2005 TOYOTA LAND CRUISER Owners Manual

327
BRAKES
Minimum pedal clearance when depressed
with the force of 490 N (50 kgf, 110 lbf)
with the engine running, mm (in.): 116 (4.6)
Pedal free play, mm (in.): 1 – 6 (0.04 – 0.24)
Pad wear limit, mm (in.): 1.0 (0.04)
Lining wear limit, mm (in.): 1.0 (0.04)
Parking brake adjustment when pulled with
the force of 196 N (20 kgf, 44 lbf): 4 – 6 clicks
Fluid type: SAE J1703 or FMVSS No.116 DOT 3
STEERING
Wheel free play: Less than 40 mm (1.6 in.)
Power steering fluid type: Automatic transmission fluid DEXRON
\bII
or III

328
Tires
Tire size and inflation pressure:kPa (psi)
Ti r e siz e
FrontRearWheel sizeNormal drivingTr ailer towingNormal drivingTr ailer towing
P275/60R18 111H200 (29)220 (32)220 (32)240 (35)18  8JJ
Wheel nut torque, N·m (kgf·m, ft·lbf): 131 (13.4, 96.6)
NOTE: For a complete information on tires (e.g. replacing tires or replacing wheels), see “Checking tire inflation pressure” on page 301 through “Aluminum wheel precautions” on page 309.

329
Fuses
Engine compartment
Fuses1. ABS NO.2 40 A: Anti−lock brake sys-
tem
2. ABS NO.1 50 A:
Anti−lock brake system
3. AHC 50 A: No circuit
4. ST1 7.5 A:
Mutiport fuel injection system/
Sequential multiport fuel injection
5. TOWING 30 A: Trailer lights
6. MIR HTR 15 A: Outside rear view mirror
defogger
7. RR HTR 10 A: Rear air conditioning sys-
tem
Left side kick panel
8. HAZTRN 15 A: Emergency flashers,
Turn signal lights
9. ALTS 7.5 A: Charging system
10. NVIR 20 A: No circuit
11. FR FOG 15 A:
Fog lights
12. TOWING BRK 30 A: Trailer lights
13. HEAD CLNER 20 A:
Headlight cleaner
14. FRIG 10 A: Charging system
15. PANEL 7.5 A: Instrument panel light
16. TOWING TAIL 30 A: Trailer lights
17. TAIL 15 A: Parking lights, Tail lights
Right side kick panel
18. BAT 30 A: All components in “ECU− B2”
19. TEL 7.5 A: No circuit
20. AMP 30 A: Audio system
21. EFI or ECD No.1 25 A: Multiport fuel
injection system/Sequential multiport fuel
injection system
22. AM2 15 A: All components in “IGN”
23. ETCS 10 A: Multiport fuel injection sys-
tem/Sequential multiport fuel injection sys-
tem
24. HORN 10 A: Horns
25. HEAD (RHLWR) 10 A: Right−hand
headlight (low beam)

