2005 NISSAN X-TRAIL sensor

ALL MODE 4X4 SYSTEM
TF-19
C
E
F
G
H
I
J
K
L
MA
B
TF

Stop lamp switch signalRT
TR
Vehicle speed signalTRR
RT
Parking brake switch signalRT
Wide open throttle position signal T R
ASCD SET lamp signal TR
ASCD CRUISE lamp signal TR Signals ECM TCMESP/TCS/
ABS control
unitSteering
angle sensor4WD control
unitCombination
meter

TROUBLE DIAGNOSIS
TF-29
C
E
F
G
H
I
J
K
L
MA
B
TF

Trouble Diagnosis Chart for SymptomsEDS001VJ
If 4WD warning lamp turns ON, perform self-diagnosis. Refer to TF-32, "SELF-DIAG RESULT MODE" .
NOTE:

Light tight-corner braking symptom may occur depending on driving conditions in AUTO mode. This is not malfunction.

Heavy tight-corner braking symptom occurs when vehicle is driven in the following conditions: LOCK mode, steering
wheel is turned fully to either sides, and accelerator pedal was depressed.Symptom Condition Check item Reference page
4WD indicator lamp and LOCK indicator
lamp do not turn ON for approx. 1 second
when the ignition switch is turned to ON.
(4WD indicator lamp and LOCK indicator
lamp check)Ignition switch: ONCAN communication line
TF-46
Power supply and ground for 4WD con-
trol unit
Unified meter control unit
4WD warning lamp does not turn ON when
the ignition switch is turned to ON.
(4WD warning lamp check)Ignition switch: ONCAN communication line
TF-47
Unified meter control unit
4WD warning lamp does not turn OFF sev-
eral seconds after engine started.Engine runningCAN communication line
TF-48
Power supply and ground for 4WD con-
trol unit
Unified meter control unit
4WD solenoid
4WD actuator relay (integrated in 4WD
control unit)
Wheel sensor
4WD mode cannot be switched after engine
is started.Engine running4WD mode switch
TF-49
CAN communication line
Unified meter control unit
Heavy tight-corner braking symptom occurs
when the vehicle is driven in AUTO mode
and the steering wheel is turned fully to
either side after the engine is started. (See
NOTE.)

While driving

AUTO mode

Steering wheel is
turned fully to either
sidesCAN communication line
TF-50
4WD mode switch
Accelerator pedal position signal
4WD solenoid
Mechanical malfunction of electric con-
trolled coupling (clutch sticking etc.)
Vehicle does not enter 4WD mode even
though 4WD warning lamp turned to OFF.Vehicle speed: 10 km/h
(6 MPH) or less4WD solenoid
TF-51
Mechanical malfunction of electric con-
trolled coupling (Mechanical engage-
ment of clutch is not possible.)
Vehicle speed: 10 km/h
(6 MPH) or moreOperating condition of parking brake
4WD solenoid
Mechanical malfunction of electric con-
trolled coupling (Mechanical engage-
ment of clutch is not possible.)
While driving, 4WD warning lamp flashes
rapidly. (When flashing in approx. 1 minute
and then turning OFF.)
Rapid flashing: 2 times/second

While driving

AUTO mode and
LOCK modeProtection function is activated due to
heavy load to electric controlled cou-
pling. (4WD system is not malfunction-
ing.)TF-52
While driving, 4WD warning lamp flashes
slowly. (When continuing to flash until turn-
ing ignition switch OFF)
Slow flashing: 1 time/2 seconds
While driving

Vehicle speed: 20 km/h
(12 MPH) or moreTire size is different between front and
rear of vehicle.TF-53

