2006 ACURA CSX navigation


(#'#


 ) Î
(#'#


 )
23-35823-358 Navigation System
HFL-Navigation Microphone
Removal/Installation
GPS Antenna Removal/Installation
B
E
D
A C
B
A
A B A
B
1. Remove the front individual map light lens (A).
2. Remove the bolts (B), then disconnect the
connectors, and remove the map lights housing (C).
3. Carefully pry off the moonroof switch (D) from the map light housing while pressing in on the
retaining tabs (E).
4. From the moonroof switch (A), remove the screw and microphone (B).
5. Install the microphone in the r everse order of
removal. 1. Remove the navigation unit (see page 23-355).
2. Remove the instrument panel visor (see page
20-98).
3. Remove the wire harness clip (A), screws, and GPS antenna (B).
4. Install the antenna in the reverse order of removal.
08/08/21 14:18:35 61SNR030_230_0361
ProCarManuals.com
DYNOMITE -2009-

Î
(#'#
)
23-359
HandsFreeLink System
Component Location Index
HFL-NAVIGATION MICROPHONE
(Built into the roof console)
HANDSFREELINK
CONTROL UNIT HFL VOLUME
(Using navigation
unit volume knob)
HFL SWITCH
LEFT FRONT
TWEETER
FRONT PASSENGER’S
DOOR SPEAKER
NAVIGATION UNIT
DRIVER’S DOOR
SPEAKER RIGHT FRONT
TWEETER
Removal/Installation, page 23-358
Input Test/Replacement, page 23-388
Test, page 23-387 Removal/Installation, page 23-355
08/08/21 14:18:36 61SNR030_230_0362
ProCarManuals.com
DYNOMITE -2009-

Navigation Through Menus
23-362HandsFreeLink System
General Troubleshooting Information (cont’d)
Many issues result from the client not using the system
properly. Make sure the client is using the HFL buttons
and not the navigation buttons. When the HFL TALK
button is pressed, the client hears one audible tone.
When the HFL BACK button is pressed, the client hears
two audible tones. Make sure to press the HFL BACK
button to exit the HFL main menu after completing a
call and before giving any navigation commands.
The HFL system may experience a number recognition
issue, such as when a client says a set of numbers in a
group unrecognized by the system. The HFL system
understands phone numbers in specific blocks of 1, 3, 4,
7, and 10 numbers. For example, the system
understands:
1234567890
123-456-7890
1-2-3-4-5-6-7-8-9-0
The system may become confused if numbers are
stated in other blocks, as following: 1234-567-890
12-34-56-78-90
12345-67890
123-4567-890 To skip a voice prompt, press and release the HFL TALK
button while the HFL system is speaking. The system
beings listening for your next voice command.
To go back a step in a voice command sequence, press
and release the HFL BLACK button, or press the HFL
TALK button and say ‘‘Go back.’’ If you
don’t say
anything while the HFL system is listening for your
voice command, it times out and stops voice
recognition. The next time you press and release the
HFL TALK button, the HFL system begins listening from
the point it timed out.
If you’ve finished or want to stop a voice command
sequence at any time, press and release the HFL BACK
button, or press and release the HFL TALK button, wait
for the beep, and say ‘‘Cancel.’’ The next time you press
and release the HFL TALK button, the HFL system
begins from its main menu. To avoid keeping the audio
system muted, press and release the HFL BACK button
when you are finished.
NOTE: You can say multiple commands in one
sequence, like ‘‘Phone setup-pair’’ after pressing the
HFL TALK button.
08/08/21 14:18:37 61SNR030_230_0365
ProCarManuals.com
DYNOMITE -2009-