330
26. HEAD (LHLWR) 10 A: Left−hand head-
light (low beam)
27. HEAD (RHUPR) 20 A: Right −hand
headlight (high beam)
28. HEAD (LHUPR) 20 A: Left −hand head-
light (high beam)
29. PWR OUTLET 15 A: Power outlets
30. CIG 15 A: Cigarette lighter
31. ACC 7.5 A: Instrument panel light
32. AM1 7.5 A: Multiport fuel injection sys-
tem/Sequential multiport fuel injection
system
33. DEFOG 20 A:
Rear window defogger
34. AHCB 15 A: Active height control sus-
pension (AHC)
35. FUEL HTR 20 A: Fuel heater
36. POWER HTR 7.5 A: Power heater
37. AHCIG 20 A: Active height control sus-
pension (AHC)
38. EFI or ECD No.2 10 A: Emission con-
trol system
39. GAUGE1 10 A: Gauges and meters
40. ECUIG1 10 A: Multiport fuel injection
system/S equential multiport fuel injec-
tion system
41. ECUB1 10 A:
Navigation system
42. DBL LOCK 15 A: Double lock system
43. A/C 15 A: Air conditioning system
44. STOP 15 A: Stop lights
45. OBD2 7.5 A: On −board diagnosis sys-
tem
46. IDEL UP 7.5 A: Idle −up system
47. LH SEAT 30 A: Power seat system
48. DOOR 25 A: Power door lock system,
Power windows
49. SUN ROOF 25 A: Electronic moon roof
50. RR WIPER 15 A: Rear wiper system
51.ECUB2 10 A: Power door lock system,
Power window
52. DIFF 20 A: Four−wheel drive system
53. WASHER 15 A: Windshield washer
54. RADIO 10 A: Audio system
55. DOME 10 A: Interior lights
56. VGRS 40 A: Variable gear ratio steer-
ing system
57. P/W (FL) 20 A: Power window
58. P/W (RL) 20 A: Power window
59. WIPER 25 A: Windshield wiper
60. ECUIG2 10 A: Rear air conditioning
system
61. SEAT HTR 15 A: Seat heater 62. GAUGE2 10 A:
Back−up lights
63. MET 7.5 A: Gauges and meters
64. IGN 7.5 A: Multiport fuel injection sys-
tem/Sequential multiport fuel injection
system
65. SECURITY 7.5 A: Theft deterrent sys-
tem
66. P/W (RR) 20 A: Power window
67. P/W (FR) 20 A: Power window
68. BATT CHARGE 30 A: Trailer charging
system
69. TIL&TEL 20 A: Tilt and telescopic
steering
70. RR A/C 30 A: Rear air conditioning
system
71. RH SEAT 30 A: Power seat system

331
REPORTING SAFETY DEFECTS FOR U.S.
OWNERS AND UNIFORM TIRE QUALITY
GRADING
Reporting safety defects for U.S. owners332
. . . . . . . . . . . . . . . . . . . . . .
SECTION 9

332
If you believe that your vehicle has
a defect whi ch coul d cause a cr ash
or could cause injury or death, you
should immediately inform the Na-
tional Highway Traffic Safety Ad-
ministration (NHTSA) in addition to
notifying Toyota Motor Sales,
U.S.A., Inc. (Toll−free:
1 −800 −331 −4331).
If NHTSA receives similar com-
plaints, it may open an investiga-
tion, and if it finds that a safety de-
fect exists in a group of vehicles, it
may order a recall and remedy
campaign. However, NHTSA cannot
become involved in individual prob-
lems between you, your dealer, or
Toyota Motor Sales, U.S.A., Inc. To contact NHTSA, you may either
call the Auto Safety Hotline toll
−free
at 1 −800 −424 −9393 (or 366 −0123
in Washington, D.C. area) or write
to: NHTSA, U.S. Department of
Transportation, Washington, D.C.
20590. You can also obtain other
information about motor vehicle
safety from the Hotline.
Reporting safety defects for
U.S. owners

