2005 INFINITI FX35 Ignition switch

BRC-52
[VDC/TCS/ABS]
TROUBLE DIAGNOSIS
Revision: 2005 July 2005 FX
Inspection 12: When “ST ANG SEN SIGNAL” Appears on Self-diagnosis Results
Display
AFS0021V
DTC C1144
INSPECTION PROCEDURE
1. CHECK SELF-DIAGNOSTIC RESULTS (1)
Check self-diagnostic results.
Does anything besides
“ST ANG SEN SIGNAL” appear on self-diagnostic results display?
YES >> Inspect and repair the indicated items. Then perform self-diagnosis again.
NO >> Perform adjustment of steering angle sensor neutral position. Then GO TO 2.
2. CHECK SELF DIAGNOSIS RESULTS (2)
Turn ignition switch OFF and ON to erase self-diagnostic results, and perform ABS actuator and electric unit
(control unit) self-diagnosis again.
Does anything appear on self-diagnostic results display?
YES >> Replace steering angle sensor. Then perform adjustment of neutral position and perform self- diagnosis again.
NO >> INSPECTION END
Inspection 13: When “DECEL G SEN SET” Appears on Self-diagnostic Results
Display (AWD Model)
AFS0021W
DTC C1160
INSPECTION PROCEDURE
1. CHECK SELF- DIAGNOSTIC RESULTS (1)
Check self-diagnostic results.
Does anything besides
“DECEL G SEN SET” appear on self-diagnostic results display?
YES >> Inspect and repair the indicated items. Then perform self-diagnosis again.
NO >> Perform calibration of Decel G Sensor. Then GO TO 2.
2. CHECK SELF-DIAGNOSIS RESULTS (2)
Turn ignition switch OFF and ON to erase self-diagnostic results, and perform ABS actuator and electric unit
(control unit) self-diagnosis again.
Does anything appear on self-diagnostic results display?
YES >> Replace Yaw rate/side/decel G sensor. Then perform adjustments of neutral position and perform self-diagnosis again.
NO >> INSPECTION END
Self-diagnostic results
ST ANG SEN SIGNAL
Self-diagnostic results DECEL G SEN SET

TROUBLE DIAGNOSIS BRC-53
[VDC/TCS/ABS]
C
D E
G H
I
J
K L
M A
B
BRC
Revision: 2005 July 2005 FX
Inspection 14: CAN Communication CircuitAFS001T5
DTC U1000, C1156
INSPECTION PROCEDURE
1. CHECK CONNECTOR
1. Turn ignition switch OFF, disconnect the ABS actuator and electric unit (control unit) connector, and check the terminal for deformation, disconnection, looseness, and so on. If there is a malfunction, repair or
replace the terminal.
2. Reconnect connector to perform self-diagnosis.
Is
“CAN COMM CIRCUIT” or “ST ANG SEN COM CIR” displayed in the self-diagnosis display items?
YES >> Print out the self-diagnostic results, and refer to LAN-5, "Precautions When Using CONSULT-II" .
NO >> Connector terminal connection is loose, damaged, open, or shorted.
Component InspectionAFS001T6
VDC OFF SWITCH

Turn ignition switch OFF and disconnect VDC OFF switch con-
nector, and check continuity between VDC OFF switch connec-
tor M32 terminals 1 and 2.
Symptom 1: Excessive ABS Function Operation FrequencyAFS001T7
1. CHECK FRONT AND REAR AXLE
Make sure there is no excessive looseness in the front and rear axles.
OK or NG
OK >> GO TO 2.
NG >> Check front or rear axle system.
2. CHECK WHEEL SENSOR
Perform following inspection for wheel sensor:

Sensor mount and damage inspection

Sensor rotor mount and damage inspection

Sensor connector connection inspection

Sensor harness inspection
OK or NG
OK >> GO TO 3.
NG >> Replace sensor or sensor rotor.
3. CHECK ABS WARNING LAMP DISPLAY
Make sure warning lamp turns off approximately 2 seconds after the ignition switch is turned ON or when driv-
ing.
OK or NG
OK >> Normal
NG >> Perform self-diagnosis. Refer to BRC-27, "
SELF-DIAGNOSIS" .
1 -2 : Continuity should exist when pushing
switch.
Continuity should not exist when releasing
switch.
SFIA1203E

