ENGINE MECHANICAL TIMING BELT (1CD−FTV)(From September, 2003)
14 −145
AVENSIS Supplement (RM1045E)
(3) Remove the backing paper from a new gasket, then
affix the gasket to the timing belt cover as shown in
the illustration.
NOTICE:
S Affix the gasket at the center of the groove.
S At the corners, try to keep the gasket thickness uni-
form.
(4) After installing the gasket, press it down so that the
adhesive firmly sticks to the timing belt cover.
(5) If there is a gap between the ends of the gasket, use
seal packing to close the gap.
Seal packing: Part No. 08826 −00080 or equivalent
(b) Install the No. 2 timing belt cover and gasket with the 7
bolts and 7 seal washers.
Torque: 7.4 N
m (75 kgf
cm, 65 in.
lbf)
31. INSTALL IDLER PULLEY SUB −ASSY
Torque: 40 N
m (408 kgf
cm, 30 ft
lbf)
32. INSTALL CRANKSHAFT PULLEY
(a) Align the keyway of the pulley with the key located on the crankshaft, then slide the pulley into place.
(b) Using SST, install the pulley bolt.
SST 09213 −54015 (09213 −70020), 09330 −00021
Torque: 180 N·m (1,835 kgf·cm, 133 ft·lbf)
HINT:
When using the bolt (91651 −60855), a plate washer (5 mm
(0.20 in.)) must be inserted between the pulley bolt and SST.
33. INSTALL ENGINE MOUNTING INSULATOR SUB −ASSY RH
Torque: 52 N·m (530 kgf·cm, 38 ft·lbf)
34. INSTALL POWER STEERING IDLE PULLEY BRACKET (See page 14 −108)
35. ADJUST V (COOLER COMPRESSOR TO CRANKSHAFT PULLEY) BELT NO.1 (See Pub. No. RM1018E on page 14 −269)
36. INSTALL INJECTOR DRIVER (See page 14 −108)
37. INSTALL ENGINE COVER SUB −ASSY NO.1 (See page 14 −90)
38. INSTALL FRONT WHEELS Torque: 103 N
m (1,050 kgf
cm, 76 ft
lbf)

141NB−01
−
ENGINE MECHANICAL CYLINDER HEAD GASKET (2AZ −FSE)
14 −79
AVENSIS Supplement (RM1045E)
REPLACEMENT
1. DISCHARGE FUEL SYSTEM PRESSURE (See page 11 −4)
2. REMOVE FRONT WHEEL RH
3. REMOVE RADIATOR SUPPORT OPENING COVER (See page 14 −23)
4. REMOVE ENGINE ROOM COVER SIDE (See page 14 −23)
5. REMOVE ENGINE UNDER COVER LH (See page 14 −23)
6. REMOVE ENGINE UNDER COVER NO.4 RH (See page 14 −23)
7. REMOVE ENGINE UNDER COVER RH (See page 14 −23)
8. DRAIN COOLANT (See page 16 −7)
9. DRAIN ENGINE OIL (See page 17 −6)
10. REMOVE ENGINE COVER SUB −ASSY NO.1 (See page 14 −45)
11. REMOVE FUEL PRESSURE PULSATION DAMPER ASSY
12. SEPARATE FUEL TUBE SUB −ASSY (See page 11 −4)
13. REMOVE FUEL PIPE SUB −ASSY NO.1 (See page 11 −24)
SST 09023 −12900
14. REMOVE FUEL PUMP ASSY (See page 11 −24)
15. REMOVE FAN AND GENERATOR V BELT (See page 14 −5)
SST 09249 −63010
16. REMOVE GENERATOR ASSY (See page 19 −8)
17. REMOVE EXHAUST PIPE ASSY FRONT (See page 15 −2)
18. SEPARATE VANE PUMP ASSY (See page 14 −45)
19. REMOVE IGNITION COIL ASSY (See page 14 −45)
20. SEPARATE RETURN TUBE SUB −ASSY (See page 14 −45)
21. SEPARATE COOLER REFRIGERANT SUCTION HOSE NO.1 (LHD STEERING POSITION TYPE) (See page 14 −45)
22. REMOVE VANE PUMP OIL RESERVOIR ASSY (See page 14 −45)
23. REMOVE OIL RESERVOIR BRACKET NO.1 (See page 14 −45)
24. SEPARATE ENGINE WIRE (See page 14 −23)
25. REMOVE COOLER BRACKET (LHD STEERING POSITION TYPE) (See page 14 −45)
26. REMOVE ENGINE SERVICE COVER BRACKET RH (RHD STEERING POSITION TYPE)
(See page 14 −45)
27. REMOVE CYLINDER HEAD COVER SUB −ASSY (See page 14 −45)
28. SET NO. 1 CYLINDER TO TDC/COMPRESSION (See page 14 −45)
29. REMOVE ENGINE MOUNTING BRACKET NO.2 RH (See page 14 −45)
30. REMOVE TRANSVERSE ENGINE ENGINE MOUNTING INSULATOR (See page 14 −45)
31. REMOVE CRANKSHAFT PULLEY (See page 14 −45)
SST 09213 −54015 (91651 −60855), 09330 −00021, 09950 −50013 (09951 −05010, 09952 −05010,
09953 −05020, 09954 −05021)
32. REMOVE CHAIN TENSIONER ASSY NO.1 (See page 14 −45)
33. REMOVE CRANKSHAFT POSITION SENSOR (See page 14 −45)
34. REMOVE OIL PAN SUB −ASSY (See page 14 −45)
SST 09032 −00100
35. REMOVE V −RIBBED BELT TENSIONER ASSY (See page 14 −45)
36. REMOVE TIMING CHAIN OR BELT COVER SUB −ASSY (See page 14 −45)
37. REMOVE CRANKSHAFT POSITION SENSOR PLATE NO.1 (See page 14 −45)
38. REMOVE CHAIN TENSIONER SLIPPER (See page 14 −45)
39. REMOVE CHAIN VIBRATION DAMPER NO.1 (See page 14 −45)
40. REMOVE TIMING CHAIN GUIDE (See page 14 −45)
41. REMOVE CHAIN SUB −ASSY (See page 14 −45)

