2005 TOYOTA AVENSIS drain bolt

−
SERVICE SPECIFICATIONS ENGINE MECHANICAL
03−1 7
AVENSIS Supplement (RM1045E) Part Tightened
ft
lbf
kgf
cm
N
m
Front suspension crossmember sub −assy x Rear engine mounting bracket8788764
Front suspension crossmember sub −assy x Front engine mounting bracket5253038
Front suspension crossmember sub −assy x Body1331,35698
Front suspension member brace x Front suspension crossmember sub −assy1331,35698
Front suspension member brace x Body8081659
Return tube sub −assy x Body8.08271 in.
lbf
Engine mounting insulator RH x Body5253038
Engine mounting insulator RH x Transverse engine engine mounting blacket5253038
Engine mounting bracket LH x Engine mounting insulator LH8081659
Air tube No. 2 hose clamp bolt Intake shutter side
Air hose No. 3 side6.0
5.361
5453 in.
lbf
47 in.
lbf
Injector driver x Engine mounting insulator RH5.55649 in.
lbf
Engine wire x Body8.48574 in.
lbf
Air tube No.2 x Manual transaxle2525518
Relay block x Radiator assy5.35447 in.
lbf
Differential pressure sensor x Body5.55649 in.
lbf
Air cleaner assy x Body x Engine mounting bracket LH7.07162 in.
lbf
Battery clamp x Body Body
Nut5.0
3.0 to 4.051
31 to 4144 in.
lbf
27 to 35 in.
lbf
Battery terminal5.45548 in.
lbf
Timing belt tensioner x Cylinder block2121415
Timing chain cover plate x Camshaft oil seal retainer9.09280 in.
lbf
Transverse engine engine mounting bracket x
Cylinder block (See page 14 −138) Bolt A
Bolt B
37
64375
65027
47
Timing belt No. 1 cover x Transverse engine engine mounting bracket7.47565 in.
lbf
Timing belt No. 1 cover x Oil pump assy7.47565 in.
lbf
Timing belt No. 2 cover x Transverse engine engine mounting bracket7.47565 in.
lbf
Timing belt No. 2 cover x Cylinder head cover sub −assy7.47565 in.
lbf
Timing belt No. 2 cover x Camshaft oil seal retainer7.47565 in.
lbf
Timing belt No. 2 cover x Timing belt cover No. 37.47565 in.
lbf
Crankshaft pulley x Crankshaft1801,835133
Camshaft bearing cap x Cylinder head2020415
Camshaft oil seal retainer x Cylinder head9.81007.2
Camshaft timing pulley x Camshaft8889965
Nozzle leakage pipe x Injector1616312
Nozzle leakage pipe x Camshaft bearing cap No. 42020415
Cylinder head cover x Cylinder head131359.7
Vacuum reservoir sub −assy x Cowl top panel outer8.38573 in.
lbf
Cylinder head x Cylinder block 1st
2nd3rd4th45
Turn 90 _
Turn 90 _
Turn 90 _459
Turn 90 _
Turn 90 _
Turn 90 _33
Turn 90 _
Turn 90 _
Turn 90 _
Exhaust fuel addition injector x Cylinder head1211 78.5
Drain plug (oil pan)3435025