TROUBLE DIAGNOSIS BRC-55
[VDC/TCS/ABS]
C
D E
G H
I
J
K L
M A
B
BRC
Revision: 2005 July 2005 FX
Symptom 4: The ABS Function Does Not OperateAFS001TA
CAUTION:
The ABS does not operate when the speed is 10 km/h (6 MPH) or less.
1. CHECK ABS WARNING LAMP DISPLAY
Make sure warning lamp turns off approximately 2 seconds after the ignition switch is turned ON or when driv-
ing.
OK or NG
OK >> GO TO symptom 1 “Step 2”. Refer to BRC-53, "Symptom 1: Excessive ABS Function Operation
Frequency" .
NG >> Perform self-diagnosis. Refer to BRC-27, "
SELF-DIAGNOSIS" .
Symptom 5: Pedal Vibration or ABS Operation Sound OccursAFS001TB
CAUTION:
Under the following conditions, when brake pedal is lightly depressed (just place a foot on it), ABS is
activated and vibration is felt. However, this is normal.

When shifting gears

When driving on slippery road

During cornering at high speed

When passing over bumps or grooves

When pulling away just after starting engine [at approximately 10 km/h (6 MPH) or higher]
1. SYMPTOM CHECK 1
Check if pedal vibration or operation sound occurs when engine is started.
OK or NG
OK >> Perform self-diagnosis. Refer to BRC-27, "SELF-DIAGNOSIS" .
NG >> GO TO 2.
2. SYMPTOM CHECK 2
Check symptom when electrical component (headlamps, etc.) switches are operated.
Does the symptom occur when the electrical component (head lamp, etc.) switches are operated?
YES >> Check if there is a radio, antenna, antenna lead wire, or wiring close to ABS actuator and electric unit (control unit) (or its wiring), and if there is, move it farther away.
NO >> GO TO symptom 1 “Step 2”. Refer to BRC-53, "
Symptom 1: Excessive ABS Function Operation
Frequency" .
Symptom 6: Vehicle Jerks During VDC/TCS/ABS ControlAFS001TC
1. CHECK ENGINE SPEED SIGNAL
Perform CONSULT-II “DATA MONITOR” to check engine speed.
Is engine speed at idle 400 rpm or higher?
YES >> GO TO 3.
NO >> GO TO 2.
2. ABS WARNING LAMP DISPLAY CHECK
Make sure warning lamp turns off approximately 2 seconds after the ignition switch is turned ON or when driv-
ing.
OK or NG
OK >> System is normal.
NG >> GO TO 3.

