14-268A/T Gear Position Indicator
Transmission Range Switch Replacement (cont’d)
A
C
B
6x1.0mm
12 N·m (1.2 kgf·m, 8.7 lbf·ft) 6x1.0mm
12 N·m (1.2 kgf·m, 8.7 lbf·ft)A
7. Install the transmission range switch (A) gently on
the selector control shaft (B) while holding it in the
N position with the 2.0 mm (0.08 in.) blade (C).
8. Tighten the bolts on the transmission range switch while you continue to holding the N position. Do
not move the transmission range switch when
tightening the bolts. Remove the feeler gauge. 9. Check the connectors for rust, dirt, or oil, clean or
repair if necessary, then connect the connector
securely.
10. Turn the ignition switch to ON (II). Move the shift lever through all positions, and check the
transmission range switch synchronization with the
A/T gear position indicator.
11. Check that the engine will start with the shift lever in P and N, and will not start in any other shift lever
position.
12. Check that the back-up lights come on when the shift lever is in R.
13. Allow the front wheels to rotate freely, then start the engine, and check the shift lever operation.
14. Install the transmission range switch cover (A).
08/08/21 14:49:03 61SNR030_140_0270
ProCarManuals.com
DYNOMITE -2009-



Wheel Bearing Replacement
18-18Front Suspension
Knuckle/Hub/Wheel Bearing Replacement (cont’d)
A
B
C
Except Type S model:
07GAF-SE00100
Type S model:
07GAF-SD40100
C Press
D D
A
B C
Except Type S model:
07GAF-SE00100
Type S model:
07GAF-SD40100
Press
17. Install the knuckle/hub in the reverse order of
removal, and note these items:
 First install all of the components, and lightly tighten the bolts and the nuts, then raise the
suspension to load it with the vehicle’s weight
before fully tightening to the specified torque
values.
 Be careful not to damage the ball joint boot when connecting the knuckle.
 Before connecting the lower ball joint to the knuckle, degrease the threaded section and the
tapered portion of the ball joint pin, the ball joint
connecting hole, the threaded section, and the
mating surfaces of the castle nut.
 Torque the castle nut to the lower torque specification, then tighten it only far enough to
align the slot with the ball joint pin hole. Do not
align the castle nut by loosening it.
 Use a new spindle nut during reassembly.
 Before installing the spindle nut, apply a small amount of engine oil to the seating surface of the
nut. After tightening, use a drift to stake the
spindle nut shoulder against the driveshaft.
 Before installing the brake disc, clean the mating surfaces of the front hub and the inside of the
brake disc.
 Before installing the wheel, clean the mating surfaces of the brake disc and the inside of the
wheel.
18. Check the wheel alignment, and adjust it if necessary (see page 18-5). 1. Separate the hub (A) from the knuckle (B) using the
hub dis/assembly tool and a hydraulic press. Hold
the knuckle with the attachment (C) of the hydraulic
press or equivalent tool. Be careful not to damage
or deform the splash guard (D). Hold onto the hub
to keep it from falling when pressed clear.
2. Press the wheel bearing inner race (A) off of the hub (B) using the hub dis/assembly tool, a
commercially available bearing separator (C), and a
press.
08/08/21 14:56:51 61SNR030_180_0018
ProCarManuals.com
DYNOMITE -2009-

(#'
) Component Inspections:Component Procedure Also check for
Brake pedal sinks/fades when braking
Brake System Test
19-4 Conventional Brake Components
Brake System Inspection and Test
Inspect the brake system components listed. Repair or replace any parts that are leaking or damaged.










Master Cylinder Look for damage or signs of fluid leakage at:
Reservoir tank, subreservoir or master
cylinder body.
Lines, reservoir tank hose and grommets,
and their joints.
Between master cylinder and booster. Bulging seal at reservoir cap. This is a
sign of fluid contamination.
Brake Hoses Look for damage or signs of fluid leakage at: Line joints and banjo bolt connections.
Hoses and lines, also inspect for twisting or
damage. Bulging, twisted, or bent lines.
Caliper Look for damage or signs of fluid leakage at: Piston seal.
Banjo bolt connections.
Bleed screw. Seized or sticking caliper pins.
ABS or VSA
Modulator-control
Unit Look for damage or signs of fluid leakage at:
Line joints.
Modulator-control unit.
1. Set the parking brake, and start the engine, then turn off the A/C. Allow the engine to warm up to normal operating temperature (radiator fan comes on twice).
2. Attach a 50 mm (2 in.) piece of masking tape along the bottom of the steering wheel, and draw a horizontal reference mark across it.
3. With the transmission in neutral (M/T) or P or N (A/T), press and hold the brake pedal lightly (about the same pressure needed to keep an A/T-equipped vehicle from creeping), then release the parking brake.
4. While still holding the brake pedal, hook the end of the tape measure behind the brake pedal, then pull the tape up to the steering wheel. Note the measurement between the brake pedal and the reference mark on the steering
wheel.
5. Apply steady pressure to the brake pedal for 3 minutes.
6. Watch the tape measure.  If the measurement increases 10 mm (0.39 in.) or less, the master cylinder is OK.
 If the measurement increases more than 10 mm (0.39 in.), replace the master cylinder.
08/08/21 15:00:49 61SNR030_190_0004
ProCarManuals.com
DYNOMITE -2009-


