2004 MERCEDES-BENZ C-Class Comand Manual

138 NavigationDestination input

Destination input

Menu overview
1
234
67
P82.85-9160-31
5

139 Navigation
Destination input
Function
Page
1
Main destination input
menu
Entering a destinati-
on address

Retrieving a destina-
tion from the destina-
tion memory

Selecting a destinati-
on via the map

Entering Points of In-
terest

Selecting the last 12
destinations
141
192
149
155
159
2
Main address menu
Entering a destination
address
141
3
Main destination
memory menu
Selecting destination
from the destination
memory
192
4
“Destination via map”
menu
Setting destination via
location on map
Setting destination via
coordinates
149
153
5
“Settings” menu
Entering vehicle location
Calibrating tires
198
199
6
“Points of Interest”
menu
Setting destination via
Point of Interest listing
155
7
Activating list of last
12 destinations for a re-
calculation
159
Function
Page

140 NavigationDestination inputMain destination input menu
Press b.
The display that appears is dependent
on the last navigation function used:Route guidance has been switched off

the main destination input menu or

the location map (
page 167).
Route guidance has been switched on

the symbol display with an arrow in-
dicating your driving direction
(page 162) or

the map with the symbol indicating
current vehicle location
(page 162)
Route guidance has been switched on,
COMAND has been switched off for
more than 2 hours

an inquiry menu (
page 187)Changing over to another system, for
e.g. radio

Press c.
Switching the navigation system on
P82.85-9162-31
iThe following message will appear when
COMAND is preparing for navigation
startup: “Navigation being activated.
Please obey all traffic rules.”. Then, one
of the 3 displays will appear.
!Potential fault messages during prepa-
ration of navigation startup:
“Navigation cannot be activated. An
error has occurred”.

“CD-Reading error. Please use ano-
ther CD”.
Eject the inserted CD and insert a
navigation CD.

“No CD available. Please insert
NAVI-CD type DX only”.
Insert a current DX-coded navigati-
on CD. Using other navigation CDs
might lead to malfunctions.
If the error has been eliminated, you will
see the message “Navigation being acti-
vated. Please obey all traffic rules”.

141 Navigation
Destination input
Select one of the following possibilities to
enter a destination:
Entering a destination address

Selecting destination via the map
(page 149)

Entering Points of Interest
(page 155)

Selecting last destinations
(page 159)

Selecting from destination memory
(page 192)
Main address menu1Info/status line
2Selecting city/suburb or selecting des-
tination that has been entered at last
3Selecting a street
4Selecting a city center (
page 148)

Press the right-hand rotary/push-
button v in the main destination input
menu and confirm “Address”.
The main address menu will appear.
Switching back to the main destination in-
put menu

Press *.
Entering destination address
iIf you have previously entered a city/
suburb, you can highlight 3 and 4.

142 NavigationDestination inputSelect city/suburb“City/Suburb Entry” input menu 5Input line, selected characters (invers)
or last city selected
6Character set
7The character selected appears
magnified
8Moves the insertion point one position
to the right
9Activates the city list

Press the right-hand rotary/push-
button v in the main address menu
and confirm and confirm “City/Sub-
urb”.
The input menu “City/Suburb Entry”
will appear.
To adopt the city last selected:

Activate the city list.
To select another city:

Turn the right-hand rotary/push-button
v until the desired letter in character
set 6 is highlighted.
The character selected appears
magnified 7.

Press the right-hand rotary/push-
button v to enter the character in in-
put line 5.
COMAND supplements the new entry
with additional letters so that the
stored name of a city/suburb will ap-
pear.

Enter other characters until the desired
city name appears in 5.
Correcting the entry

Last character entered
Press r briefly.

All of the characters entered
Press r longer than 2 seconds.
iFor quicker input, COMAND will offer
available characters from the character
set 6 based on your selections and the
names of the cities stored on the navi-
gation CD.

143 Navigation
Destination input
Activating the city listCity listaSelected city is highlighted
bDisplay the previous page, if :
cDisplay the next page, if ;If the input menu “City/Suburb Entry” is
displayed

Press the right-hand rotary/push-
button v longer than 2 seconds.
or

Turn the right-hand rotary/push-button
v to highlight menu field 9 and press
to confirm.
The city list will appear.
You can now do the following in the city
list:

Confirm the city/suburb that has alrea-
dy been highlighted

Select another city/suburb
Turn the right-hand rotary/push-
button v until the desired city/
suburb is highlighted.

Display the previous/next page
Turn the right-hand rotary/push-
button v to highlight one of the ar-
rows b or c.

Press the right-hand rotary/push-
button v.
Confirming the city

Press the right-hand rotary/push-
button v longer than 2 seconds.
A selection menu will appear.iIf several options of a city/suburb are
available, another menu will appear
where you must make and confirm your
desired selection.

144 NavigationDestination inputdCity previously selected
eSelecting a street
fSelecting a city center (
page 148)

Press the right-hand rotary/push-
button v to activate the input menu
“Street”.Entering a street
“Street Entry” input menugInput line with letters that have already
been entered
hCharacter set
jThe character selected appears
magnified
kMoves the insertion point one position
to the right
lActivates the street list

Turn the right-hand rotary/push-
button v to highlight the desired cha-
racter in the character set h.
The character selected appears
magnified j.

Press the right-hand rotary/push-
button v to enter the character in in-
put line g.
COMAND supplements the new entry
with additional letters so that a saved
street name will appear.

Enter other characters until the desired
street name appears in g.
Correcting the entry (
page 142).
iFor quicker input, COMAND will offer
available characters from the character
set h based on your selections and the
names of the streets stored on the navi-
gation CD.

145 Navigation
Destination input
Activating the street listStreet listmStreet previously selected
nDisplay the previous page, if :
oDisplay the next page, if ;If the input menu “Street Entry” is display-
ed

Press the right-hand rotary/push-
button v longer than 2 seconds.
or

Turn the right-hand rotary/push-button
v to highlight menu field l and press
to confirm.
The street list appears.
Here you can, as in the city list
(page 143), select another street or
display the previous/next page.

Press the right-hand rotary/push-
button v longer than 2 seconds.
This will confirm city/suburb and street
of the desired destination. The selec-
tion menu “Destination Entry” appears.
P82.85-9169-31
212223
iIf several options of a street are availab-
le, another menu will appear where you
must make and confirm your desired se-
lection.