TF-30
TROUBLE DIAGNOSIS

4WD Control Unit Input/Output Signal Reference ValuesEDS001VK
4WD CONTROL UNIT INSPECTION TABLE
Specifications with CONSULT-II
Monitor item [Unit] Content Condition Display value
FR RH SENSOR [km/h] or [mph]Wheel speed (Front wheel
right)Vehicle stopped 0.00 km/h (0.00 mph)
Vehicle running
CAUTION:
Check air pressure of tire under
standard condition.Approximately equal to
the indication on speed-
ometer (Inside of ±10%)
FR LH SENSOR [km/h] or [mph]Wheel speed (Front wheel
left)Vehicle stopped 0.00 km/h (0.00 mph)
Vehicle running
CAUTION:
Check air pressure of tire under
standard condition.Approximately equal to
the indication on speed-
ometer (Inside of ±10%)
RR RH SENSOR [km/h] or [mph]Wheel speed (Rear wheel
right)Vehicle stopped 0.00 km/h (0.00 mph)
Vehicle running
CAUTION:
Check air pressure of tire under
standard condition.Approximately equal to
the indication on speed-
ometer (Inside of ±10%)
RR LH SENSOR [km/h] or [mph]Wheel speed (Rear wheel
left)Vehicle stopped 0.00 km/h (0.00 mph)
Vehicle running
CAUTION:
Check air pressure of tire under
standard condition.Approximately equal to
the indication on speed-
ometer (Inside of ±10%)
BATTERY VOLT [V]Power supply voltage for
4WD control unitIgnition switch: ON Battery voltage
THRTL POS SEN [%] Throttle opening conditionWhen depressing accelerator pedal
(Value rises gradually in response to
throttle position.)0 - 100%
ETS SOLENOID [A]Monitored value of current at
4WD solenoidEngine speed
: At idle2WD Approx. 0.000A
AUTO Approx. 0.000A
LOCK Approx. 0.000A
Engine speed
: 3,000 rpm or more con-
stant2WD Approx. 0.000A
AUTO Approx. 0.000 - 1.500A*
LOCK Approx. 2.800A
STOP LAMP SW [ON/OFF]Condition of brake pedal
operationBrake pedal: Depressed ON
Brake pedal: Released OFF
ENG SPEED SIG [RUN/STOP] Condition of engine runningEngine stopped
(Engine speed: Less than 400 rpm)STOP
Engine running
(Engine speed: 400 rpm or more)RUN
ETS ACTUATOR [ON/OFF]Operating condition of 4WD
actuator relay (integrated in
4WD control unit)Engine stopped (Ignition
switch: ON)OFF
Engine running ON
4WD WARN LAMP [ON/OFF] 4WD warning lamp condition4WD warning lamp: ON ON
4WD warning lamp: OFF OFF
4WD MODE SW [2WD/AUTO/
LOCK]Input condition from 4WD
mode switch4WD mode switch2WD 2WD
AUTO AUTO
LOCK LOCK

TF-32
TROUBLE DIAGNOSIS

5. Touch “ALL MODE AWD/4WD”.
If “ALL MODE AWD/4WD” is not indicated, go to GI-35, "
CON-
SULT-II Data Link Connector (DLC) Circuit" .
6. Perform each diagnostic test mode according to each service
procedure.
SELF-DIAG RESULT MODE
Operation Procedure
1. Perform “CONSULT-II SETTING PROCEDURE”. Refer to TF-31, "CONSULT-II SETTING PROCEDURE"
.
2. Start engine and drive at 30 km/h (19 MPH) or more for approx. 1 minute.
3. Stop vehicle. With engine at idle, touch “SELF-DIAG RESULTS”.
Display shows malfunction experienced since the last erasing
operation.
NOTE:

The details for “TIME” are as follow:
–“0”: Error currently detected with 4WD control unit.
–Except for “0”: Error detected in the past and memorized
with 4WD control unit.
Detects frequency of driving after DTC occurs (frequency
of turning ignition switch “ON/OFF”).
Display Item List
CAUTION:

If “CAN COMM CIRCUIT [U1000]” is displayed with other DTCs, first perform the trouble diagnosis for CAN communica-
tion line.

