REFRIGERANT PRESSURE SENSOR

3. CHECK REFRIGERANT PRESSURE SENSOR POWER SUPPLY CIRCUIT
1. Disconnect refrigerant pressure sensor harness connector.
2. Turn ignition switch ON.
3. Check voltage between refrigerant pressure sensor terminal 3
and ground with CONSULT-II or tester.
OK or NG
OK >> GO TO 5.
NG >> GO TO 4.
4. DETECT MALFUNCTIONING PART
Check the following.

Harness connectors E61, F38

Harness for open or short between refrigerant pressure sensor and ECM
>> Repair open circuit or short to ground or short to power in harness or connectors.
5. CHECK REFRIGERANT PRESSURE SENSOR GROUND CIRCUIT FOR OPEN AND SHORT
1. Turn ignition switch OFF.
2. Disconnect ECM harness connector.
3. Check harness continuity between refrigerant pressure sensor terminal 1 and ECM terminal 57.
Refer to Wiring Diagram.
4. Also check harness for short to ground and short to power.
OK or NG
OK >> GO TO 7.
NG >> GO TO 6.
6. DETECT MALFUNCTIONING PART
Check the following.

Harness connectors E61, F38

Harness for open or short between refrigerant pressure sensor and ECM
>> Repair open circuit or short to ground or short to power in harness or connectors.
PBIB0503E
Voltage: Approximately 5V
SEF479Y
Continuity should exist.

REFRIGERANT PRESSURE SENSOR
EC-919
[QR (WITHOUT EURO-OBD)]
C
D
E
F
G
H
I
J
K
L
MA
EC

7. CHECK REFRIGERANT PRESSURE SENSOR INPUT SIGNAL CIRCUIT FOR OPEN AND SHORT
1. Check harness continuity between refrigerant pressure sensor terminal 2 and ECM terminal 69.
Refer to Wiring Diagram.
2. Also check harness for short to ground and short to power.
OK or NG
OK >> GO TO 9.
NG >> GO TO 8.
8. DETECT MALFUNCTIONING PART
Check the following.

Harness connectors E61, F38

Harness for open or short between refrigerant pressure sensor and ECM
>> Repair open circuit or short to ground or short to power in harness or connectors.
9. CHECK INTERMITTENT INCIDENT
Refer to EC-624, "
TROUBLE DIAGNOSIS FOR INTERMITTENT INCIDENT" .
OK or NG
OK >> Replace refrigerant pressure sensor.
NG >> Repair or replace.
Removal and InstallationEBS0114X
REFRIGERANT PRESSURE SENSOR
Refer to ATC-141, "REFRIGERANT LINES" . Continuity should exist.

AUTOMATIC SPEED CONTROL DEVICE (ASCD)
EC-969
[QR (WITHOUT EURO-OBD)]
C
D
E
F
G
H
I
J
K
L
MA
EC

AUTOMATIC SPEED CONTROL DEVICE (ASCD)PFP:18930
System DescriptionEBS01FBZ
INPUT/OUTPUT SIGNAL CHART
*: This signal is sent to the ECM through CAN communication line.
BASIC ASCD SYSTEM
Refer to Owner's Manual for ASCD operating instructions.
Automatic Speed Control Device (ASCD) allows a driver to keep vehicle at predetermined constant speed
without depressing accelerator pedal. Driver can set vehicle speed in advance between approximately 40 km/
h (25 MPH) and 144 km/h (89 MPH).
ECM controls throttle angle of electric throttle control actuator to regulate engine speed.
Operation status of ASCD is indicated by CRUISE indicator and SET indicator in combination meter. If any
malfunction occurs in ASCD system, it automatically deactivates control.
NOTE:
Always drive vehicle in safe manner according to traffic conditions and obey all traffic laws.
SET OPERATION
Press ASCD MAIN switch. (The CRUISE indicator in combination meter illuminates.)
When vehicle speed reaches a desired speed between approximately 40 km/h (25 MPH) and 144 km/h (89
MPH), press SET/COAST switch. (Then SET indicator in combination meter illuminates.)
ACCEL OPERATION
If the RESUME/ACCELERATE switch is pressed during cruise control driving, increase the vehicle speed until
the switch is released or vehicle speed reaches maximum speed controlled by the system.
And then ASCD will keep the new set speed.
CANCEL OPERATION
When any of following conditions exist, cruise operation will be canceled.

