2006 Acura RSX Owner's Manual

The height of your driver’s seat is
adjustable. Turn the dial on the
outside of the seat cushion to change
the height of the seat bottom.To change the lumbar support, move
the lever on the right side of the
seat-back forward or backward.
Keep moving the lever f orward or
backward until you f ind a suitable
position.To get into the back seat, pull up on
the seat-back adjustment lever.
U.S.:
Canada: All models
U.S.:
Canada: All models
Premium and Type-S models only Premium and Type-S models
only
Driver’s Seat Height A djustment Driver’s L umbar Support Rear Seat A ccess
Seats
72

The back of the rear seat folds down
to give you more cargo space. Each
side f olds down separately. With only
half the seat f olded, you can still
carry a passenger in the back seat.
To unlatch either side of the seat-
back, pull up on the release tab.
Move the seat belt out of the way
and fold the seat-back down.To lock the seat-back upright, push
the seat-back firmly against its latch.
Tug on the seat-back to make sure it
is latched.
Do not put any heavy items on the
seat-back when it is folded.
Make sure all items in the cargo area
are secured. Loose items can f ly
f orward and cause injury if you have
to brake hard (See
on page ).
To get out f rom the rear seat on the
passenger’s side, push down on the
release lever at the base of the seat-
back. The seat-back will tilt f orward,
and the seat will slide f orward.
Af ter a passenger gets into the back
seat, push the seat-back to the
upright position and push the whole
seat backwards until it latches. Make
sure the seat is f ully latched bef ore
sitting in it. 141
Carrying Cargo
Folding Rear Seat
Seats
Inst rument s and Cont rols
73
RELEASE TAB
RELEASE LEVER

Do not use the seat heaters when the
engine is of f or when idling f or a
long period of time. They can drain
the battery, making your vehicle
hard to start.
Both f ront seats are equipped with
seat heaters. The ignition switch
must be in the ON (II) position to
use them. Push the heater switch to
turn the power on or of f . The
indicators will come on and remain
on while the heaters are on.
On Canada Type-S and Premium model with leather seats
Seat Heaters
74
SEAT HEATER SWITCHES

The cargo area cover may be
removed to give you more cargo
room.Open the hatch. Push up on the sides of the cargo
area cover to release the cover
f rom the hooks.
Pull down on the cover to remove
the mounting pins f rom the holes
in the hatch lining.
1. 2.
3.
CONT INUED
Cargo Area Cover
Inst rument s and Cont rols
75
MOUNTING PIN
HOOK

Reverse this procedure to install the
cargo area cover.Thereisareferencelineonthe
cargo area side panel. To avoid
damaging the cargo cover, remove
the cover if the cargo goes above
that line.
Do not place items on the cargo area
cover, or stack objects higher than
the top of the back seat. They could
block your view and be thrown about
the vehicle during a crash or sudden
stop.
Cargo Area Cover
76
REFERENCE

µTo open/close the driver’s
window, push the window switch
f irmly down or up to the second
detent, and release it. The window
will automatically go up or down all
the way. To stop the window, pull/
push on the window switch brief ly.
If the MAIN switch is OFF, the
passenger window cannot be raised
or lowered. Keep the MAIN switch
off whenyouhavechildreninthe
vehicle so they do not injure
themselves by operating the window
unintentionally.
Turn the ignition switch to the ON
(II) position to raise or lower either
window. To open the window, push
the switch down and hold it. Release
the switch when you want the
window to stop. Pull back on the
switchandholdittoclosethe
window.
CONT INUED
AUTO
Power Windows
Inst rument s and Cont rols
77
MAIN SWITCH
DRIVER’S WINDOW SWITCH
Closing a power window on
someone’s hands or fingers can
cause serious injury.
Make sure your passengers are
away from the windows before
closing them.

µ
Auto reverse stops sensing when the
window is almost closed. You should
always check that all passengers and
objects are away from the window
bef ore closing it. If your vehicle’s battery is
disconnected or goes dead, or the
driver’s window f use is removed, the
AUTO f unction will be disabled. The
power window system needs to be
reset af ter reconnecting the battery
or installing the f use.
Start the engine. Push down and
hold the driver’s window switch
until the window is f ully open.
Pull and hold the driver’s window
switch to close the window
completely, then hold the switch
f or a second or two more.
If the driver’s
window senses any obstacle while it
is closing automatically, it will
reverse direction, and then stop. To
close the window, remove the
obstacle, then use the window switch
again.
If the power windows do not operate
properly af ter resetting, have your
vehicle checked by your dealer. 1.
2.
Power Windows
AUTO REVERSE
78

Usetheswitchonthedashboardto
open and close the moonroof . The
ignition switch must be in the ON
(II) position. Push and hold theswitch to open the moonroof .
Release the switch when the
moonroof reaches the desired
position. To close the moonroof ,
press and hold the switch. Keeptheinsideandoutsidemirrors
clean and adjusted f or best visibility.
Be sure to adjust the mirrors bef ore
you start driving.
The inside mirror has day and night
positions. The night position reduces
glare f rom headlights behind you.
Flip the tab on the bottom edge of
the mirror to select the day or night
position.
CONT INUED
U.S.: All models
Canada: Premium and Type-S models only
Moonroof Mirrors
Moonroof , Mirrors
Inst rument s and Cont rols
79
TAB
Closing the moonroof on
someone’s hands or fingers can
cause serious injury.
Make sure passengers are
clear of the moonroof before
closing it.
If you try to open the moonroof in
below-f reezing temperatures, or when
it is covered with snow or ice, you can
damage the moonroof panel or motor.
