Special Tools Required
11-227
ECM/PCM Update
A
 Honda diagnostic system (HDS) tablet tester
 Honda interface module (HIM) and an iN workstation
with the latest HDS software version
 HDS pocket tester
 GNA 600 and iN workstation with the latest HDS software version
Any one of the above updating tools can be used.
NOTE:  Make sure the HDS/iN workstation has the latest HDS software version.
 Before you update the ECM/PCM, make sure the battery in the vehicle is fully charged, and connect a
jumper battery (not a battery charger) to maintain
system voltage.
 Never turn the ignition switch to LOCK (0) or ACC (I) during the update. If there is a problem with the
update, l eave the ignition switch to ON (II).
 To prevent ECM/PCM damage, do not operate anything electrical (headlights, audio system, brakes,
A/C, power windows, moonroof (if equipped), door
locks, etc.) during the update.
 To ensure the latest program is installed, do an ECM/ PCM update when ever the ECM/PCM is substituted or
replaced.
 You cannot update an ECM/PCM with a program it already has. It will only accept a new program.
 High temperature in the engine compartment might cause the ECM/PCM to become too hot to run the
update. If the engine was running before this
procedure, open the hood, and cool the engine
compartment.
 If you need to diagnose the Honda interface module (HIM) because the HIM’s red ( 3) light came on or
was flashing during the update, l eave the ignition
switch in ON (II) when you disconnect the HIM from
the data link connector (DLC). This will pr event ECM/
PCM damage. 1. Turn the ignition switch to ON (II), but do not start
the engine.
2. Connect the HDS to the data link connector (DLC) (A) located under the driver’s side of the dashboard.
3. Make sure the HDS communicates with the ECM/ PCM. If it doesn’t, go to the DLC circuit
troubleshooting (see page 11-204). If you are
returning from the DLC circuit troubleshooting, skip
steps 4 to 5 and clean the throttle body after
updating the ECM/PCM (see page 11- 344).
4. Select the INSPECTION MENU with the HDS.
5. Select the ETCS TEST, then select the TP POSITION CHECK, and follow the HDS screen prompts.
NOTE: If the TP POSITION CHECK indicates FAILED,
continue this procedure.
6. Exit the HDS diagnostic system, then select the update mode, and follow the screen prompts to
update the ECM/PCM.
(cont’d)
08/08/21 14:23:39 61SNR030_110_0227
ProCarManuals.com
DYNOMITE -2009-

µ
µ
µ
µ
µ
µ
µ µ
µ
µ
µ
YES
NO
YES
NO
YES
NO
YES
NO
YES
NO
11-299
14. Monitor the OBD STATUS for DTC P0506 in the
DTCs MENU with the HDS.
Troubleshooting is complete. If any other
Temporary DTCs or DTCs were indicated in step 13,
go to the indicated DTC’s troubleshooting.
If the screen indicates FAILED, go to step 19. If
the screen indicates EXECUTING, keep idling until
a result comes on. If the screen indicates OUT OF
CONDITION, go to step 11.
15. Remove the intake air duct from the throttle body; K20Z2 engine (see page 11-348), K20Z3 engine
(see page 11-349).
16. Check for dirt, carbon, or damage in the throttle bore.
If there is dirt or carbon, clean the throttle
body (see page 11- 344). Also check for damage to
the air cleaner element (see page 11-346), then go
to step 9. If there is damage in the throttle bore, go
to step 8.
Go to step 17.
17. Recheck with different load conditions (turn on the headlights, blower motor, rear window defogger
and/or A/C, change the gear position, etc.).
18. Monitor the OBD STATUS for DTC P0506 in the DTCs MENU with the HDS.
Intermittent failure, the system is OK at this
time.
If the screen indicates FAILED, check the A/C
system and/or the charging system, then go to step
1 and recheck. If the screen indicates EXECUTING,
keep idling until a result comes on. If the screen
indicates OUT OF CONDITION, go to step 17. 19. Update the ECM/PCM if it does not have the latest
software (see page 11-227), or substitute a known-
good ECM/PCM (see page 11-7).
20. Start the engine. Hold the engine speed at 3,000 rpm without load (A/T in P or N, M/T in
neutral) until the radiator fan comes on, then let it
idle.
21. Check under these DATA LIST conditions with the HDS:
 ECTSENSOR1above70°C(156°F)
 IAT SENSOR above 0 °C (32 °F)
 VSSis0km/h(0mph)
 ST FUEL TRIM between 0.69 1.47
 FSS is CLOSED
22. Check for Temporary DTCs or DTCs with the HDS.
Check for poor connections or loose
terminals at the throttle body and the ECM/PCM. If
the ECM/PCM was updated, substitute a known-
good ECM/PCM (see page 11-7), then go to step 20.
If the ECM/PCM was substituted, go to step 1.
Go to step 23.
23. Monitor the OBD STATUS for DTC P0506 in the DTCs MENU with the HDS.
If the ECM/PCM was updated,
troubleshooting is complete. If the ECM/PCM was
substituted, replace the original ECM/PCM
(see page 11-228). If any other Temporary DTCs or
DTCs were indicated in step 22, go to the indicated
DTC’s troubleshooting.
If the screen indicates FAILED, check for poor
connections or loose terminals at the throttle body
and the ECM/PCM. If the ECM/PCM was updated,
substitute a known-good ECM/PCM (see page 11-7),
then go to step 20. If the ECM/PCM was substituted,
go to step 1. If the screen indicates EXECUTING,
keep idling until a result comes on. If the screen
indicates OUT OF CONDITION, go to step 20.
Does t he scr een i nd i cat e PASSE D?
Is there dirt, carbon, or damage in the throttlebor e?
Does t he scr een i nd i cat e PASSE D? Is DT C P0506 ind icated ?
Does t he scr een i nd i cat e PASSE D?
08/08/21 14:28:31 61SNR030_110_0299
ProCarManuals.com
DYNOMITE -2009-

