11-200PGM-FI System
F-CAN Circuit Troubleshooting (cont’d)
ECM/PCM CONNECTOR A (44P)
CANH (WHT) ECM/PCM CONNECTOR A (44P)
CANL (RED)
46. Check for continuity between ECM/PCM connectorterminal A36 and body ground.
Repair short in the wire between the ECM/
PCM connector terminal A36 and the gauge control
module (tach), the ABS modulator-control unit, the
VSA modulator-control unit, the yaw rate-lateral
acceleration sensor, the SRS unit, the EPS control
unit, the TPMS control unit (with TPMS), or the
DLC.
Go to step 47. 47. Check for continuity between ECM/PCM connector
terminal A37 and body ground.
Repair short in the wire between ECM/PCM
connector terminal A37 and the gauge control
module (tach), the ABS modulator-control unit, the
VSA modulator-control unit, the yaw rate-lateral
acceleration sensor, the SRS unit, the EPS control
unit, the TPMS control unit (with TPMS), or the
DLC.
Go to step 48.
Terminal side of female terminals Terminal side of female terminals
I s t her e cont i nui t y ?I s t her e cont i nui t y ?
08/08/21 14:21:53 61SNR030_110_0200
ProCarManuals.com
DYNOMITE -2009-

µ
µ
µ
µ µ
µ
YES
NO
YES
NO YES
NO
11-202PGM-FI System
F-CAN Circuit Troubleshooting (cont’d)
64. Turn the ignition switch to LOCK (0).
65. Reconnect the ABS modulator-control unit 25P
connector (or the yaw rate-lateral acceleration
sensor 4P connector).
66. Disconnect SRS unit connector A (28P).
67. Turn the ignition switch to ON (II), and read the HDS.
Replace the SRS unit (see page 24-203).
Go to step 68.
68. Turn the ignition switch to LOCK (0).
69. Reconnect SRS unit connector A (28P).
70. Disconnect EPS control unit connector D (28P).
71. Turn the ignition switch to ON (II), and read the HDS.
Replace the EPS control unit (see page 17-84).
 With TPMS: Go to step 72.
 Without TPMS: Update the ECM/PCM if it does not have the latest software (see page 11-227), or
substitute a known-good ECM/PCM (see page
11-7), then recheck. If the symptom/indication
goes away with a known-good ECM/PCM,
replace the original ECM/PCM (see page 11-228). 72. Turn the ignition switch to LOCK (0).
73. Reconnect EPS control unit connector D (28P).
74. Disconnect the TPMS control unit 20P connector.
75. Turn the ignition switch to ON (II), and read the
HDS.
Replace the TPMS control unit (see page
18-75).
Update the ECM/PCM if it does not have the
latest software (see page 11-227), or substitute a
known-good ECM/PCM (see page 11-7), then
recheck. If the symptom/indication goes away with
a known-good ECM/PCM, replace the original ECM/
PCM (see page 11-228).
Does the HDS identif y the vehicle?
Does the HDS identif y the vehicle? Does the HDS identif y the vehicle?
08/08/21 14:21:54 61SNR030_110_0202
ProCarManuals.com
DYNOMITE -2009-


µ
µ
µ
µ
µ
µ µ
µ
µ
µ
YES
NO
YES
NO
YES
NO
YES
NO
YES
NO
11-205
DATA LINK CONNECTOR (DLC)
K-LINE (LT BLU)
13. Turn the ignition switch to LOCK (0).
14. Turn the ignition switch to ON (II), and watch theimmobilizer indicator.
Go to the immobilizer system’s
troubleshooting (see page 22- 315).
 With TPMS: Go to step 15.
 Without TPMS: Go to step 17.
15. Turn the ignition switch to LOCK (0).
16. Turn the ignition switch to ON (II), and watch the TPMS indicator.
Go to the TPMS’s general troubleshooting
information (see page 18-49).
Go to step 17.
17. Do the gauge self-diagnostic function (see page 22-241).
18. Check for B-CAN system DTCs without the HDS (see page 22-74).
Go to the indicated DTC’s troubleshooting.
Go to step 19.
19. Turn the ignition switch to LOCK (0).
20. Disconnect the HDS from the DLC. 21. Check for continuity between DLC terminal No. 7
and body ground.
Go to step 22.
Go to step 23.
22. Continue to check for continuity between DLC terminal No. 7 and body ground, while
disconnecting these parts, one at a time:
 SRS unit connector A (28P)
 ABS modulator-control unit 25P connector (with ABS)
 VSA modulator-control unit 37P connector (with VSA system)
 EPS control unit connector D (28P)
 Immobilizer-keyless control unit 7P c onnector
 TPMS control unit 20P connector (with TPMS)
 Audio unit 17P connector
 Under-dash fuse/relay box Q (16P) connector
Replace the part that caused an open when it
was disconnected.
Repair short in the wire between the DLC (K-
line) and the ABS modulator-control unit (with
ABS), the VSA modulator-control unit (with VSA
system), the SRS unit, the EPS control unit, the
immobilizer-keyless control unit, the audio unit, the
TPMS control unit (with TPMS), or the under-dash
fuse/relay box.
(cont’d)
Terminal side of female terminals
Does the immobilizer indicator stay on or f lash?
Does t he T PM S i nd i cat or st ay on?Ar e any B-CAN DT Cs i nd i cat ed ? Is there continuity?
Does cont i nui t y go aw ay w hen one of t he abov econnect or s i s d i sconnect ed ?
08/08/21 14:21:54 61SNR030_110_0205
ProCarManuals.com
DYNOMITE -2009-