14−84
−
ENGINE MECHANICAL CYLINDER HEAD GASKET (2AZ −FSE)
AVENSIS Supplement (RM1045E)
94. INSTALL FUEL PIPE SUB −ASSY NO.1 (See page 11 −24)
SST 09023 −12900
95. INSTALL FUEL TUBE SUB −ASSY (See page 11 −24)
96. INSTALL FUEL PRESSURE PULSATION DAMPER ASSY (See page 11 −24)
97. INSTALL ENGINE COVER SUB −ASSY NO.1
Torque: 7.0 N
m (71 kgf
cm, 62 in.
lbf)
98. INSTALL VANE PUMP ASSY Torque: 37 N
m (377 kgf
cm, 27 ft
lbf)
99. INSTALL EXHAUST PIPE ASSY FRONT (See page 15 −2)
100. INSTALL GENERATOR ASSY (See page 19 −8)
101. INSTALL FAN AND GENERATOR V BELT (See page 14 −5)
SST 09249 −63010
102. ADD COOLANT (See page 16 −7)
103. ADD ENGINE OIL (See page 17 −6)
104. CHECK FOR ENGINE COOLANT LEAKS (See page 16 −1)
105. CHECK FOR ENGINE OIL LEAKS
106. CHECK FOR FUEL LEAKS (See page 11 −4)
107. INSTALL FRONT WHEEL RH Torque: 103 N
m (1,050 kgf
cm, 76 ft
lbf)
108. ADD POWER STEERING FLUID (See Pub. No. RM1018E on page 51 −4)
109. BLEED POWER STEERING FLUID (See Pub. No. RM1018E on page 51 −4)
110. CHECK POWER STEERING FULUID LEVEL IN RESERVOIR
(See Pub. No. RM1018E on page 51 −4)
111. CHECK FUNCTION OF THROTTLE BODY

300N6−01
C53220F45751
SST
F13686
Hold
Turn
C80291
F44775
30−4
− DRIVE SHAFT / PROPELLER SHAFTFRONT DRIVE SHAFT (2AZ−FSE)
AVENSIS Supplement (RM1045E)
OVERHAUL
HINT:
Overhaul the RH side following the same procedure as for the LH side.
1. DRAIN AUTOMATIC TRANSAXLE FLUID (A/T TRANSAXLE)
(a) Remove the drain plug and gasket, and then drain the ATF.
(b) Install a new gasket and drain plug.
Torque: 49 N
m (500 kgf
cm, 36 ft
lbf)
2. REMOVE FRONT WHEEL
3. REMOVE ENGINE UNDER COVER LH
4. SEPARATE FRONT AXLE HUB LH NUT
(a) Using SST and a hammer, unstake the staked part of the
nut.
SST 09930−00010
(b) While applying the brake, remove the axle hub LH nut.
NOTICE:
Loosen the staked part of the lock nut completely, other-
wise the screw of the drive shaft may become damaged.
5. SEPARATE FRONT STABILIZER LINK ASSY LH
(a) Remove the nut and separate the front stabilizer link assy
LH from the shock absorber assy LH.
HINT:
If the ball joint turns together with the nut, use a hexagon
wrench (6 mm) to hold the stud.
6. DISCONNECT SPEED SENSOR FRONT LH
(a) Remove the bolt, and disconnect the speed sensor wire
and flexible hose from the shock absorber.
(b) Remove the bolt, and disconnect the speed sensor from
the steering knuckle.
NOTICE:
SBe careful not to damage the speed sensor.
SPrevent foreign matter from adhering to the speed
sensor.

