2005 NISSAN X-TRAIL check

START SIGNAL
EC-1347
[YD (WITH EURO-OBD)]
C
D
E
F
G
H
I
J
K
L
MA
EC

4. CHECK INTERMITTENT INCIDENT
Refer to EC-1045, "
TROUBLE DIAGNOSIS FOR INTERMITTENT INCIDENT" .
>>INSPECTION END

INDEX FOR DTC
EC-1351
[YD (WITHOUT EURO-OBD)]
C
D
E
F
G
H
I
J
K
L
MA
EC

[YD (WITHOUT EURO-OBD)]INDEX FOR DTCPFP:00024
Alphabetical IndexEBS011WP
Check if the vehicle is a model with Euro-OBD (E-OBD) system or not by the “Type approval number” on the
identification plate. Refer to GI-46, "
IDENTIFICATION PLATE" .
NOTE:
If DTC U1000 is displayed with other DTC, first perform the trouble diagnosis for DTC U1000. Refer to
EC-1425, "
DTC U1000 CAN COMMUNICATION LINE" .
X: Applicable —: Not applicable
Items
(CONSULT-II screen terms) DTC
MI lighting
up Reference page
CONSULT-II
ECM*
1
APP SEN 1/CIRCUIT P0122 0122 —EC-1455
APP SEN 1/CIRCUIT P0123 0123 —EC-1455
APP SEN 2/CIRCUIT P0222 0222 —EC-1493
APP SEN 2/CIRCUIT P0223 0223 —EC-1493
APP SENSOR P2135 2135 —EC-1624
BARO SEN/CIRC P2228 2228 —EC-1641
BARO SEN/CIRC P2229 2229 —EC-1641
BATTERY VOLTAGE P0563 0563 —EC-1554
BRAKE SW/CIRCUIT P0504 0504 —EC-1544
CAN COMM CIRCUIT U1000
1000*2—EC-1425
CKP SEN/CIRCUIT P0335 0335×EC-1512
CKP SENSOR P0336 0336×EC-1518
CMP SEN/CIRCUIT P0340 0340×EC-1525
CMP SENSOR P0341 0341×EC-1531
CMP/CKP RELATION P0016 0016 —EC-1428
CYL1 INJECTOR P0201 0201 —EC-1474
CYL2 INJECTOR P0202 0202 —EC-1474
CYL3 INJECTOR P0203 0203 —EC-1474
CYL4 INJECTOR P0204 0204 —EC-1474
ECM P0605 0605×EC-1566
ECM P0606 0606×EC-1568
ECM RELAY P0686 0686 —EC-1584
ECT SEN/CIRC P0117 0117 —EC-1449
ECT SEN/CIRC P0118 0118 —EC-1449
ENG OVER TEMP P0217 0217×EC-1480
FRP RELIEF VALVE P1272 1272 —EC-1602
FRP SEN/CIRC P0192 0192 —EC-1466
FRP SEN/CIRC P0193 0193 —EC-1466
FUEL LEAK P0093 0093×EC-1434
FUEL PUMP P0089 0089 —EC-1432
FUEL PUMP P1273 1273 —EC-1609
FUEL PUMP P1274 1274×EC-1614
FUEL PUMP P1275 1275×EC-1619
FUEL PUMP/CIRC P0628 0628×EC-1570
FUEL PUMP/CIRC P0629 0629×EC-1570
FUEL TEMP SEN/CIRC P0182 0182 —EC-1462

