2006 Acura RSX Owner's Manual

This indicator comes on when the
security system is set. See pagef or more inf ormation on the
security system.
If you exceed 10,000 miles (16,000
km) without having the scheduled
maintenance perf ormed, this
indicator will remain on as a constant
reminder.
Your dealer will reset this indicator
af ter completing the scheduled
maintenance. If this maintenance is
done by someone other than your
dealer, reset the indicator as f ollows.
Turn of f the engine. Press and hold the select/reset
knob in the instrument panel, then
turn the ignition switch to the ON
(II) position.
Hold the knob f or about10
seconds until the indicator goes
off.
1.
2.
3. 126
Security System Indicator
Instrument Panel Indicators
56
SECURITY SYSTEM INDICATOR
SELECT/RESET KNOB

The odometer shows the total
distance your vehicle has been
driven. It measures miles in U.S.
models and kilometers in Canadian
models. It is illegal under U.S.
federal law and Canadian provincial
regulations to disconnect, reset, or
alter the odometer with the intent to
change the number of miles or
kilometers indicated.This meter shows the number of
miles (U.S.) or kilometers (Canada)
driven since you last reset it.To reset a trip meter, display it and
then press and hold the select/reset
knob until the number resets to ‘‘0.0’’.
There are two trip meters: Trip A
and Trip B. The odometer and the
two trip meters use the same display.
Switch between these displays and
the odometer by pressing the select/
reset knob repeatedly. Each trip
meter works independently, so you can keep track of two dif f erent
distances.
Odometer T rip Meter
Gauges
Inst rument s and Cont rols
57
TEMPERATURE GAUGE TACHOMETER SPEEDOMETER FUEL GAUGE
ODOMETER/TRIP METER SELECT/RESET KNOB

This shows how much f uel you have.
It may show slightly more or less
than the actual amount. The needle
returns to the bottom after you turn
of f the ignition.(Odometer/trip meter message)
This shows the temperature of the
engine’s coolant. During normal
operation, the pointer should rise
from the bottom white mark to about
the middle of the gauge. In severe
driving conditions, such as very hot
weather or a long period of uphill
driving, the pointer may rise to near
the upper white mark. If it reaches
the red (Hot) mark, pull safely to the
side of the road. Turn to page f or
instructions and precautions on
checking the engines cooling system. If your f uel cap is loose or missing, a
‘‘CHECK FUEL CAP’’ message
appears as text in the odometer/trip
meter display after you start the
engine. Turn the engine of f and
conf irm the f uel cap is installed. If it
is, loosen the cap, then retighten it
until it clicks at least once. When you
restart the engine, the message
appears again. To clear the message,
press and hold the select/reset knob
until the message is replaced on the
odometer/trip meter display.
If the system still detects a loose or
missing f uel f ill cap, the malf unction
indicator lamp (MIL) comes on.
Turn the engine of f , and check or
retighten the f uel f ill cap until it
clicks at least once. The MIL goes
out af ter 3 days of normal driving
once the cap is tightened or replaced.
If it does not go out, have your
dealer inspect the vehicle. For more
inf ormation, see page .
214
217
Fuel Gauge
T emperature GaugeCheck Fuel Cap Indicator
Gauges
58
Avoid driving with an extremely low
f uel level. Running out of f uel could
cause the engine to misf ire, damaging
the catalytic converter.

ÎÎ
Î
Î
Î
ÎTo use the horn, press the center pad on the steering wheel.
If equipped.
1:
2:
Controls Near the Steering Wheel
Inst rument s and Cont rols
59
WINDSHIELD
WIPERS/WASHERS
REAR WINDOW DEFOGGER
HAZARD WARNING BUTTON
HEADLIGHTS/TURN SIGNALS INSTRUMENT PANEL BRIGHTNESS
(P.62)
(P.62)
(P.62)
(P.60)
HORNCRUISE CONTROL BUTTONS
(P.63) (P.128)
(P.127)
(P.79) STEERING WHEEL ADJUSTMENT
CRUISE CONTROL
MASTER SWITCH
MOONROOF SWITCH(P.61)
1 2
2
2

