2006 HONDA RIDGELINE Owners Manual

The pickup bed on your vehicle
allows you to carry heavy and large
cargo. You can also store items in
theIn-BedTrunkandonaroof-rack
(if equipped).
Your vehicle also has these
convenient storage areas inside:Glove box
Front door and seat-back pockets
Fold-up rear seat with under-seat
storage
Console compartments
Pockets on the dashboard
However, carrying too much cargo,
or improperly storing it, can af f ect
your vehicle’s handling, stability,
stopping distance, and tires, and
make it unsaf e. Bef ore carrying any
type of cargo, be sure to read the
f ollowing pages.
Carrying Cargo
182
GLOVE BOX DOOR POCKETS
DASHBOARD
POCKETS
PICKUP BED
CONSOLE
COMPARTMENTS
SEAT-BACK POCKETS
FOLD-UP REAR SEAT WITH UNDER-SEAT STORAGE IN-BED TRUNK
—
—y
y
(y
y

µ·
Locate the statement, ‘‘the
combined weight of occupants and
cargo should never exceed 1,530
(1,480) lbs’’ on your vehicle’s
placard. [The placard is on the
driver’s doorjamb.]
To determine the correct cargo and
luggage load limit:
The maximum load f or your vehicle
is:
These f igures include the total
weight of all occupants, cargo, and
accessories, and the tongue load if
you are towing a trailer.
In addition, the total weight of the
vehicle, all passengers,
accessories,cargo,andtrailer
tongue load must not exceed the
Gross Vehicle Weight Rating
(GVWR) or the Gross Axle
Weight Rating (GAWR). Both are
on a label on the driver’s doorjamb. If your vehicle will be towing a
trailer, load f rom your trailer will
be transf erred to your vehicle.
Consult this manual to determine
how this reduces the available
cargo and luggage load capacity of
yourvehicle(seepage ). Determine the combined weight
of luggage and cargo being loaded
on the vehicle. That weight may
not saf ely exceed the available
cargo and luggage load capacity in
step 4.
Subtract the combined weight of
the driver and passengers f rom
1,530 (1,480) pounds or 690 (670)
kilograms. Determine the combined weight
of the driver and passengers that
will be riding in your vehicle.
The resulting f igure equals the
available amount of cargo and
luggage load capacity. For
example, if the maximum load is
1,530 lbs and there will be f ive 150
lb. passengers in your vehicle, the
amount of available cargo and luggage load capacity is 780 lbs.
[1,530 750 (5 150) = 780 lbs.]
1.
2.
3.
4. 5.
6.
207
On vehicles without moonroof ornavigation system
On vehicles with moonroof and/ornavigation system
Carrying Cargo
Load Limit (Payload)
Bef ore Driving
183
1,530 lbs (690 kg)
1,480 lbs (670 kg)
Overloading or improper
loading can affect handling and
stability and cause a crash in
which you can be hurt or killed.
Follow all load limits and other
loading guidelines in this
manual.
—
—
y

y
(y
y

Store or secure all items that could
be thrown around and hurt
someone during a crash.
Be sure items placed on the f loor
behind the f ront seats cannot roll
under the seats and interf ere with
the pedals or seat operation.
Keep the glove box closed while
driving. If it is open, a passenger
could injure their knees during a
crash or sudden stop.
If you lif t up the rear seats, f ollow
the instructions above, and be sure
to keep cargo height below the
bottom of the windows. If cargo is
higher, it could interf ere with
proper operation of the side
curtain airbags.Distribute cargo evenly on the
f loor in the In-Bed Trunk, placing
the heaviest items on the bottom
and as far forward as possible. Tie
down items that could be thrown
during a crash or sudden stop.
Make sure the In-Bed Trunk lid is
closed securely bef ore driving.
Distribute cargo evenly on the
floor of the cargo area with the
rear seats f olded up, placing the
heaviest items on the bottom and
as far forward as possible. Tie
down items that could be thrown
about the vehicle during a crash or
sudden stop.
Be sure the total weight of the
items in the In-Bed Trunk does not
exceed 300 lbs (136 kg).
If you carry any items on a roof
rack,besurethetotalweightof
the rack and the items does not
exceed 165 lbs (75 kg).
If you use an accessory roof rack,
the roof rack weight limit may be
lower. Ref er to the inf ormation that
came with your roof rack.
Carrying Items in the Passenger
Compartment
Carrying Cargo in the In-Bed
T runk or on a Roof Rack
Carrying Cargo
184
—
—y