CANCEL switch is pressed

More than 2 switches at ASCD steering switch are pressed at the same time (Set speed will be cleared)

Brake pedal is depressed

Clutch pedal is depressed or gear position is changed to the neutral position

Vehicle speed decreased to 13 km/h (8 MPH) lower than the set speed

ESP/TCS system is operated
When the ECM detects any of the following conditions, the ECM will cancel the cruise operation and inform
the driver by blinking indicator lamp.

Engine coolant temperature is slightly higher than the normal operating temperature, CRUISE lamp may
blink slowly.
When the engine coolant temperature decreases to the normal operating temperature, CRUISE lamp will
stop blinking and the cruise operation will be able to work by pressing SET/COAST switch or RESUME/
ACCELERATE switch.

Malfunction for some self-diagnoses regarding ASCD control: SET lamp will blink quickly.
If MAIN switch is turned to OFF during ASCD is activated, all of ASCD operations will be canceled and vehicle
speed memory will be erased.
Sensor Input signal to ECM ECM function Actuator
ASCD brake switch Brake pedal operation
ASCD vehicle speed controlElectric throttle control
actuator Stop lamp switch Brake pedal operation
ASCD clutch switch (M/T models) Clutch pedal operation
ASCD steering switch ASCD steering switch operation
Park/Neutral position (PNP)
switchGear position
Wheel sensor* Vehicle speed

SERVICE DATA AND SPECIFICATIONS (SDS)
EC-971
[QR (WITHOUT EURO-OBD)]
C
D
E
F
G
H
I
J
K
L
MA
EC

SERVICE DATA AND SPECIFICATIONS (SDS)PFP:00030
Fuel PressureEBS01158
Idle Speed and Ignition TimingEBS01159
*: Under the following conditions:

Air conditioner switch: OFF

Electric load: OFF (Lights, heater fan & rear window defogger)

Steering wheel: Kept in straight-ahead position
Mass Air Flow SensorEBS0115B
*: Engine is warmed up to normal operating temperature and running under no-load.
Intake Air Temperature SensorEBS0115C
Engine Coolant Temperature SensorEBS0115D
Heated Oxygen Sensor 1 HeaterEBS0115E
Heated Oxygen sensor 2 HeaterEBS0115F
Crankshaft Position Sensor (POS)EBS0115G
Refer to EC-699, "Component Inspection" .
Fuel pressure at idle
Approximately 350 kPa (3.5bar, 3.57kg/cm2 , 51psi)
Target idle speedQR20DEM/T No load* (in Neutral position) 650±50 rpm
A/T No load* (in P or N position)
700±50 rpm
QR25DEM/T No load* (in Neutral position)
A/T No load* (in P or N position)
Air conditioner: ONQR20DEM/T In Neutral position
725 rpm or more
A/T In P or N position
QR25DEM/T In Neutral position 750 rpm or more
A/T In P or N position 700 rpm or more
Ignition timingQR20DEM/T In Neutral position
15°±5° BTDC A/T In P or N position
QR25DEM/T In Neutral position
A/T In P or N position
Supply voltageBattery voltage (11 - 14V)
Output voltage at idle0.7 - 1.1*V (QR20DE)
0.8 - 1.2*V (QR25DE)
Temperature °C (°F) Resistance kΩ
25 (77)1.800 - 2.200
80 (176)0.283 - 0.359
Temperature °C (°F) Resistance kΩ
20 (68)2.1 - 2.9
50 (122)0.68 - 1.00
90 (194)0.236 - 0.260
Resistance [at 25°C (77°F)] 3.3 - 4.0Ω
Resistance [at 25°C (77°F)] 5.0 - 7.0Ω

EC-972
[QR (WITHOUT EURO-OBD)]
SERVICE DATA AND SPECIFICATIONS (SDS)

Camshaft Position Sensor (PHASE)EBS0115H
Refer to EC-708, "Component Inspection" .
Throttle Control MotorEBS0115I
InjectorEBS0115J
Fuel PumpEBS0115K
Resistance [at 25°C (77°F)] Approximately 1 - 15Ω
Resistance [at 10 - 60°C (50 - 140°F)] 13.5 - 17.5Ω
Resistance [at 25°C (77°F)] Approximately 0.2 - 5.0Ω