(#'
)
µ
µ
µ
µ µ
µ
µ
µ
DTC P0507:
YES
NO
YES
NO YES
NO
YES
NO
11-300Idle Control System
DTC Troubleshooting (cont’d)
Idle Control System RPM Higher
Than Expected
NOTE: Before you troubleshoot, record all freeze data
and any on-board snapshot, and review the general
troubleshooting information (see page 11-3).
1. Turn the ignition switch to ON (II).
2. Clear the DTC with the HDS.
3. Start the engine. Hold the engine speed at 3,000 rpm without load (A/T in P or N, M/T in
neutral) until the radiator fan comes on, then let it
idle for at least 20 seconds.
4. Monitor the OBD STATUS for DTC P0507 in the DTCs MENU with the HDS.
Go to step 5.
If the screen indicates PASSED, intermittent
failure, the system is OK at this time. If the screen
indicates EXECUTING, keep idling until a result
comes on. If the screen indicates OUT OF
CONDITION, recheck with different load conditions
(electrical, A/C, gear position, etc.), then go to
step 3.
5. Check for vacuum leaks at these parts:  PCV valve
 PCV hose
 EVAP canister purge valve
 Throttle body
 Intake manifold
 Brake booster hose
 Brake booster
Repair or replace the leaking part(s), then go
to step 6.
Go to step 6. 6. Turn the ignition switch to ON (II).
7. Reset the ECM/PCM with the HDS.
8. Do the ECM/PCM idle learn procedure (see page
11-310).
9. Start the engine. Hold the engine speed at 3,000 rpm without load (A/T in P or N, M/T in
neutral) until the radiator fan comes on, then let it
idle for at least 20 seconds.
10. Check for Temporary DTCs or DTCs with the HDS.
Go to step 12.
Go to step 11.
11. Monitor the OBD STATUS for DTC P0507 in the DTCs MENU with the HDS.
Troubleshooting is complete. If any other
Temporary DTCs or DTCs were indicated in step 10,
go to the indicated DTC’s troubleshooting.
If the screen indicates FAILED, check for poor
connections or loose terminals at the throttle body
and the ECM/PCM, then go to step 1. If the screen
indicates EXECUTING, keep idling until a result
comes on. If the screen indicates OUT OF
CONDITION, recheck with different load conditions
(turn on the headlights, blower motor, or A/C;
change the gear position, etc.), then go to step 9.
Does t he scr een i nd i cat e F AILE D?
Ar e t her e any l eak s? Is DT C P0507 ind icated ?
Does t he scr een i nd i cat e PASSE D?
08/08/21 14:28:31 61SNR030_110_0300
ProCarManuals.com
DYNOMITE -2009-



(#'


