2006 HONDA RIDGELINE Owners Manual

µ
µ µ
Press this button once
to unlock the driver’s door. Push it
twice to unlock the other doors and
the In-Bed Trunk.
Some exterior and interior lights will
f lash twice each time you push the
button.
When you press the UNLOCK
button, the f ront and rear individual
map lights, depending on the interior
light control switch position, will
come on (see page ). If you do not
open any door, the lights stay on f or
about 30 seconds, then go out. If you
relock the doors and the In-Bed
Trunk with the remote transmitter
bef ore 30 seconds have elapsed, the
lights will go of f immediately.
Press this button once to
lock all doors and the In-Bed Trunk.
Some exterior and interior lights will
flash once.
When you push LOCK twice within 5
seconds, you will hear a beep to
verify that the doors and In-Bed
Trunk are locked and the security
system (if equipped) has set. This
button does not work if any door is
not f ully closed or the key is in the
ignition switch. Press and hold this
button for about 1 second to attract
attention; the horn will sound and
the exterior lights will f lash f or about
30 seconds. To cancel panic mode,
press any other button on the remote
transmitter, or turn the ignition
switch to ON (II). Panic mode does
not work when the key is in the
ignition switch. If you do not open any door within 30
seconds, the doors automatically
relock, and the security system sets
(if equipped). The UNLOCK button
does not work when the key is in the
ignition switch.
You can also open all side windows
f rom outside the vehicle with the
remote transmitter (see page ).
115 104
UNL OCK
LOCK PA NIC
Remote Transmitter
86
LED
UNLOCK
BUTTON
PANIC
BUTTON LOCK
BUTTON
—
—y
y
(y
y

Avoid dropping or throwing the
transmitter.
Protect the transmitter from
extreme temperature.
Do not immerse the transmitter in
any liquid.
If you lose a transmitter, the
replacement needs to be
reprogrammed by your dealer.Remove the screw at the base of
the transmitter with a small
Phillips-head screwdriver.
To replace the battery: Battery type: CR1616 If it takes several pushes on the
button to lock or unlock the doors,
replace the battery as soon as
possible.
Inside the transmitter, separate
the inner cover f rom the keypad
by releasing the two tabs on the
cover. Separate the transmitter by prying
its middle seam with your
f ingernail.
1. 2.
3.
CONT INUED
Remote Transmitter
Remote Transmitter Care
Replacing the Transmitter
Battery
Inst rument s and Cont rols
87
SCREWBATTERY
—
—y
y
(yy

´
As required by the FCC:This device complies with Part 15 of theFCC rules. Operation is subject to thef ollowing two conditions: (1) This devicemay not cause harmf ul interf erence, and(2) this device must accept anyinterf erence received, includinginterf erence that may cause undesiredoperation.
Changes or modif ications not expresslyapproved by the party responsible f orcompliance could void the user’sauthority to operate the equipment.
This device complies with IndustryCanada Standard RSS-210.Operation is subject to the f ollowing twoconditions: (1) this device may not causeinterf erence, and (2) this device mustaccept any interf erence that may causeundesired operation of the device.Remove the old battery from the
back of the inner cover, and insert
a new battery into the back of the
cover with the side f acing down.
Install the parts in reverse order.
4.
5.
Remote Transmitter
88
—
—y

y
(yy

Youcanopenthetailgatetwo
dif f erent ways:Drop it open by using the upper
handle.
Swingitopenbyusingtheright
lower handle.
To drop open the tailgate, pull up the
upper handle, then pull down the
tailgate. To close the tailgate, push
f irmly up until it latches.
Bef ore you open the tailgate a
dif f erent way (dropped open, and
then swung open), make sure it is
f ully closed.
Make sure all passengers and
objects are clear of the tailgate
bef ore opening and closing it, and
make sure the tailgate is closed
securely bef ore driving.
As a saf ety f eature, the upper handle
is disabled if you do not f ully close
the tailgate af ter it is swung open.
And the lower handle is disabled if
you do not f ully close the tailgate
af ter it is dropped open.
CONT INUED
Dual-Action Tailgate
To Drop Open the Tailgate
Inst rument s and Cont rols
89
NOTE:
UPPER HANDLE
—
—y
y
(yy