Make sure that ABS warning lamp turns OFF by driving for a minute at vehicle speed of 30 km/h (19 MPH) or more after
turning ignition switch “OFF” if 4WD warning lamp turns ON with system malfunction of “ABS SYSTEM [C1203]”. 4WD
warning lamp may not turn OFF if it is normal unless ignition switch turns OFF at once and engine restarts after that.
BCIA0030E
SDIA2217E
Items (CONSULT-II screen
terms)Diagnostic item is detected when... Check item
CONTROLLER FAILURE
[C1201]Malfunction has occurred inside 4WD control unit.TF-36, "
4WD Control Unit"
ABS SYSTEM
[C1203]Malfunction related to wheel sensor has been detected by ABS actu-
ator and electric unit (control unit) (without ESP) or ESP/TCS/ABS
control unit (with ESP).TF-36, "ABS System"
4WD SOLENOID
[C1204]Malfunction related to 4WD solenoid has been detected.TF-37, "4WD Solenoid"
4WD ACTUATOR RLY
[C1205]Malfunction has been detected from 4WD actuator relay integrated
with 4WD control unit, or malfunction related to 4WD solenoid has
been detected.TF-40, "4WD Actuator
Relay" or TF-37, "4WD
Solenoid"
MODE SW
[C1209]More than two switch inputs are simultaneously detected due to
short circuit of 4WD mode switch.TF-42, "4WD Mode Switch"
ENGINE SIGNAL 1
[C1210]Malfunction has been detected from ECM.TF-44, "Engine Control Sig-
nal"
CAN COMM CIRCUIT
[U1000]Malfunction has been detected from CAN communication line.TF-45, "CAN Communica-
tion Line"
NO DTC IS DETECTED.
FURTHER TESTING MAY BE
REQUIRED.No NG item has been detected. —

TROUBLE DIAGNOSIS
TF-33
C
E
F
G
H
I
J
K
L
MA
B
TF

How to Erase Self-diagnostic Results
1. Perform applicably inspection of malfunctioning item and then repair or replace.
2. Start engine and drive at 30 km/h (19 MPH) or more for approx. 1 minute.
3. Make sure that ABS warning lamp turns OFF.
NOTE:
Make sure that ABS warning lamp turns OFF by driving for a minute at vehicle speed of 30 km/h
(19 MPH) or more after turning ignition switch “OFF” if 4WD warning lamp turns ON with system
malfunction of “ABS SYSTEM [C1203]”. 4WD warning lamp may not turn OFF if it is normal unless
ignition switch turns OFF at once and engine restarts after that.
4. Turn ignition switch “OFF” to erase memory.
5. Start engine and select “SELF-DIAG RESULTS” mode for “ALL MODE AWD/4WD” with CONSULT-II.
6. Touch “ERASE” on CONSULT-II screen to erase DTC memory.
CAUTION:
If memory cannot be erased, perform applicably diagnosis.
7. Drive at 30 km/h (19 MPH) or more for approx. 1 minute. Be sure 4WD warning lamp is OFF.
DATA MONITOR MODE
Operation Procedure
1. Perform “CONSULT-II SETTING PROCEDURE”. Refer to TF-31, "CONSULT-II SETTING PROCEDURE"
.
2. Touch “DATA MONITOR”.
3. Select from “SELECT MONITOR ITEM”, screen of data monitor mode is displayed.
NOTE:
When malfunction is detected, CONSULT-II performs REAL-TIME DIAGNOSIS.
Also, any malfunction detected while in this mode will be displayed at real time.
Display Item List
×: Standard –: Not applicable
Monitor item (Unit)SELECT MONITOR ITEM
Remarks
ECU INPUT
SIGNALSMAIN
SIGNALSSELECTION
FROM MENU
FR RH SENSOR [km/h] or [mph]×××Wheel speed calculated by front wheel
sensor RH signal is displayed.
FR LH SENSOR [km/h] or [mph]×××Wheel speed calculated by front wheel
sensor LH signal is displayed.
RR RH SENSOR [km/h] or [mph]×××Wheel speed calculated by rear wheel
sensor RH signal is displayed.
RR LH SENSOR [km/h] or [mph]×××Wheel speed calculated by rear wheel
sensor LH signal is displayed.
BATTERY VOLT [V] – –×Power supply voltage for 4WD control unit.
THRTL POS SEN [%] – –×Throttle opening status is displayed.
ETS SOLENOID [A] – –×Monitored value of current at 4WD sole-
noid.
STOP LAMP SW [ON/OFF] – –×Stop lamp switch signal status via CAN
communication line is displayed.
ENG SPEED SIG [RUN/STOP] – –×Engine status is displayed.
ETS ACTUATOR [ON/OFF] – –×Operating condition of 4WD actuator relay
(integrated in 4WD control unit) is dis-
played.
4WD WARN LAMP [ON/OFF] – –×Control status of 4WD warning lamp is dis-
played.
4WD MODE SW [2WD/AUTO/LOCK] – –×4WD lock switch signal status via CAN
communication line is displayed.