170IZ−01
A57104
SST
A09582
−
LUBRICATION OIL PUMP ASSY (1CD −FTV)(From September, 2003)
17 −11
AVENSIS Supplement (RM1045E)
OIL PUMP ASSY (1CD −FTV)(From September, 2003)
REPLACEMENT
1. DRAIN ENGINE OIL (See Pub. No. RM1018E on page 17 −30)
2. REMOVE RADIATOR SUPPORT OPENING COVER
3. REMOVE ENGINE ROOM COVER SIDE
4. REMOVE FRONT WHEEL RH
5. REMOVE ENGINE UNDER COVER SUB −ASSY NO.1
6. REMOVE ENGINE UNDER COVER RH
7. REMOVE ENGINE COVER SUB −ASSY NO.1 (See page 14 −90)
8. REMOVE INJECTOR DRIVER (See page 14 −108)
9. REMOVE V (COOLER COMPRESSOR TO CRANKSHAFT PULLEY) BELT NO.1 (See Pub. No. RM1018E on page 14 −269)
10. REMOVE GENERATOR V BELT (See Pub. No. RM1018E on page 14 −269)
11. SEPARATE POWER STEERING IDLE PULLEY BRACKET (See page 14 −138)
12. DISCONNECT ENGINE WIRE (See page 14 −138)
13. DISCONNECT VACUUM HOSE (See page 14 −108)
14. REMOVE ENGINE MOUNTING INSULATOR SUB −ASSY RH (See page 14 −138)
15. REMOVE CRANKSHAFT PULLEY (See page 14 −138)
SST 09213 −54015 (09213 −70020), 09330 −00021, 09950 −50013 (09951 −05010, 09952 −05010,
09953 −05020, 09954 −05031)
16. REMOVE IDLER PULLEY SUB −ASSY (See page 14 −138)
17. REMOVE TIMING BELT NO.2 COVER (See page 14 −138)
18. REMOVE TIMING BELT NO.1 COVER (See page 14 −138)
19. REMOVE TIMING BELT GUIDE
20. REMOVE TRANSVERSE ENGINE ENGINE MOUNTING BRACKET (See page 14 −138)
21. SET NO. 1 CYLINDER TO TDC/COMPRESSION (See page 14 −138)
22. REMOVE TIMING CHAIN COVER PLATE (See page 14 −138)
23. REMOVE TIMING BELT (See page 14 −138)
24. REMOVE TIMING BELT IDLER SUB −ASSY NO.2
25. REMOVE CRANKSHAFT TIMING PULLEY
(a) If the timing pulley cannot be removed by hand, use SST to remove the pulley.
SST 09950 −50013 (09951 −05010, 09952 −05010,
09953 −05010, 09953 −05020, 09954 −05021)

A57102
Turn
17
−18
−
LUBRICATION OIL PUMP ASSY (1CD −FTV)(From September, 2003)
AVENSIS Supplement (RM1045E)
54. INSTALL TIMING BELT IDLER SUB −ASSY NO.2
(a) Install the idler pulley with bolt. Torque: 47 N
m (475 kgf
cm, 34 ft
lbf)
(b) Check that the idler pulley moves smoothly.
55. SET NO. 1 CYLINDER TO TDC/COMPRESSION (See page 14 −138)
SST 09960 −10010 (09962 −01000, 09963 −01000)
56. INSTALL TIMING BELT (See page 14 −138)
57. CHECK VALVE TIMING (See page 14 −138)
58. INSTALL TIMING CHAIN COVER PLATE (See page 14 −138)
59. INSTALL TRANSVERSE ENGINE ENGINE MOUNTING BRACKET (See page 14 −138)
60. INSTALL TIMING BELT GUIDE (See page 14 −138)
61. INSTALL TIMING BELT NO.1 COVER (See page 14 −138)
62. INSTALL TIMING BELT NO.2 COVER (See page 14 −138)
63. INSTALL IDLER PULLEY SUB −ASSY (See page 14 −138)
64. INSTALL CRANKSHAFT PULLEY (See page 14 −138)
SST 09213 −54015 (09213 −70020), 09330 −00021
65. INSTALL ENGINE MOUNTING INSULATOR SUB −ASSY RH (See page 14 −138)
66. INSTALL POWER STEERING IDLE PULLEY BRACKET (See page 14 −108)
67. ADJUST V (COOLER COMPRESSOR TO CRANKSHAFT PULLEY) BELT NO.1 (See Pub. No. RM1018E on page 14 −269)
68. INSTALL INJECTOR DRIVER (See page 14 −108)
69. INSTALL ENGINE COVER SUB −ASSY NO.1 (See page 14 −90)
70. INSTALL FRONT WHEEL RH Torque: 103 N
m (1,050 kgf
cm, 76 ft
lbf)
71. ADD ENGINE OIL (See Pub. No. RM1018E on page 17 −30)
72. CHECK FOR ENGINE OIL LEAKS