(#'


)
Functional Test
Leak Test
19-26 Conventional Brake Components
Brake Booster Test
A
1. With the ignition switch in LOCK (0), press the
brake pedal several times to deplete the vacuum
reservoir, then press the brake pedal hard, and hold
it for 15 seconds. If the brake pedal sinks, either the
master cylinder is bypassing internally, or the
brake system is leaking. Inspect the brake hoses
and lines (see page 19-37).
2. Start the engine with the brake pedal pressed. If the brake pedal sinks slightly, the vacuum booster is
operating normally. If the brake pedal height does
not vary, do the brake system test (see page 19-4).
1. Press the brake pedal with the engine running, then stop the engine. The brake pedal height should not
vary while pressed for 30 seconds.
 If the pedal height rises, go to step 6.
 If it does not rise, go to step 2.
2. Start the engine and let it idle for 30 seconds. Turn the ignition switch to LOCK (0), and wait
30 seconds. Press the brake pedal s everal times
using normal pressure. When the pedal is first
pressed, it should be low. On consecutive
applications, the pedal height should gradually rise.
Does the pedal rise on each consecutive
application?
 If it rises the booster is OK.
 If it does not rise, go to step 3. 3. Disconnect the brake booster vacuum hose (A) at
the booster. The check valve is built into the hose.
NOTE: If the check valve is faulty, replace the brake
booster vacuum hose/check valve as an assembly.
4. Start the engine, and let it idle. There should be vacuum available.
 If no vacuum is available, the check valve is not working properly. Replace the brake booster
vacuum hose and check valve, and retest.
 Ifthereisvacuum,gotostep5.
5. With the ignition switch in LOCK (0), reconnect the vacuum hose to the brake booster.
6. Start the engine, and then pinch the brake booster vacuum hose between the check valve and the
booster.
7. Turn the ignition switch to LOCK (0), and wait 30 seconds. Press the brake pedal several times
using normal pressure. When the pedal is first
pressed, it should be low. On consecutive
applications, the pedal height should gradually rise.
 If the pedal position does not vary inspect the seal between the master cylinder and booster. If
the seal is OK, replace the brake booster.
 If the pedal position varies, replace the brake booster vacuum hose/check valve as an
assembly.
08/08/21 15:01:00 61SNR030_190_0026
ProCarManuals.com
DYNOMITE -2009-

Displaying Sensor Inputs at the Climate Control Unit
Check these items before using the sensor input display mode
To run the sensor input display mode, follow these steps
21-13
The climate control unit has a mode that displays the sensor inputs it receives. This mode shows you what data the
climate control unit is receiving from each of the sensors, one at a time, and it can help you determine if a sensor is
faulty.1. Turn the ignition switch to ON (II), and check the recirculation door function; press the recirculation button to switch from FRESH to RECIRC. The air volume and sound should change slightly.
2. Set the temperature control knob to the desired test temperature. When selecting the test temperature, note these items:
 ‘‘Lo’’ temperature setting will default to MAX COOL, VENT, and RECIRC.
 ‘‘Hi’’ temperature setting will default to MAX HOT, FLOOR, and FRESH.
 19 through 31 °C settings will use the automatic climate control logic.
3. Turn the ignition switch to LOCK (0).
1. Turn the ignition switch to LOCK (0).
2. Press and hold both the AUTO and MODE buttons, then start the engine.
3. After the engine starts, release both buttons. The display panel will flash the sensor number and then the value for that sensor. Record the value displayed.
4. To advance to the next sensor, press the A/C button. Sensor Item Displayed Value1 Mode Positioning BIT
2 In-car Temperature °C
3 Outside Air Temperature °C
4 Solar Radiation Sensor Value: Dark = 00, Flashlight = 04, Cloudy = 10, Sunny = 65 10 kcal/m ·h
5 Evaporator Outlet Air Temperature °C
6 Air Mix Opening (Low value indicates cooler air distribution, higher value indicates warmer air distribution) % of opening
7 Recirculation Opening % of opening
8 Vehicle Speed (Vehicle must be driven to display speed) km/h
9 Engine Coolant Temperature °C
A Vent Temperature Air Out (TAO) °C
NOTE:  The sensor values will be displayed in degrees Celsius (°C) or an alphanumeric code. Use the chart to convert the value to degrees Fahrenheit (°F).
 If the sensor value displays ‘‘Er’’ this indicates there is an open or short in the circuit or sensor. Check for DTCs using the HDS, or use the climate control self-diagnostic function.
 If necessary, compare the sensor input display to a known-good vehicle under the same test conditions.
 If the sensor is out of the normal range, refer to the sensor test or substitute a known-good sensor, and recheck.
5. To cancel the sensor input display mode, press the AUTO button or turn the ignition switch to LOCK (0). (cont’d)
2
08/08/21 14:40:58 61SNR030_210_0014
ProCarManuals.com
DYNOMITE -2009-