To swing open the tailgate, f irst
make sure it is f ully closed, then pull
up the right lower handle, and swing
the tailgate to the lef t.
To close, swing the tailgate back,
and push it f irmly until it is latched.
The dropped open tailgate can be
used as an extended pickup bed.
Make sure to secure the items in the
pickup bed, and do not exceed the
maximum allowable weight on the
tailgate(seepage ).
To turn the bed lights on or off, use
the bed light switch on the
dashboard (see page ).
Bef ore opening or closing the
tailgate, check that passengers,
especially children, are not in the
tailgate’s path.
117
185
Dual-Action Tailgate
T o Swing Open the T ailgate
90
HANDLESwinging the tailgate open or
closed while anyone is in its
path can cause serious injury.
Make sure all passengers are
clear of the tailgate’s path
before opening or closing it.
Do not drive with the tailgate swung
open. This could damage the tailgate.
—
—y
y
(yy

See page for information on
cargo loading and weight limits.
You can also store and lock items in
the In-Bed Trunk (see page ). If you do not f asten the seat belt, you
f irst hear the seat belt reminder
alarm, then the tailgate reminder
beeper sounds.
The indicator does not monitor the
tailgate when it is dropped open.
This indicator is in the door and
tailgate open monitor on the
instrument panel. It comes on when
the tailgate is swung open or it is not
completely closed. This indicator
worksevenif thekeyisnotinthe
ignition switch.
If the tailgate is swung open or not
closed tightly when the ignition
switch is in the ON (II) position, you
will hear six beeps and see the
indicator blinking. The indicator
stays on until you close the tailgate.
The beeper also sounds and the
indicator blinks when you move the
shif t lever out of the Park or neutral
position.
Do not allow anyone to hang on the
swung open tailgate. This could
damage the tailgate.
Do not leave the tailgate swung open.
The tailgate may swing and shut
accidentally. This could cause
serious injuries.
Thebedlightscomeonwhenyou
swing open the tailgate. You can also
turn the bed lights on or off by
pushing the bed light switch on the
dashboard (see page ).
183
117 92
Dual-Action Tailgate
Loading Cargo
T ailgat e Open Indicat or
Inst rument s and Cont rols
91
—
—y
y
(yy

YoucanopentheIn-BedTrunktwo
dif f erent ways:Push the release button on the
lower right side of the In-Bed
Trunk lid when the driver’s door is
unlocked. To close the In-Bed Trunk, lower the
lid, then press down on the back
edge. If your vehicle’s battery is
disconnected or goes dead, the
release button on the In-Bed Trunk
lid is disabled. To open the In-Bed
Trunk, use the master key.
Usethemasterkeytoopenthe
In-Bed Trunk when the driver’s
door is locked. Thebedlightscomeonwhenyou
open the In-Bed Trunk. You can also
turn the bed lights on or off by
pushing the bed light switch on the
dashboard (see page ).
You can store items in the In-Bed
Trunk up to 300 lbs (136 kg). Do not
exceed this weight limit, or you may
damage the In-Bed Trunk. See page
f or inf ormation on loading cargo
and weight limits.
To store items separately in the
In-Bed Trunk, optional divider
guides are available f rom your dealer.
When the In-Bed Trunk is closed
securely, it can be locked or
unlocked along with the power door
locks (see page ). 117
183
80
In-Bed Trunk
92
RELEASE
BUTTON
TM
—
—y
y
(yy

To avoid damaging the key and key
cylinder of the In-Bed Trunk lid, do
notclosethetailgatewhenthekeyis
in the lid.As a saf ety f eature, your vehicle has
a release lever on the latch of the
In-Bed Trunk lid so it can be opened
f rom the inside. To open the In-Bed
Trunk, push the release lever in the
direction of the arrow.
Parents should decide if their
children should be shown how to use
this f eature. For more inf ormation
about child saf ety, see page .
To avoid damaging the seal on the
In-Bed Trunk lid, remove any debris
from the lid’s mating surface before
you close it.
To avoid damaging the bottom of the
In-Bed Trunk, do not drive over large
obstacles, and do not use it as a
jacking point to raise the vehicle. To avoid damaging the In-Bed Trunk
lid, and to prevent items f rom being
thrown about the vehicle and
possibly hurting someone in an
accident or sudden stop, be sure the
In-Bed Trunk lid is securely closed
bef ore driving away. This indicator on the instrument
panel reminds you that the In-Bed
Trunk is open (see page ). 34
66 Emergency Opener
In-Bed T runk Open
Indicator
In-Bed Trunk
Inst rument s and Cont rols
93
TM
—