Pairing TroubleshootingPairing Checks
23-364HandsFreeLink System
General Troubleshooting Information (cont’d)
Many pairing issues are resolved by altering the client’s
phone settings.
Bluetooth feature settings must be turned on. Phone
manufacturers set the default to disable Bluetooth
features to conserve battery life. Cell phones may
provide procedures to Temporary Power On Bluetooth,
or Power On Bluetooth. Turn the Bluetooth feature on,
pair the phone to the vehicle, and confirm the phone is
linked. Do this by turning the phone off and back on.
Make or receive a call to confirm that the cell phone is
successfully paired.
When the phone’s Bluetooth feature is on, other
handsfree accessories such as earpieces or headsets
may automatically reconnect to the phone when you
turn on the accessory or move it within range of the cell
phone. This results in the phone not connecting to the
HFL system when the client’s enters the vehicle. You
must unlink the hands-free accessory from the phone
before the HFL system can reconnect.
Some phones have an Auto Answer setting that
functions with a headset. This setting must be turned
off or the HFL system cannot accept any incoming calls.
When this setting is on, it blocks the HFL system from
answering the call, and the call goes to voice mail. This
can cause the client to think that the cell phone is not
paired properly.
If the HFL system has six phones paired, it will not tell
you that it has reached its maximum, and will not allow
you to pair a new phone. To check how many phones
are paired, press and release the HFL TALK button.
After the beep, say ‘‘Phone setup list.’’ The HFL system
lists every assigned
phone name paired with it, then
finishes by saying ‘‘The entire list has been read.
Returning to the main menu.’’ Count the number of
phones listed. If there are six, you must delete one
phone before adding a new one. For more information about pairing, refer to the cell
phone owner’s manual, or go to handsfreelink.com.
1. Is the cell phone compatible with the HFL?
2. Is the Bluetooth feature turned on?
3. Is the client using the HFL buttons, not the navigation buttons, when pairing?
4. Is the cell phone battery fully charged, and is there good signal strength when pairing?
5. Do a soft reset on the cell phone.
6. If the client is trying to pair a Blackberry
or Palm
Treo device, make sure the client uses the shift
key when entering the pass code. If the shift key is
not pressed, the client may be entering letters. The
HFL does not recognize letters.TM
08/08/21 14:18:37 61SNR030_230_0367
ProCarManuals.com
DYNOMITE -2009-

Phone Will Not Automatically Connect the
HFL
Incoming Calls
23-366HandsFreeLink System
General Troubleshooting Information (cont’d)
Many reasons for a dropped call are not related to the
HFL system. Here are some causes for dropped calls:
 If the quantity of dropped calls is about the same when the client uses the HFL system versus the
handset, the issue is likely due to the cellular phone
or carrier.
 If the phone is equipped with a retractable antenna, it needs to be extended to maximize signal strength.
 If a client also notices that the calls tend to drop in the same areas, the HFL system may be operating
normally, but something about the area diminishes
cellular coverage to a point where the call drops.
 Hills or m ountains can block or interfere with cellular
signals.
 High-rise buildings, bridges, or other large structures may block or interfere with cellular signals.
 Placing the cell phone in a purse, in a metal briefcase, under the seat, in the glove box, or in the trunk can all
affect signal reception.
 There are coverage gaps in the cellular service. When driving, a call is typically passed from one tower to
another. If the client drives through an area where
there is a coverage gap between towers, the call
drops.
 Electrical storms, heavy rain, or overcast c onditions
interfere with signal strength.
 The cell phone battery’s state of change can affect signal reception. A low battery may reduce the
phone’s ability to boost the antenna’s power and
function properly, especially in low signal strength
areas. Some phone manufacturers trade off signal
transmission and reception strength for battery life.
As the battery weakens, the signal strength may also
weaken. Some cell phones may operate more
effectively than others in low signal strength areas,
especially with a partially charged battery, and
depending on whether or not the retractable antenna
is fully extended (if applicable). On these models,
make sure the antenna is always extended to
maximize signal strength and extend battery life. If a client complains that their cell phone is not
automatically connecting to the HFL system when they
enter the vehicle, do this:
1. Make sure the Bluetooth feature is turned on in the cell phone.
2. Make sure the cell phone is properly painted to the HFL system.
3. Do a soft reset to the cell phone.
4. Check if the phone has an Authorized Connection or Trusted option.
5. Check the battery and signal strength on the cell phone. Pairing a phone requires optimal signal
strength and a nearly full battery.
If a client complains that they cannot receive incoming
calls through the HFL system, see if the call is routing to
the cell phone instead of the HFL system. An easy way
to know if the call is routed to the cell phone is when the
client says, ‘‘I can’t hear the caller, but they can hear me.’’ 1. Make sure the Bluetooth feature is turned on in the cell phone.
2. Make sure the cell phone is paired to the HFL system and linked.
3. Make sure the answer settings in the cell phone are set to multi-key or any-key answer. If the phone is
set to flip open to answer, recommend changing
the setting to Any Key or leaving the phone flipped
open when using the HFL system.
4. Make sure the Auto Answer feature is turned off in the cell phone.
5. Do a soft reset to the phone.
6. Make sure the battery is fully charged and there is adequate signal strength.
7. Ask the client if they have set specific ring tones or ringer IDs to specific contacts. If they have,
recommend using one standard ring tone for all
calls.
8. Make sure the client is pressing the HFL TALK button and not the HFL BACK button or the
navigation buttons.
08/08/21 14:18:37 61SNR030_230_0369
ProCarManuals.com
DYNOMITE -2009-