INDEX FOR DTC
EC-1353
[YD (WITHOUT EURO-OBD)]
C
D
E
F
G
H
I
J
K
L
MA
EC

DTC No. IndexEBS011WQ
Check if the vehicle is a model with Euro-OBD (E-OBD) system or not by the “Type approval number” on the
identification plate. Refer to GI-46, "
IDENTIFICATION PLATE" .
NOTE:
If DTC U1000 is displayed with other DTC, first perform the trouble diagnosis for DTC U1000. Refer to
EC-1425, "
DTC U1000 CAN COMMUNICATION LINE" .
X: Applicable —: Not applicable
DTC
Items
(CONSULT-II screen item) MI lighting up Reference page
CONSULT-II
ECM*
1
U1000
1000*2CAN COMM CIRCUIT —EC-1425
P00000000NO DTC IS DETECTED.
FURTHER TESTING
MAY BE REQUIRED.——
P0016 0016 CMP/CKP RELATION —EC-1428
P0088 0088 HIGH FUEL PRESS×EC-1430
P0089 0089 FUEL PUMP —EC-1432
P0093 0093 FUEL LEAK×EC-1434
P0102 0102 MAF SEN/CIRCUIT —EC-1438
P0103 0103 MAF SEN/CIRCUIT —EC-1438
P0112 0112 IAT SEN/CIRCUIT —EC-1443
P0113 0113 IAT SEN/CIRCUIT —EC-1443
P0117 0117 ECT SEN/CIRC —EC-1449
P0118 0118 ECT SEN/CIRC —EC-1449
P0122 0122 APP SEN 1/CIRCUIT —EC-1455
P0123 0123 APP SEN 1/CIRCUIT —EC-1455
P0182 0182 FUEL TEMP SEN/CIRC —EC-1462
P0183 0183 FUEL TEMP SEN/CIRC —EC-1462
P0192 0192 FRP SEN/CIRC —EC-1466
P0193 0193 FRP SEN/CIRC —EC-1466
P0200 0200 INJECTOR×EC-1472
P0201 0201 CYL1 INJECTOR —EC-1474
P0202 0202 CYL2 INJECTOR —EC-1474
P0203 0203 CYL3 INJECTOR —EC-1474
P0204 0204 CYL4 INJECTOR —EC-1474
P0217 0217 ENG OVER TEMP×EC-1480
P0222 0222 APP SEN 2/CIRCUIT —EC-1493
P0223 0223 APP SEN 2/CIRCUIT —EC-1493
P0234 0234 TC SYSTEM —EC-1500
P0237 0237 TC BOOST SEN/CIRC —EC-1506
P0238 0238 TC BOOST SEN/CIRC —EC-1506
P0335 0335 CKP SEN/CIRCUIT×EC-1512
P0336 0336 CKP SENSOR×EC-1518
P0340 0340 CMP SEN/CIRCUIT×EC-1525
P0341 0341 CMP SENSOR×EC-1531
P0501 0501 VEHICLE SPEED —EC-1538
P0502 0502 VEHICLE SPEED —EC-1540
P0503 0503 VEHICLE SPEED —EC-1542

PRECAUTIONS
EC-1357
[YD (WITHOUT EURO-OBD)]
C
D
E
F
G
H
I
J
K
L
MA
EC


After performing each TROUBLE DIAGNOSIS, perform DTC
Confirmation Procedure or Overall Function Check.
The DTC should not be displayed in the DTC Confirmation
Procedure if the repair is completed. The Overall Function
Check should be a good result if the repair is completed.

When measuring ECM signals with a circuit tester, never
allow the two tester probes to contact.
Accidental contact of probes will cause a short circuit and
damage the ECM power transistor.

Do not use ECM ground terminals when measuring input/
output voltage. Doing so may result in damage to the ECM's
transistor. Use a ground other than ECM terminals, such as
the ground.

Do not disassemble fuel pump.
If NG, take proper action.

Do not disassemble fuel injector.
If NG, replace fuel injector.

Do not depress accelerator pedal when staring.

Immediately after staring, do not rev up engine unnecessar-
ily.

Do not rev up engine just prior to shutdown.

When installing C.B. ham radio or a mobile phone, be sure
to observe the following as it may adversely affect elec-
tronic control systems depending on installation location.
–Keep the antenna as far as possible from the electronic
control units.
–Keep the antenna feeder line more than 20 cm (8 in) away
from the harness of electronic controls.
Do not let them run parallel for a long distance.
–Adjust the antenna and feeder line so that the standingwave
radio can be kept smaller.
–Be sure to ground the radio to vehicle body.
SAT652J
SEF348N
SEF709Y
SEF708Y

