FEATURES OF YOUR HYUNDAI
7
3. Close the glove box, and lock the glove box using the master key.
4. Leave the sub key with the atten- dant. Trunk and glove box are se- cured because sub key only allowsengine start and door lock and un- lock.
In the interest of security, the number tag attached to the keys which bearsthe key number should be removed from the key string after you receive your new vehicle. In addition, key num-bers cannot be provided by Hyundai for security reasons. If you need additional keys or if youshould lose your keys, your authorized Hyundai dealer can make new keys if you can supply the key number andmaster key.
B880C01NF-GAT Key Numbers The vehicle key number is recorded upon a number tag attached to the keys when the vehicle is first deliveredto you. The key number should be recorded and kept in a safe place in case theneed to order further keys arises. New keys are available from any Hyundai dealer by quoting the relevant keynumber.
B880C01TG

1
FEATURES OF YOUR HYUNDAI
9
B030C01JM-AAT ILLUMINATED IGNITION SWITCH Whenever either front door is opened, the ignition switch will be illuminatedfor your convenience, provided the ignition switch is not in the "ON" posi- tion.The light will go off approximately 10 seconds after closing the door or when the ignition switch is turned on. B030C01E
CAUTION:
o If you fail to try the limp home procedure with the sequence ofthree times, you have to wait forabout one hour to do the limp home procedure again.
o If you cannot start your engine in
spite of limp home procedure,have your vehicle towed by an authorized Hyundai dealer.
!!
DOOR LOCKS
B040A01NF-GAT
WARNING:
o Unlocked doors can be danger- ous. Before you drive away (es- pecially if there are children inthe car), be sure that all the doors are securely closed and locked so that the doors cannot be inad-vertently opened from the inside. This helps ensure that doors will not be opened accidentally. Also,when combined with the proper use of seat belts, locking the doors will keep occupants frombeing ejected from the car in case of an accident.
o Before opening the door, always
look for and avoid oncoming traffic.
o In case of accident, the door is
unlocked automatically (If In- stalled).
o Do not lock the door using the key
or the transmitter until all passen-gers have left the car because the door is not unlocked by the door lock switch when locking the doorusing the key or the transmitter (If Installed).

1
FEATURES OF YOUR HYUNDAI
13THEFT-ALARM SYSTEM
B070A01A-AAT (If Installed) This system is designed to provide protection from unauthorized entry intothe car. This system is operated in three stages: the first is the "Armed" stage, the second is the "Alarm" stage,and the third is the "Disarmed" stage. If triggered, the system provides an audible alarm with blinking of the turnsignal lights.
B070B01TG-AAT Armed Stage
B070B01TG1) Remove the ignition key from the
ignition switch.
2) Make sure that the engine hood and trunk lid are closed and latched.
3) Lock the doors using the transmitter
of the keyless entry system.
If the steps are completed as above, the security LED lamp on the passenger’s crash pad will illuminate for about 30 seconds, and then thelamp will blink continuously when the system is entered into the armed stage. The turn signal lights will blink once toindicate that the system is armed. NOTE:
1) If any door, trunk lid or engine hood remains open, the system will not be armed.
2) If this happens, rearm the system
as previously described.
Lock
Unlock
Trunk Unlock
Park the car and stop the engine. Arm the system as described below.
! CAUTION:
Do not arm the system until all pas- sengers have left the car. If the sys- tem is armed while a passenger(s)remains in the car, the alarm may be activated when the remaining passenger(s) leaves the car.