INDEX FOR DTC
EC-973
[YD (WITH EURO-OBD)]
C
D
E
F
G
H
I
J
K
L
MA
EC

[YD (WITH EURO-OBD)]INDEX FOR DTCPFP:00024
Alphabetical IndexEBS0116O
Check if the vehicle is a model with Euro-OBD (E-OBD) system or not by the “Type approval number” on the
identification plate. Refer to GI-46, "
IDENTIFICATION PLATE" .
NOTE:
If DTC U1000 is displayed with other DTC, first perform the trouble diagnosis for DTC U1000. Refer to
EC-1056, "
DTC U1000 CAN COMMUNICATION LINE" .
X: Applicable —: Not applicable
Items
(CONSULT-II screen terms) DTC*
1
TripMI lighting
up Reference page
CONSULT-II
GST*
2ECM*3
APP SEN 1/CIRCUIT P0122 0122 1 —EC-1099
APP SEN 1/CIRCUIT P0123 0123 1 —EC-1099
APP SEN 2/CIRCUIT P0222 0222 1 —EC-1138
APP SEN 2/CIRCUIT P0223 0223 1 —EC-1138
APP SENSOR P2135 2135 1 —EC-1285
BARO SEN/CIRC P2228 2228 3×EC-1303
BARO SEN/CIRC P2229 2229 3×EC-1303
BATTERY VOLTAGE P0563 0563 1 —EC-1215
BRAKE SW/CIRCUIT P0504 0504 1 —EC-1206
CAN COMM CIRCUIT U1000
1000*41—EC-1056
CKP SEN/CIRCUIT P0335 0335 3×EC-1157
CKP SENSOR P0336 0336 3×EC-1163
CMP SEN/CIRCUIT P0340 0340 3×EC-1169
CMP SENSOR P0341 0341 3×EC-1175
CMP/CKP RELATION P0016 0016 3×EC-1059
CYL1 INJECTOR P0201 0201 3×E C - 111 8
CYL2 INJECTOR P0202 0202 3×E C - 111 8
CYL3 INJECTOR P0203 0203 3×E C - 111 8
CYL4 INJECTOR P0204 0204 3×E C - 111 8
ECM P0605 0605 3×EC-1227
ECM P0606 0606 3×EC-1229
ECM RELAY P0686 0686 1 —EC-1245
ECT SEN/CIRC P0117 0117 3×EC-1093
ECT SEN/CIRC P0118 0118 3×EC-1093
EGR SYSTEM P0401 0401 3×EC-1186
EGR VALVE P0404 0404 3×EC-1193
ENG OVER TEMP P0217 0217 1×EC-1124
FRP RELIEF VALVE P1272 1272 3×EC-1263
FRP SEN/CIRC P0192 0192 3×E C - 111 0
FRP SEN/CIRC P0193 0193 3×E C - 111 0
FUEL LEAK P0093 0093 3×EC-1071
FUEL PUMP P0089 0089 3×EC-1068
FUEL PUMP P1273 1273 3×EC-1270
FUEL PUMP P1274 1274 1×EC-1275
FUEL PUMP P1275 1275 1×EC-1280

EC-974
[YD (WITH EURO-OBD)]
INDEX FOR DTC

FUEL PUMP/CIRC P0628 0628 3×EC-1231
FUEL PUMP/CIRC P0629 0629 3×EC-1231
FUEL TEMP SEN/CIRC P0182 0182 3×EC-1106
FUEL TEMP SEN/CIRC P0183 0183 3×EC-1106
GLOW RELAY P0380 0380 3×EC-1182
HIGH FUEL PRESS P0088 0088 3×EC-1066
IAT SEN/CIRCUIT P0112 0112 3×EC-1088
IAT SEN/CIRCUIT P0113 0113 3×EC-1088
INJ ADJ RES/CIRC1 P1260 1260 3×EC-1251
INJ ADJ RES/CIRC1 P1261 1261 3×EC-1251
INJ ADJ RES/CIRC2 P1262 1262 3×EC-1251
INJ ADJ RES/CIRC2 P1263 1263 3×EC-1251
INJ ADJ RES/CIRC3 P1264 1264 3×EC-1251
INJ ADJ RES/CIRC3 P1265 1265 3×EC-1251
INJ ADJ RES/CIRC4 P1266 1266 3×EC-1251
INJ ADJ RES/CIRC4 P1267 1267 3×EC-1251
INJ PWR/CIRC P2146 2146 3×EC-1292
INJ PWR/CIRC P2149 2149 3×EC-1292
INJECTOR P0200 0200 3×E C - 111 6
INJECTOR/CIRC P2147 2147 3×EC-1297
INJECTOR/CIRC P2148 2148 3×EC-1297
INJECTOR 1 P1268 1268 1 —EC-1257
INJECTOR 2 P1269 1269 1 —EC-1257
INJECTOR 3 P1270 1270 1 —EC-1257
INJECTOR 4 P1271 1271 1 —EC-1257
MAF SEN/CIRCUIT P0102 0102 3×EC-1083
MAF SEN/CIRCUIT P0103 0103 3×EC-1083
MAF SENSOR P0101 0101 3×EC-1075
NATS MALFUNCTION P1610 - P1617 1610 - 1617 1 —EC-1001
NO DTC IS DETECTED.
FURTHER TESTING
MAY BE REQUIRED.P0000 0000—— —
SENSOR PWR/CIRC1 P0642 0642 3×EC-1236
SENSOR PWR/CIRC1 P0643 0643 3×EC-1236
SENSOR PWR/CIRC2 P0652 0652 3×EC-1240
SENSOR PWR/CIRC2 P0653 0653 3×EC-1240
STRG SW/CIRC P0580 0580 1 —EC-1218
STRG SW/CIRC P0581 0581 1 —EC-1218
TC BOOST SEN/CIRC P0237 0237 3×EC-1151
TC BOOST SEN/CIRC P0238 0238 3×EC-1151
TC BOOST SOL/CIRC P0045 0045 3×EC-1061
TC SYSTEM P0234 0234 1 —EC-1145
TCS/CIRC P1212 1212 1 —EC-1250
Items
(CONSULT-II screen terms) DTC*
1
TripMI lighting
up Reference page
CONSULT-II
GST*
2ECM*3

