2005 Peugeot 407 Owner's Manual

94 -
14-02-2005
95
-
14-02-2005
By pressing the navigator, you can
activate/deactivate the following
functions:
- random play with "Activate Random",
- playing of the start of the track with
"Activate Introscan",
- programming of tracks with "Pro- gram tracks".
You can also select a track directly
via the list of tracks on the CD:
- press the "LIST" button to display
the list,
- press button 5 or 6 or turn the dial
to select the track,
- press the navigator to start playing the track.
Compact disc source
The use of copied compact discs
may cause faults.
Insert circular compact discs only.
Selecting CD mode
After inserting a disc,
printed face upwards,
the CD player starts
automatically.
If a disc has already
been inserted, press
the "SOURCE" button to select CD
mode.
Ejecting a disc
Press the button to eject
the disc from the player. Selecting a track
Press button 8 to se-
lect the following track.
Press button 7 to re-
turn to the start of the
current track or to select
the previous track. "CD" menu
Accelerated play
Press and hold button
7 or 8 for
backwards or forwards accelerated
play.
Accelerated play stops as soon as
the button is released.
407 saloon and 407 SW comfort

94 -
14-02-2005
95
-
14-02-2005
"CHANGER" menu
Selecting a track
Press button 8 to select the next
track.
Press button 7 to return to the start
of the current track or to select the
previous track.
You can also select a track directly
via the list of tracks on the CD:
- press the "LIST" button to display the list,
- press the 5 or 6 down button or
turn the dial to select the track,
- press the navigator to start playing the track.
Compact disc changer source
The CD changer is located in the boot
on the right-hand side and can hold
6 discs.
Press the navigator to activate/
deactivate the following functions:
- random play with "Activate Random",
- playing of the start of the track with "Activate Introscan",
- repeating of the CD with "Activate repeat".
Insert circular compact discs
only.
Compact discs of the irst
generation of laser techno-
logy are no longer detected.
Some anti-pirating systems, on origi-
nal discs or CDs copied by a personal
writer may cause faults, irrespective
of the quality of the original player.
Selecting the CD changer source
Press the "SOURCE"
button several times.
Selecting a disc
Press one of the but-
tons "1" to "6" to select
the corresponding disc.
Buttons 5 and 6
permit the selection
of the previous/next
disc in the changer.
To insert a disc in the changer:
- open the sliding lap A,
-
press button B to eject the cartridge C,- open one of the six drawers of the
cartridge by pulling the tab D,
- insert the disc in the cartridge,
printed face upwards, and close
the drawer,
- insert the cartridge in the changer following the direction of the arrow,
- close the sliding lap A.
407 saloon and 407 SW comfort

97
-
14-02-2005
Using the menus
Press the "MENU"
button to dis-
play the general menu. Select the
"Telematics" application, then vali-
date "Telephone functions" to access
the principal telephone functions,
then the various menus, in order to
reach the one required.
RT3 TELEPHONE
This function is a GSM dual-band tele-
phone (900 and 1 800 MHz) incorpo-
rated in the RT3 GPS audio/telephone.
It is a "hands-free" telephone. This
function is provided by a microphone
located next to the front courtesy
light, the audio equipment speak-
ers, a steering column control and
voice commands which allow access
to most of the functions (the audio/
telephone control panel buttons al-
low access to all of the functions).
Display of the principal "mobile" type
functions, as well as consultation of
the directories, is provided by the
multi-function display.
This function is active whatever posi-
tion the ignition key is in, even after
thirty minutes, when the switch to
economy mode message appears
on the multi-function display.
When the ignition has been switched
off, the audio/telephone can be
switched on again by pressing the
"TEL" (green) button or by inserting
a CD in the player.
For safety reasons, the driver must
carry out the operations while the
vehicle is stationary. Within each menu:
Move around by
pressing the 5 or 6
buttons or by turning
the navigator, then
validate by pressing
the navigator to se-
lect a function.
Cancel an operation by means of the
"ESC" button.
- Network: allows you to select the network search mode and to see
the networks available.
- Duration of calls: allows you to con- sult the duration recorder of calls
made and zero re-set.
- Security: allows you to use or modi- fy the PIN code and to erase the list
of calls and text messages (SMS).
- Telephone options: allows you to conigure the calls with entering of
my number, automatic answering
after X rings, speciication of ring
options and allows you to conigure
the call diversion number. This menu allows you
to access the following
functions:
Using the alphanumeric
keypad
For a given button, to input a charac-
ter in the second or subsequent rows
press until you obtain the character
required.
Buttons Associated characters
[1]
1 or space
[2] 2 or A B C 2 or a b c 2
[3] 3 or D E F 3 or d e f 3
[4] 4 or G H I 4 or g h i 4
[5] 5 or J K L 5 or j k l 5
[6] 6 or M N O 6 or m n o 6
[7] 7 or P Q R S 7 or p q r s 7
[8] 8 or T U V 8 or t u v 8
[9] 9 or W X Y Z 9 or w x y z 9
[0] 0 or + (long press)
[#] # or conirmation
[*] * or erasing of last character
input (long press)
407 saloon and 407 SW comfort