´
µ
µ µ
µ
µ
µ
Connector Terminal
YES
NO YES
NO
YES
NO
11-206
PGM-FI System
DLC Circuit Troubleshooting (cont’d)
DATA LINK CONNECTOR (DLC)
K-LINE (LT BLU)
JUMPER WIRE
DATA LINK CONNECTOR (DLC)B(WHT)
23. Connect DLC terminal No. 7 to body ground with ajumper wire.
24. Check for continuity between body ground and these connector terminals:
SRS unit A (28P) No. 24 (LT BLU)
ABS modulator-control unit
25P (with ABS) No. 10
(LT BLU)
VSA modulator-control unit
37P (with VSA system) No. 26
(LTBLU)
EPS control unit D (28P) No. 17 (LT BLU)
Immobilizer-keyless control
unit 7P No. 5 (LT BLU)
TPMS control unit 20P No. 7 (LT BLU)
Audio unit 17P No. 6 (LT BLU)
Under-dash fuse/relay box Q
(16P) No. 8 (LT BLU)
Replace the part which cannot communicate
with the HDS.
Repair open in the wire between the DLC (K-
line) and the appropriate connector. 25. Do the gauge self-diagnostic function (see page
22-241).
26. Check for B-CAN system DTCs without the HDS (see page 22-74).
Go to step 39.
Go to step 27.
27. Turn the ignition switch to LOCK (0).
28. Disconnect the HDS from the DLC.
29. Measure the voltage between DLC terminal No. 16 and body ground.
Go to step 30.
Repair open in the wire between DLC terminal
No.16andtheNo.23BACKUP(10A)fuseinthe
under-hood fuse/relay box.
Terminal side of female terminals
Terminal side of female terminals
Is t her e cont i nui t y bet w een t he bod y gr ound andeach of t he t er mi nal s i n t he char t ? I s DT C B1168, B1169, and / or B117 8 i nd i cat ed ?
Is there battery voltage?
08/08/21 14:21:55 61SNR030_110_0206
ProCarManuals.com
DYNOMITE -2009-

(#'

/)
Suspension
Front and Rear Suspension
Front Suspension
Rear Suspension............................................. .............................................
TPMS (Tire Pressure Monitoring System)
(’08-09 Models) . 18-47
................................................................
........................................
......................................................... ...........................
...........................................
............................................
...................................................... ...................
................................................................
........................................
......................................................... ...........................
...........................................
............................................
...................................................... ...................
Special Tools . 18-2
Component Location Index . 18-3
Wheel Alignment . 18-5
Wheel Bearing End Play Inspection . 18-9
Wheel Runout Inspection . 18-9
Wheel Bolt Replacement . 18-10
Ball Joint Removal . 18-12
Ball Joint Boot Inspection/Replacement . 18-13
...............
................................... ............................... ..........................
........................................ .................
................................... ...............
................................... ............................... ..........................
........................................ .................
...................................
Knuckle/Hub/Wheel Bearing Replacement . 18-14
Lower Ball Joint Replacement
. 18-20
Lower Arm Removal/Installation . 18-22
Stabilizer Link Removal/Installation . 18-25
Stabilizer Bar Replacement . 18-25
Damper/Spring Removal and Installation . 18-26
Damper/Spring Disassembly, Inspection, and Reassembly . 18-28
...................
............................... ............................. ..........................
........................................
.................................................
.................................................... ...................
............................... ............................. ..........................
........................................
.................................................
....................................................
Knuckle/Hub Bearing Unit Replacement
. 18-31
Upper Arm Removal/Installation . 18-35
Trailing Arm Removal/Installation . 18-36
Stabilizer Link Removal/Installation . 18-37
Stabilizer Bar Replacement . 18-38
Damper Replacement . 18-39
Spring Replacement . 18-42
08/08/21 14:56:38 61SNR030_180_0001
ProCarManuals.com
DYNOMITE -2009-