Outgoing CallsClearing the HFL System
23-367
If a client says that they cannot place a call using the
HFL system, ask if the call was initiated through the HFL
system or the cell phone itself.
IfthecallisplacedbytheHFLsystem:
1. Make sure the Bluetooth feature is turned on in the cell phone.
2. Make sure the cell phone is paired to the HFL system and linked.
3. Make sure the client is pressing the HFL TALK button before each command and going through
the calling process correctly.
4. Make sure the client is pressing the HFL TALK button and not the HFL BACK button or the
navigation buttons.
5. Check if the cell phone has an Authorized Connections or Trusted option.
6. Do a soft reset to the cell phone.
If the call is placed by the cell phone:
The call will remain on the handset until you transfer it
over to the HFL system. To continue the call on the HFL
system, you must use the Transfer command by
pressing and releasing the HFL TALK button during an
active call and saying ‘‘Transfer.’’ The client can now
continue the call using the HFL system. NOTE:
 This operation clears the HFL system of all passcode(s), any paired phones, and all names in the
HFL phonebook.
 Clearing the HFL system is recommend before selling the vehicle.
 If the system is locked and the pass code is lost or forgotten, see the symptom troubleshooting.
1. Press and release the HFL TALK button. After the beep, say ‘‘System clear’’ and the HFL system
responds, ‘‘This process will clear all paired phone,
clear all entries in the phonebook, clear the
passcode and restore all defaults in the system
setup. Is this what you would like to do?’’
2. Press and release the HFL TALK button. After the beep, say ‘‘Yes’’ and the HFL system responds,
‘‘Preparing to clear all paired phone, all phonebook
entries, the passcode. This may take up to 2
minutes to complete’’.
3. Press and release the HFL TALK button. After the beep, say ‘‘OK’’ to proceed, or say ‘‘Go back’’ or
‘‘Cancel’’.
4. If you said ‘‘OK’’, after a short period of time, the HFL system responds, ‘‘System has been cleared.
Returning to the main menu, the Clearing HFL
system procedure is now complete’’.
(cont’d)
08/08/21 14:18:38 61SNR030_230_0370
ProCarManuals.com
DYNOMITE -2009-