)
µ
µ µ
µ
µ
µ
YES
NO
YES
NO
YES
NO
11-30711-307
Alternator FR Signal Circuit
Troubleshooting
ECM/PCM CONNECTOR A (44P)
ACC (RED)JUMPER WIRE
ECM/PCM CONNECTOR B (44P)ALTF
(WHT/RED)
13. Momentarily connect ECM/PCM connector terminalA14 to body ground with a jumper wire s everal
times.
Update the ECM/PCM if it does not have the
latest software (see page 11-227), or substitute a
known-good ECM/PCM (see page 11-7), then
recheck. If the symptom/indication goes away with
a known-good ECM/PCM, replace the original ECM/
PCM (see page 11-228).
Check for poor connections or loose terminals
attheA/CclutchrelayandtheECM/PCM.Ifthe
connections and the terminals are OK, check the
A/C compressor clutch relay (see page 22-70),
repair open in the wires between the ECM/PCM
(A14), the A/C compressor clutch relay, and other
A/C systems parts. 1. Start the engine, and let it idle.
2. Monitor the ALTERNATOR in the DATA LIST with
the HDS.
3. Check if the indicated percentage varies when the headlight switch is turned on.
The alternator signal circuit is OK.
Go to step 4.
4. Turn the headlight switch and ignition switch to LOCK (0).
5. Jump the SCS line with the HDS.
6. Disconnect the alternator 4P connector.
7. Disconnect ECM/PCM connector B (44P).
8. Check for continuity between body ground and ECM/PCM connector terminal B43.
Repair short in the wire between the ECM/
PCM (B43) and the alternator.
Update the ECM/PCM if it does not have the
latest software (see page 11-227), or substitute a
known-good ECM/PCM (see page 11-7), then
recheck. If the symptom/indication goes away with
a known-good ECM/PCM, replace the original ECM/
PCM (see page 11-228).
Terminal side of female terminals
Terminal side of female terminals
I s t her e a cl i ck i ng noi se f r om t he A/ C compr essorclutch? Does t he per cent age v ar y ?
Is there continuity?
08/08/21 14:29:37 61SNR030_110_0307
ProCarManuals.com
DYNOMITE -2009-



(#'


)
µ
µ µ
µ
µ
µ
YES
NO
YES
NO
YES
NO
11-30711-307
Alternator FR Signal Circuit
Troubleshooting
ECM/PCM CONNECTOR A (44P)
ACC (RED)JUMPER WIRE
ECM/PCM CONNECTOR B (44P)ALTF
(WHT/RED)
13. Momentarily connect ECM/PCM connector terminalA14 to body ground with a jumper wire s everal
times.
Update the ECM/PCM if it does not have the
latest software (see page 11-227), or substitute a
known-good ECM/PCM (see page 11-7), then
recheck. If the symptom/indication goes away with
a known-good ECM/PCM, replace the original ECM/
PCM (see page 11-228).
Check for poor connections or loose terminals
attheA/CclutchrelayandtheECM/PCM.Ifthe
connections and the terminals are OK, check the
A/C compressor clutch relay (see page 22-70),
repair open in the wires between the ECM/PCM
(A14), the A/C compressor clutch relay, and other
A/C systems parts. 1. Start the engine, and let it idle.
2. Monitor the ALTERNATOR in the DATA LIST with
the HDS.
3. Check if the indicated percentage varies when the headlight switch is turned on.
The alternator signal circuit is OK.
Go to step 4.
4. Turn the headlight switch and ignition switch to LOCK (0).
5. Jump the SCS line with the HDS.
6. Disconnect the alternator 4P connector.
7. Disconnect ECM/PCM connector B (44P).
8. Check for continuity between body ground and ECM/PCM connector terminal B43.
Repair short in the wire between the ECM/
PCM (B43) and the alternator.
Update the ECM/PCM if it does not have the
latest software (see page 11-227), or substitute a
known-good ECM/PCM (see page 11-7), then
recheck. If the symptom/indication goes away with
a known-good ECM/PCM, replace the original ECM/
PCM (see page 11-228).
Terminal side of female terminals
Terminal side of female terminals
I s t her e a cl i ck i ng noi se f r om t he A/ C compr essorclutch? Does t he per cent age v ar y ?
Is there continuity?
08/08/21 14:29:37 61SNR030_110_0307
ProCarManuals.com
DYNOMITE -2009-

(#'

)

