Map MatchingObtaining A Navigation DVD
23-269
Something is interfering with the system’s ability to
acquire its location. Check the following:
* The vehicle must be in an open area with a clear
* Remove sources of GPS interference like metallic
* Check GPS antenna cable connection.
* Restart the engine and repeat the GPS acquire view of the sky.
window tint above antenna, or electrical items
near antenna(see owner’s manual for details).
procedure. If the problem persists, see your dealer.
If this procedure is not necessary, the system proceeds
directly to the Disclaimer screen. During initialization,
the system searches for all available GPS satellites, and
obtains their orbital information. During this procedure
the vehicle should be out in the open with a clear view
of the sky.
If the navigation system finds the satellites properly,
this box clears, and changes to the Disclaimer screen. If
within 10 minutes the system fails to locate a sufficient
number of satellites to locate your position, the
following screen appears.
It this screen appears, turn off the engine, then restart
the vehicle and move it to a different location. If the
disclaimer screen appears, the GPS initialization is
complete.
NOTE:
 The average acquiring time is less than 10 minutes, but it can take as long as 45 minutes.
 If the system is still unable to acquire a signal, follow the instructions on the screen. If this screen appears
again, go to troubleshooting for the GPS icon is white
or not shown (see page 23-341).
 Skip to a CSF screen by pushing the MENU and INFO buttons at the same time and can move to an System
Links screen.
This part of the initialization matches the GPS
coordinates with a road on the map screen. To do this
part of the procedure, make sure that the navigation
system is displays a map, and drive the vehicle on a
mapped road shown on the map screen. Do not enter a
destination at this time. When the name of the current
road you are driving on, appears at the bottom of the
screen, the entire procedure is complete. Your system
is now ready to use. If the Navigation DVD is lost or damaged, or you need a
yearly
updated DVD, you have two ways to purchase
one. You can either call 888-549-3798, or order on-line
at www.acura.com.
Both methods require a credit card. The DVD cannot be
ordered through the parts system. The following DVDs
will not work in this navigation system:
 Earlier model navigation DVDs (black, orange, light blue label and the older versions with a white label)
 Map software programs manufactured by other companies
 DVD movies, or DVDs containing audio recordings
Update DVDs are available for purchase usually in the
fall of each year. They may contain the following:  Enhanced maps and points of interest (POI) coverage
 Fixes for minor software bugs
 Additional features
NOTE:  Map matching must be done any time the DVD is removed or replaced.
 Always order navigation DVDs on an as-needed basis. During a typical model year, each color DVD may
undergo a half a dozen software only version
upgrades to fix minor issues on some or all models
the DVD supports. This is normal. Usually only the
letter at the end of the version number changes,
while the database (maps and POIs) remain
unchanged.
 Never promise your customer future free updates.
There are no free programs for updating the
navigation DVD. Update DVDs are generally available
for purchase each fall. The online DVD order site
provides information when an update for a particular
color DVD is available.
 Damaged discs are not covered by warranty unless they have been damaged by the navigation system.
(cont’d)
08/08/21 14:15:38 61SNR030_230_0272
ProCarManuals.com
DYNOMITE -2009-

How to Identify Navigation DVD Versions,
and How to Inspect A DVD for Damage
23-271
To determine the navigation version on a particular
model, start the engine, then locate the navigation unit.
Open the DVD door, and push the eject button to eject
the DVD. Hold the DVD by the edges, and check for
these items: Check any official Acura service website for more service information about the navigation DVDs.
 The DVD label color.
 Read the DVD version on the label, and note it on the repair order. The version number is near the bottom
of the label text (for example, ver: 4.23A). You will
need this version number:
– To verify that the DVD version is appropriate for the vehicle. Check any official Honda service website
for more service information.
– Any time you call Tech Line regarding a navigation system issue.
– To answer client inquires concerning update or coverage issue.
NOTE: Client’s may obtain DVDs from sources
outside the normal ordering process. If you
determine this is the case, recommend that your
customer purchase the appropriate DVD from the
Acura Disc Fulfillment Center (see ORDERING A
DVD).
– Check the underside of the DVD for signs of mishandling. Deep scratches, or random scratches,
light swirl marks, or fingerprints can cause random
lock-ups, reboots, erratic voice response, erratic
positioning errors, and DVD read or format errors.
NOTE: A damaged DVD is not covered under
warranty unless the disc is damaged by the
navigation unit. Damage by the navigation unit
typically appears as circular scratches caused by
something rubbing against the DVD as it spins. The
damage may appear as arcs or complete circles on
the DVD reading surface.
– Verify that the underside of the DVD is silver, and not a copy with a blue color. Copies will not work
properly and can cause other symptoms that mimic
hardware problems.  Incorrectly colored DVDs being put into navigation
vehicles. This causes the system to either display
error messages, or causes system malfunctions that
mimic a hardware problem. This results in the client
leaving with a malfunctioning navigation system.
 The DVD version provided to the client is out-of date or incompatible with a particular model. This
inconveniences your client by delaying the repair, or
by causing additional (and unnecessary) returns to
your dealership.
 The client experiences bugs or other issues that have already been resolved in later versions currently
available at the fulfillment desk.
If the DVD is defective, or has any of the issues
mentioned above, return the vehicle to your client and
recommend that they order the proper DVD from the
Acura Disc Fulfillment Center.
NOTE: Navigation DVDs do not come with replacement
navigation units. If you are replacing a navigation unit
because it is defective (following appropriate service
manual troubleshooting), and the DVD does not eject,
order a DVD. See Obtaining a navigation DVD.
(cont’d)
08/08/21 14:15:39 61SNR030_230_0274
ProCarManuals.com
DYNOMITE -2009-

´
(#'#
)

(#'#
)

µ
µ
µ
µ µ
µ
Display day/night mode does not work or
does not work properly System locks up or freezes constantly
YES
NO
YES
NO YES
NO
23-34823-348Navigation System
Symptom Troubleshooting (cont’d)
NOTE:
 Check the vehicle battery condition first.
 Check the connectors for poor connection or loose terminals.
 Before troubleshooting, get the navigation system anti-theft code.
 After troubleshooting, enter the navigation system anti-theft code.
 Full brightness on the instrument panel brightness control with the head lights turned on causes the
system to stay in the day mode, even when the lights
are on.
1. Make sure the instrument panel brightness control is not on full brightness. Turn the headlights on,
and adjust the dash brightness to the middle range.
2. Change the day/night mode under Set-up to AUTO, and recheck.
The system is OK at this time.
Go to step 3.
3. Go into the Diagnostic Menu and use the Car Status test to check for an ILL signal (see page 23-315).
Replace the navigation unit (see page 23-355).
Check the ILL circuit between the
navigation unit and the No. 14 (7.5 A) fuse in the
under-dash fuse/relay box. NOTE:
 Check the vehicle battery condition first.
 Make sure that the correct DVD color and version are installed.
 Check any official Honda service website for more service information about the navigation system.
1. Start the engine, and turn the ignition switch to LOCK (0), then turn the ignition switch to ON (II).
The system is OK at this time.
Check the DVD for scratches or damage, and
the navigation unit for water damage. If OK, go into
the Diagnostic Menu, and do all of the Unit Check
tests (see page 23-305). Also check for low battery
charge or poor charging system performance.
Does t he d i spl ay change t o d ay and ni ght mod es w hen t ur ni ng t he head l i ght s on and of f ?
I s t he I LL si gnal OK ? Does the system reboot?