ENGINE CONTROL SYSTEM
EC-1365
[YD (WITHOUT EURO-OBD)]
C
D
E
F
G
H
I
J
K
L
MA
EC

Crankcase Ventilation SystemEBS011X4
DESCRIPTION
In this system, blow-by gas is sucked into the air duct after oil separation by oil separator in the rocker cover.
INSPECTION
Ventilation Hose
1. Check hoses and hose connections for leaks.
2. Disconnect all hoses and clean with compressed air. If any hose
cannot be freed of obstructions, replace.
CAN CommunicationEBS01H7B
SYSTEM DESCRIPTION
CAN (Controller Area Network) is a serial communication line for real time application. It is an on-vehicle mul-
tiplex communication line with high data communication speed and excellent error detection ability. Many elec-
tronic control units are equipped onto a vehicle, and each control unit shares information and links with other
control units during operation (not independent). In CAN communication, control units are connected with 2
communication lines (CAN H line, CAN L line) allowing a high rate of information transmission with less wiring.
Each control unit transmits/receives data but selectively reads required data only.
CAN COMMUNICATION UNIT
Go to CAN system, when selecting your CAN system type from the following table.
PBIB0590E
SEC692
Body typeWagon
Axle 4WD 2WD
EngineYD22DDTi
TransmissionM/T
Brake control ABS ESP ABS ESP
ECM×××
ESP/TCS/ABS control unit××
ABS actuator and electric unit (control unit)××

ON BOARD DIAGNOSTIC (OBD) SYSTEM
EC-1373
[YD (WITHOUT EURO-OBD)]
C
D
E
F
G
H
I
J
K
L
MA
EC


If the battery is disconnected, the emission-related diagnostic information will be lost within 24
hours.

The following data are cleared when the ECM memory is erased.
–Diagnostic trouble codes
–Freeze frame data
–Fuel pump learning value
–Others
Actual work procedures are explained using a DTC as an example. Be careful so that not only the DTC, but all
of the data listed above, are cleared from the ECM memory during work procedures.
Freeze Frame DataEBS011XA
The ECM records the driving conditions such as calculated load value, engine coolant temperature, engine
speed, vehicle speed and intake manifold pressure at the moment a malfunction is detected.
The data, stored together with the DTC data, are called freeze frame data and displayed on CONSULT-II. For
details, see EC-1407
.
Only one set of freeze frame data can be stored in the ECM. If freeze frame data is stored in the ECM memory
and another freeze frame data occurs later, the first (original) freeze frame data remains unchanged in the
ECM memory.
Freeze frame data (along with the DTCs) are cleared when the ECM memory is erased. Procedures for clear-
ing the ECM memory are described in EC-1372, "
HOW TO ERASE DTC" .
NATS (Nissan Anti-theft System)EBS011XB

If the security indicator lights up with the ignition switch in
the ON position or "NATS MALFUNCTION" is displayed on
"SELF-DIAG RESULTS" screen, perform self-diagnostic
results mode with CONSULT-II using NATS program card.
Refer to NATS (Nissan Anti-Theft System) in BL section.

Confirm no self-diagnostic results of NATS is displayed
before touching "ERASE" in "SELF-DAIG RESULTS" mode
with CONSULT-II.

When replacing ECM, initialization of NATS system and reg-
istration of all NATS ignition key IDs must be carried out
with CONSULT-II using NATS program card.
Therefore, be sure to receive all keys from vehicle owner.
Regarding the procedure of NATS initialization and NATS ignition key ID registration, refer to CON-
SULT-II operation manual, NATS.
Malfunction Indicator (MI)EBS01F88
DESCRIPTION
The MI is located on the instrument panel.
1. The MI will light up when the ignition switch is turned ON without
the engine running. This is a bulb check.

If the MI does not light up, refer to EC-1699, "MI & DATA LINK
CONNECTORS" .
2. When the engine is started, the MI should go off.
If the MI remains on, the on board diagnostic system has
detected an engine system malfunction.
ON BOARD DIAGNOSTIC SYSTEM FUNCTION
The on board diagnostic system has the following three functions.
SEF543X
SAT652J

EC-1374
[YD (WITHOUT EURO-OBD)]
ON BOARD DIAGNOSTIC (OBD) SYSTEM

HOW TO SWITCH DIAGNOSTIC TEST MODE
NOTE:

It is better to count the time accurately with a clock.