DI-1
DRIVER INFORMATION SYSTEM
K ELECTRICAL
CONTENTS
C
D E
F
G H
I
J
L
M
SECTION DI
A
B
DI
Revision: 2005 July 2005 FX
DRIVER INFORMATION SYSTEM
PRECAUTION ............................................................ 4
Precautions for Supplemental Restraint System
(SRS) “AIR BAG” and “SEAT BELT PRE-TEN-
SIONER” ............................................................. ..... 4
COMBINATION METERS ...................................... ..... 5
System Description ............................................. ..... 5
UNIFIED METER CONTROL UNIT ................. ..... 5
UNIFIED METER AND A/C AMP. .................... ..... 5
HOW TO CHANGE THE DISPLAY FOR ODO/
TRIP METER ................................................... ..... 6
POWER SUPPLY AND GROUND CIRCUIT ... ..... 6
SPEEDOMETER .............................................. ..... 7
TACHOMETER ................................................ ..... 7
WATER TEMPERATURE GAUGE ................... ..... 7
FUEL GAUGE .................................................. ..... 7
Component Parts and Harness Connector Location ..... 7
Arrangement of Combination Meter .................... ..... 8
Circuit Diagram ................................................... ..... 9
Wiring Diagram — METER — ............................. ... 10
Terminals and Reference Value for Combination
Meter ................................................................... ... 12
Terminals and Reference Value for Unified Meter
and A/C Amp. ...................................................... ... 13
Self-Diagnosis Mode of Combination Meter ........ ... 14
SELF-DIAGNOSIS FUNCTION ....................... ... 14
OPERATION PROCEDURE ............................ ... 14
CONSULT-II Function (METER A/C AMP) .......... ... 14
Trouble Diagnosis ............................................... ... 15
HOW TO PERFORM TROUBLE DIAGNOSIS ... 15
PRELIMINARY CHECK ................................... ... 15
Symptom Chart 1 ................................................ ... 17
Symptom Chart 2 ................................................ ... 17
Power Supply and Ground Circuit Inspection ..... ... 18
Vehicle Speed Signal Inspection ......................... ... 20
Engine Speed Signal Inspection ......................... ... 21
Engine Coolant Temperature Signal Inspection .. ... 21
Fuel Level Sensor Signal Inspection ................... ... 22
Odo/Trip Meter and Illumination Control Switch
Inspection ............................................................ ... 24
Fuel Gauge Pointer Fluctuates, Indicator Wrong Value or Varies ....................................................
... 24
Fuel Gauge Does Not Move to FULL Position .... ... 24
Electrical Components Inspection ....................... ... 25
CHECK FUEL LEVEL SENSOR UNIT ............. ... 25
Removal and Installation of Combination Meter .. ... 25
Disassembly and Assembly of Combination Meter ... 26
DISASSEMBLY ................................................ ... 26
ASSEMBLY ...................................................... ... 27
Removal and Installation of Odo/Trip Meter and Illu-
mination Control Switch ....................................... ... 27
REMOVAL ........................................................ ... 27
INSTALLATION ................................................ ... 27
UNIFIED METER AND A/C AMP ........................... ... 28
System Description .............................................. ... 28
INPUT/OUTPUT SIGNALS .............................. ... 28
FAIL-SAFE ....................................................... ... 29
CAN Communication System Description ........... ... 29
CAN Communication Unit .................................... ... 29
Schematic ............................................................ ... 30
CONSULT-II Function (METER A/C AMP) .......... ... 31
CONSULT-II BASIC OPERATION .................... ... 31
SELF-DIAGNOSTIC RESULTS ........................ ... 32
DATA MONITOR .............................................. ... 32
DTC [U1000] CAN Communication Circuit .......... ... 34
DTC [B2202] Meter Communication Circuit ........ ... 34
DTC [B2205] Vehicle Speed Circuit ..................... ... 37
Removal and Installation of Unified Meter and A/C
Amp. .................................................................... ... 37
REMOVAL ........................................................ ... 37
INSTALLATION ................................................ ... 37
COMPASS .............................................................. ... 38
System Description .............................................. ... 38
DIRECTION DISPLAY ...................................... ... 38
Wiring Diagram – COMPAS – ............................. ... 40
Removal and Installation of Compass ................. ... 41
WARNING LAMPS ................................................. ... 42
Schematic ............................................................ ... 42
Wiring Diagram — WARN — ............................... ... 43
Oil Pressure Warning Lamp Stays Off (Ignition
Switch ON) .......................................................... ... 51

