1FEATURES OF YOUR HYUNDAI
20SEATS
Driver’s seat 1. Seat forward/rearward lock releaselever
2. Seatback recliner control lever 3. Seat height control lever (If Installed) 4. Lumbar support control knob5. Seat warmer switch (If Installed) Front passenger’s seat 6. Seat forward/rearward lock release
lever
7. Seatback recliner control lever 8. Seat warmer switch (If Installed) Front power seats (If Installed) 9. Lumbar support control knob
10. Seatback recliner control knob
11. Seat forward/rearward lock release
knob, Seat height control knob
12. Seatback recliner control knob
13. Seat forward/rearward lock release
knob
B080A01TG-GAT
B080A01TG

1
FEATURES OF YOUR HYUNDAI
21
!
!
SEATS
B080A01A-AAT
ADJUSTABLE FRONT SEATS
WARNING:
Never attempt to adjust the seat while the vehicle is moving. This could result in loss of control, or an accident which may cause death,serious injury, or property damage. B080B02A-AAT Adjusting Seat Forward and Rearward To move the seat toward the front or rear, pull the lock release lever up-ward. This will release the seat on its track so you can move it forward or rearward to the desired position. Whenyou find the position you want, release the lever and slide the seat forward or rearward on its track until it locks intothe desired position and cannot be moved further.HTG2033
B080C01A-AAT Adjusting Seatback Angle To recline the seatback, lean forward to take your weight off it, then pull up on the recliner control lever at the outsideedge of the seat. Now lean back until the desired seatback angle is achieved.
HTG2034
WARNING:
To ensure the seat is locked se-curely, attempt to move the seat forward or rearward without usingthe lock release lever.

1FEATURES OF YOUR HYUNDAI
22
!
!
WARNING:
WARNING:
To minimize risk of severe injury in the event of a collision or a suddenstop, both the driver and passen- ger seatbacks should always be in an upright position while the ve-hicle is in motion. The protection provided by the seat belts and airbags may be reduced signifi-cantly when the seatbacks are re- clined. There is greater risk that the driver and passenger will slide un-der the seat belt which may result in serious injury if a crash occurs when the seatbacks are reclined.The seat belt cannot provide full protection to an occupant if the seatback is reclined. B080D02JM-AAT Adjustable Headrests
Headrests are designed to help reduce the risk of neck injuries. To raise the headrest, pull it up. Tolower it, push it down while pressing the lock knob. To remove the head- rest, raise it as far as it can go thenpress the lock knob while pulling up-
ward. This should only be done when the seat is not occupied. B080D02TG
To lock the seatback into position,release the recliner control lever.
B080D01TGo For maximum effectiveness in caseof an accident the headrest shouldbe adjusted so the middle of the headrest is at the same height as the top of the occupant's eyes. Forthis reason, the use of a cushion that holds the body away from the seatback should not be recom-mended.
o Do not operate vehicle with the
headrests removed as injury tothe occupants may occur in the event of an accident. Headrests may provide protection against
Lock knob

1FEATURES OF YOUR HYUNDAI
28
!
NOTE:
o The seat warmer may not operate
if ambient temperature is warm enough.
o If the seat warmer doesn't work when the ambient temperature islower than 24°C, it must bechecked at an authorized dealer.
WARNING:
Be very careful not to injure by lowtemperature burn or an attack offever as following occupants; infants, children, old man, drunken man, people who is taken sleeping drug orcold remedy.B100A01TG-GAT SEAT WARMER (If Installed) The front seats can be electrically heated individually when the ignition switch is ON. When the switch is ON, anumber ranging from 1 to 5 is displayed on the switch (5 = warmest setting). To turn off the seat warmer, set theswitch to 0. B100A01TG
L
: When the remote control outside
rearview mirror switch knob is se-lected to the "L" position, both ofthe outside rearview mirrors will move downward.
R : When the remote control outside
rearview mirror switch knob is se-lected to the "R" position, only thepassenger's outside rearview mir- ror will move downward.
Neutral :When the remote control out-
side rearview mirror switchknob is placed in the middle position, the outside rearviewmirrors will not operate while the vehicle is moving back- ward.
NOTE: When the ignition key is in the "LOCK" position, the shift lever is moved to any position except "R"position, or the remote control out- side rearview mirror switch knob is placed in the middle position, theoutside rearview mirrors will auto- matically revert to original position.