µ
µ
µ µ
µ µ
µ
µ
µ The wipers are not activated.
The wipers run at low speed.
The wipers run at high speed. Hold past ON to turn the rear
window wiper on and to spray the
rear window washer.
OFF
Rotate counterclockwise to turn
the window wiper on and the
window washer to spray.
The length of the wiper
interval is varied automatically
according to the vehicle’s speed.
Vary the delay by turning the INT
TIME ring. If you turn it to the
shortest delay, the wipers will
change to low speed operation
when the vehicle speed exceeds 12
mph (20 km/h).
Push the right lever up or down to
select a position. The wipers run at high
speed until you release the lever. Pull the
wiper control lever toward you and
hold it. The washers spray until
you release the lever. The wipers
run at low speed, then complete
one more sweep af ter you release
the lever. Rotate the switch clockwise to
turn the rear window wiper ON.
MIST
OFF
INT Intermittent
LO Low speed
HI High speed
Windshield washers
1.
2.
3.
4.
5.
6. 1.
2.
3.
4.
OFF
LO
HI
Rear Window Wiper and Washer
INT
MIST Windshield Wiper Windshield Washers
Windshield Wipers and Washers
60

µ
µ µ
Turning the switch to the ‘‘ ’’
position turns on the headlights. If
you leave the lights on with the key
removed f rom the ignition switch,
you will hear a reminder beeper
when you open the driver’s door. To turn on the high
beams, push the lef t lever f orward
until it clicks. The blue high beam
indicator will come on (see page ).
Pull it back to return to low beams.
To f lash the high beams, pull the
lever back lightly, then release it.
The high beams will stay on as long
as you hold the lever back.
Push down on the
lef t lever to signal a lef t turn and up
to signal a right turn. To signal a lane
change, push lightly on the lever,
and hold it. The lever will return to center when you release it or
complete a turn.
The headlights revert to normal
operation when you turn them on
with the switch. With the headlight switch off, the
high beam headlights come on with
reduced brightness when you turn
the ignition switch to the ON (II)
position and release the parking
brake. They remain on until you turn
the ignition switch of f , even if you
set the parking brake.
Turn signal
Of f
Parking and interior lights
Headlights
High beams
Flashhighbeams Turning the switch to
the ‘‘ ’’ position turns on the
parking lights, taillights, instrument
panel lights, side-marker lights, and
rear license plate lights.
1.
2.
3.
4.
5.
6. 54
Canadian model only
Turn Signal and Headlights Daytime Running L ights
High Beams
Turn Signal Headlights
Turn Signal and Headlights
Inst rument s and Cont rols
61

The knob on the instrument panel
controls the brightness of the
instrument panel. Turn the knob to
adjust the brightness.Pushtheredbuttontoturnonthe
hazard warning lights (f our-way
flashers). This causes all four
outside turn signals and both
indicators in the instrument panel to
f lash. Use the hazard warning lights
if you need to park in a dangerous
area near heavy traffic, or if your
vehicle is disabled.The rear window def ogger will clear
fog, frost, and thin ice from the
window. Push the def ogger button to
turn it on and off. The indicator in
the button comes on to show the
def ogger is on. If you do not turn it
of f , the def ogger will shut itself of f
af ter about 25 minutes. It also shuts
of f when you turn of f the ignition
switch. You have to turn it on again
when you restart the vehicle. Rear Window Def ogger
Instrument Panel Brightness Hazard Warning Button
Instrument Panel Brightness, Hazard Warning Button, Rear Window Def ogger
62

Make sure the rear window is clear
and you have good visibility bef ore
starting to drive.
Thedefoggerwiresontheinsideof
the rear window can be accidentally
damaged. When cleaning the glass,
always wipe side-to-side.Make any steering wheel adjustment
bef ore you start driving.
Push the lever under the steering
column all the way down. Move the steering wheel so it
points to your chest, not toward
your f ace. Make sure you can see
the instrument panel gauges and
indicators.
Push the lever up to lock the
steering wheel in position.
Make sure you have securely
locked the steering wheel in place
by trying to move it up and down.
1.
2.
3.
4.
Steering Wheel A djustment
Rear Window Def ogger, Steering Wheel A djustment
Inst rument s and Cont rols
63
Adjusting the steering wheel
position while driving may
cause you to lose control of the
vehicle and be seriously injured
inacrash.
Adjust the steering wheel only
when the vehicle is stopped.