(#'

/)

Suspension
............................
............................
Front and Rear Suspension . 18-2
............................................
............................................
Front Suspension . 18-14
..............................................
..............................................
Rear Suspension . 18-31
TPMS (Tire Pressure Monitoring System) (’08-09 Models)
........................................
........................................
...................................
....................................... ..............................
.....................................................
............................................................ ....................................................................................................................................................
........................................
........................................
...................................
....................................... ..............................
.....................................................
............................................................ ....................................................................................................................................................
Component Location Index . 18-48
General Troubleshooting Information . 18-49
Memorizing the Tire Pressure Sensor ID . 18-52
Tire Pressure Sensor Location . 18-53
DTC Troubleshooting Index . 18-55
Symptom Troubleshooting Index . 18-56
System Description . 18-57
Circuit Diagram . 18-61
DTC Troubleshooting . 18-63
Symptom Troubleshooting . 18-71
TPMS Control Unit Replacement . 18-75
Tire Pressure Sensor Replacement . 18-76
08/08/21 14:58:20 61SNR030_180_0047
ProCarManuals.com
DYNOMITE -2009-

Î
(#'

)
18-48TPMS
Component Location Index
TIRE PRESSURE SENSOR
DATA LINK CONNECTOR (DLC) UNDER-DASH FUSE/RELAY BOX
TPMS CONTROL UNIT
TIRE PRESSURE SENSOR
TIRE PRESSURE SENSOR
TIRE PRESSURE SENSOR UNDER-HOOD FUSE/RELAY BOX
Replacement, page 18-76 Replacement, page 18-75
Replacement, page 18-76
Replacement, page 18-76
Replacement, page 18-76
08/08/21 14:58:21 61SNR030_180_0048
ProCarManuals.com
DYNOMITE -2009-

Î
Î
(#' )
µ
µ
System Indicator
The Low Tire Pressure Indicator
The TPMS Indicator DTC 11, 13, 15, 17
Tire Pressure Changing by Temperature
18-49
General Troubleshooting Information
Low Tire Pressure
Indicator
TPMS
Indicator
20
0 20 4060
43 2 6 8 104 1 40
psi
(kgf/cm , kPa)
38
(2. 6, 260)
35
(2. 4, 240)
32
(2. 2, 220)
29
(2. 0, 200)
26
(1. 8, 180)
23
(1. 6, 160)
20
(1. 4, 140)
2
The TPMS (tire pressure monitoring system) has the
low tire pressure indicator and the TPMS indicator.
 If the system detects low pressure in any of the four tires, the low tire pressure indicator comes on.
 When this happens, inflate the air and test-drive the vehicle at 45 km/h (28 mph) or more for at least 1
minute, and the low tire pressure indicator will go off.
 If the control unit detects a problem in the system during an indication of low tire pressure, it turns off
the low tire pressure indicator, stores the DTC(s), and
turns on the TPMS indicator.
 If a problem is detected in the system, the TPMS indicator comes on.
 If low tire pressure and a problem in the system are detected, only the TPMS indicator comes on.
If the system is OK, the TPMS indicator and the low
tire pressure indicator should come on when you turn
the ignition switch to ON (II), and then go off 2
seconds later. If they don’t, there is a problem with
the system. If the system detects low pressure in any of the four
tires, the low tire pressure indicator comes on, and the
control unit sets one or more of these codes: DTC 11,
13, 15, 17. When the tire pressure returns to normal,
and the TPMS control unit receives the normal pressure
signal from the tire pressure sensor, the control unit
turns off the indicator. However TPMS control unit still
retains the DTC(s).
NOTE: It is necessary to test-drive the vehicle at
45 km/h (28 mph) or more for at least 1 minute so that
tire pressure sensor transmits the signal.
The pressures increase slightly as the temperature in
the tires rises during driving.
Pressures can also increase or decrease slightly with
changes in outside air temperature.
A temperature change of about 10 °C (18 °F) changes
tire pressure by about 10 kPa (0.1 kgf/cm , 1.5 psi). If the
temperature drops, tire pressure could decrease just
enough to turn on the low tire pressure indicator, but
later, the tire temperature could increase enough to
turn the indicator off. To resolve a complaint of such
intermittent indications, confirm and clear the stored
DTC(s) and check the tire pressures. Then explain to the
client how temperature changes can affect the system.
(cont’d)
2
08/08/21 14:58:22 61SNR030_180_0049
ProCarManuals.com
DYNOMITE -2009-