98 -
14-02-2005
99
-
14-02-2005
Cancelling of PIN code request
In the menu "Telephone functions"

select "Security", then "Process the
PIN code", then validate the "Cancel"
function.
Recommendation: do not lose your
SIM card. Losing it would mean
anyone who inds it would be able to
make unlimited calls.
Open the lap by pressing the point
of a pencil on the circular opening
above the lap.
Insert your SIM card (available from
a mobile telephone operator) in the
holder as indicated in the graphics,
then re-insert the holder.
Note: removal or insertion of the SIM
card must only be carried out after
the RT3 GPS audio/telephone has
been switched off.
Handle the SIM card with care.Installing the SIM card
(not supplied)
The PIN code is required each time
the ignition is switched on, unless the
PIN code has been stored or protec-
tion by PIN is not activated on the
SIM card.
Input your PIN code using the al-
phanumeric keypad and validate by
pressing the navigator or button #
to access the network. Connection
to the network is validated by the
appearance of a symbol on the multi-
function screen.
If you make three errors in succes-
sion when inputting your PIN code,
your SIM card will be blocked. To
unblock it, you will need to input
the PUK code. The PUK code will
be supplied to you by the person sell-
ing your SIM card (input of the PUK
code allows for 10 errors in succes-
sion; after this the SIM card becomes
permanently unusable).
Inputting the PIN code
407 saloon and 407 SW comfort

98 -
14-02-2005
99
-
14-02-2005
Telephone function screens
Not in use
The screen indicates the presence
of voice messages or text messages
(SMS) not listened to, the cumulatve
time in use since the last zero reset
and the status of your telephone.
In use
The screen indicates the time
elapsed since the start of the con-
versation, as well as the number* or
name of the person to whom you are
speaking (if recorded in the directory)
and the status of your telephone.
* If this option and service are available.
Press the button
to display the
contextual menu of the telephone.
Pressing the end of the steering
column control for more than
2 seconds calls up a contextual
menu limited to the "Directory", "List
of calls" and "Voice mail" functions.
Making a call
Select the function "En-
ter number" then enter
the number of the per-
son you wish to speak to
using the alphanumeric
keypad.
Press the "Pick up" button to make
the call.
Entering a number
Making a call from a directory
Select the "Directory" function to
access all the iles containing a tele-
phone number or the "List of calls"

function to access the list of the
last twenty incoming (if the number
display option is active) or outgoing
calls.
There are two directories, the RT3
GPS audio/telephone directory and
the SIM card directory. To consult the
SIM directory, insert your SIM card
and enter your PIN code. When a ringing sounds
to let you know that a
call is waiting, you can
choose either to accept
it by pressing the "Pick
up" button or the end of the steer-
ing wheel control or not to accept it
by pressing the "Hang up" button or
by selecting and validating the "NO"
button on the "Answer?" screen.
Receiving a call
If you accept the call, to
end your communica-
tion, press the "Hang up"
button.
If you do not accept the
call, it is transferred to
your voice mail or to a call diversion
number.
You can activate or deactivate this
transfer by pressing the "Hang up"
button for more than two seconds.
407 saloon and 407 SW comfort

100 -
14-02-2005
101
-
14-02-2005
Text messages (SMS)
Accessing text messages
When the buzzer sounds (if the
SMS text messages buzzer option is
active) and a superimposed screen
announces "Do you wish to read
the new text message (SMS)?",
you can choose to read the text
message received by selecting and
validating "YES" or postpone reading
it by selecting and validating "NO",
by pressing the "ESC" button or
by waiting until the announcement
disappears.
Note:
the old text messages
stored and the new text messages,
the reading of which you wish to
postpone, can be consulted. Press
the "MENU" button then validate
the "Telematic" icon, select "Text
messages (SMS)" and validate the
function "Reading of text messages
received" by pressing the navigator.
Then scroll through the list by turning
the knob and press the knob to select
the text message to be read (if the
voice synthesiser is active). Sending a text message
Before typing your irst text mes-
sage, check that your text messages
(SMS) centre number is stored cor-
rectly in the sub-menu "Server cen-
tre N°". If it is not, any text messages
typed before this number is entered
will not be sent.
In the menu "Text messages (SMS)"
validate the function "Typing of a text
message". Type your text message
using the alphanumeric keypad and
validate it using the "OK" button to
store it or validate the "Send" button
to send it. Validation of the "Send"
button enables you to enter the
number of your recipient or select it
from the directory or from the list of
calls and send the message.
"Telephone options" menu
Select the "Telephone options"
func-
tion from the "Telephone functions"
menu to access the functions: • "Conigure the calls" which permits
activation and deactivation of the
"show my number" and "automatic
answering after X rings" functions,
• "Ringing options" which permits
adjustment of the ringing volume
for voice calls, activation of the text
messages (SMS) receipt buzzer
and selection of a ring tone from
the ive offered,
• "Diversion number/voice mail"
which permits recording of the call
diversion number chosen by the
customer, otherwise the call will be
transferred to the voice mail.
"Duration of calls" menu
Select the "Duration of calls" function
from the "Telephone functions" menu
to consult the duration counters for
the calls made. The part counter to-
tals the duration of the calls since the
last zero reset carried out using the
"Zero reset" button.
407 saloon and 407 SW comfort

