2005 Alfa Romeo GT Owner handbook (in English)

GETTING TO KNOW YOUR CAR
95
Warning
light on dialMessage
on display
F
PASSENGER’S FRONT AIR BAG DEACTIVATED
With the passenger’s front Air bag engaged, turning the ignition key to MARthe warning light
turns on, but it should go off after 4 seconds.
á
VDC SYSTEM (VEHICLE DYNAMICS CONTROL) (where fitted)
Turning the ignition key to MAR, the warning light on the dial turns on and it should go off
after approx. 4 seconds.
If the warning light does not go out or stays on when travelling together with the message +
symbol shown on the reconfigurable multifunction display, contact Alfa Romeo Authorised
Services.
The flashing of the warning light when travelling indicates the cutting in of the VDC system.
ASR – WHEEL ANTISKID SYSTEM (where fitted)
Turning the ignition key to MAR, the warning light on the dial turns on, but is should go off
after approx. 4 seconds. The warning light turns on together with the led on the ASR OFF button
when the system is switched off. The warning light flashes when the system cuts in, to alert the
driver that the system is adapting to the road surface grip conditions. The turning on of the warn-
ing light, together with the message + symbol shown by the reconfigurable multifunction display,
also indicates a failure of the ASR system. In this case contact Alfa Romeo Authorised Services as
soon as possible.
Warning light Findicates also warning light ¬failure. This is indi-
cated by intermittent flashing, over 4 seconds, of warning light
F. In
this event, warning light
¬could be not up to indicate restraint sys-
tem failures, if any. Stop the car and contact Alfa Romeo Authorized Services
to have the system checked immediately.
The warning light turns on when the passenger’s front Air bag is deactivated.

GETTING TO KNOW YOUR CAR
96
Warning
light on dialMessage
on display
W
LIGTH FAILURE
Turning the key to MAR, the warning light on the dial turns on but should go out after about
6 seconds.
The message + symbol are shown by the reconfigurable multifunction display when a fault to
any one of the following ligths is detected:
- sidelights
- braking lights and corresponding fuse
- rear fog lights
- number plate lights.
The failure referring to these lights could be: one or more blown bulbs, a blown protection fuse
or a cut-off electric connection.

GETTING TO KNOW YOUR CAR
97
Warning
light on dialMessage
on display
SPEED LIMIT EXCEEDED
On some versions the warning light turns on, together with the message on the display and the
sounding of the buzzer, when the vehicle exceeds the speed limit set previously (see the
“Reconfigurable multifunction display” chapter).
K
FUEL RESERVE
The warning light on the dial turns on (on some versions the message + symbol are shown on
the reconfigurable multifunction display) when about 7 litres of fuel are left in the tank and on
certain versions when autonomy is below 50 km.
AUTONOMY (TRIP COMPUTER)
The message + symbol are shown on the reconfigurable multifunction display when autonomy
is below 50 km.
SCHEDULED MAINTENANCE
This is shown on the reconfigurable multifunction display 2000 km from the deadline given in
the Scheduled Maintenance Programme (every 20,000 km) and it is shown again at timed inter-
vals, turning the ignition key to MARevery 200 km.

GETTING TO KNOW YOUR CAR
98
Warning
light on dialMessage
on display
R
LEFT-HAND DIRECTION INDICATOR (INTERMITTENT)
The warning light on the dial turns on when the direction indicator control lever is moved down-
wards or, together with the right indicator, when the hazard warning light button is pressed.
E
RIGHT-HAND DIRECTION INDICATOR (INTERMITTENT)
The warning light on the dial turns on when the direction indicator control lever is moved
upwards or, together with the left indicator, when the hazard warning light button is pressed.
3
SIDELIGHTS AND DIPPED-BEAMS
The warning light on the dial turns on when the sidelights or dipped beams are turned on.
Ü
CONSTANT SPEED ADJUSTMENT (CRUISE CONTROL)
The warning light on the dial turns on (on some versions the symbol is shown on the reconfig-
urable multifunction display) with the knurled ring of the cruise control in the ON position.
1
MAIN BEAMS
The warning light on the dial turns on when the main beams are turned on or when the “Follow
me home” device is turned on (see corresponding chapter).

GETTING TO KNOW YOUR CAR
99
Warning
light on dialMessage
on display
WARNING LIGHT FAILURE
This is shown on the reconfigurable multifunction display when a fault is detected to one of the
warning lights indicated.
POSSIBLE PRESENCE OF ICE ON THE ROAD
The symbol √+ message are shown by the reconfigurable multifunction display and the buzzer
sounds, when the outside temperature reaches or falls below 3° C to warn the driver about the pos-
sible presence of ice on the road. The buzzer lasts for 2 seconds while the outside temperature flash-
ing message is displayed for about 10 seconds; after that time, only the symbol
√is displayed until
the temperature goes beyond 6° C or the engine is stopped. If during travelling, after the signal of
possible presence of ice on the road, temperature goes beyond 6° C, the symbol disappears and if
the temperature reaches again 3°C, a new message (with outside temperature flashing) will be dis-
played together with the corresponding symbol
√accompanied by the sound signal.

GETTING TO KNOW YOUR CAR
100
1Upper stationary vent for defrosting or demisting windscreen - 2Upper centre adjustable vent - 3Stationary vents for defrosting or demist-
ing side windows - 4Adjustable centre, swivel vents - 5Side adjustable and swivel outlets - 6Front feet area fixed vents - 7Rear feet area
fixed vents - 8Rear adjustable swivel outlet.
CLIMATE CONTROL SYSTEM
fig. 88
A0A0703b

GETTING TO KNOW YOUR CAR
101fig. 89fig. 90fig. 91
UPPER CENTRE VENT
ADJUSTMENT
(fig. 89)
The vent (1) has an opening/closing con-
trol (A).
•= Completely closed.
I= Completely open.
CENTRE SWIVEL VENT
ADJUSTMENT
(fig. 89)
Each vent (2) has a lever (B) which
makes it possible to direct the flow of air (in
the 4 directions: up/down, right/left).
To adjust the air flow, use control (C):
•= Completely closed.
I= Completely open.
SIDE SWIVEL OUTLET
ADJUSTMENT
(fig. 90)
To direct the flow of air, turn the knurled
ring (A) and/or directly use control (B) as
required.
To adjust the air flow, use control (C):
•= Completely closed.
I= Partially open.
II= Completely open.
D- fixed vent for defrosting or demisting
side windows.
REAR SWIVEL OUTLET
ADJUSTMENT
(fig. 91)
To direct the flow of air, turn the knurled
ring (A) and/or directly use control (B) as
required.
To adjust the air flow, use control (C):
•= Completely closed.
I= Partially open.
II= Completely open.
A0A0085bA0A0086bA0A0087b

GETTING TO KNOW YOUR CAR
102
Below is a brief description of the manu-
al heating system.
To obtain best performance from manual
heater, set the knob pointer as shown in the
different figures.
For more detailed information about the
system and how to make the best use of
it, read the instructions given in the follow-
ing pages.
MANUAL HEATER
QUICK DEMISTING/DEFROSTING
MAXIMUM HEATING POWERA0A0730b
A0A0731b
fig. 93
fig. 94