y
(y
y

CONT INUED
Your vehicle can carry a large
amount of cargo in the pickup bed.
However, the pickup bed is not
intended f or carrying passengers.
Peoplewhorideinthepickupbed
can be very seriously injured or
killed in a crash (see page ).
Make sure your cargo is properly
loaded and all items are secured so
they will not shif t or f all out while
driving.When loading cargo, make sure all
passengers or any objects are
clear of the tailgate bef ore
opening and closing it. The
tailgate should be closed securely
bef ore driving when it is not used
as the extended pickup bed.
The maximum allowable loading
weight on the pickup bed is 1,100
lbs (500 kg). Do not exceed the
load limit (see page ).
Distribute cargo evenly on the
pickup bed. Place the heaviest
items on the bottom and as f ar
f orward as possible of the rear
axle. Tie down and secure all
items that could be thrown out of
the vehicle during a crash or
sudden stop.If you stack items higher than the
bed sides, tailgate, or back window,
secure them with a net or cover.
This will reduce the risk of items
beingthrownoutof thepickup
bed during a crash or sudden stop.
When the tailgate is dropped open,
itcanbeusedasanextended
pickup bed. The maximum
allowable weight on the tailgate
while driving is 300 lbs (136 kg).
Exceeding this limit could damage
the tailgate.
Carrying heavy cargo in the
pickup bed will raise your vehicle’s
center of gravity. This can affect
handling and perf ormance. Drive
more slowly and cautiously, and
allow extra time and distance f or
braking.
8
183
Carrying Cargo
Carrying Cargo in the Pickup Bed
Bef ore Driving
185
Allowing passengers to ride in
the pickup bed or on the tailgate
can result in death or serious
injury in a crash.
Make sure all passengers ride
in a seat and wear a seat belt
properly.
——y

y
(y
y

Your vehicle has six tie down cleats
on the pickup bed.You can also support motorcycles on
the pickup bed floor with the cleats.
The f loor panel of the pickup bed is
designed to hold motorcycle tires. Be
sure to tighten motorcycles securely
with rope or cord according to the
motorcycle maker’s instructions.
When carrying motorcycles, do not
spill any oil or f luid on the pickup
bed. A spilled liquid may damage the
pickup bed.
They are used to secure cargo on the
pickup bed and to install a cargo net
f or securing items. Do not use any
other parts of the pickup bed to
secure cargo or nets.
Carrying Cargo
Tie Down Cleats
186
TIE DOWN CLEATNever let passengers ride on
the pickup bed or in the In-Bed
Trunk space. This could cause
very serious injuries or death in
a collision. No one should ride
in any position on your vehicle
that is not equipped with seats
and seat belts.
Exceeding load limits or
improperly loading cargo on the
vehicle can cause a crash in
which you can be seriously
injured or killed.
Load the cargo carefully before
starting to drive.
—
—y
y
(y

y

The cargo net can be used to hold
items in the pickup bed. Secure all
items properly. The net may not
prevent heavy items f rom being
thrown outward in a crash or a
sudden stop.The cargo cover can be used to
cover the cargo area on the pickup
bed.
Your vehicle’s pickup bed has a rust
resistant surf ace. To repair small
chips and scratches in the bed, a
repair kit is available f rom your
dealer. More extensive damage
should be repaired by your dealer.
To avoid problems with the bed
surf ace and the In-Bed Trunk lid, do
not use spray-in bed liner products.
Carrying Cargo
Optional Cargo Net
Optional Cargo Cover
Pickup Bed Repair
Bef ore Driving
187
—
—y
y
(y
y

188
—
—y
y
(y
y

This section gives you tips on
starting the engine under various
conditions, and how to operate the
automatic transmission. It also
includes important inf ormation on
parking your vehicle, the braking
system, the VTM-4system, the VSA
system, the tire pressure monitoring
system, and f acts you need if you are
planning to tow a trailer.........................
Driving Guidelines .190
........................
Preparing to Drive .191
.......................
Starting the Engine .192
..............
Automatic Transmission .193
Variable Torque Management
.........
4WD (VTM-4) System .198
..............................
VTM-4Lock .198
Tire Pressure Monitoring System ......................................
(TPMS) .199
...........................................
Parking .201
.............................
Braking System .202
...............
Anti-lock Brakes (ABS) .203
Vehicle Stability Assist (VSA)
........................................
System .205
.................
Towing Weight Limits .207
..........
Towing Weight Guidelines .209
...........................
Towing a Trailer .210
Of f -Highway Driving
..................................
Guidelines .219
Driving
Driving
189
—