FAX-4
PREPARATION

KV40106200
Drift
a: 114.3 mm (4.50 in) dia.
b: 105.3 mm (4.15 in) dia.Removing wheel bearings, installing splash
guards
KV401047S0
Drift set
KV40104710
Drift
a: 76.3 mm (3.004 in) dia.
b: 67.9 mm (2.673 in) dia.
KV40104720-1
KV40104720-2
KV40104730Installing wheel bearings and splash guard
ST30022000
Drift
a: 110 mm (4.33 in) dia.
b: 46 mm (1.81 in) dia.Installing splash guard
KV401053S0
Drift set
KV40105310
Drift
a: 89.1 mm (3.508 in) dia.
b: 80.7 mm (3.177 in) dia.
KV40105320
KV40105330Installing wheel hub
ST35271000
Drift
a: 72 mm (2.83 in) dia.
b: 63 mm (2.48 in) dia.Assembling support bearings
Installing wheel bearing
KV38107800
Protector
a: 29 mm (1.14 in) dia.
KV38105500
Protector
a: 40 mm (1.57 in) dia.Installing drive shaft
KV40101840
Collar
a: 67 mm (2.64 in) dia.
b: 85 mm (3.35 in) dia.Installing sensor rotor Tool number
Tool nameDescription
ZZA0936D
ZZA0808D
ZZA0920D
ZZA0808D
ZZA0837D
ZZA0835D
ZZA1113D

PREPARATION
FAX-5
C
E
F
G
H
I
J
K
L
MA
B
FA X

ST17130000
Drift
a: 32 mm (1.26 in) dia.
b: 60 mm (1.57 in) dia.Disassembling support bearing
ST33252000
Drift
a: 82 mm (3.23 in) dia.
b: 60 mm (2.36 in) dia.Assembling support bearing
KV38100500
Drift
a: 80 mm (3.15 in) dia.
b: 60 mm (2.36 in) dia.Installing sensor rotor
ST35271000
Drift
a: 72 mm (2.83 in) dia.
b: 63 mm (2.48 in) dia.Installing wheel bearing
ST35300000
Drift
a: 45.1 mm (1.776 in) dia.
b: 59 mm (2.32 in) dia.Installing wheel hub Tool number
Tool nameDescription
ZZA0836D
ZZA0838D
ZZA0701D
ZZA0814D
ZZA0881D

FRONT WHEEL HUB AND KNUCKLE
FAX-7
C
E
F
G
H
I
J
K
L
MA
B
FA X

FRONT WHEEL HUB AND KNUCKLEPFP:40202
On-Vehicle InspectionEDS0005R
Inspect to check that there is no excessive play, cracking, wear, or
other damage to front axle.

Turn front wheels (left/right) and check the play.

Check that no nails or other foreign objects are embedded.

Retighten all axle nuts and bolts to the specified torque.
FRONT WHEEL BEARINGS
With the vehicle raised, inspect the following.

Move wheel hub in the axial direction by hand. Check that there is no looseness of front wheel bearings.

Rotate wheel hub and check that there is no unusual noise or other irregular conditions. If there are any
irregular conditions, replace the wheel bearing.
Removal and InstallationEDS0005S
REMOVAL
1. Remove tyre. Remove brake hose lock plate from strut.
2. Remove brake caliper from steering knuckle. Hang it in a place where it will not interfere with work. Refer
to BR-27, "
FRONT DISC BRAKE" .
CAUTION:
Avoid depressing the brake pedal with brake caliper removed.
3. Remove wheel sensor from steering knuckle. Refer to BRC-116, "
WHEEL SENSORS" .
CAUTION:
Do not pull on wheel sensor harness.
SMA525A
Axial end play : 0.05 mm (0.002 in)
1. Steering knuckle 2. Splash guard 3. Wheel bearing assembly
4. Snap ring 5. Wheel hub 6. Hub bolt
7. Cotter pin
SDIA0131E