DI-2Revision: 2005 July 2005 FX
Oil Pressure Warning Lamp Does Not Turn Off (Oil
Pressure Is Normal) ............................................. ... 52
Component Inspection ......................................... ... 53
OIL PRESSURE SWITCH ................................ ... 53
A/T INDICATOR ..................................................... ... 54
Wiring Diagram — AT/IND — .............................. ... 54
A/T Indicator Is Malfunction ................................. ... 56
WARNING CHIME .................................................. ... 58
System Description .............................................. ... 58
FUNCTION ....................................................... ... 58
IGNITION KEY WARNING CHIME (WITHOUT
INTELLIGENT KEY) ......................................... ... 58
IGNITION KEY WARNING CHIME (WITH INTEL-
LIGENT KEY) ................................................... ... 59
LIGHT WARNING CHIME ................................ ... 59
SEAT BELT WARNING CHIME ........................ ... 59
CAN Communication System Description ........... ... 60
CAN Communication Unit .................................... ... 60
Component Parts and Harness Connector Location ... 61
Schematic ............................................................ ... 62
Wiring Diagram — CHIME — .............................. ... 63
Terminals and Reference Value for BCM ............. ... 66
Terminals and Reference Value for Unified Meter
and A/C Amp. ...................................................... ... 67
Terminals and Reference Value for Combination
Meter ................................................................... ... 67
Trouble Diagnosis ................................................ ... 68
HOW TO PERFORM TROUBLE DIAGNOSIS . ... 68
PRELIMINARY CHECK .................................... ... 68
CONSULT-II Function (BCM) ............................... ... 69
DIAGNOSTIC ITEMS DESCRIPTION .............. ... 69
CONSULT-II BASIC OPERATION PROCEDURE
... 69
DATA MONITOR ............................................... ... 70
ACTIVE TEST .................................................. ... 70
SELF-DIAGNOSTIC RESULTS ........................ ... 71
All Warnings Are Not Operated ........................... ... 71
Key Warning Chime and Light Warning Chime Does
Not Operate (Seat Belt Warning Chime Does Oper-
ate) ...................................................................... ... 72
Key Warning Chime Does Not Operate (Without
Intelligent Key) ..................................................... ... 73
Key Warning Chime Does Not Operate (With Intel-
ligent Key, When Mechanical Key Is Used) ......... ... 75
Key Warning Chime Does Not Operate (With Intel-
ligent Key, When Intelligent Key Is Carried With The
Driver) .................................................................. ... 77
Light Warning Chime Does Not Operate ............. ... 79
Seat Belt Warning Chime Does Not Operate ...... ... 80
LANE DEPARTURE WARNING SYSTEM ............. ... 82
Precautions for Lane Departure Warning (LDW)
system ................................................................. ... 82
System Description .............................................. ... 82
LDW SYSTEM OPERATION ............................ ... 82
POWER SUPPLY AND GROUND CIRCUIT .... ... 84
CAN Communication ........................................... ... 84
SYSTEM DESCRIPTION ................................. ... 84
CAN COMMUNICATION UNIT ......................... ... 85
Action Test ........................................................... ... 85 LDW SYSTEM RUNNING TEST ......................
... 85
Camera Aiming Adjustment ................................. ... 86
OUTLINE .......................................................... ... 86
PREPARATION ................................................. ... 86
TARGET SETTING ........................................... ... 86
VEHICLE HEIGHT CHECK .............................. ... 89
AIMING ADJUSTMENT .................................... ... 89
Component Parts and Harness Connector Location ... 93
Schematic ............................................................ ... 94
Wiring Diagram — LDW — .................................. ... 95
Terminals and Reference Value for LDW Camera
Unit ....................................................................... ... 98
CONSULT-II Function (LDW) ............................... ... 98
DESCRIPTION ................................................. ... 98
CONSULT-II BASIC OPERATION .................... ... 98
WORK SUPPORT ............................................ ... 99
SELF-DIAG RESULTS ...................................... ... 99
DATA MONITOR ............................................... .100
ACTIVE TEST ................................................... .101
Trouble Diagnosis ................................................ .102
HOW TO PERFORM TROUBLE DIAGNOSIS . .102
SYMPTOM CHART ........................................... .102
Preliminary Inspection .......................................... .103
Power Supply and Ground Circuit Inspection ...... .104
DTC [C1B00] CAMERA UNIT MALF ................... .104
DTC [C1B01] CAM AIMING INCMP .................... .104
DTC [C1B02] VHCL SPD DATA MALF ................ .105
DTC [C1B03] ABNRML TEMP DETECT ............. .105
DTC [U1000] CAN COMM CIRCUIT ................... .105
DTC [U1010] CONTROL UNIT (CAN) ................. .105
LDW Chime Circuit Inspection ............................. .106
LDW Switch Circuit Inspection ............................. .107
LDW Indicator Lamp Circuit Inspection ................ .109
Turn Signal Input Inspection ................................ .110
Removal and Installation for LDW Camera Unit .. . 111
REMOVAL ......................................................... . 111
INSTALLATION ................................................. . 111
Removal and Installation for LDW Chime ............ . 111
REMOVAL ......................................................... . 111
INSTALLATION ................................................. . 111
Removal and Installation for LDW Switch ............ . 111
CLOCK ................................................................... .112
Wiring Diagram — CLOCK — .............................. .112
Removal and Installation of Clock ........................ .113
REMOVAL ......................................................... .113
INSTALLATION ................................................. .113
REAR VIEW MONITOR .......................................... .114
System Description .............................................. .114
POWER SUPPLY AND GROUND .................... .114
AV COMMUNICATION LINE ............................ .114
REAR VIEW CAMERA OPERATION ............... .114
Component Parts and Harness Connector Location .115
Schematic ............................................................ .116
Wiring Diagram — R/VIEW — ............................. .117
Terminals and Reference Value for Rear View Cam-
era Control Unit .................................................... .120
CONSULT-II Function (REARVIEW CAMERA) ... .121
CONSULT-II BASIC OPERATION .................... .121
WORK SUPPORT ............................................ .122

COMBINATION METERS DI-5
C
D E
F
G H
I
J
L
M A
B
DI
Revision: 2005 July 2005 FX
COMBINATION METERSPFP:24814
System DescriptionAKS005MH
UNIFIED METER CONTROL UNIT

Speedometer, odo/trip meter, tachometer, fuel gauge and water temperature gauge are controlled by the
unified meter control unit, which is built into the combination meter. Unified meter control unit receives sig-
nals from unified meter and A/C amp.

