2. This device must accept any interference that may be
received, including interference that may cause undes-
ired operation.
STEERING WHEEL LOCK Ð IF EQUIPPED
Your vehicle may be equipped with a passive steering
wheel lock (manual transmission only). This lock pre-
vents steering the vehicle without the ignition key. If the
steering wheel is moved a half turn in either direction
and the key is not in the ignition, the steering wheel will
lock.
To Manually Lock the Steering Wheel
With the engine running, rotate the steering wheel 1/2
revolution from straight ahead position, turn off the
engine and remove the key. Rotate the steering wheel
slightly in both directions until the lock engages.
To Release the Steering Wheel Lock
Insert the key in the ignition and turn the wheel slightly
to the right or left to disengage the lock.
NOTE:If you turned the wheel to the right to engage
the lock, you must turn the wheel slightly to the right to
disengage it. If you turned the wheel to the left to engage
the lock, turn the wheel slightly to the left to disengage it.
ILLUMINATED ENTRY
The interior lights come on when you open any door.
They will remain on for about 30 seconds after all doors
are closed then fade to off.
The lights also will fade to off if you turn on the ignition
after you close all the doors.
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 17
2

DOORS AND DOOR LOCKS
The vacuum fluorescent (VF) display located in the
odometer area displays the word ªdoorº as an indication
of a door ajar or door not completely closed. When the
vehicle is not moving and the door is ajar or not
completely closed, the VF display will show the word
ªdoorº and then show the odometer/trip odometer
mileage (each for 2 seconds). The display will continue to
cycle.
NOTE:If vehicle is equipped with the optional Elec-
tronic Vehicle Information Center (EVIC) in the overhead
console, all warnings including ªdoorº, ªGATEº,
ªGLASSº, and ªLOWASHº will only be displayed in the
EVIC display (not in the instrument cluster). For addi-
tional information, refer to ªOverhead Console Ð If
Equippedº in Section 3.If any other active warnings including ªGATEº,
ªGLASSº, or ªLOWASHº are present, they will be shown
in the VF display and will also continue to cycle. If the
vehicle is moving, three single chimes will occur (One
chime for each complete display cycle (three cycles total).
After this, the display will continue to cycle only (no
chimes).
18 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE

If the trip/reset button is pressed while the VF warnings
are being displayed, the VF display will revert back to
only displaying the odometer/trip odometer mileage.
Manual Door Locks
Use the manual door lock plunger to lock the doors from
inside the vehicle. If the plunger is down when the door
is closed, the door will lock. Therefore, make sure the
keys are not inside the vehicle before closing the door.
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 19
2

WARNING!
²For personal security, and safety in the event of an
accident, lock the vehicle doors as you drive as
well as when you park and leave the vehicle.
²When leaving the vehicle always remove the key
from the ignition lock, and lock your vehicle. Do
not leave children unattended in the vehicle, or
with access to an unlocked vehicle. Unsupervised
use of vehicle equipment may cause severe per-
sonal injuries and death.
CAUTION!
An unlocked vehicle is an invitation to thieves.
Always remove the key from the ignition and lock
all of the doors when leaving the vehicle unattended.
20 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE

Power Door Locks Ð If Equipped
A door lock switch is on each front door panel. Press this
switch to lock or unlock the doors.
If the plunger is down when the door is closed, the door
will lock. Therefore, make sure the keys are not inside the
vehicle before closing the door.If you press the door lock switch while the keys are in the
ignition switch, and the driver's door is open, the doors
will not lock.
The rear doors cannot be opened from inside the vehicle
until you pull up the lock plungers.
Automatic Door Locks Ð If Equipped
The doors will lock automatically if:
1. all doors are closed,
2. vehicle speed is above 15 mph (24 km/h),
3. and the accelerator pedal is depressed.
This will occur only once, will not reoccur until a door is
opened.
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 21
2

Child Protection Locks
The rear doors of your vehicle are equipped with child
protection locks. If you push up on the lever on the open
edge of the door it cannot be opened from the inside of
the vehicle. Push the lever down to disengage the child
protection locks.
WARNING!
Avoid trapping anyone in the vehicle in a collision.
Remember that the rear doors can only be opened
from the outside when the child protection locks are
engaged.
22 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE

REMOTE KEYLESS ENTRY
This system allows you to lock or unlock the doors or
open the swing gate flip-up window from distances of
23±50 feet (7±15 meters) using a transmitter. You don't
have to point the transmitter at the vehicle to activate the
system. Each vehicle comes with two transmitters.
To Unlock the Doors
Press and release the ªUnlockº button once to unlock the
driver's door. Press the button again within 5 seconds to
unlock all the doors. If your vehicle is equipped with
Illuminated Entry, the interior lights also come on and
remain on for about 30 seconds, when you unlock the
doors. The park lights will flash twice to acknowledge
the unlock signal.NOTE:The transmitter can be programmed to unlock
all the doors upon the first press of the9Unlock9button
(within 23±50 feet (7±15 meters) of the vehicle) by per-
forming the following procedure:
1. Press and hold the9Unlock9button on the transmitter.
2. Continue to hold the9Unlock9button, wait at least 4
but no longer than 10 seconds, then press the ªLockº
button.
3. Release both buttons.
4. Repeating steps 1±3 will restore original operation.
NOTE:The Light Flash can be enabled or disabled
(within 23±50 feet (7±15 meters) of the vehicle) by per-
forming the following procedure:
1. Press and hold the9Lock9button on the transmitter.
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 23
2

2. Continue to hold the9Lock9button, wait at least 4 but
no longer than 10 seconds, then press the ªRear Releaseº
button.
3. Release both buttons.
4. Repeating steps 1±3 will restore original transmitter
operation.
To Lock the Doors
Press and release the ªLockº button once to lock the
doors, swing gate flip-up window, and swing gate.
The horn will chirp and the park lights will flash once to
acknowledge the lock signal.
NOTE:The horn chirp can be enabled or disabled
(within 23±50 feet (7±15 meters) of the vehicle) by the
following procedure:
1. Press and hold the9Lock9button on the transmitter.2. Continue to hold the9Lock9button, wait at least 4 but
no longer than 10 seconds, then press the9Unlock9
button.
3. Release both buttons.
4. Repeating steps 1±3 will restore original transmitter
operation.
To Unlatch the Swing Gate Flip-Up Window
Press and hold the ªRear Releaseº button on the trans-
mitter to unlatch the swing gate flip-up window.
WARNING!
To avoid injury stand back when opening. Glass will
automatically rise.
24 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE
