1FEATURES OF YOUR HYUNDAI
40
B230C02TG
Rear seat package tray
Tether Strap Hook
Front of Vehicle
2. Route the child restraint seat strap
over the seatback. For vehicles with adjustable head- rests, route the tether strap under the headrest and between the head-rest posts, otherwise route the tether strap over the top of the seatback. Child Restraint Hook Holders
B230C03A-GAT Securing a Child Restraint Sys- tem with "Tether Anchorage"System Three child restraint hook holders are located on the rear seat package tray.
B230C01NF
Tether Anchor Cover
1. Open the tether anchor cover on therear seat package tray. Child Restraint Hook Holder
B230B02A-AAT Using a Child Restraint System With "Tether Anchorage" Sys-tem For small children and babies, the use of a child seat or infant seat is stronglyrecommended and may be required in your state. This child seat or infant seat should be of appropriate size for thechild and should be installed in accor- dance with the manufacturer's instruc- tions. It is further recommended thatthe seat be placed in the vehicle's rear seat since this can make an important contribution to safety. Your vehicle isprovided with three child restraint hook holders on the rear seat package tray for installing the child seat or infant seat.Holder Bolt (5/16"-22 mm)
B230B01TG
Conical Spring Washer Child Restraint Hook HolderRetainer Washer

1
FEATURES OF YOUR HYUNDAI
41
B230D01TG-GAT Securing a Child Restraint Sys- tem with "ISOFIX" System and"Tether Anchorage" System ISOFIX is a standardized method of fitting child seats that eliminates the need to use the standard adult seat belt to secure the seat in the vehicle.This enables a much more secure and positive location with the added benefit of easier and quicker installation. B230D01NF
On each side of the rear seat, between the cushion and backrest, are located apair of ISOFIX anchorage points to- gether with a top tether mounting on the rear seat package tray. During the in-stalling, the seat has to be engaged at the anchorage-points in a way you can hear it clicking (check by pulling!) andhas to be fixed with the TopTether-belt on the belonging point of the rear seat package tray. The installing and theuse of a child-seat has to be done according to the installing-manual, which is added to the ISOFIX-seat.B230D02TG
ISOFIX Anchor
ISOFIX Anchor Position Indicator
3. Connect the tether strap hook to the
child restraint hook holder and tighten to secure the seat.
B230D03TG
NOTE: An ISOFIX-child-seat can only be installed if the seat has a vehicle- specific approval according to ECE-R44. Before using the ISOFIX-child- seat, which was bought for another car, ask your Hyundai-dealerwhether this seat-type is approved and recommended for your Hyundai. To secure the child restraint seat
1. To engage the child restraint seat tothe ISOFIX anchor, insert the child restraint seat latch into the ISOFIXanchor. Listen for the audible "click" sound.

1FEATURES OF YOUR HYUNDAI
42
B230H01JM-GAT Child Seat Restraint Suitability For Seat Position Use child safety seats that have been officially approved and are appropriatefor your children. When using the child safety seats, refer to the following table.
Rear
Center
Age Group Seating Position
L1, L2,
L3, L4 X
XX XX XX Rear
Outboard
Front
Passenger
0 : Up to 10 kg (0 ~ 9 months)0+ : Up to 13 kg(0 ~ 2 years)I : 9kg to 18kg(9 months ~ 4 years)II & III : 15kg to 36kg(4 ~ 12 years) X
L1, L2,
L3, L4
L3, L5,
L6, L7, L8
L6, L9
L1 : Suitable for Bebe confort ELIOS (E2 037014) approved for the use in this mass group
L2 : Suitable for PegPerego primo Viaggio (E13 030010) approvedfor the use in this mass group
vehicle rear seat belt metal latch plates or tabs must be latchedsecurely in their seat belt buckles and the seat belt webbing must be retracted behind the child restraintto prevent the child from reaching and taking hold of unretracted seat
belts. Unlatched metal latch platesor tabs may allow the child to reach the unretracted seat belts which may result in strangulationand a serious injury or death to the child in the child restraint.
o Do not mount more than one child
restraint to a single tether or achild restraint lower anchorage point. The improper increased loadmay cause the anchorage points or tether anchor to break, causing serious injury or death.
o Attach the ISOFIX or ISOFIX-com- patible child seat only to the ap-propriate locations shown in theillustration.
o Always follow the installation and
use instructions provided by themanufacturer of the child re- straint.
!WARNING:
o Do not install a child restraint seat at the center of the rear seat using the vehicle's ISOFIX anchors. The ISOFIX anchors are only providedfor the left and right outboard rear seating positions. Do not misuse the ISOFIX anchors by attemptingto attach a child restraint seat in the middle of the rear seat to the ISOFIX anchors. In a crash, thechild seat ISOFIX attachments may not be strong enough to secure the child restraint seat properly inthe center of the rear seat and may break, causing serious injury or death.
o When using the vehicle’s “ISOFIX” system to install a child restraintsystem in the rear seat, all unused
2. Connect the tether strap hook to the
child restraint hook holder and tightento secure the seat. Refer to "Secur- ing a Child Restraint System With Tether Anchorage System" on page1-40.

1FEATURES OF YOUR HYUNDAI
54
B990C01JM-GAT Curtain Airbag (If Installed)
Curtain airbags are located along both sides of the roof rails above the front and rear doors.They are designed to help protect the heads of the front seat occupants and the rear outboard seat occupants incertain side impact collisions. The curtain airbags are designed to deploy only during certain side impact collisions, depending on the crash se- verity, angle, speed and impact. Thecurtain airbags are not designed to deploy in all side impact situations, collisions from the front or rear of thevehicle or in most rollover situations. HLZ2051
Curtain Airbag
o Do not place any objects (an um-
brella, bag, etc.) between the frontdoor and the front seat. Such ob-jects may become dangerous pro- jectiles and cause injury if the supplemental side impact air baginflates.
o To prevent unexpected deploy-
ment of the side impact air bagthat may result in personal injury, avoid impact to the side airbag sensor when the ignition key ison.The airbags deploy only in certain side impact conditions severe enough to cause significant injuryto the vehicle occupants.
o For best protection from the side
airbag system and to avoid beinginjured by the deploying side im- pact airbag, each seat occupants should sit in an upright positionwith the seat belt properly fas- tened. The driver's hands should be placed on the steering wheel atthe 9:00 and 3:00 positions. The passenger's arms and hands should be placed on their laps.
o Do not use any accessory seat covers.
o Use of seat covers could reduce
or prevent the effectiveness of the system.
o Do not install any accessories on
the side or near the side impactairbag.
o Do not use excessive force on the
side of the seat.
o Do not place any objects over the
airbag or between the airbag and yourself.

1
FEATURES OF YOUR HYUNDAI
55
o The built in coat hooks should
only be used for light weight cloth- ing, ensure that pockets are free of any heavy or sharp objects. When using coat hooks, do not hangclothes on coat hangers.
o The space between the occupant
and the curtain airbag must neverbe occupied by children, passen- gers or pets. Occupants should never lean out or have any parts oftheir body protruding from the window while the engine is run- ning.
o Do not move the sun visor out to cover the side window if there isan item attached to it such asgarage door remote control, pens, air fresheners or the like. These objects may cause injury if theCurtain Airbag is deployed.
o Where sun blinds are fitted to the
rear doors, these must not ob-struct or impair the airbag in any way. o Do not install any accessories or
children’s toys in the Curtain Airbag deployment zones, as thismay impair the operation of the system or throw parts of them into the vehicle cabin causing injury tooccupants if the system is de- ployed.
o To maintain the integrity of the Curtain Airbag system, any work,removal or installation of the airbag and associated compo-nents (such as roof lining and side trims) should always be performed by an authorized Hyundai dealer.
!WARNING:
o Before installing child restraints , always refer to “Child Restraint System” to ensure correct instal- lation and occupant protection is maximized.
o Make sure that the occupant does not have any body parts (head,arms & legs) protruding outsidethe restraining system. If an inflat- ing airbag was to strike an infant child on the head, it may causeserious injury.
o Ensure the opening for the Cur-
tain Airbag System remains unob-structed at all times, so that the airbags can inflate properly if needed.
Important Safety Notes for Cur- tain Airbag Systems Following is a number of safety points concerning this system which shouldalways be observed to ensure risk of injury is reduced in an accident.

