2006 CHEVROLET MALIBU Owners Manual

When your vehicle has a at tire, use the following
example as a guide to assist you in the placement of
wheel blocks.
The following information will tell you next how to use
the jack and change a tire.Removing the Spare Tire and Tools
The equipment you will need is in the trunk or cargo area.
1. Open the trunk for sedan models. SeeTrunk
(Sedan) on page 2-15for more information.
For MAXX models, open the liftgate. SeeLiftgate
(MAXX) on page 2-16.
2. For the sedan, lift the handle on the spare tire
cover. The handle may hook on the trunk front
edge weatherstrip to hold the cover out of the way.
For the MAXX, lift the handle to release the latch on
the spare tire cover.
3. For the MAXX, lift and remove the cover.
5-73

4. Turn the wing nut counterclockwise and remove it.
Then remove the compact spare tire. SeeCompact
Spare Tire on page 5-88for more information.
5. Remove the wing nut holding the jack in place.
6. Remove the extension bolt (MAXX models
and Sedan SS only) that is clipped to the jack.
You will need this later to store the at tire.
7. Remove the jack and wheel wrench from the trunk
or cargo area.
Tire Changing Tools
The tools you will be using include the wheel wrench (A)
and jack (B). The MAXX and all SS models include
an additional extension.
Sedan shown, MAXX Models and Sedan SS similar
5-74

1. Turn the plastic wing nut counterclockwise to
loosen wheel wrench.
2. Unhook the wheel wrench from the jack.3. Extend the handle on the wheel wrench by pressing
the button with your index nger and pulling on
the end of the wrench. You must do this before
using the wheel wrench.
5-75

Removing the Flat Tire and
Installing the Spare Tire
1. If your vehicle has a wheel cover or hubcap that
has plastic wheel nut caps, loosen the plastic nut
caps. You may need to use the wheel wrench
to loosen them. Do not pry off wheel covers
or center caps that have plastic wheel nut caps.
2. Remove the wheel cover or center cap from the
wheel to locate the wheel nuts.
If your vehicle has a wheel cover or hubcap without
plastic wheel nut caps, gently pry on the edge of
the plastic wheel trim to remove it from the wheel to
locate the wheel nuts.
3. Use the wrench to loosen all the wheel nuts. Do not
remove them yet.
5-76

4. Position the lift head at the jack location nearest the
at tire. Make sure all of the jack lift head is touching
the jacking ange under the body. Do not place the
jack under a body panel. The lower body panel has
an arrow to aid in locating the jacking location.5. Put the compact spare tire near the at tire being
changed.
{CAUTION:
Getting under a vehicle when it is jacked up is
dangerous. If the vehicle slips off the jack you
could be badly injured or killed. Never get under
a vehicle when it is supported only by a jack.
5-77

{CAUTION:
Raising your vehicle with the jack improperly
positioned can damage the vehicle and even
make the vehicle fall. To help avoid personal
injury and vehicle damage, be sure to t the
jack lift head into the proper location before
raising the vehicle.
6. Raise the vehicle by turning the wrench clockwise.
Raise the vehicle far enough off the ground so there
is enough room for the compact spare tire to t.
5-78

7. Remove all of the
wheel nuts.
8. Remove the at tire.
{CAUTION:
Rust or dirt on the wheel, or on the parts to
which it is fastened, can make the wheel nuts
become loose after a time. The wheel could
come off and cause an accident. When you
change a wheel, remove any rust or dirt from
the places where the wheel attaches to the
vehicle. In an emergency, you can use a cloth
or a paper towel to do this; but be sure to use
a scraper or wire brush later, if needed, to get
all the rust or dirt off.
9. Remove any rust or dirt
from the wheel bolts,
mounting surfaces
and spare wheel.
5-79

10. Install the compact spare tire.
{CAUTION:
Never use oil or grease on studs or nuts. If you
do, the nuts might come loose. Your wheel
could fall off, causing a serious accident.
11. Put the wheel nuts back on with the rounded end
toward the wheel. Tighten each nut by hand or with
the wrench until the wheel is held against the hub.
12. Lower the vehicle by turning the wrench
counterclockwise. Lower the jack completely.
5-80