100 -
14-02-2005
101
-
14-02-2005
* If option and service available.
If you have signed the speciic
PEUGEOT contract, your call will
be located and you will be put in
contact with a PEUGEOT emergency
representative.
For further details, refer to the gen-
eral conditions of your contract.
"PEUGEOT Assistance"/
Emergency call
A green diode lashes on the RT3
GPS audio/telephone panel, when
the emergency call procedure or a
call to "PEUGEOT Assistance" be-
gins, then lights continuously when
the call is taken by the services con-
cerned.
It is not possible to make or receive
calls or send or receive SMS text
messages during the connection;
these will be diverted to your voice
mail.
Services*
Press the button to
display the "Services"
menu and select one of
the following services:
• "Customer Contact Centre" con-
tacts the PEUGEOT Customer
Contact Centre directly and permits
access to the services offered (this
call is suspended if an emergency
or assistance call has been made).
• "PEUGEOT Assistance" enables
you to contact the call centre which
controls the PEUGEOT assistance
service directly, make an assist-
ance request and receive rapid
assistance (you have 6 seconds
within which to cancel the call
when it is made) . During the as-
sistance call phase it is not pos-
sible to make any other calls with
the exception of emergency calls.
Signing the speciic PEUGEOT
contract means that you will be
located; in this case, a star will ap-
pear in the text on the multifunction
screen.
• "Operator services" gives access
to the list of services speciic
to your operator (e.g.: customer
service, consumption monitoring,
news, stock market, weather, travel,
games, etc) if access is available.
* If option and service available.
Emergency call*
In an emergency,
press and hold the
"SOS" button until a
signal is heard and
a call validation/de-
letion screen is dis-
played (delay of 6 seconds) or enter
112 directly.
Make an emergency call when you
are involved in a situation which
leads you to fear serious conse-
quences (injuries, ...) for those
exposed to it (if you witness or are
involved in an accident resulting in
injuries, an attack, ...).
Before making a call of this kind, the
audio/telephone must detect a cel-
lular network and you must have
inserted your SIM card .
If you have not signed the speciic
PEUGEOT contract, the parameters
of the "SOS" button are set so that a
call is made to 112 - unique number
made available by the worldwide
GSM network, reserved for emer-
gency calls.
407 saloon and 407 SW comfort

102 -
14-02-2005
103
-
14-02-2005
Main menu
From the general menu, select the
"Directory"
application to access its
main menu and select one of the fol-
lowing functions:
• "Call", to call a number stored in a ile,
• "Activate guidance to", to initiate guidance to a location stored in a
ile,
• "Management of directory iles", to add, delete, modify and consult di-
rectory iles or exchange them with
the SIM card,
• "Directory coniguration", to select the working directory and deine
the default directory when the sys-
tem is switched on. Creation/Modiication of a ile
To create a ile, from the "Directory"
menu, select the "Management of di-
rectory iles" function, then "Add".
In the ile, select the section to be
illed in, conirm and then enter the
information.
To modify an existing ile, select it by
means of the "Consult or modify the
ile" function of the "Management of
directory iles" menu, then make the
modiications.
When entering the address, the navi-
gation CD ROM must be present to
obtain guidance to this destination.
Recording a description
associated with a directory ile
When a description is associated
with a directory ile, you can record
the description vocally to use it later
for direct access by means of voice
commands (e.g.: "Call" "[Name of
voice description]" or "Guide to"
"[Name of voice description]").
Select "Consult or modify the ile"
from the "Management of directory
iles" menu to access the description
entering and recording screen.
Press the record button and follow
the instructions.
The "Directory" appli-
cation gives access to
400 iles divided into
4 independent sub-direc-
tories ("User1", "User2",
"User3" and "User4"). It
enables you to manage these iles,
make calls using the SIM card and
activate guidance.
Directory
General
RDS TMC (Traffic Message
Channel) Traffic Information
You can access the information relat-
ing to trafic conditions from the "Au-
dio functions" or "Telematics" menu,
then from the "TMC Trafic Informa-
tion" function (see section "Satellite
navigation system").
The RT3 GPS audio/telephone per-
mits access to the TMC RDS trafic
information broadcast free on the FM
waveband.
407 saloon and 407 SW comfort