1111 4−01
A88253
(a)
(b)
Pull Out
A88252
(a)
(b)
(c)
(d)
A77920
RHD:
LHD:
−
FUEL FUEL INJECTOR ASSY (2AZ −FSE)
11 −13
AVENSIS Supplement (RM1045E)
REPLACEMENT
1. DISCHARGE FUEL SYSTEM PRESSURE (See page 11 −1)
2. REMOVE RADIATOR SUPPORT OPENING COVER (See page 10 −8)
3. REMOVE ENGINE ROOM COVER SIDE (See page 10 −8)
4. DISCONNECT ENGINE WIRE NO.3 (BATTERY NEGATIVE TERMINAL)
5. DRAIN ENGINE COOLANT (See page 16 −7)
6. REMOVE ENGINE COVER SUB −ASSY NO.1 (See page 10 −8)
7. REMOVE AIR CLEANER CAP SUB −ASSY (See page 10 −8)
8. REMOVE THROTTLE BODY ASSY (See page 10 −8)
9. REMOVE FUEL TUBE SUB −ASSY (See page 11 −24)
SST 09617 −24011
10. REMOVE FUEL HOSE (See page 11 −24)
11. REMOVE FUEL PIPE SUB −ASSY NO.1 (See page 11 −24)
SST 09023 −12900
12. REMOVE FUEL PUMP ASSY (See page 11 −24)
13. REMOVE CHARCOAL CANISTER ASSY
(a) Disconnect the fuel hose from the charcoal canister hose.
(b) Disconnect the charcoal canister outlet hose No. 1 from the charcoal canister.
(c) Pull out the charcoal canister from the charcoal canister base bracket.
14. REMOVE VACUUM SENSOR ASSY (LHD STEERING POSITION TYPE)
(a) Remove the wiring harness clamp.
(b) Disconnect the vacuum sensor connector.
(c) Disconnect the vacuum hose from the vacuum sensor.
(d) Remove the bolt, then remove the vacuum sensor.
15. REMOVE INTAKE MANIFOLD
(a) Disconnect the union to connector tube hose from the
brake booster.

141NG−01
A84393
(a)
(a)
(b)(b)
(a)
A84286
14 −108−
ENGINE MECHANICAL PARTIAL ENGINE ASSY (1CD −FTV)(From September,
2003)
AVENSIS Supplement (RM1045E)
REPLACEMENT
1. REMOVE FRONT WHEELS
2. REMOVE ENGINE UNDER COVER LH
3. REMOVE ENGINE UNDER COVER SUB −ASSY NO.1
4. REMOVE ENGINE UNDER COVER RH
5. REMOVE RADIATOR SUPPORT OPENING COVER
6. REMOVE ENGINE ROOM COVER SIDE
7. DRAIN ENGINE COOLANT (See page 16 −19)
8. DRAIN ENGINE OIL (See Pub No. RM1018E on page 17 −30)
9. DRAIN MANUAL TRANSAXLE OIL
Torque: 49 N
m (500 kgf
cm, 36 ft
lbf)
10. REMOVE ENGINE COVER SUB −ASSY NO.1
(a) Remove the 5 nuts, then remove the engine cover.
11. REMOVE BATTERY
12. REMOVE AIR CLEANER ASSY
(a) Disconnect the mass air flow meter connector.
(b) Remove the air cleaner cap together with the air cleaner hose.
(c) Remove the air cleaner filter element.
(d) Remove the 3 bolts and air cleaner case.
13. REMOVE VACUUM RESERVOIR SUB −ASSY
(a) Disconnect the 2 vacuum hoses and connector.
(b) Remove the 2 bolts and vacuum reservoir.
14. REMOVE FUEL FILTER ASSY (See Pub. No. RM1018E on page 11 −82)
15. REMOVE RADIATOR HOSE INLET
16. REMOVE RADIATOR HOSE OUTLET
17. DISCONNECT WATER BY−PASS HOSE NO.2

1308N−01
A84393
(a)
(b)
(a)
(a)
(b)
A93661
(a)
(a) (a)
(a) (b)
(a)
(b)
13
−12
−
INTAKE TURBOCHARGER SUB −ASSY (1CD −FTV)(From
September, 2003)
AVENSIS Supplement (RM1045E)
REPLACEMENT
1. REMOVE ENGINE UNDER COVER SUB −ASSY NO.1
2. DRAIN ENGINE COOLANT (See page 16 −19)
3. REMOVE RADIATOR SUPPORT OPENING COVER
4. REMOVE ENGINE COVER SUB −ASSY NO.1
(a) Remove the 5 nuts and engine cover.
5. REMOVE VACUUM RESERVOIR SUB −ASSY
(a) Disconnect the 2 vacuum hoses and connector.
(b) Remove the 2 bolts and vacuum reservoir.
6. REMOVE DIFFERENTIAL PRESSURE SENSOR ASSY (See page 14 −108)
7. DISCONNECT ENGINE WIRE (See page 14 −138)
8. REMOVE AIR CLEANER ASSY
(a) Disconnect the PCV hose and connector.
(b) Remove the air cleaner cap with the air cleaner hose.
(c) Remove the air cleaner filter element.
(d) Remove the 3 bolts and air cleaner case.
9. REMOVE AIR TUBE NO.1
(a) Remove the 3 bolts and nut, then separate the air tubeNo. 1.
(b) Loosen the hose clamp bolts.
10. REMOVE FUEL FILTER ASSY (See Pub. No. RM1018E on page 11 −82)