333
INDEX
SECTION 10

334 A
Adding washer fluid315
. . . . . . . . . . . . . . . . . .
Adjustment
Front seats 36
. . . . . . . . . . . . . . . . . . . . . . . . .
Seat belt 48
. . . . . . . . . . . . . . . . . . . . . . . . . . .
Second seat 37
38
. . . . . . . . . . . . . . . . . . . .
Third seat 42 . . . . . . . . . . . . . . . . . . . . . . . . . .
Air conditioning system 176 . . . . . . . . . . . . . . .
Airbags 58 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Aluminum wheel precautions 309 . . . . . . . . . .
Anti −theft steering column lock 134 . . . . . . . .
Appearance care
Cleaning the interior 279 . . . . . . . . . . . . . . . .
Protecting your Toyota from corrosion 276 . . . . . . . . . . . . . . . . . . .
Washing and waxing 277 . . . . . . . . . . . . . . . .
Armrest 37 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Automatic transmission
Driving with an automatic transmission 135 . . . . . . . . . . . . . . . . . . . . .
Shift lock override button 272 . . . . . . . . . . . .
Shift pattern 135 . . . . . . . . . . . . . . . . . . . . . . .
Shifting speed 135 . . . . . . . . . . . . . . . . . . . . .
Auxiliary box 198 . . . . . . . . . . . . . . . . . . . . . . . .
Auxiliary catch, Engine hood 27 . . . . . . . . . . .
B
Back door 25
. . . . . . . . . . . . . . . . . . . . . . . . . . . .
Back door lock 25
. . . . . . . . . . . . . . . . . . . . . . . . Battery
Checking battery condition 312
. . . . . . . . . .
Gas caution 312
. . . . . . . . . . . . . . . . . . . . . . .
Handling safety 312
. . . . . . . . . . . . . . . . . . . .
Recharging precautions 313
. . . . . . . . . . . . .
Winter driving tips 240
. . . . . . . . . . . . . . . . . .
Before starting the engine 236
. . . . . . . . . . . . .
Brake pad wear limit indicators 219 . . . . . . . .
Brake system 215
. . . . . . . . . . . . . . . . . . . . . . . .
Brakes
Fluid level 300
. . . . . . . . . . . . . . . . . . . . . . . . .
Pad wear limit indicators 219
. . . . . . . . . . . .
Parking 142
. . . . . . . . . . . . . . . . . . . . . . . . . . .
Break −in tips 209
. . . . . . . . . . . . . . . . . . . . . . . .
Brightness control 110
. . . . . . . . . . . . . . . . . . . .
C
Car audio system 152
. . . . . . . . . . . . . . . . . . . .
Carbon monoxide caution 213
. . . . . . . . . . . . .
Cargo and luggage
Capacity 230
. . . . . . . . . . . . . . . . . . . . . . . . . .
Distribution 231
. . . . . . . . . . . . . . . . . . . . . . . .
Stowage precautions 230
. . . . . . . . . . . . . . .
Cassette player 152
. . . . . . . . . . . . . . . . . . . . . .
Checking and replacing fuses 314
. . . . . . . . .
Checking and replacing tires 304
. . . . . . . . . .
Checking brake fluid 300
. . . . . . . . . . . . . . . . . .
Checking the engine oil level 296
. . . . . . . . . .
Checking the radiator and condenser 299
. . . . . . . . . . . . . . . . . . . . .
Child restraint
Child restraint system 77
. . . . . . . . . . . . . . .
Installation 78, 83
. . . . . . . . . . . . . . . . . . . . . . Precautions
76
. . . . . . . . . . . . . . . . . . . . . . . .
Types of child restraint system 77 . . . . . . . .
Using a top strap 92
. . . . . . . . . . . . . . . . . . . .
Cigarette lighter and ashtray 192
. . . . . . . . . .
Cleaning the interior 279
. . . . . . . . . . . . . . . . . .
Clock 188
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Coat hooks 205
. . . . . . . . . . . . . . . . . . . . . . . . . .
Cold weather
Operation 240
. . . . . . . . . . . . . . . . . . . . . . . . .
Compact disc auto changer
controller 152
. . . . . . . . . . . . . . . . . . . . . . . . . .
Compact disc player 152
. . . . . . . . . . . . . . . . . .
Controls, Instrument panel 2, 6
. . . . . . . . . . . .
Cooling system
Coolant level 298
. . . . . . . . . . . . . . . . . . . . . .
Radiator and reservoir 298
. . . . . . . . . . . . . .
Winter driving tips 240
. . . . . . . . . . . . . . . . . .
Corrosion prevention 276
. . . . . . . . . . . . . . . . .
Cruise control 142
. . . . . . . . . . . . . . . . . . . . . . .
Cup holder 199
. . . . . . . . . . . . . . . . . . . . . . . . . .
D
Defogger, Rear window 115
. . . . . . . . . . . . . . .
Differential, Limited slip 220
. . . . . . . . . . . . . . .
Dimmer switch, Headlight 108
. . . . . . . . . . . . .
Directional signals 108
. . . . . . . . . . . . . . . . . . .