(#'#
)
Symptom Diagnostic procedure Also check for
23-371
Symptom Troubleshooting Index
HFL does not respond
Control Unit Input Test
(see page 23-388) Check and repair all CAN related DTCs
The Bluetooth icon in the
navigation display is grayed-out There is no HFL-compatible
phone paired to the vehicle. Pair
an approved HFL-compatible
phone to the vehicleThe phone must be on the Honda list of
approved Bluetooth phones and
configured correctly. For a current list of
approved phones, go to www.acura.com/
handsfreelink, or call 888-528-7876 for
further assistance.
Check the Diagnostic Menu and use the
Navi System Link
The Honda approved Bluetooth
phone is having problems pairing
to the vehicle HFL System Troubleshooting
(see page 23-373)
The phone must be on the Honda list of
approved Bluetooth phones and
configured correctly. For a current list of
approved phones, go to www.acura.com/
handsfreelink, or call 888-528-7876 for
further assistance.
Check the Diagnostic Menu and use the
Navi System Link
The Honda approved Bluetooth
phone cannot use all its functions HFL System Troubleshooting
(see page 23-373)The phone must be on the Honda list of
approved Bluetooth phones and
configured correctly. For a current list of
approved phones, go to www.acura.com/
handsfreelink, or call 888-528-7876 for
further assistance.
Check the Diagnostic Menu and use the
Navi System Link
The Honda approved Bluetooth
phone does not place or receive
calls using the HFL system HFL System Troubleshooting
(see page 23-373)
The phone must be on the Honda list of
approved Bluetooth phones and
configured correctly. For a current list of
approved phones, go to www.acura.com/
handsfreelink, or call 888-528-7876 for
further assistance.
Check the Diagnostic Menu and use the
Navi System Link
The client wants the HFL system
reset (all phones and address
information cleared from the HFL
system) Clearing the system (see page
23-367)
See the owner’s manual for additional
information.
The HFL system is locked and the
pass code has been lost or
forgotten Symptom Troubleshooting
(see page 23-383)
The HFL system does not
recognize all voice prompts Symptom Troubleshooting
(see page 23-382)Also see Voice control tips.
The address book does not
transfer from Honda approved
Bluetooth phone to HFL system There is no HFL compatible
phone paired to the vehicle or
the approved phone does not
support the function. Pair an
approved HFL compatible
phone to the vehicle.The phone must be on the Honda list of
approved Bluetooth phones and
configured correctly. For a list of approved
phones, go to www.acura.com/
handsfreelink, or call 888-528-7876.
The HFL messages cannot be
heard or are weak Symptom Troubleshooting
(see page 23-383)Excessive interior noise (open windows,
vents blowing on microphone, etc.).
The Bluetooth icon does not
display (the Bluetooth phone is
linked) Symptom Troubleshooting
(see page 23-386)
08/08/21 14:18:38 61SNR030_230_0374
ProCarManuals.com
DYNOMITE -2009-

´´
µ ´
µ
´
µ
Î
Î
(#'#
)
HandsFreeLink Control Unit Inputs and Outputs
HANDSFREELINK CONTROL UNIT 28P CONNECTOR
Cavity Wire Color Connect to
23-372 HandsFreeLink System
System Description
HANDSFREELINK CONTROL UNIT 28P CONNECTOR
1 BLK Body ground to G501 (GND)
2 BLU HFL switch (HFL STRG SW)
3 LT BLU Navigation unit (HFL MUTE)
6 WHT Navigation unit (HFL/NAVI COMM4)
7 RED Navigation unit (HFL/NAVI COMM3)
8 GRY Shield for terminals No. 6, No. 7, No. 20, and No. 21 (HFL/NAVI COMM SH)
11 BLU Navigation unit (TELM SIG )
12 GRY Shield for terminals No. 13 and No. 14 (MIC SH)
13 YEL HFL-navigation microphone (MIC )
14 BRN HFL-navigation microphone (MIC )
15 WHT No. 23 (10 A) fuse in the under-dash fuse/relay box ( B)
16 PUR No. 35 (7.5 A) fuse in the under-dash fuse/relay box (ACC)
18 PNK B-CAN communication (B-CAN)
19 LT GRN Navigation unit (HFL icon)
20 BLK Navigation unit (HFL/NAVI COMM1)
21 GRN Navigation unit (HFL/NAVI COMM2)
25 PNK Navigation unit (TELM SIG )
26 GRY Shield for terminals No. 11 and No. 25 (TELM SIG SH)
27 GRN Navigation unit (MIC SIG )
28 RED Navigation unit (MIC SIG )
: The shielded wires have a heat-shrunk tube insulating the outside of the wire. The color of the insulating tube, typically black or dark gray, may not match the color of the wire listed on the schematic.
Wire side of female terminals
08/08/21 14:18:38 61SNR030_230_0375
ProCarManuals.com
DYNOMITE -2009-