¶
¶
¶
¶
¶
¶
Idle speed should be:
K20Z2 engine:
M/T 700 50 rpm
A/T 800 50 rpm (in P or N)
K20Z3 engine: M/T 750 50 rpm
Idle speed should be:
K20Z2 engine: M/T 780 50 rpm
A/T 800 50 rpm (in P or N)
K20Z3 engine: M/T 750 50 rpm
Procedure
11-31011-310Idle Control System
Idle Speed Inspection (cont’d) ECM/PCM Idle Learn Procedure
4. Start the engine. Hold the engine speed at
3,000 rpm without load (A/T in P or N, M/T in
neutral) until the radiator fan comes on, then let it
idle.
5. Check the idle speed without load conditions: headlights, blower fan, radiator fan, and air
conditioner off.
6. Let the engine idle for 1 minute with high electric load (A/C switch on, temperature set to max cool,
blower fan on high, and headlights on high beam).
NOTE: If the idle speed is not within specification,
dotheECM/PCMidlelearnprocedure(seepage
11-310). If the idle speed is still not within
specification, go to the symptom troubleshooting.
7. Reconnect the EVAP canister purge valve connector. The idle learn procedure must be done so the ECM/PCM
can learn the engine idle characteristics.
Do the idle learn procedure whenever you do any of
these actions:
 Replace the ECM/PCM.
 Reset the ECM/PCM.
 Update the ECM/PCM.
 Replace or clean the throttle body.
 Disassemble the engine or the transmission.
NOTE: Erasing DTCs with the HDS does not require you
to do the idle learn procedure.
1. Make sure all electrical items (A/C, audio, lights, etc.) are off.
2. Reset the ECM/PCM with the HDS.
3. Turn the ignition switch to ON (II), and wait 2 seconds.
4. Start the engine. Hold the engine speed at 3,000 rpm without load (A/T in P or N, M/T in
neutral) until the radiator fan comes on, or until the
engine coolant temperature reaches 90 °C (194 °F).
5. Let the engine idle for about 5 minutes with the throttle fully closed.
NOTE: If the radiator fan comes on, do not include
its running time in the 5 minutes.
08/08/21 14:29:38 61SNR030_110_0310
ProCarManuals.com
DYNOMITE -2009-

(#'

)

¶
¶
¶
¶
¶
¶
Idle speed should be:
K20Z2 engine:
M/T 700 50 rpm
A/T 800 50 rpm (in P or N)
K20Z3 engine: M/T 750 50 rpm
Idle speed should be:
K20Z2 engine: M/T 780 50 rpm
A/T 800 50 rpm (in P or N)
K20Z3 engine: M/T 750 50 rpm
Procedure
11-31011-310Idle Control System
Idle Speed Inspection (cont’d) ECM/PCM Idle Learn Procedure
4. Start the engine. Hold the engine speed at
3,000 rpm without load (A/T in P or N, M/T in
neutral) until the radiator fan comes on, then let it
idle.
5. Check the idle speed without load conditions: headlights, blower fan, radiator fan, and air
conditioner off.
6. Let the engine idle for 1 minute with high electric load (A/C switch on, temperature set to max cool,
blower fan on high, and headlights on high beam).
NOTE: If the idle speed is not within specification,
dotheECM/PCMidlelearnprocedure(seepage
11-310). If the idle speed is still not within
specification, go to the symptom troubleshooting.
7. Reconnect the EVAP canister purge valve connector. The idle learn procedure must be done so the ECM/PCM
can learn the engine idle characteristics.
Do the idle learn procedure whenever you do any of
these actions:
 Replace the ECM/PCM.
 Reset the ECM/PCM.
 Update the ECM/PCM.
 Replace or clean the throttle body.
 Disassemble the engine or the transmission.
NOTE: Erasing DTCs with the HDS does not require you
to do the idle learn procedure.
1. Make sure all electrical items (A/C, audio, lights, etc.) are off.
2. Reset the ECM/PCM with the HDS.
3. Turn the ignition switch to ON (II), and wait 2 seconds.
4. Start the engine. Hold the engine speed at 3,000 rpm without load (A/T in P or N, M/T in
neutral) until the radiator fan comes on, or until the
engine coolant temperature reaches 90 °C (194 °F).
5. Let the engine idle for about 5 minutes with the throttle fully closed.
NOTE: If the radiator fan comes on, do not include
its running time in the 5 minutes.
08/08/21 14:29:38 61SNR030_110_0310
ProCarManuals.com
DYNOMITE -2009-


(#'
")


(#'
")
K20Z2 engine K20Z3 engine
11-37211-372PCV System
PCV Valve Inspection
B
B
A
A B
A B
A
1. Check the PCV valve (A), the hoses (B), and the connections for leaks or restrictions.
2. At idle, make sure there is a clicking sound from the PCV valve when the hose between the PCV valve
and intake manifold is lightly pinched (A) with your
fingers or pliers.
If there is no clicking sound, check the PCV valve
washer for cracks or damage. If the washer is OK,
replace the PCV valve then recheck. 1. Check the PCV valve (A), hoses (B), and
connections for leaks or restrictions.
2. At idle, make sure there is a clicking sound from the PCV valve when the hose between the PCV valve
and intake manifold is lightly pinched (A) with your
fingers or pliers.
If there is no clicking sound, check the PCV valve
washer for cracks or damage. If the washer is OK,
replace the PCV valve and recheck.
08/08/21 14:32:29 61SNR030_110_0372
ProCarManuals.com
DYNOMITE -2009-
