2005 PEUGEOT 807 Owners Manual

98 -
28-02-2005
99
-
28-02-2005
THE DOORS
Opening the doors from outside
Opening the doors from inside
Note: the door opening switches
do not function when the vehicle is
deadlocked. Locking/Unlocking from the inside
Press button
A, the red warning light
comes on when the vehicle is locked
and switches off when it is unlocked.
This locks/unlocks the doors and the
tailgate.
Note: if the vehicle is locked or dead-
locked from outside, the red warning
light lashes and button A does not
function. In this case, use the key or
the remote control for unlocking.
Electric sliding side doors
Opening/Closing from the front:
- press the corresponding switch B
to open or close.
An audible signal accompanies the
opening and closing of the door.
Automatic central locking
The doors can lock automatically
when you are driving (at a speed of
more than 6 mph (10 km/h)).
You can activate or deactivate this
function.
To switch on
Press and hold button
A.
Activation of the function is accom-
panied by an audible signal and the
message ''Automatic locking of
the doors activated'' on the multi-
function display.
To switch off
Press and hold button A.
Deactivation of the function is ac-
companied by an audible signal.
"Door open" alert
With the engine running or the vehi-
cle moving, a diagram locating the
door on the multi-function display
and an audible signal warn you that
a door is not properly closed. Opening/Closing from the
2nd row:
- press the corresponding switch
C
to open or close.
Disarming the 2nd row controls:
- press the rear electric functions disarming switch.
Access and starting

98 -
28-02-2005
99
-
28-02-2005
Opening/Closing using the
remote control:
- press button C to open or close the
rear right door.
- press button D to open or close the
rear left door.
Note: the electric sliding side doors
are itted with an obstacle detection
system.
If an obstacle appears while the door
is closing, the door re-opens.
If an obstacle appears while the door
is opening, the door stops.
In both cases, complete the required
action manually using the handle. The force with which the
door moves may cause
injury.
When opening or closing the
door, ensure that nothing
prevents the required manoeuvre.
Do not leave children or animals
near the door controls without super-
vision. If necessary, disarm the con-
trols, then remove the key from the
ignition, even for a short time.
Before setting off, check that the
door is correctly closed and locked
(see "door open" warning).
Child safety
A - Mechanical
This prevents either of the rear doors
being opened from inside.
F Turn the switch A a quarter of a
turn using the ignition key.
B - Electric
This disarms all the electrical con-
trols in the rear:
F electric windows,
F sliding side doors,
F sunroofs.
With the ignition on, press button B.
The message "Child safety acti-
vated" appears on the multi-function
display, accompanied by an audible
signal.
Always remove the ignition
key when leaving the vehi-
cle, even for a short time.
Access and starting

98 -
28-02-2005
99
-
28-02-2005
Opening/Closing using the
remote control:
- press button C to open or close the
rear right door.
- press button D to open or close the
rear left door.
Note: the electric sliding side doors
are itted with an obstacle detection
system.
If an obstacle appears while the door
is closing, the door re-opens.
If an obstacle appears while the door
is opening, the door stops.
In both cases, complete the required
action manually using the handle. The force with which the
door moves may cause
injury.
When opening or closing the
door, ensure that nothing
prevents the required manoeuvre.
Do not leave children or animals
near the door controls without super-
vision. If necessary, disarm the con-
trols, then remove the key from the
ignition, even for a short time.
Before setting off, check that the
door is correctly closed and locked
(see "door open" warning).
Child safety
A - Mechanical
This prevents either of the rear doors
being opened from inside.
F Turn the switch A a quarter of a
turn using the ignition key.
B - Electric
This disarms all the electrical con-
trols in the rear:
F electric windows,
F sliding side doors,
F sunroofs.
With the ignition on, press button B.
The message "Child safety acti-
vated" appears on the multi-function
display, accompanied by an audible
signal.
Always remove the ignition
key when leaving the vehi-
cle, even for a short time.
Access and starting

100 -
28-02-2005
101
-
28-02-2005
TAILGATE
Simultaneous locking or
unlocking of the tailgate and the
doors
The tailgate is locked or unlocked
by the remote control or the driver's
door or passenger door lock.
To open, operate the handle A and
lift the tailgate.
Note: The tailgate locks automati-
cally when the vehicle is being driven
at more than 6 mph (10 km/h) and
unlocks when one of the front doors
is opened.
Tailgate release
This enables the tailgate to be un-
locked in the event of a central lock-
ing fault.
F Fold back a 2nd row rear seat,
F Fold back a 3rd row rear seat or
the bench seat to gain access to
the lock from inside the boot,
F Insert a small screwdriver into
hole B in the lock and push it
towards the left to unlock the tail-
gate.
REAR WINDOWS
To partially open the rear windows,
tilt the lever and push it fully to lock
the windows in the open position.
"Tailgate open" warning
When the engine is running or the
vehicle is being driven, you are
warned if the tailgate is not closed
correctly by a diagram on the multi-
function display, accompanied by an
audible signal.
Access and starting

100 -
28-02-2005
101
-
28-02-2005
SUNROOFS
You have three sunroofs each with
an independent control.
However, the front passengers' con-
trol can also operate the two rear
sunroofs simultaneously.
• to partially open the roof: press
and hold part A of the switch.
• to open the roof completely:
press part A of the switch briely.
• to close it completely: press part
B of the switch briely, then keep it
pressed.
• safety auto-reverse
When the sunroof is sliding closed
and meets an obstacle, it stops then
partially opens again. Notes:

In the event of unwanted opening of
the roof on closing (for example, in
the presence of ice), if the sunroof
does not close, press section A of
the control until the roof is fully open,
then close the roof.
Continue to press the control for ap-
proximately one second after closing.
Following reconnection of the bat-
tery, in the event of a malfunction,
release the control and press it again
until the roof is fully closed. Continue
to press the control for approximately
ive seconds after closing.
The safety auto-reverse function is
not active during these operations. Always remove the key
from the ignition when leav-
ing the vehicle, even for a
short time.
Always ensure that the
sunroofs are closed correctly before
leaving the vehicle.
In the event of contact during opera-
tion of the roof, you must reverse the
movement of the roof. To do this,
press the switch concerned.
When the driver operates the roof
switch, he must ensure that no one
is preventing correct closing of the
roof.
The driver must ensure that the pas-
sengers use the sunroof correctly.
Be aware of children when operating
the roof.
Disarming of the 2nd and 3rd row
controls:
- press the rear electrical functions disarming switch.
Note: the sunroof shutter is manual.
To open it, lift the handle and slide it
rearwards.
To close it, slide it forwards until the
handle locks.
Do not open the sunroofs immedi-
ately after a shower or immediately
after washing the car.
Access and starting

102 -
28-02-2005
FILLING THE FUEL TANK
Low fuel level
OPENING THE BONNET
From inside: -
lift the cover located at the left foot
of the driver's seat.
- pull the control upwards.
From outside: lift the catch and
raise the bonnet. The tank must be illed with fuel with
the engine off
.
F Open the fuel iller lap.
F Insert the key then turn it to the
left.
F Remove the cap and attach it to
the clip located on the inside of
the lap.
A label on the inside of the lap indi-
cates which type of fuel to use.
If you ill your tank, do not continue
after the third cut-off of the pump
nozzle. This could result in vehicle
malfunctions.
The capacity of the tank is approx-
imately 18 gallons (80 litres).
F After illing the tank, lock the cap
and close the lap.
When the tank's minimum
level is reached, this warning
light comes on, accompa-
nied by the message "Fuel
level low" on the multi-func-
tion display.
You have enough fuel left to cover
approximately 30 miles (50 km).
If the warning light lashes, this indi-
cates a fuel gauge malfunction.
Contact a PEUGEOT dealer.
When the fuel iller lap is
open, a system limits the
opening of the rear left slid-
ing side door.
The key cannot be re-
moved from the cap's lock until the
cap is reitted on the tank.
Bonnet strut
Secure the strut to hold the bonnet
open.
Before closing the bonnet, replace
the strut in its housing.
To close
Lower the bonnet and release it at
the end of its travel. Check that the
bonnet is properly locked.
"Bonnet open" warning

This warning is linked to the alarm
option only.
With the engine running or the vehicle
moving, a diagram on the multi-
function display accompanied by an
audible signal, warns you that the
bonnet is not properly closed. Fuel supply cut-off
If the warning light lashes, accom-
panied by the message
"Fuel circuit
disarmed" , this indicates that the
fuel supply has been cut off.
Restore the supply (refer to the cor-
responding section).
Access and starting

103
-
28-02-2005
LIGHTING CONTROL
Front and rear lights
Selection is by turning ring A.
Lights off
Dipped beam/Main
beam Front fog lights (1st rotation
of the ring forwards)
Side lights on
Automatic switching
on of lights Dipped beam/main beam change
Pull the stalk fully towards you.
Front and rear fog
lights (2nd rotation
of the ring forwards)
These operate with the side lights
and the dipped beam headlamps. These operate with the side lights
and the dipped beam headlamps.
Note:
to switch off the front and rear
fog lights, turn the ring rearwards
twice in succession.
In clear weather or in rain,
both day and night, rear
fog lights dazzle and are
prohibited.
Do not forget to switch
them off when they are no longer
needed.
Automatic switching on of the lights
switches off the rear fog lamps, but
the front fog lamps remain on.
Left: downwards.
Right: upwards.
Direction indicators (lashers)
Lights-on buzzer
When the ignition is switched off,
when the driver's door is opened, a
buzzer sounds, accompanied by the
message
"Side lights on" on the
multi-function display if you have left
your lights on.
Front and rear fog lights
Rotate ring B forwards to switch on
and rearwards to switch off. The sta-
tus is conirmed by the light on the
instrument panel.
Visibility

104 -
28-02-2005
105
-
28-02-2005
AUTOMATIC SWITCHING ON
OF LIGHTS
The side lights and dipped beam
headlamps switch on automatically if
the light is poor. They switch off when
the light becomes bright enough.
Note: in foggy weather, the bright-
ness sensor can detect suficient
light. As a consequence, the lights
will not come on automatically.
This function is active when the vehi-
cle is supplied to the customer.
To disarm or activate the function:
F Start with the key in the accesso-
ries position (1st notch),
F Place the lights stalk in position 0,
F Press the end of the stalk for more
than two seconds.
Note: after the ignition is switched off
and depending on the brightness, the
lights remain on for approximately
45 seconds or until the vehicle is
locked.
Do not cover the brightness sensor
located in the centre of the fascia. It
is used for automatic switching on
of the lights.
Operating check
Activation
Activation of this function is accom-
panied by an audible signal and the
message "Automatic lighting ac-
tive" on the multi-function display.
Disarming
Disarming of the function is accom-
panied by an audible signal.
Note: the function is disarmed tem-
porarily when the driver uses the
manual lighting controls.
Visibility