Warning lamp and indicator lamp of combination meter are controlled by signals drawn from the unified
meter and A/C amp.

Digital meter is adopted for odo/trip meter*.
*The record of the odo meter is kept even if the battery cable is disconnected. The record of the trip meter
is erased when the battery cable is disconnected.

Odo/trip meter, A/T indicator and ICC system display segments can be checked in diagnosis mode.

Meters/gauges can be checked in diagnosis mode.
Illumination Control
The unified meter control unit outputs the odo/trip meter and A/T
indicator lighting when the ignition switch is turned on. When the
lighting switch is turned on, light on for the combination meter dial,
illumination control switch and external lighting are output. In addi-
tion, when the lighting switch is turned on, the illumination control
switch on the left side of the combination meter can be used to
adjust the brightness of each light. The brightness can be adjusted
to sixteen different levels: From 0 (no lights) to 15 (maximum).
Pressing the illumination control switch will brighten or darken the
lights. When the ignition switch is in the START position, the combi-
nation meter dial lighting and illumination control switch lighting are
turned off.
UNIFIED METER AND A/C AMP.
Refer to DI-28, "System Description" in “UNIFIED METER AND A/C AMP”.
SKIA4795E

DI-6
COMBINATION METERS
Revision: 2005 July 2005 FX
HOW TO CHANGE THE DISPLAY FOR ODO/TRIP METER

The vehicle speed signal and the memory signals from the meter memory circuit are processed by the
combination meter and the mileage is displayed.

Switch modes with following procedure.

When trip transfer switch is pressed, trip meter display changes.

If trip reset switch is pressed for 1 second or more while trip A is
displayed, only trip A is reset. (Trip B operates the same way.)

If the battery is disconnected, odometer mileage will be retained
but the trip meter is reset to 0.0.
POWER SUPPLY AND GROUND CIRCUIT
Power is supplied at all times

through 10A fuse [No. 19, located in the fuse block (J/B)]

to combination meter terminal 8, and

to unified meter and A/C amp. terminal 21.
With the ignition switch in the ON or START position, power is supplied

through 10A fuse [No. 14, located in the fuse block (J/B)]

to combination meter terminal 7,

through 10A fuse [No. 12, located in the fuse block (J/B)]

to unified meter and A/C amp. terminal 22.
With the ignition switch in the ACC or ON position, power is supplied

through 15A fuse [No. 10, located in the fuse block (J/B)], and

through 15A fuse [No. 11, located in the fuse block (J/B)]

to unified meter and A/C amp. terminal 46.
Ground is supplied

to combination meter terminals 5, 6 and 15

through grounds M35, M45 and M85,

to unified meter and A/C amp. terminals 29 and 30

through grounds M35, M45 and M85.
PKIA2382E
SKIA4817E

DI-12
COMBINATION METERS
Revision: 2005 July 2005 FX
Terminals and Reference Value for Combination MeterAKS005MM
Terminal
No. Wire
color Item Condition
Reference value
Ignition
switch Operation or condition
1R/G Vehicle speed signal
(8-pulse) ON Speedometer operated
[When vehicle speed is
approx. 40 km/h (25 MPH)] NOTE:
Maximum voltage may be 5 V due
to specifications (connected units).
5 B Ground ON — Approx. 0 V
6
7 G/Y Ignition switch ON or START ON — Battery voltage
8 R/W Battery power supply OFF — Battery voltage
13 L/B TX communication line (To
unified meter and A/C amp.) ON —
14 PU RX communication line (From
unified meter and A/C amp.) ON —
15 B Ground ON — Approx. 0 V
19 R/B Illumination signal ON Lighting switch ON, then oper-
ate the illumination control
switch. When brightness level is
midway.
Lighting switch OFF Approx. 0 V
25 — Illumination control switch (–) OFF Illumination control switch (–)
is pushed. Approx. 0 V
Illumination control switch (–)
is released. Approx. 5 V
26 — Illumination control switch (+) OFF Illumination control switch (+)
is pushed. Approx. 0 V
Illumination control switch (+)
is released. Approx. 5 V
27 — Odo/trip meter and illumina-
tion control switch ground OFF — Approx. 0 V
PKIA1935E
SKIA3361E
SKIA3362E
SKIA8970E