1FEATURES OF YOUR HYUNDAI
14
CAUTION:
Only the transmitter can disarm the armed stage. If the transmitter doesnot disarm the system, it is neces- sary to take the following steps;
1. Unlock the door with the key, which will cause the alarm to be activated.
2. Insert the key in the ignition key cylinder and turn the ignition keyto "ON" position.
3. Wait for 30 seconds. After completing the steps above, the system will be disarmed.
!
! CAUTION:
Avoid trying to start the engine while the system is armed. B070D01TG-GAT Disarmed Stage The system will be disarmed when the driver's or passeng er's door is un-
locked by depressing the "UNLOCK
( )" button on the transmitter. After completion of the step above, the turn signal lights will blink twice to indicate that the system is disarmed. NOTE: Although the system is disarmed, the security LED lamp will blink con- tinuously. Insert the key in the igni-tion key cylinder to turn off the lamp. If any door, trunk lid or engine hood is not opened or the ignition key is not inserted in the ignition switch within 30 seconds, the system will be rearmed.
B070C01TG-GAT Alarm Stage The alarm will be activated if any of the following occurs while the car is parked and the system is armed.
1) A front or rear door is opened with-
out using the transmitter.
2) The trunk lid is opened without us- ing the transmitter.
3) The engine hood is opened.The alarming horn will sound and the turn signal lights will blink continuouslyfor 27 seconds. To turn off the system, unlock the door or trunk lid with the transmitter. B070C01TG
NOTE: When the system is disarmed while the "DOOR" button of the interior light is depressed, the interior lightwill illuminate for 30 seconds.

1
FEATURES OF YOUR HYUNDAI
31SEAT BELTS
B150A02A-GAT SEAT BELT PRECAUTIONS All occupants of the vehicle should wear their seat belts at all times. In-deed, your province's laws may re- quire that some or all occupants of the vehicle use seat belts.The possibility of injury or the severity of injury in an accident will be de- creased if this elementary safety pre-caution is observed. In addition, the following recommendations are made: B150B01Y-GAT Infant or Small Child Some countries require the use of child restraint systems for infants and small children. Whether this is requiredby law or not, it is strongly recom- mended that a child restraint seat or infant restraint system be used forinfants or small children weighing less than 18 kilograms (40 pounds). NOTE: Small children are best protected in an accident when properly re- strained by a child restraint sys- tem. B150C02A-AAT Larger Children Children who are too large for child restraint systems should always oc-cupy the rear seat and use the avail- able lap/shoulder belts. The lap por- tion should be fastened snug on thehips and as low as possible. Check belt fit periodically. A child's squirming could put the belt out of position. Chil-dren are afforded the most safety in the event of an accident when they are restrained by a proper restraint sys-tem in the rear seat. If a larger child (over age 13) must be seated in the front seat, the child should be securelyrestrained by the available lap/shoul- der belt and the seat should be placed in the rearmost position. Children un-der the age of 13 should be restrained securely in the rear seat. NEVER place a child under the age of 13 in the frontseat. NEVER place a rear facing child seat in the front seat of a vehicle.
B150D01A-AAT Pregnant Women The use of a seat belt is recommended for pregnant women to lessen thechance of injury in an accident. When a seat belt is used, the lap belt portion should be placed as low and snugly aspossible on the hips, not across the abdomen. For specific recommenda- tions, consult a physician. B150E01A-AAT Injured Person A seat belt should be used when an injured person is being transported.When this is necessary, you should consult a physician for recommenda- tions.
B150F01A-AAT One Person Per Belt Two people (including children) should never attempt to use a single seat belt.This could increase the severity of injuries in case of an accident.

1
FEATURES OF YOUR HYUNDAI
37
!
!
B220C02A-GAT To Release the Seat Belt When you want to release the seat belt, press the button in the locking buckle.
WARNING:
When fastening the outboard seatbelts or the center seat belt, makesure they are inserted into the cor- rect buckles to obtain maximum protection from the seat belt sys-tem and assure proper operation. B220C01TG
CHILD RESTRAINT SYSTEM
B230A03A-GAT (If Installed) Children riding in the car should sit in the rear seat and must always beproperly restrained to minimize the risk of injury in an accident, sudden stop or sudden maneuver. Accordingto accident statistics, children are safer when properly restrained in the rear seats than in the front seat. Largerchildren not in a child restraint should use one of the seat belts provided. You are required by law to use safetyrestraints for children. If small children ride in your vehicle you must put them in a child restraint system (safety seat).Children could be injured or killed in a crash if their restraints are not properly secured. For small children and ba-bies, a child seat or infant seat must be used. Before buying a particular child restraint system, make sure it fits yourcar seat and seat belts, and fits your child. Follow all the instructions pro- vided by the manufacturer when in-stalling the child restraint system. WARNING:
o A child restraint system must be placed in the rear seat. Never install a child or infant seat on the front passenger's seat.Should an accident occur and cause the passenger's front airbag to deploy, it could severely injureor kill an infant or child seated in an infant or child seat. Thus, only use a child restraint in the rearseat of your vehicle.
o A safety belt or child restraint
system can become very hot if itis left in a closed vehicle on a sunny day, even if the outside temperature does not feel hot. Besure to check the seat cover and buckles before placing a child there.
o When the child restraint system is not in use, store it in the trunkor fasten it with a safety belt sothat it will not be thrown forward in the case of a sudden stop or an accident.

