2006 Acura MDX Owner's Manual

Your vehicle has three accessory
power sockets. The f ront accessory
power socket is located under the
audio system. The second socket is
located in the center console
compartment. The rear socket is
behind the third seat on the driver’s
side.
Tousethesocketintheconsole
compartment, pull the cover up.
These sockets are intended to supply
power f or 12 volt DC accessories
that are rated 120 watts or less (10
amps).When both the front and console
sockets are being used, the
combined power rating of both
accessories should be 120 watts or
less (10 amps).
None of the sockets will power an
automotive type cigarette lighter
element.
To use an accessory power socket,
the ignition switch must be in the
ACCESSORY (I) or ON (II) position. A ccessory Power Sockets
Interior Convenience Items
104

The standard audio system has
many f eatures. This section
describes those f eatures and how to
use them. (If you selected an
optional audio system, ref er to the
operating instructions that came
with it.) The climate control system in your
vehicle provides a comfortable
driving environment in all weather
conditions.
Your vehicle has an anti-theft audio
system that requires a code number
to enable it..............
Vents, Heating, and A/C . 106
.............................
Airflow Buttons .107
...................
Rear Climate Control . 111
..............
Climate Control Sensors . 111
..........................
Playing the Radio .112
............................
Radio Reception .116
........
Playing XM
Satellite Radio . 118
..................................
Playing a CD .123
...................................
CD Changer .126
....................
Protecting Your CDs .128
.....
CD Changer Error Messages . 129
.............
Steering Wheel Controls . 130
.................
Radio Thef t Protection . 131
........
Rear Entertainment System . 132
............................
Security System .145
...............................
Cruise Control .146
..............................
Trip Computer .149
.
Rear View Camera and Monitor . 155
HomeLink Universal ................................
Transceiver .156
..........................
HandsFreeLink .161
............................................
OnStar .175
Features
Features
105
TM

Vents, Heating, and A/C
106
RECIRCULATION BUTTONTEMPERATURE DISPLAY
AUTO BUTTON
OFF BUTTON REAR A/C CONTROL
(Without Navigation System) (With Navigation System)
A/C
BUTTON
MODE
BUTTON FAN SPEED
BUTTONA/C
ICON FAN SPEED
ICONS
MODE
ICONS
WINDSHIELD
DEFROSTER
BUTTON
TEMPERATURE CONTROL BUTTONS
REAR WINDOW DEFOGGER BUTTON

ÚÜ
Û
Ý
The climate control system f or your
vehicle can also be operated using
the voice control system. See the
Navi section in your Quick Start
Guide f or an overview of this system,
and the Navigation System manual
f or complete details.
When the indicator in the button is
on, air f rom the vehicle’s interior is
recirculated throughout the system.
When the indicator is off, air is
brought in f rom the outside of the
vehicle (Fresh Air mode).
The outside air intakes f or the
heating and cooling system are at
the base of the windshield. Keep this
area clear of leaves and other debris.
Thesystemshouldbeleftinfresh
air mode under almost all conditions.
Keeping the system in recirculation
mode, particularly with the A/C of f ,
can cause the windows to fog up.
Switch to recirculation mode when
driving through dusty or smoky
conditions, then return to fresh air
mode.
Push the button to increase the
temperature of air f low. Push the
button to decrease it. When you set
the temperature to its lower limit or
its upper limit, the system runs at f ull
cooling or heating only. It does not
regulate the interior temperature.
This button or icon turns the air
conditioningonandoff.Youwillsee
A/C ON or A/C OFF in the display.
This button turns the rear window
def ogger on and of f (see page ).
Push the button or icon to
increase the f an speed and air f low.
Push the button or icon to
decrease it.
77Only on models equipped withNavigation System
Airflow Buttons
Voice Control System Recirculation Button
Temperature Control Buttons
Air Conditioning (A/C) Button/
Icon
Rear Window Def ogger Button
Fan Speed Control Button/Icon
Features
107

ÛÝÚ
Ü
The heater uses engine coolant to
warm the air. If the engine is cold, it
will be several minutes bef ore you
f eel warm air coming f rom the
system.
Select and Fresh Air mode.
Set the f an to the desired speed.
Adjust the warmth of the air with
the temperature control buttons.
Press the A/C-INFO button to
show the inf ormation screen.
Select the desired mode by
touching the MODE icon, and set
the f an to the desired speed by
touching the or icon.
Adjustthewarmthwiththe
temperature control buttons ( or).
Air f lows f rom the def roster
vents at the base of the windshield.
When you select , the system
automatically switches to f resh air
mode and turns on the A/C.
The f low-through ventilation system
draws in outside air, circulates it
through the interior, then exhausts it
through vents near the rear side
panels.
Set the temperature to maximum.
Make sure the A/C is of f .
Select and Fresh Air mode.
Set the f an to the desired speed.
Use the mode control button or icon
to select the vents the air flows from.
Regardless of what mode you
are in, air flows out of the corner
vents unless the system is shut of f or
the vent is manually shut of f .
Air flows from the center
vents in the dashboard.
Airf low is divided between
the vents in the dashboard and the
f loor vents.
Air f lows f rom the f loor
vents.
Airf low is divided between
the f loor vents and the def roster
vents at the base of the windshield. 1.
2.
3.
1.
2.
3.
4. 1.
2.
3.
Vehicles without Navigation System
Vehicles with Navigation System
Vents, Heating, and A/C
Using the Heater
Ventilation
Mode Control Button/Icon
108
NOTE:

When you switch to another mode
f rom , the A/C turns of f . But
if it was on to start with, it stays on. This setting is suitable f or all driving
conditions whenever the outside
temperature is above 32°F (0°C).
To remove f og f rom the inside of the
windows:Set the f an to the desired speed, or
high f or f aster def rosting.
Select . The system
automatically switches to Fresh
Air mode and turns on the A/C.
The A/C indicator will not come
on in U.S. vehicles, if the A/C was
off to start with.
Adjust the temperature so the
airflow feels warm.
Select to help clear the
rear window.
To increase airf low to the
windshield, close the corner vents.
you can
cool it down more rapidly by partially
opening the windows, turning on the
A/C, and setting the fan to
maximum speed in f resh air mode.
The vehicle has two A/C and
heater units. Both these units are
controlled by the f ront panel controls,
unless the RR A/C button is turned
on. The rear passengers can also
adjust the direction, and temperature
and amount of the airf low.
Air conditioning, as it cools, removes
moisture from the air. When used in
combination with the heater, it
makes the interior warm and dry.
Switch the f an on.
Turn on the air conditioning.
Select and Fresh Air mode.
Adjust the temperature to your
pref erence.
Air conditioning places an extra load
on the engine. Watch the engine
coolant temperature gauge (see page
). If it moves near the red zone,
turn of f the A/C until the gauge
reads normally.
Turn on the A/C by pressing the
A/CbuttonortouchingtheA/C
icon on the models with navigation
system. A/C ON will be displayed
on the screen.
Make sure the temperature is set
to maximum cold.
Select .
If the outside air is humid, select
Recirculation mode. If the outside
air is dry, select Fresh Air mode.
Set the f an to the desired speed. 1.
2.
3.
4.
69
1.
2.
3.
4.
5. 1.
2.
3.
4.
5.
If the interior is very warm,
Vents, Heating, and A/C
To Def og and Def rost
Dehumidif y the Interior
Using the A/C
Features
109
NOTE:

The Automatic Climate Control
system can adjust the f an speed and
airflow levels to maintain the interior
temperature you select.Press the AUTO button.
Set the desired temperature with
the temperature control buttons.
You will see FULL AUTO in the
system’s display.
The system automatically selects the
proper mix of conditioned and/or
heated air that will, as quickly as
possible, raise or lower the interior
temperature f rom its current level to
the set temperature. In FULL AUTO
the rear A/C control panel cannot be
used. In cold weather, the f an will not
come on automatically until the
heater starts to develop warm air.
You can manually select various
f unctions of the Climate Control
system when it is in FULL AUTO.
All other f eatures remain
automatically controlled.
Manually selecting a f unction causes
thewordFULLinthedisplaytogo
out.
Press the OFF button. However, a
lack of airf low can cause the
windowstofogup.Youshouldkeep
the fan on at all times so stale air and
moisture do not build up in the
interior and cause fogging.
If you set the temperature to its
lower or its upper limit, the system
runs at f ull cooling or heating only. It
does not regulate the interior
temperature.
Select . The system
automatically switches to Fresh
Air mode and turns on the A/C.
The A/C indicator will not come
on in U.S. vehicles, if the A/C was
off to start with.
Select .
Set the f an and temperature
controls to maximum level.
For your saf ety, make sure you have
a clear view through all the windows
bef ore driving. To clear the windshield f aster, you
can close the dashboard corner vents
by rotating the wheel below each
vent. This sends more warm air to
the windshield def roster vents. Once
the windshield is clear, select Fresh
Air mode to avoid f ogging the
windows. 1.
2.
1.
2.
3.
Vents, Heating, and A/C
T o Remove Exterior Frost or Ice
From the Windows
Manual Operation
To Turn Everything Off
Using A utomatic Climate Control
110

Press the RR A/C MANUAL button
to enable the rear A/C control panel.
The indicator in the button will come
on. A passenger in the second row
can then use the temperature control
dial, f an speed dial, and mode
buttons to adjust the temperature
and airflow to their preference. This
is limited by the system’s minimum
and maximum temperature.Individual rear control
settings are shut off when the
ignition is turned off and return to
the automatic settings. They must be
reset when the ignition is turned on
again.
Theclimatecontrolsystemhastwo
sensors. A sunlight sensor is in the
top of the dashboard, and a
temperature sensor is next to the
steering column. Do not cover the
sensors or spill any liquid on them.
Rear Climate Control, Climate Control Sensors
Using the Rear A /C Unit Climate Control Sensors
Features
111
NOTE:
TEMPERATURE SENSOR
TEMPERATURE CONTROL DIAL
MODE BUTTONS
FAN SPEED CONTROL DIAL
