Standard: 0.05 0.15 mm (0.002 0.006 in.)
14-35614-356 A/T Differential
Backlash Inspection
Differential Carrier and Final Driven
Gear Replacement
A
B
C
B
A
B
103 N·m (10.5 kgf·m, 75.9 lbf·ft)
10 Bolts
1. Install both axles into the differential, and place the
axles on V-blocks (A).
2. Measure the backlash of the pinion gears (B) using a dial indicator (C).
3. If the backlash is out of standard, replace the differential carrier. NOTE: Inspect and adjust the carrier bearing preload
(see page 14-361) whenever the differential carrier is
replaced.
1. Remove the final driven gear (A) from the differential carrier (B).
NOTE: The final driven gear bolts have left-hand
threads.
2. Install the final driven gear on the differential carrier in the direction shown. Tighten the bolts to
103 N·m (10.5 kgf·m, 75.9 lbf·ft) in a crisscross
pattern in at least two steps.