141NN−01
A61184
A85928
−
ENGINE MECHANICAL CRANKSHAFT SEAL (1CD−FTV)(From September,
2003)14 −177
AVENSIS Supplement (RM1045E)
CRANKSHAFT SEAL (1CD −FTV)(From September, 2003)
REPLACEMENT
1. DRAIN ENGINE OIL
(a) Install a new gasket and the drain plug after draining engine oil.
Torque: 34 N
m (350 kgf
cm, 25 ft
lbf)
2. REMOVE FRONT WHEEL RH
3. REMOVE ENGINE UNDER COVER SUB −ASSY NO.1
4. REMOVE ENGINE UNDER COVER RH
5. REMOVE RADIATOR SUPPORT OPENING COVER
6. REMOVE ENGINE ROOM COVER SIDE
7. REMOVE ENGINE COVER NO.1 (See page 14 −90)
8. REMOVE INJECTOR DRIVER (See page 14 −108)
9. REMOVE V (COOLER COMPRESSOR TO CRANKSHAFT PULLEY) BELT NO.1
(See Pub. No. RM1018E on page 14 −269)
10. REMOVE GENERATOR V BELT (See Pub. No. RM1018E on page 14 −269)
11. SEPARATE POWER STEERING IDLE PULLEY BRACKET (See page 14 −138)
12. DISCONNECT ENGINE WIRE (See page 14 −138)
13. DISCONNECT VACUUM HOSE (See page 14 −108)
14. REM O VE ENG I NE M O UNTI NG I NSULATO R SUB−ASSY RH
(a) Place a wooden block on a jack underneath the engine.
(b) Remove the 3 bolts and 3 nuts, then detach the engine mounting insulator sub −assembly.
15. REMOVE CRANKSHAFT PULLEY (See page 14 −138)
SST 09213 −54015 (09213 −70020), 09330 −00021, 09950 −50013 (09951 −05010, 09952 −05010,
09953 −05020, 09954 −05031)
16. REMOVE IDLER PULLEY SUB −ASSY (See page 14 −138)
17. REMOVE TIMING BELT NO.2 COVER (See page 14 −138)
18. REMOVE TIMING BELT NO.1 COVER (See page 14 −138)
19. REMOVE TIMING BELT GUIDE
20. REMOVE TRANSVERSE ENGINE ENGINE MOUNTING BRACKET (See page 14 −138)

−
ENGINE MECHANICAL CRANKSHAFT SEAL (1CD−FTV)(From September,
2003)14 −179
AVENSIS Supplement (RM1045E)
31. INSTALL TIMING CHAIN COVER PLATE (See page 14 −138)
32. INSTALL TRANSVERSE ENGINE ENGINE MOUNTING BRACKET (See page 14 −138)
33. INSTALL TIMING BELT GUIDE (See page 14 −138)
34. INSTALL TIMING BELT NO.1 COVER (See page 14 −138)
35. INSTALL TIMING BELT NO.2 COVER (See page 14 −138)
36. INSTALL IDLER PULLEY SUB −ASSY (See page 14 −138)
37. INSTALL CRANKSHAFT PULLEY (See page 14 −138 )
SST 09213 −54015 (09213 −70020), 09330 −00021
38. INSTALL ENGINE MOUNTING INSULATOR SUB −ASSY RH (See page 14 −138)
39. INSTALL POWER STEERING IDLE PULLEY BRACKET (See page 14 −108)
40. ADJUST V (COOLER COMPRESSOR TO CRANKSHAFT PULLEY) BELT NO.1 (See Pub. No. RM1018E on page 14 −269)
41. INSTALL INJECTOR DRIVER (See page 14 −108)
42. INSTALL ENGINE COVER NO.1 (See page 14 −90)
43. INSTALL FRONT WHEEL RH
Torque: 103 N
m (1,050 kgf
cm, 76 ft
lbf)
44. ADD ENGINE OIL
45. CHECK FOR ENGINE OIL LEAKS