1
FEATURES OF YOUR HYUNDAI
29
!WARNING:
The purpose of the folding rear seatbacks is to allow you to carry longer objects than could other-wise be accommodated. Do not al- low passengers to sit on top of the folded down seatback, while thecar is moving as this is not a proper seating position and no seat belts are available for use. This couldresult in serious injury or death in case of an accident or sudden stop. Objects carried on the folded downseatback should not extend higher than the top of the front seats. This could allow cargo to slide forwardand cause injury or damage during sudden stops.
B110A01NF-GAT REAR SEAT FOLDING REAR SEATBACKS
o To unlock the seatback, pull the seatback release lever, then pull for- ward on the seatback panel.
o When you return the seatback to its
upright position, always be sure ithas locked into position by pulling and pushing on the top of the seatback. B110A01TGB085D01TG-AAT Adjustable Headrests
Headrests are designed to help reduce the risk of neck injuries. To raise the headrest, pull it up. Tolower it, push it down while pressing the lock knob. To remove the head- rest, raise it as far as it can go thenpress the lock knob while pulling up- ward. This should only be done when the seat is not occupied. B080D01TG-1
Lock knob

1FEATURES OF YOUR HYUNDAI
30
B140A01S-AAT REAR SEAT WARNING For the safety of all passengers, lug- gage or other cargo should not be piled higher than the top of the seatback. Inaddition, do not place objects on the rear shelf as they may move forward during braking or in an accident andstrike vehicle passengers. B140A01TGB120A01NF-GAT REAR SEATBACK SAFETY LOCK (If Installed) If the rear seatback lock knob (located on the backside of the rear seatback)is in the "LOCK" position when the rear seatbacks are closed, it will not be possible to fold the rear seatback byusing the seatback release lever. In this instance, move the lock knob to the "UNLOCK" position and fold therear seatback. The rear seatback lock knob is designed to provide protection from unauthorized entry into the trunk. B120A01TG
!WARNING:
B080D02TG-1
o For maximum effectiveness in case of an accident the headrest should be adjusted so the middle of the headrest is at the same height as the top of the occupant's eyes. Forthis reason, the use of a cushion that holds the body away from the seatback should not be recom-mended.
o Do not operate vehicle with the
headrests removed as injury tothe occupants may occur in the event of an accident. Headrests may provide protection againstneck injuries when properly ad- justed.

1
FEATURES OF YOUR HYUNDAI
33
B170A04A-GAT HEIGHT ADJUSTABLE FRONT SEAT SHOULDER BELT You can adjust the height of the shoul- der belt anchor to one of 4 positions for maximum comfort and safety.If the height of the adjusting seat belt is too near your neck, you will not be getting the most effective protection.The shoulder portion should be ad- justed so that it lies across your chest and midway over your shoulder near-est the door and not your neck. To adjust the height of the seat belt anchor, lower or raise the height ad-juster into an appropriate position. HTG2058
!
To raise the height adjuster, pull it up. To lower it, push it down while pressingthe height adjuster button. Release the button to lock the anchor into position. Try sliding the heightadjuster to make sure that it has locked into position.
WARNING:
o The height adjuster must be in the locked position when the vehicle is moving.
o The misadjustment of height of
the shoulder belt could reducethe effectiveness of the seat belt in a crash.B180A01TG-GAT
SEAT BELTS 3-Point System with Emergency Locking Retractor
To Fasten Your Belt To fasten your seat belt, pull it out of the retractor and insert the metal tab intothe buckle. There will be an audible "click" when the tab locks into the buckle.The seat belt automatically adjusts to the proper length only after the lap belt is adjusted manually so that it fitssnugly around your hips. If you lean forward in a slow, easy motion, the belt will extend and let you move around. Ifthere is a sudden stop or impact, how- ever, the belt will lock into position.
B180A01NF

1FEATURES OF YOUR HYUNDAI
34
It will also lock if you try to lean forward too quickly. Check to make sure thatthe belt is properly locked and that the belt is not twisted. NOTE: If the seat belt is not fastened when the ignition key is turned from the "OFF" position to the "ON" position, the seat belt warning will activate toremind the driver and front passen- ger to fasten the seat belt as follows. B260E01TG-GAT Seat Belt Warning Light
(Except E.C)
The seat belt warning light blinks for about 6 seconds when the ignition keyis turned from the "OFF" position to the "ON". NOTE: You can find the front passenger's seat belt warning light on the center fascia panel.
*1) When the ignition key is turned from "OFF" position to "ON" within 1 minute.
*2) If the vehicle speed exceeds 9km/ h, the seat belt chime also soundsfor about 1~2 minutes.If the vehicle speed is below 9km/h, 1 minute later the seat belt chime also sounds for about 1~2 minutes.
The seat belt warning light and chimewill activate to the following table.
B265E01TG-GAT
Seat Belt Warning Light
and Chime (E.C only)
User (Driver+Front Passenger) Condition Sat Belt WarningLight
Seat Belt Ignition Switch
Unbuckled ON Stay on until buckled up
Buckled ON Come on for 6 seconds
Unbuckled ON * 1
Blink until buckled up
ON Blink until buckled up* 2
Buckled



Unbuckled NOTE:
o You can find the front passenger's
seat belt warning light on the cen- ter fascia panel.
o If the driver's seat belt is operated in this order "unbuckled

buck-
led

unbuckled" within 9 sec-
onds after the seat belt is buckled, the seat belt warning light and chime will not activate.
o Although the front passenger seat is not occupied, the seat belt warn-ing light will illuminate for 6 sec-onds.
o The seat belt warning light can be
operated when luggage is placedon the front passenger seat.