300N6−01
C53220F45751
SST
F13686
Hold
Turn
C80291
F44775
30−4
− DRIVE SHAFT / PROPELLER SHAFTFRONT DRIVE SHAFT (2AZ−FSE)
AVENSIS Supplement (RM1045E)
OVERHAUL
HINT:
Overhaul the RH side following the same procedure as for the LH side.
1. DRAIN AUTOMATIC TRANSAXLE FLUID (A/T TRANSAXLE)
(a) Remove the drain plug and gasket, and then drain the ATF.
(b) Install a new gasket and drain plug.
Torque: 49 N
m (500 kgf
cm, 36 ft
lbf)
2. REMOVE FRONT WHEEL
3. REMOVE ENGINE UNDER COVER LH
4. SEPARATE FRONT AXLE HUB LH NUT
(a) Using SST and a hammer, unstake the staked part of the
nut.
SST 09930−00010
(b) While applying the brake, remove the axle hub LH nut.
NOTICE:
Loosen the staked part of the lock nut completely, other-
wise the screw of the drive shaft may become damaged.
5. SEPARATE FRONT STABILIZER LINK ASSY LH
(a) Remove the nut and separate the front stabilizer link assy
LH from the shock absorber assy LH.
HINT:
If the ball joint turns together with the nut, use a hexagon
wrench (6 mm) to hold the stud.
6. DISCONNECT SPEED SENSOR FRONT LH
(a) Remove the bolt, and disconnect the speed sensor wire
and flexible hose from the shock absorber.
(b) Remove the bolt, and disconnect the speed sensor from
the steering knuckle.
NOTICE:
SBe careful not to damage the speed sensor.
SPrevent foreign matter from adhering to the speed
sensor.

160MR−02
B12054
SST
B12052
B12053
Pry
PryPry
16
−12
−
COOLING WATER PUMP ASSY (2AZ −FSE)
AVENSIS Supplement (RM1045E)
WATER PUMP ASSY (2AZ −FSE)
REPLACEMENT
1. DRAIN COOLANT (See page 16 −7)
2. REMOVE RADIATOR SUPPORT OPENING COVER (See page 14 −23)
3. REMOVE ENGINE ROOM COVER SIDE (See page 14 −23)
4. REMOVE ENGINE UNDER COVER LH (See page 14 −23)
5. REMOVE ENGINE UNDER COVER NO.4 RH (See page 14 −23)
6. REMOVE ENGINE UNDER COVER RH (See page 14 −23)
7. REMOVE FAN AND GENERATOR V BELT (See page 14 −5)
SST 09249 −63010
8. REMOVE GENERATOR ASSY (See page 19 −8)
9. REMOVE WATER PUMP PULLEY
(a) Using SST, remove the 4 bolts and pump pulley. SST 09960 −10010 (09962 −01000, 09963 −00700)
(b) Disconnect the crankshaft position sensor wire clamp
from the water pump.
(c) Disconnect the crankshaft position sensor wire from the clamp on the water pump.
10. REMOVE WATER PUMP ASSY
(a) Remove the 4 bolts, 2 nuts, wire clamp and water pump.
(b) Using a screwdriver, pry out between the water pump and cylinder block, and remove the water pump.
NOTICE:
Be careful not to damage the contact surface of the water
pump and cylinder block.