1
FEATURES OF YOUR HYUNDAI
101
!
B541A01TG-GAT Trunk Lid Control Button The trunk lid control button located in the vehicle glove box is used to preventunauthorized access to the trunk. Locking To activate the trunk lock system so that the trunk can only be opened with the master key, perform the following: 1. Open the glove box. 2. Set the trunk lid control button to
"OFF" position (not depressed).
3. Close the glove box and lock the glove box with the master key. B541A01TG
When leaving the key with a parking lot attendant or valet, perform steps 1 to 3above and leave the sub key with the attendent. Sub key can start the engine and operate door locks only. Releasing To release the trunk lock feature, open the glove box with master key and setthe trunk lid control button to "ON" position (depressed). In this position the trunk will open with trunk lid releaselever or transmitter. The trunk can never be opened with the sub key.
!WARNING:
The trunk lid should be always kept completely closed while the vehicle is in motion. If it is left open or ajar, poisonous exhaust gases may en-ter the car and serious illness or death may result. See additional warnings concerning exhaust gases on page 2-2. To be sure the trunk lid is securely fastened, always check by trying to pullit up again.
WARNING:
Doors and trunk should be keptlocked and keys be kept out of thereach of children. Parents also should teach their children about the dan- gers of playing in trunks.

1FEATURES OF YOUR HYUNDAI
104
o Automotive fuels are flammable/
explosive materials. When refuel- ing, please note the following guidelines carefully. Failure tofollow these guidelines may re- sult in severe personal injury, se- vere burns or death by fire orexplosion.
- Before refueling always note thelocation of the Emergency Gaso- line Shut-Off, if available, at the gas station facility.
- Before touching the fuel nozzle
or fuel filler cap, you shouldeliminate potentially dangerous static electricity discharge bytouching another metal part of the front of the vehicle, a safe distance away from the fuel fillerneck, nozzle, or other gas source.
- Do not get back into a vehicle
once you have begun refueling.Do not touch, rub or slide against any item or fabric (polyester,satin, nylon, etc.) capable of pro- ducing static electricity. Static electricity discharge can ignitefuel vapors resulting in explo- sion.If you must re-enter the vehicle,
you should once again elimi- nate potentially dangerous static electricity discharge by touch-ing a metal part of the vehicle, away from the fuel filler neck, nozzle or other gasoline source.
- When using a portable fuel con- tainer be sure to place the con-tainer on the ground prior torefueling. Static electricity dis- charge from the container can ignite fuel vapors causing a fire.Once refueling has begun, con- tact with the vehicle should be maintained until the filling iscomplete. Use only portable fuel containers designed to carry and store gasoline.
- Do not use cellular phones around a gas station or whilerefueling any vehicle. Electriccurrent and/or electronic inter- ference from cellular phones can potentially ignite fuel vaporscausing a fire. If you must use your cellular phone use it in a place away from the gas station. - When refueling always shut the
engine off. Sparks produced byelectrical components related tothe engine can ignite fuel va- pors causing a fire. Always in- sure that the engine is OFF be-fore and during refueling. Once refueling is complete, check to make sure the fuel filler cap anddoor are securely closed, before starting the engine.
- Do not light any fire around a gas station. DO NOT use matchesor a lighter and DO NOT SMOKE or leave a lit cigarette in yourvehicle while at a gas station especially during refueling. Automotive fuel is highly flam-mable and can, when ignited, result in explosion by flames.
- If a fire breaks out during refuel- ing, leave the vicinity of the ve-hicle, and immediately contact the manager of the gas stationor contact the police and local fire department. Follow any safety instructions they provide.

1FEATURES OF YOUR HYUNDAI
108
B611A01Y-GAT
B611A01TG
REAR SEAT ARMREST
The rear seat armrest is located in the center of the rear seatback.
STEERING WHEEL TILT & TELESCOPIC
B600A01TG-GAT Manual type
To adjust the steering wheel:
1. Push the lever downward fully to
unlock.
2. Adjust upward or downward and for-
ward or backward to set the steering wheel to the desired position.
3. After adjustment, securely tighten
the lever by pulling it upward.
HTG2076
REAR WINDOW CURTAIN
B265C01TG
B265C01TG-GAT (If Installed)
Press the curtain switch to raise the rear window curtain. To lower the rearwindow curtain, press the switch once again. NOTE:
o When the transaxle gear is shifted into reverse "R", the rear window curtain will automatically lower.
o Be sure to lower the rear window curtain when the vehicle is mov-ing.
o Do not attempt to raise or lower the rear window curtain manu-ally.