EC-976
[YD (WITH EURO-OBD)]
INDEX FOR DTC

DTC No. IndexEBS0116P
Check if the vehicle is a model with Euro-OBD (E-OBD) system or not by the “Type approval number” on the
identification plate. Refer to GI-46, "
IDENTIFICATION PLATE" .
NOTE:
If DTC U1000 is displayed with other DTC, first perform the trouble diagnosis for DTC U1000. Refer to
EC-1056, "
DTC U1000 CAN COMMUNICATION LINE" .
X: Applicable —: Not applicable
DTC*
1
Items
(CONSULT-II screen item) TripMI lighting
upReference page
CONSULT-II
GST*
2ECM*3
U1000
1000*4CAN COMM CIRCUIT 1 —EC-1056
P0000 0000NO DTC IS DETECTED.
FURTHER TESTING
MAY BE REQUIRED.—— —
P0016 0016 CMP/CKP RELATION 3×EC-1059
P0045 0045 TC BOOST SOL/CIRC 3×EC-1061
P0088 0088 HIGH FUEL PRESS 3×EC-1066
P0089 0089 FUEL PUMP 3×EC-1068
P0093 0093 FUEL LEAK 3×EC-1071
P0101 0101 MAF SENSOR 3×EC-1075
P0102 0102 MAF SEN/CIRCUIT 3×EC-1083
P0103 0103 MAF SEN/CIRCUIT 3×EC-1083
P0112 0112 IAT SEN/CIRCUIT 3×EC-1088
P0113 0113 IAT SEN/CIRCUIT 3×EC-1088
P0117 0117 ECT SEN/CIRC 3×EC-1093
P0118 0118 ECT SEN/CIRC 3×EC-1093
P0122 0122 APP SEN 1/CIRCUIT 1 —EC-1099
P0123 0123 APP SEN 1/CIRCUIT 1 —EC-1099
P0182 0182 FUEL TEMP SEN/CIRC 3×EC-1106
P0183 0183 FUEL TEMP SEN/CIRC 3×EC-1106
P0192 0192 FRP SEN/CIRC 3×E C - 111 0
P0193 0193 FRP SEN/CIRC 3×E C - 111 0
P0200 0200 INJECTOR 3×E C - 111 6
P0201 0201 CYL1 INJECTOR 3×E C - 111 8
P0202 0202 CYL2 INJECTOR 3×E C - 111 8
P0203 0203 CYL3 INJECTOR 3×E C - 111 8
P0204 0204 CYL4 INJECTOR 3×E C - 111 8
P0217 0217 ENG OVER TEMP 1×EC-1124
P0222 0222 APP SEN 2/CIRCUIT 1 —EC-1138
P0223 0223 APP SEN 2/CIRCUIT 1 —EC-1138
P0234 0234 TC SYSTEM 1 —EC-1145
P0237 0237 TC BOOST SEN/CIRC 3×EC-1151
P0238 0238 TC BOOST SEN/CIRC 3×EC-1151
P0335 0335 CKP SEN/CIRCUIT 3×EC-1157
P0336 0336 CKP SENSOR 3×EC-1163
P0340 0340 CMP SEN/CIRCUIT 3×EC-1169
P0341 0341 CMP SENSOR 3×EC-1175
