2005 Hyundai Azera Owner's Manual

1FEATURES OF YOUR HYUNDAI
112
2. TAPE mode
o Pressing the SEEK ( ) will play thebeginning of the next music seg- ment.
o Pressing the SEEK ( ) will start
replay at the beginning of the musicjust listened to.
3. CD (Compact Disc)/CDC (Compact Disc Changer) mode
o Press the SEEK ( ) once to skip forward to the beginning of the next track.
o Press the SEEK ( ) once to skip back to the beginning of the track.
MUTE Switch
o Press the MUTE switch to disap- pear the sound.
o Press the MUTE switch again to
reproduce the sound.
VOL ( / ) Switch
o Press the VOL ( ) switch to in- crease volume.
o Press the VOL ( ) switch to de-
cease volume.
RADIO (FM1 FM2 AM) TAPE CD CDC
SEEK ( / ) Switch Press the SEEK switch 1 sec. or more.
1. RADIO mode When the SEEK ( ) is pressed, the unit will automatically tune to the next higher frequency and when the SEEK ( ) switch is pressed, it will automati-cally tune to the next lower frequency.

NOTE: Do not operate audio remote con- trol switches simultaneously. MODE Switch Press the MODE switch to select Ra- dio, Tape, CD (Compact Disc) andCDC (Compact Disc Changer). Each press of the switch changes the display as follows:
AUDIO REMOTE CONTROL SWITCH
B610A01L-GAT (If Installed) The steering wheel audio remote con- trol switch is installed to promote safe driving. B610A02TG
Without Cruise Control System
B610A03TG
With Cruise Control System

1
FEATURES OF YOUR HYUNDAI
113HEATING AND COOLING CONTROL
1. Side Defroster Nozzle
2. Side Ventilator
3. Windshield Defroster Nozzle
4. Center Ventilator
5. Rear Ventilator
B710A01TG-GAT
B710A01TG

1FEATURES OF YOUR HYUNDAI
114HEATING AND VENTILA- TION
B670A01NF-GAT Rotary and Push Button Type
1. Temperature control
2. Fan speed control
3. Air flow control
4. Air conditioning switch
5. Air intake control switch
6. Rear window defroster switch HTG2125
B710B01TG-AAT Ventilator
B710B01TG
To change the direction of the air flow, turn the control knob (1). To control the amount of air, turn the control knob (2).
B710B02TG The vents are opened when the vent knob is moved to "
" position. The
vents are closed when the vent knob is moved to "
". Keep these vents clear
of any obstructions.

1
FEATURES OF YOUR HYUNDAI
115
B670B01A-AAT Fan Speed Control (Blower Control) This is used to turn the blower fan on/ off and to select the fan speed.The blower fan speed, and therefore the volume of air delivered from the system, may be controlled manuallyby setting the blower control between the "1" and "4" position. HTG2132B670E02A-AAT Temperature Control This control is used to adjust the degree of heating or cooling desired.
HTG2133
Cool
WarmB670D01TG-AAT Air Flow Control This is used to direct the flow of air. Air can be directed to the floor, dashboard outlets, or windshield. Five symbolsare used to represent Face, Bi-Level, Floor, Floor-Defrost and Defrost air position. HTG2126

1FEATURES OF YOUR HYUNDAI
116
Floor-Level
Air is discharged through the floor vents, windshield defroster nozzle, sidedefroster nozzle and side ventilator. HTG2129Face-Level
Selecting the "Face" mode will cause air to be discharged through the face level vents and rear ventilator. Bi-Level
Air is discharged through the face vents, floor vents and rear ventilator. This makes it possible to have cooler air from the dashboard vents and warmerair from the floor outlets at the same time. HTG2128
HTG2127

1
FEATURES OF YOUR HYUNDAI
117
Floor-Defrost Level
Air is discharged through the wind- shield defroster nozzle, the floor vents, side defroster nozzle and side ventila-tor . If the "Floor-Defrost" mode is selected, the A/C will turn on automatically and"Fresh" mode will be activated. Defrost-Level
Air is discharged through the wind- shield defroster nozzle, side defroster nozzle and side ventilator.If the "Defrost" mode is selected, the A/C will turn on automatically and "Fresh" mode will be activated to im-prove windshield defrosting. HTG2131
HTG2130
B670C01TG-AAT Air Intake Control Switch This is used to select fresh outside air or recirculation of inside air.
FreshRecirculation
With the "
" mode selected, air en-
ters the vehicle from outside and is heated or cooled according to the otherfunctions selected. With the "
" mode selected, air from
within the passenger compartment is drawn through the heating system and heated or cooled according to the other functions selected.
B670C01TG

1FEATURES OF YOUR HYUNDAI
118
B700A02A-AATBI-LEVEL HEATING
Your Hyundai is equipped with bi-level heating controls. This makes it pos-sible to have cooler air from the dash- board vents and warmer air from the floor outlets at the same time. To usethis feature:
o Set the air intake control switch to
the fresh air ( ) position.
o Set the air flow control at the bi-level
( ) position.
o Adjust the fan speed control to the desired speed.
o Set the temperature control between "Cool" and "Warm". B700A01TG
NOTE: It should be noted that prolonged operation of the heating system in "
" mode will give rise to fogging
of the windshield and side windows and the air within the passenger com- partment will become stale. In addi-tion prolonged use of the air condi- tioning with the "
" mode selected
may result in the air within the pas- senger compartment becoming ex- cessively dry.
HEATING CONTROLS
B690A02S-AAT
For normal heating operation, set the air intake control to the fresh air ( )position and the air flow control to the floor ( ) position. For faster heating, the air intake con- trol switch should be set in the recircu- late ( ) position. If the windows fog up, set the air flow control to the defrost ( ) position.(The A/C will turn on automatically and "Fresh" mode will be activated.) For maximum heat, move the tem- perature control to "Warm". B690A01TG

1
FEATURES OF YOUR HYUNDAI
119VENTILATION
B710A01A-AAT
DEFROSTING/DEFOGGING
B720A02FC-AAT Use the heating/ventilation system to defrost or defog the windshield. To remove interior fog on the wind- shield:
o Set the air flow control to the defrost ( ) position.(The A/C will turn on automatically and "Fresh" mode will be activated.)
o Set the temperature control to the desired position.
o Set the fan speed control between
"1" and "4" position. B720A01TG
To operate the ventilation system:
o Set the air intake control switch at
the fresh air ( ) position.
o To direct all intake air to the dash-
board vents, set the airflow control to the face ( ) position.
o Adjust the fan speed control to the
desired speed.
o Set the temperature control between "Cool" and "Warm".
B710A02TGTo remove frost or exterior fog on the windshield:
o Set the air flow control to the defrost
( ) position.(The A/C will turn on automatically and "Fresh" mode will be activated.)
o Set the temperature control to warm.
o Set the fan speed control to position "3" or "4".
B720A02TG
