170 NavigationRoute guidanceOnce the route has been calculated, the
symbol display will appear.
If you now are at the maneuver point, you
will also hear a voice output, e.g. “Please
turn right”.During route guidance, you can select the
following 3 screen displays:

Symbol display

Map display

Mix of map and symbol display
(page 175)
Voice output
During the trip, apart from visual informati-
on (symbol or map displays), COMAND
also provides all of the necessary route in-
formation via voice output.
COMAND gives you spoken recommenda-
tions

when route guidance begins

after the route has been calculated

before and during a change in the dri-
ving direction

on reaching the destination or a way
point
Beginning route guidance
Warning
G
Voice output is intended to direct you while
driving without diverting your attention from
the road and driving. Please always use this
feature instead of consulting the symbol or
map display for directions while driving
which may cause you to divert your attenti-
on from driving and increase your risk of ac-
cident.

171 Navigation
Route guidance
If an audio source is switched on, e.g. the
radio, the voice output will be mixed with
that of the audio source.
You can individually set the audio volume
differential between voice output/audio
source (
page 64). COMAND mutes navi-
gation voice outputs during telephone/
Tele Aid operation.
Repeating current voice output

Press the left-hand rotary/push-button
v briefly.
Muting current voice output

Press Ö briefly during a voice out-
put. You will hear the next announce-
ment normally.Switching the voice output off for the
duration of the current route guidance

Press Ö longer than 2 seconds du-
ring a voice output.
You will see the message “Voice output
is muted”.
Switching the voice output on again
The current route guidance has been com-
pleted.
Voice output will automatically switch on
again.
During a voice output

Press the left-hand rotary/push-button
v.Altering the voice output volume
At the COMAND control unit

Turn the left-hand rotary/push-button
v during a voice output.
COMAND will accept this setting for
following voice outputs.
At the multifunctional steering wheel
You can alter the volume with the steering
wheel keys during a voice output as well.
To raise the volume

Press J.
To lower the volume

Press I.

172 NavigationRoute guidanceExample of a traffic situation with voice
output
1“Prepare to turn right” (advance notice)
2“Turn right after 250 feet”
3“Please, turn next right”
Manual recall of the current voice instruc-
tion
Press left-hand rotary/push-button v.Advance notice of right turn
4Name of the street you are to turn onto
5Arrow indicating driving direction
6Name of the street you are travelling on
7Distance in miles to right turn Just before a right turn
8Name of the street you will to turn onto
9Right-turn arrow
aName of the street you are now driving
on
bDistance graph to turning point, redu-
ces as you approach the intersectionTurning onto a street
iAs you approach a junction or inter-
change (e.g. I-695), COMAND will advi-
se you the direction of travel to follow
(e.g. North) as well as the name of the
route.
iIn special situations, e.g. when turning
quickly several times in succession, the-
re may be deviations in the accuracy of
the voice instructions.

173 Navigation
Route guidance
1Distance to destination
2Arrow indicating driving direction
3Name of the road you are currently dri-
ving on
4Distance in miles to the next maneuver
point1Name of the street onto which you are
to drive
2Part of the street, not to be followed
3Name of the street you should drive on
4Distance graph to turning-pointBefore you drive through an intersection,
you will be informed of the continued rou-
te, e.g.

“Prepare to bear left soon” (advance
notice)

“Bear left after 250 feet”

“Please bear left”
Please note the following difference in
voice output
Following the course of the road
Driving through an intersectioniAs you approach a junction or inter-
change (e.g. I-695), COMAND will advi-
se you the direction of travel to follow
(e.g. North) as well as the name of the
route.
Situation
Example of voice
output
Making a turn
onto a street
...turn left/right.
Driving through

an intersection ...bear left/right.

174 NavigationRoute guidance1Activates map display2Return to symbol display
3Last scale selected
Altering the map scale (
page 176)
4Actual vehicle location
5Name of the street you will turn ontoYou can select one of the two possibilities:

Press the right-hand rotary/push-
button v to confirm 1.
or

Press l.
The map will appear in the scale last se-
lected.
Changing to map display
iCOMAND will remove the menu bar (ex-
cept for 3) after 6 seconds.
Turn the right-hand rotary/push-
button v to recall the menu bar to
the screen.

175 Navigation
Route guidance
If the function Mix is switched on, the sym-
bol display is activated automatically from
the map display before making a maneu-
ver. After you have made the maneuver,
the map will appear again.
Switching the mix function on
Turn the right-hand rotary/push-button
v to highlight “Mix” in the symbol dis-
play and press to confirm.
“Mix” appears in red.
Switching the mix function off

Turn the right-hand rotary/push-button
v to highlight “Mix” in the map or sym-
bol display and press to confirm.
“Mix” appears in black again.Map display before a maneuver, mix func-
tion is switched on
-As the vehicle approaches the maneuver
point (e.g. U-turn), COMAND will activate
the symbol display.
After you have made the U-turn, the map
will appear again.
Mix of map and symbol display

176 NavigationRoute guidanceActivating the scale selector
Press + or ,.
or

Turn the right-hand rotary/push-button
v to highlight 1 and press to con-
firm.
The scale bar will appear.
1Current map scale
2Scale selector
3New map scale
Zooming in for more detailed map

Press +.
or

Turn the right-hand rotary/push-button
v to the left.
The map will appear automatically.Zooming out for less detailed map

Press ,.
or

Turn the right-hand rotary/push-button
v to the right.
The map will appear automatically.
Altering the map scaleiA division mark corresponds to an avai-
lable scale. You can select 13 different
scales ranging from 0.05 miles/inch to
500 miles/inch.

177 Navigation
Route guidance
You can either select the map north or po-
sition it with the driving direction pointing
up.North-up: Map is displayed facing north 1Selecting map orientation
North arrow ! or compass needle <
(black tipping pointing to the north)
2Symbol for current vehicle locationSelecting driving direction pointing up
Heading-up: Map is displayed facing driving
direction pointing up
Turn the right-hand rotary/push-button
v to highlight 1 and press to con-
firm.
Symbol 2 points in the driving direc-
tion, the compass needle will appear.To return to North-up

Turn the right-hand rotary/push-button
v to highlight 1 and press to con-
firm.
The north arrow will appear again.
Selecting map orientation
Map orienta-
tion
Characteristics
North-up
North arrow always
points to the top
The symbol for the cur-
rent vehicle location is
turning on the map
Heading-up
The symbol for the cur-
rent vehicle location al-
ways points to the top
The compass needle is
turning, the black point
always points north
