2005 Peugeot 407 Owner's Manual

20 -
14-02-2005
21
-
14-02-2005
CONFIDENTIAL CARD
This is given to you on delivery of
your vehicle with the duplicate keys.
It contains the identiication code
necessary for any work carried out
by a PEUGEOT dealer on the elec-
tronic immobiliser system. This code
is hidden by a ilm, which should be
removed only if necessary.
Keep your card in a safe place,
never inside the vehicle.
When undertaking a long trip or jour-
ney, however, it is advisable to take
it with you along with your personal
papers.
CHILD LOCK ON THE DOORS
Manual mode
This prevents each of the rear doors
from being opened from inside.
F
Turn the switch on the edge of the
door a quarter of a turn using the
ignition key.
A message appears on the display, if
the two rear doors are locked. Electric mode
This prevents opening of both of the
rear doors from the inside.
With the ignition on, press the button.
A message appears on the multi-
function display.
Warning:
this system is independent
of the central locking control.
Always remove the ignition key
when leaving the vehicle, even for
a short time.
Access and starting

22 -
14-02-2005
23
-
14-02-2005
Make a careful note of the
number on each key. The
key number is coded on the
label attached to the key.
If the keys are lost, your PEUGEOT
dealer can rapidly supply you with
new keys.
The high frequency remote con-
trol is a sensitive system; do not
operate it while it is in your pocket
as there is a possibility that it may
unlock your vehicle, without you
being aware of it.
The remote control does not oper-
ate when the key is in the ignition,
even when the ignition is switched
off, except for reprogramming.
Do not operate the deadlocking
function if there is anyone inside
the vehicle. Driving with the doors locked may
make access to the passenger
compartment by the emergency
services more dificult in an emer-
gency.
As a safety precaution (with chil-
dren on board), remove the ignition
key when you leave the vehicle,
even for a short time.
Do not repeatedly press the but-
ton of your remote control out of
range and out of sight of your ve-
hicle. You run the risk of stopping
it from working and the remote
control would have to be repro-
grammed.
When purchasing a second-hand
vehicle:
- ensure that you are given the
conidential card;
- have the key codes memorised by a PEUGEOT dealer, to ensure
that the keys in your possession
are the only ones which can start
the vehicle.
Do not make any modiications to
the electronic engine immobiliser
system.
Access and starting

18 -
14-02-2005
19
-
14-02-2005
LOCKING/UNLOCKING FROM
THE INSIDE
F
Press the button.
This allows the doors and the boot to
be locked or unlocked.
If the vehicle is deadlocked, the
button is not active. In this case,
use the key or the remote control to
unlock.
Automatic central locking of the
doors
The doors can lock automatically
while driving (speed above 6 mph
[10 km/h]).
Press and hold the button to activate
or deactivate this function.
Note: driving with the doors locked
may make access to the passenger
compartment by the emergency serv-
ices more dificult in an emergency.
KEY IN IGNITION
A buzzer sounds on opening the
driver's door, if the key has been left
in the ignition.
LOCATING YOUR VEHICLE
To locate your vehicle, if you have
locked or deadlocked it, in a car
park:
F press button
B on the remote con-
trol, the courtesy lights come on
and the direction indicators lash
for a few seconds.
Using the remote control
F
Pressing button B locks the vehicle
(the direction indicators come on
for approximately two seconds).
F A second press within ive sec-
onds deadlocks the vehicle (the
direction indicators come on for
approximately two seconds).
MANUAL LOCKING
(EMERGENCY MODE)
Driver's door
Insert the key in the lock to lock or
unlock the door.
Passenger doors
To lock, insert the key in the control
located on the edge of the door then
turn to the right.
Access and starting

20 -
14-02-2005
21
-
14-02-2005
CHANGING THE REMOTE
CONTROL BATTERY
The information is given by an audible
signal accompanied by a message
on the multifunction display or by the
service indicator light.
REPROGRAMMING THE
REMOTE CONTROL
F Switch off the ignition.
F Switch the ignition on again.
F Press the remote control locking
button immediately for a few sec-
onds.
F Switch off the ignition and remove
the remote control key from the
ignition lock. The remote control
is now working again.
ELECTRONIC ENGINE
IMMOBILISER
This locks the engine control system as
soon as the ignition has been switched
off and therefore prevents starting of
the vehicle by anyone who does not
have the key.
The ignition key has an electronic chip
which has a special code. When the
ignition is switched on, the code must
be recognised for starting to be pos-
sible.
If the system does not function
correctly , the following indicator light
comes on:
To change the battery, unclip the
casing using a coin at the notch
(CR 1620/3 volt battery).
If the remote control does not work
after the battery has been changed,
re-program the remote control. Service indicator
light
Electronic engine
immobiliser
indicator light
or
It is accompanied by a message on
the multi-function display.
Your vehicle will not start.
Contact a PEUGEOT dealer.
Access and starting