µ
(#'
)
GroundComponent or Circuit Grounded
22-64Ground Distribution
Ground to Components Index
G1 Battery
G2 Engine
G3 Transmission housing
G101 A/T clutch pressure control solenoid valves A, B, C (A/T), CKP sensor, CMP sensor A, CMP sensor B, Data link connector (DLC), ECM/PCM (LG1), ECM/PCM (LG2), ECM/PCM (PG1), ECM/PCM (PG2), ECM/PCM (PGMETCS), EGR valve (K20Z2 engine), Ignition
coils, Immobilizer-keyless control unit, Rocker arm oil control solenoid, Rocker arm oil pressure switch, Transmission range
switch (A/T), VTC oil control solenoid valve
Shielding between the ECM/PCM and Knock sensor (KS) has wire.
Shielding between the ECM/PCM and Secondary HO2S (Sensor 2) has wire.
G201 Right fog light , Right front parking light, Right front side marker light, Right front turn signal light, Right headlight (high/low beams), Right HID unit , Windshield washer motor, Windshield wiper motor
G202 ABS modulator-control unit , VSA modulator-control unit
G301 A/C condenser fan motor, Blower motor relay, ELD, Left fog light , Left front parking light, Left front side marker light, Left front turn signal light, Left headlight (high/low beams), Left HID unit , Radiator fan motor (via fan control relay)
G401 Brake fluid level switch, Clutch interlock switch (M/T), Clutch pedal position switch (M/T), Hood switch, MICU (PG), Power transistor, Washer fluid level switch (G401 connects to G601 via under-dash fuse/relay box)
G402 EPS control unit
G403 Torque sensor
G501 Dash lights brightness controller and odometer select/reset switch, Driver’s door key cylinder switch, Driver’s door lock knob switch, HandsFreeLink control unit , MICU (SG), VSA OFF switch
G502 Data link connector (DLC), Front accessory power socket, Glove box light, Right power mirror defogger, Right side turn signal light
G503 Accessory power socket relays (front and console), Driver’s door lock switch, Gauge control module (tach), Left power mirror defogger, Left side turn signal light, Moonroof control unit/motor, Power mirror switch light, Power mirror switch, Power
window master switch (main switch), Power window master switch, Vanity mirror lights (driver’s and front passenger’s)
G504 Cable reel (steering wheel switches ground), Climate control unit, Front passenger’s door lock knob switch, Front passenger’s door lock switch, Gauge control module (speedo), Gauge control module (tach), Ignition key switch, Navigation unit , TPMS
control unit
G505 Audio unit , Navigation unit
G506 Memory erase signal (MES) connector, SRS unit (2 wires)
G601 A/T gear position console panel light/Park-pin switch (A/T), Console accessory power socket , Fuel pump, MICU (PG), Seat heater relays (driver’s and front passenger’s), Seat heater switches (driver’s and front passenger’s), Seat heaters (driver’s and
front passenger’s), Stereo amplifier (G601 connects to G401 via under-dash fuse/relay box)
Shielding between the left side impact sensor (FIRST) and rear safing sensor has wire.
Shielding between the SRS unit and left side impact sensor (FIRST) has wire.
G602 Driver’s seat belt buckle switch, Front passenger’s seat belt buckle switch, Left rear door lock knob switch, MICU (SG), MICU service check connector, ODS unit, Right rear door lock knob switch, Yaw rate-lateral acceleration sensor
Shielding between the right side impact sensor (FIRST) and right side impact sensor (SECOND) have wires.
Shielding between the SRS unit and right side impact sensor (FIRST) has wire.
G603 Noise condenser Shielding between the rear safing sensor and left side impact sensor (SECOND) has wire.
G701 High mount brake light, Left back-up light, Left inner taillight, Left rear side marker light, Left rear turn signal light, Left taillight/ brake light, License plate lights, Right back-up light, Right inner taillight, Right rear side marker light, Right rear turn signal light,
Right taillight/brake light, Trunk lid release actuator/Trunk lid latch switch
G801 Rear window defogger ( )
1: ’06-07 Touring and Premium models
2: ’07 TYPE S and ’08-09 models
3: ’08-09 models
4: TYPE S and ’08 premium and ’09 models
5: With HID
6: Without navigation system
7: With navigation system
8: ’09 model with navigation system
9: ’06-08 models, and ’09 model without navigation system
10: TYPE S model
4
512 4
5
82 3
7
3
67
9
10
2
08/08/21 14:24:03 61SNR030_220_0066
ProCarManuals.com
DYNOMITE -2009-

