. Check continuity between relay terminals 3 and 5.
5. If NG, replace transfer motor relay. Refer to TF-22, "
Location of
Electrical Parts" .
Transfer Motor
1. Turn ignition switch “OFF”. (Stay for at least 5 seconds.)
2. Remove transfer motor. Refer to TF-142, "
Removal and Installation" .
3. Apply 12V direct current between transfer motor terminals 14 and 15.
4. If transfer motor does not operate, replace transfer motor. Refer to TF-142, "
Removal and Installation" .
Transfer Fluid TemperatureEDS002IJ
CONSULT-II REFERENCE VALUE IN DATA MONITOR MODE
Data are reference value.
TRANSFER CONTROL UNIT TERMINALS AND REFERENCE VALUE
Data are reference value and are measured between each terminal and ground.
CAUTION:
When using a circuit tester to measure voltage for inspection, be sure not to extend forcibly any connector terminals. Condition
Continuity
12V direct current supply between terminals 1 and 2 Yes
OFF No
LDIA0098E
LDIA0097E
Monitored item [Unit]Content ConditionDisplay value
(Approx.)
FLUID TEMP SE [V] Condition of transfer fluid
temperature Transfer fluid temperature approx. 20 - 80
°C (68 -
176° F) 1.1 - 0.3V
Te r m i n a lWire
color Item
ConditionData (Approx.)
28 B/G Sensor ground Always0V
31 G Transfer fluid temperature
sensor
Ignition switch: ONTransfer fluid temperature approx. 20°C
(68
°F) 1.1V
Transfer fluid temperature approx. 80°C
(176 °F) 0.3V
Page 3208 of 3383
TROUBLE DIAGNOSIS FOR SYSTEMTF-103
CE F
G H
I
J
K L
M A
B
TF
Revision: November 2009 2006 QX56
DIAGNOSTIC PROCEDURE
1. CHECK TRANSFER FLUID TEMPERATURE SENSOR SIGNAL
With CONSULT-II
1. Start engine.
2. Select “DATA MONITOR ” mode for “ALL MODE AWD/4WD ” with CONSULT-II.
3. Read out the value of “FLUID TEMP SE”.
Without CONSULT-II
1. Start engine.
2. Check voltage between transfer control unit harness connector terminals and ground.
OK or NG
OK >> GO TO 4.
NG >> GO TO 2.
2. CHECK HARNESS BETWEEN TRANSFER CONTROL UNIT AND TRANSFER TERMINAL CORD
ASSEMBLY 1. Turn ignition switch “OFF”. (Stay for at least 5 seconds.)
2. Disconnect transfer control unit harness connector and transfer terminal cord assembly harness connec- tor.
3. Check continuity between the following terminals.
–Transfer control unit harness connector E143 terminal 28 and
transfer terminal cord assembly harness connector F56 terminal
3.
–Transfer control unit harness connector E143 terminal 31 and
transfer terminal cord assembly harness connector F56 terminal
2.
Also check harness for short to ground and short to power.
OK or NG
OK >> GO TO 3.
NG >> Repair or replace damaged parts.
Condition Display value
(Approx.)
Transfer fluid temperature approx. 20 - 80 °C (68 - 176°F) 1.1 - 0.3V
SDIA2741E
Connector Terminal ConditionData
(Approx.)
E143 28 -
Ground Always
0V
31 -
Ground Ignition switch:
ON Transfer fluid temperature
approx. 20
°C (68°F) 1.1V
Transfer fluid temperature
approx. 80 °C (176°F) 0.3V
SDIA2742E
Continuity should exist.
SDIA2743E
Page 3209 of 3383
TF-104
TROUBLE DIAGNOSIS FOR SYSTEM
Revision: November 20092006 QX56
3. CHECK TRANSFER FLUID TEMPERATURE SENSOR
1. Turn ignition switch “ OFF”. (Stay for at least 5 seconds.)
2. Disconnect transfer terminal cord assembly harness connector.
3. Check resistance between transfer terminal cord assembly ter- minals 2 and 3.
OK or NG
OK >> GO TO 4.
NG >> Replace transfer fluid temperature sensor. Refer to TF-
22, "Location of Electrical Parts" .
4. CHECK TRANSFER CONTROL UNIT
Check transfer control unit input/output signal. Refer to TF-54, "
TRANSFER CONTROL UNIT TERMINALS
AND REFERENCE VALUE" .
OK or NG
OK >> GO TO 5.
NG >> Check transfer control unit pin terminals for damage or loose connection with harness connector. If any items are damaged, repair or replace damaged parts.
5. CHECK DTC
Perform the self-diagnosis, after driving a vehicle for a while.
OK or NG
OK >> Inspection End.
NG >> Replace transfer control unit. Refer to TF-132, "
Removal and Installation" .
COMPONENT INSPECTION
1. Turn ignition switch “OFF ”. (Stay for at least 5 seconds.)
2. Disconnect transfer terminal cord assembly harness connector.
3. Check resistance between transfer terminal cord assembly har- ness connector F56 terminals 2 and 3.
4. If NG, replace the transfer fluid temperature sensor. Refer to TF-
22, "Location of Electrical Parts" .
Temperature °C (°F) Resistance (Approx.)
20 (68) 2.5 k\b
80 (176) 0.3 k\b
WDIA0188E
Temperature °C (°F) Resistance (Approx.)
20 (68) 2.5 k\b
80 (176) 0.3 k\b
WDIA0188E