22 -
14-02-2005
23
-
14-02-2005
Make a careful note of the
number on each key. The
key number is coded on the
label attached to the key.
If the keys are lost, your PEUGEOT
dealer can rapidly supply you with
new keys.
The high frequency remote con-
trol is a sensitive system; do not
operate it while it is in your pocket
as there is a possibility that it may
unlock your vehicle, without you
being aware of it.
The remote control does not oper-
ate when the key is in the ignition,
even when the ignition is switched
off, except for reprogramming.
Do not operate the deadlocking
function if there is anyone inside
the vehicle. Driving with the doors locked may
make access to the passenger
compartment by the emergency
services more dificult in an emer-
gency.
As a safety precaution (with chil-
dren on board), remove the ignition
key when you leave the vehicle,
even for a short time.
Do not repeatedly press the but-
ton of your remote control out of
range and out of sight of your ve-
hicle. You run the risk of stopping
it from working and the remote
control would have to be repro-
grammed.
When purchasing a second-hand
vehicle:
- ensure that you are given the
conidential card;
- have the key codes memorised by a PEUGEOT dealer, to ensure
that the keys in your possession
are the only ones which can start
the vehicle.
Do not make any modiications to
the electronic engine immobiliser
system.
Access and starting

20 -
14-02-2005
21
-
14-02-2005
CONFIDENTIAL CARD
This is given to you on delivery of
your vehicle with the duplicate keys.
It contains the identiication code
necessary for any work carried out
by a PEUGEOT dealer on the elec-
tronic immobiliser system. This code
is hidden by a ilm, which should be
removed only if necessary.
Keep your card in a safe place,
never inside the vehicle.
When undertaking a long trip or jour-
ney, however, it is advisable to take
it with you along with your personal
papers.
CHILD LOCK ON THE DOORS
Manual mode
This prevents each of the rear doors
from being opened from inside.
F
Turn the switch on the edge of the
door a quarter of a turn using the
ignition key.
A message appears on the display, if
the two rear doors are locked. Electric mode
This prevents opening of both of the
rear doors from the inside.
With the ignition on, press the button.
A message appears on the multi-
function display.
Warning:
this system is independent
of the central locking control.
Always remove the ignition key
when leaving the vehicle, even for
a short time.
Access and starting

22 -
14-02-2005
23
-
14-02-2005
Make a careful note of the
number on each key. The
key number is coded on the
label attached to the key.
If the keys are lost, your PEUGEOT
dealer can rapidly supply you with
new keys.
The high frequency remote con-
trol is a sensitive system; do not
operate it while it is in your pocket
as there is a possibility that it may
unlock your vehicle, without you
being aware of it.
The remote control does not oper-
ate when the key is in the ignition,
even when the ignition is switched
off, except for reprogramming.
Do not operate the deadlocking
function if there is anyone inside
the vehicle. Driving with the doors locked may
make access to the passenger
compartment by the emergency
services more dificult in an emer-
gency.
As a safety precaution (with chil-
dren on board), remove the ignition
key when you leave the vehicle,
even for a short time.
Do not repeatedly press the but-
ton of your remote control out of
range and out of sight of your ve-
hicle. You run the risk of stopping
it from working and the remote
control would have to be repro-
grammed.
When purchasing a second-hand
vehicle:
- ensure that you are given the
conidential card;
- have the key codes memorised by a PEUGEOT dealer, to ensure
that the keys in your possession
are the only ones which can start
the vehicle.
Do not make any modiications to
the electronic engine immobiliser
system.
Access and starting

20 -
14-02-2005
21
-
14-02-2005
CONFIDENTIAL CARD
This is given to you on delivery of
your vehicle with the duplicate keys.
It contains the identiication code
necessary for any work carried out
by a PEUGEOT dealer on the elec-
tronic immobiliser system. This code
is hidden by a ilm, which should be
removed only if necessary.
Keep your card in a safe place,
never inside the vehicle.
When undertaking a long trip or jour-
ney, however, it is advisable to take
it with you along with your personal
papers.
CHILD LOCK ON THE DOORS
Manual mode
This prevents each of the rear doors
from being opened from inside.
F
Turn the switch on the edge of the
door a quarter of a turn using the
ignition key.
A message appears on the display, if
the two rear doors are locked. Electric mode
This prevents opening of both of the
rear doors from the inside.
With the ignition on, press the button.
A message appears on the multi-
function display.
Warning:
this system is independent
of the central locking control.
Always remove the ignition key
when leaving the vehicle, even for
a short time.
Access and starting