1FEATURES OF YOUR HYUNDAI
38
Use the center seat belt for the rear to secure the child restraint system as illustrated. After installation of thechild restraint system, rock the child seat back and forth, and side to side to ensure that it is properly secured bythe seat belt. If the child seat moves, readjust the length of the seat belt. Then, ifequipped, insert the child restraint tether strap hook into the child re- straint hook holder and tighten to se-cure the seat. Always refer to the child restraint system manufacturer's rec- ommendation before installing the childrestraint system in your vehicle.
B235G01TG
B230F01A-GAT Installation on Center Rear Seats
o Never use an infant carrier or child
safety seat that "hooks" over a seatback; it may not provide ad-equate security in an accident.
o Never allow a child to be held in a
person's arms while they are in amoving vehicle, as this could re- sult in serious injury to the child in the event of an accident or asudden stop. Holding a child in a moving vehicle does not provide the child with any means of pro-tection during an accident, even if the person holding the child is wearing a seat belt.
o If the child restraint seat is not anchored properly, the risk of achild being seriously injured orkilled in a collision greatly in- creases.o Children who are too large to be ina child restraint should sit in the rear seat and be restrained withthe available lap/shoulder belts. Never allow children to ride in the front passenger seat.
o Always make sure that the shoul- der belt portion of the outboardlap/shoulder belt is positionedmidway over the shoulder, never across the neck or behind the back. Moving the child closertoward the seat belt buckle may help provide a good shoulder belt fit. The lap belt portion of thelap/shoulder belt or the center seat lap belt must always be po- sitioned as low as possible onthe child's hips and as snug as possible.
o If the seat belt will not properly fit the child, Hyundai recommendsthe use of an approved booster seat in the rear seat in order toraise the child's seating height so that the seat belt will properly fit the child.
o Never allow a child to stand up or kneel on the seat.

1
FEATURES OF YOUR HYUNDAI
39
!
B230G01NF
B230G01JM-GAT Installation on the Outboard Rear Seats To install a child restraint system on the outboard rear seats, extend the shoul- der/lap belt from its retractor. Buckle the seat belt and allow the seat belt totake up any slack. Make sure that the lap portion of the belt is tight around the child restraint system and the shoulderportion of the belt is positioned so that it cannot interfere with the child's head or neck. After installation of the childrestraint system, try to move it in all directions to be sure the child restraint system is securely installed.
If you need to tighten the belt, pull more webbing toward the retractor. When youunbuckle the seat belt and allow it to retract, the retractor will automatically revert back to its normal seated pas-senger emergency locking usage con- dition. NOTE:
o Before installing the child re-
straint system, read the instruc- tions supplied by the child re- straint system manufacturer.
o If the seat belt does not operate as described, have the systemchecked immediately by yourauthorized Hyundai dealer. WARNING:
o Do not install any child restraint system in the front passenger seat. Should an accident occur and cause the passenger's front airbagto deploy, it could severely injure or kill an infant or child seated in an infant or child seat. Therefore,only use a child restraint system in the rear seat of your vehicle.
o Before installing Child Restraint
System to vehicles fitted with Cur-tain Airbags, always refer to safety notices for Curtain Airbag sys- tems on this manual. Whenever installing child restraints, use onlyapproved devices and refer to "Child Restraint System" to en- sure correct installation and occu-pant protection is maximized.