141NN−01
A61184
A85928
−
ENGINE MECHANICAL CRANKSHAFT SEAL (1CD−FTV)(From September,
2003)14 −177
AVENSIS Supplement (RM1045E)
CRANKSHAFT SEAL (1CD −FTV)(From September, 2003)
REPLACEMENT
1. DRAIN ENGINE OIL
(a) Install a new gasket and the drain plug after draining engine oil.
Torque: 34 N
m (350 kgf
cm, 25 ft
lbf)
2. REMOVE FRONT WHEEL RH
3. REMOVE ENGINE UNDER COVER SUB −ASSY NO.1
4. REMOVE ENGINE UNDER COVER RH
5. REMOVE RADIATOR SUPPORT OPENING COVER
6. REMOVE ENGINE ROOM COVER SIDE
7. REMOVE ENGINE COVER NO.1 (See page 14 −90)
8. REMOVE INJECTOR DRIVER (See page 14 −108)
9. REMOVE V (COOLER COMPRESSOR TO CRANKSHAFT PULLEY) BELT NO.1
(See Pub. No. RM1018E on page 14 −269)
10. REMOVE GENERATOR V BELT (See Pub. No. RM1018E on page 14 −269)
11. SEPARATE POWER STEERING IDLE PULLEY BRACKET (See page 14 −138)
12. DISCONNECT ENGINE WIRE (See page 14 −138)
13. DISCONNECT VACUUM HOSE (See page 14 −108)
14. REM O VE ENG I NE M O UNTI NG I NSULATO R SUB−ASSY RH
(a) Place a wooden block on a jack underneath the engine.
(b) Remove the 3 bolts and 3 nuts, then detach the engine mounting insulator sub −assembly.
15. REMOVE CRANKSHAFT PULLEY (See page 14 −138)
SST 09213 −54015 (09213 −70020), 09330 −00021, 09950 −50013 (09951 −05010, 09952 −05010,
09953 −05020, 09954 −05031)
16. REMOVE IDLER PULLEY SUB −ASSY (See page 14 −138)
17. REMOVE TIMING BELT NO.2 COVER (See page 14 −138)
18. REMOVE TIMING BELT NO.1 COVER (See page 14 −138)
19. REMOVE TIMING BELT GUIDE
20. REMOVE TRANSVERSE ENGINE ENGINE MOUNTING BRACKET (See page 14 −138)

I35328
(1)(2)
(3)
(4)
−
HEATER & AIR CONDITIONER W/PULLEY COMPRESSOR ASSY (2AZ −FSE)
55 −5
AVENSIS Supplement (RM1045E)
9. INSPECT COMPRESSOR OIL
(a) When replacing the w/pulley compressor assy with a new one, after gradually removing the refrigerant
gas from the service valve, drain the following amount of oil from the new w/pulley compressor assy
before installation.
Standard:
(Oil capacity inside new w/pulley compressor assy: 90 + 15 cc (3.0 + 0.5 fl. oz.) ) − (Remaining
oil amount in the removed w/pulley compressor assy) = (Oil amount to be removed when replac-
ing)
NOTICE:
S When checking the compressor oil level, observe the precautions on the cooler removal/instal-
lation.
S Since compressor oil remains in the pipes of the vehicle, if a new w/pulley compressor assy
is installed without removing some oil inside, the oil amount becomes excessive, preventing
heat exchange in the refrigerant cycle and causing refrigerant failure.
S If the remaining oil in the removed w/pulley compressor assy is too small in volume, check for
oil leakage.
S Be sure to use ND −OIL 8 for compressor oil.
10. INSTALL W/PULLEY COMPRESSOR ASSY
(a) Install the w/pulley compressor assy with the 4 bolts.
Torque: 29 N
m (300 kgf
cm, 2 1 ft
lbf)
NOTICE:
Tighten the bolts in the order shown in the illustration to
install the w/pulley compressor assy.
(b) Connect the connector.
11 . INSTALL FAN AND GENERATOR V BELT (See page 14− 5)
SST 09249 −63010
12. INSTALL COOLER REFRIGERANT DISCHARGE
HOSE NO. 1
(a) Remove the attached vinyl tape from the hose.
(b) Sufficiently apply compressor oil to a new O −ring and the
fitting surface of the w/pulley compressor assy.
Compressor oil: ND −OIL 8 or equivalent
(c) Install the O −ring on the cooler refrigerant discharge hose
No.1.