Î
(#'


)
22-163
MICU Input Test
UNDER-DASH FUSE/RELAY BOX CONNECTOR E (42P)
BLK RED
GRN WHT
ORN
PNKPUR
WHT
GRY LT BLU UNDER-DASH FUSE/RELAY BOX CONNECTOR F (34P)
UNDER-DASH FUSE/RELAY BOX CONNECTOR G (21P)
UNDER-DASH FUSE/RELAY BOX CONNECTOR S (20P) UNDER-DASH FUSE/RELAY BOX CONNECTOR T (34P) BLK
BLK BLK
RED
RED
RED ORN
PNK BLK
NOTE:
 The MICU turns on the headlights (high beams) in a dimming mode for the Daytime Running Lights under the following conditions:
– With the ignition switch turned to ON (II)
– The headlight switch OFF
– The parking brake is released (parking brake switch OFF)
 The DRL indicator will come on when one of the headlight (high beams) bulbs is blown, or if the high beam wiring has an open circuit with the daytime running lights ON.
 If the vehicle is equipped with an optional remote control engine start system, the daytime running lights will not function when started with the remote start.
1. Before testing the lighting system, troubleshoot the system using B-CAN System Diagnosis Test Mode A (see page 22-93).
2. Check the No. 12 (10 A), No. 13 (10 A), No. 15 (7.5 A), No. 16 (15 A) , (10 A) , No. 17 (15 A) , (10 A) , No. 18 (20 A), No. 19 (15 A), No. 21 (30 A) , (20 A) , and No. 37 (7.5 A) fuses in the under-dash fuse/relay box. If any fuse
is blown, replace it and go to step 3.
1: With HID
2: Without HID
3. Disconnect under-dash fuse/relay box connectors E, F, G, S, and T. NOTE: All connector views are shown from wire side of female terminals.
(cont’d)
1212
12
08/08/21 14:26:58 61SNR030_220_0165
ProCarManuals.com
DYNOMITE -2009-

Î
(#'#
)
µ
µ
µ
µ
µ
µ µ
µ
µ
µ
Poor AM or FM radio reception or
interference (with navigation)
YES
NO
YES
NO
YES
NO YES
NO
YES
NO
23-29
Symptom Troubleshooting
A
B
NOTE:
 Check the vehicle battery condition first.
 Check for aftermarket accessories plugged into the vehicle accessory power sockets (including cell
phone).
 Check the connectors for poor connections or loose terminals.
 Check the radio reception in an open area. Compare it to a known-good vehicle when ever possible.Poor
reception/interference can be caused by the
following:
– The radio station is far away.
– Atmospheric conditions are unfavorable.
– Tall buildings, mountains, or high-voltage power lines are nearby.
– Aftermarket metallic wi ndow tint.
1. Turn the ignition switch to ON (II).
2. Do the seek stop test (see page 23-78).
Multipath interference or weak station.
Operation is normal. Go to step 3.
3. Check if the radio reception/interference is the same in several locations.
Go to step 4.
Multipath interference or weak station.
Operation is normal.
4. Start the engine.
5. Check the reception/interference.
Check the antenna and radio grounds. If OK,
check the charging system and the ignition
system. Go to step 6.
6. Turn the ignition switch to LOCK (0). 7. Remove the right side C-pillar trim (see page 20-75).
8. Check the connections from the AM/FM antenna
amplifier to the window antenna.
Repair the connections, or substitute a
known-good AM/FM antenna amplifier and retest.
If the symptom/condition goes away, replace the
original AM/FM antenna amplifier (see page 23-87).
Go to step 9.
9. With the help of an assistant inside the vehicle, have the assistant shine a flashlight (A) along each
antenna wire (B). Check from the outside of the
vehicle for any breaks or openings in the antenna
wires (the light shines through).
Repair the window antenna. Go to AM/FM
antenna repair (see page 23-87), or replace the rear
window (see page 20-47).
Go to step 10.
(cont’d)
I s t he t est v ehi cl e w i t hi n 10 % of t he k now n-goodvehicle?
Is t he r ecept i on/ i nt er f er ence t he same?
I s t her e noi se ( st at i c or w hi ne) onl y w i t h t heengi ne r unni ng? Ar e t her e any l oose or d amaged connect i ons?
Ar e t her e any br eak s or cut s i n t he ant enna?
08/08/21 14:04:37 61SNR030_230_0032
ProCarManuals.com
DYNOMITE -2009-