It is impossible to switch the diagnostic mode when an accelerator pedal position sensor circuit
has a malfunction.

Always ECM returns to Diagnostic Test Mode I after ignition switch is turned OFF.
How to Set Diagnostic Test Mode II (Self-diagnostic Results)
1. Confirm that accelerator pedal is fully released, turn ignition switch ON and wait 3 seconds.
2. Repeat the following procedure quickly five times within 5 seconds.
a. Fully depress the accelerator pedal.
b. Fully release the accelerator pedal.
3. Wait 7 seconds, fully depress the accelerator pedal and keep it for approx. 10 seconds until the MI starts
blinking.
4. Fully release the accelerator pedal.
ECM has entered to Diagnostic Test Mode II (Self-diagnostic results).
Diagnostic Test
ModeKEY and ENG.
Sta tusFunction Explanation of Function
Mode I Ignition switch in
ON position
Engine stoppedBULB CHECK This function checks the MI bulb for damage (blown, open
circuit, etc.).
If the MI does not come on, check MI circuit. (See EC-
1699, "MI & DATA LINK CONNECTORS" .)
Engine running MALFUNCTION
WARNINGThis is a usual driving condition. When ECM detects a mal-
function, the MI will light up to inform the driver that a mal-
function has been detected.
Mode II Ignition switch in
ON position
Engine stoppedSELF-DIAGNOSTIC
RESULTSThis function allows DTCs to be read.
PBIB0092E

ON BOARD DIAGNOSTIC (OBD) SYSTEM
EC-1375
[YD (WITHOUT EURO-OBD)]
C
D
E
F
G
H
I
J
K
L
MA
EC

How to Erase Diagnostic Test Mode II (Self-diagnostic Results)
1. Set ECM in Diagnostic Test Mode II (Self-diagnostic results). Refer to EC-1374, "How to Set Diagnostic
Test Mode II (Self-diagnostic Results)" .
2. Fully depress the accelerator pedal and keep it for more than 10 seconds.
The emission-related diagnostic information has been erased from the backup memory in the ECM.
3. Fully release the accelerator pedal, and confirm the DTC 0000 is displayed.
DIAGNOSTIC TEST MODE I — BULB CHECK
In this mode, the MI on the instrument panel should stay ON. If it remains OFF, check the bulb. Refer to EC-
1699, "MI & DATA LINK CONNECTORS" .
DIAGNOSTIC TEST MODE I — MALFUNCTION WARNING
These DTC numbers are clarified in Diagnostic Test Mode II (SELF-DIAGNOSTIC RESULTS)
DIAGNOSTIC TEST MODE II — SELF-DIAGNOSTIC RESULTS
In this mode, the DTC is indicated by the number of blinks of the MI as shown below. A DTC will be used as an
example for how to read a code.
A particular trouble code can be identified by the number of four-digit numeral flashes. The “zero” is indicated
by the number of ten flashes. The length of time the 1,000th-digit numeral flashes on and off is 1.2 seconds
consisting of an ON (0.6-second) - OFF (0.6-second) cycle.
The 100th-digit numeral and lower digit numerals consist of a 0.3-second ON and 0.3-second OFF cycle.
A change from one digit numeral to another occurs at an interval of 1.0-second OFF. In other words, the later
numeral appears on the display 1.3 seconds after the former numeral has disappeared.
A change from one trouble code to another occurs at an interval of 1.8-second OFF.
In this way, all the detected malfunctions are classified by their DTC numbers. The DTC 0000 refers to no mal-
function. (See EC-1351, "
INDEX FOR DTC" )
How to Erase Diagnostic Test Mode II (Self-diagnostic Results)
The DTC can be erased from the back up memory in the ECM by depressing accelerator pedal. Refer to EC-
1375, "How to Erase Diagnostic Test Mode II (Self-diagnostic Results)" .

If the battery is disconnected, the DTC will be lost from the backup memory within 24 hours.

Be careful not to erase the stored memory before starting trouble diagnoses.
MI Condition
ON When the malfunction is detected.
OFF No malfunction.
PBIA3905E
