2004 JEEP LIBERTY Owners Manual

THINGS TO KNOW BEFORE STARTING YOUR VEHICLE
CONTENTS
mA Word About Your Keys..................12
NIgnition Key..........................12
NKey-In-Ignition Reminder................14
mSentry Key Immobilizer System Ð If Equipped . .14
NImportant Note About Service.............15
NReplacement Keys......................15
NCustomer Key Programming..............16
NGeneral Information....................16
mSteering Wheel Lock Ð If Equipped..........17NTo Manually Lock The Steering Wheel.......17
NTo Release The Steering Wheel Lock.........17
mIlluminated Entry........................17
mDoors And Door Locks....................18
NManual Door Locks.....................19
NPower Door Locks Ð If Equipped..........21
NAutomatic Door Locks Ð If Equipped.......21
NChild Protection Locks..................22
mRemote Keyless Entry.....................23
2

NTo Unlock The Doors...................23
NTo Lock The Doors.....................24
NTo Unlatch The Swing Gate Flip-Up Window . .24
NPanic Alarm..........................25
NTo Use The Panic Alarm.................25
NTo Program Additional Transmitters.........26
NGeneral Information....................26
NTransmitter Battery Service...............27
mSecurity Alarm System Ð If Equipped.........28
NTo Set The Alarm......................28
NTo Disarm The System...................28
mRear Swing Gate........................29
mWindows.............................32NPower Windows Ð If Equipped............32
NWind Buffeting........................34
mOccupant Restraints......................34
NLap/Shoulder Belts.....................35
NLap/Shoulder Belt Operating Instructions.....36
NAdjustable Upper Shoulder Belt Anchorage....40
NAutomatic Locking Mode Ð If Equipped.....41
NEnergy Management Feature..............42
NSeat Belt Pretensioners...................43
NEnhanced Driver Seat Belt Use Reminder System
(BeltAlert)...........................44
NSeat Belts And Pregnant Women............45
NSeat Belt Extender......................45
10 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE

NDriver And Front Passenger Supplemental
Restraint Systems (SRS) Ð Airbags..........46
NChild Restraint........................58
mEngine Break-In Recommendations...........68
mSafety Tips............................68NExhaust Gas..........................68
NSafety Checks You Should Make Inside The
Vehicle..............................69
NSafety Checks You Should Make Outside The
Vehicle..............................70
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 11
2

A WORD ABOUT YOUR KEYS
The keys for your new vehicle are enclosed in a plastic
bag with the key code number on it. If you received your
keys without the bag, ask your dealer to give you the
number. The key code can also be obtained by the dealer
from your vehicle invoice.
Ignition Key
Insert the key fully, then turn the switch to one of the four
illustrated positions. The key can be inserted or with-
drawn only in the LOCK position. The automatic trans-
mission gear selector must be in the P (Park) position.
12 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE

To remove the ignition key on models with an automatic
transmission, place the gearshift lever in P (Park), turn
the ignition key to LOCK and remove the key.
To remove the ignition key on models with a manual
transmission, depress and hold the key release button,
turn the ignition key to LOCK and remove the key.WARNING!
Leaving children in a vehicle unattended is danger-
ous for a number of reasons. A child or others could
be injured. Children should be warned not to touch
the parking brake, brake pedal, or the gear selector
lever. Do not leave the keys in the ignition. A child
could operate power windows, other controls, or
move the vehicle.
CAUTION!
An unlocked vehicle is an invitation to thieves.
Always remove the key from the ignition, and lock
all doors when leaving the vehicle unattended.
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 13
2

Key-In-Ignition Reminder
If you open the driver's door and the key is fully inserted
in the ignition switch, a chime will sound to remind you
to remove the key.
SENTRY KEY IMMOBILIZER SYSTEM Ð IF
EQUIPPED
The Sentry Key Immobilizer System (SKIS) prevents
unauthorized operation of the vehicle by disabling the
engine. The system will shut the engine down after 2
seconds of running if an invalid key is used to start the
vehicle. This system utilizes ignition keys which have an
electronic chip (transponder) embedded into them. Only
keys that have been programmed to the vehicle can be
used to start and operate the vehicle for longer than the
2 second validation time period.
The Sentry Key Immobilizer System does not need to be
armed or activated. Operation of the system is automatic
regardless of whether or not the vehicle is locked orunlocked. During normal operation, the SKIS indicator
light will come on for 3 seconds immediately after the
ignition switch is turned on for a bulb check. Afterwards,
if the bulb remains on, this indicates a malfunction in the
electronics. If the bulb begins to flash immediately after
the ignition switch is turned on, this indicates that an
invalid key is being used to start the vehicle. Both of
these conditions will result in the engine being shut
down after 2 seconds of running. Keep in mind that a key
which has not been programmed is also considered an
invalid key even if it is cut to fit the ignition for that
vehicle.
If the SKIS indicator light comes on during normal
vehicle operation (it has been running for longer than 10
seconds) a fault has been detected in the electronics and
the vehicle should be serviced as soon as possible.
14 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE

NOTE:
²The Sentry Key Immobilizer System is not compatible
with remote starting systems. Use of these systems
may result in vehicle starting problems and loss of
security protection.
²Mobil SpeedpassŸ, additional Sentry Keys, or any
other transponder equipped components on the same
keychain will not cause a key-related (Transponder)
fault unless the additional part isphysically held
against the ignition keybeing used when starting the
vehicle. Also, cell phones, pagers, or other RF electron-
ics will not cause interference with this system.
All of the keys provided with your new vehicle have
been programmed to the vehicle electronics.
Important Note About Service
A four digit PIN number is needed to service the Sentry
Key Immobilizer System. This number can be obtained
from your authorized dealer. However, this number can
also be found on your customer invoice that you were
given upon receipt of your vehicle.
Replacement Keys
NOTE:Only keys that have been programmed to the
vehicle electronics can be used to start the vehicle. Once
a Sentry Key has been programmed to a vehicle, it cannot
be programmed to any other vehicle.
At the time of purchase, the original owner is provided
with a four digit PIN number. This number is required
for dealer replacement of keys. Duplication of keys may
be performed at an authorized dealer or by using the
Customer Key Programming procedure. This procedure
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 15
2

consists of programming a blank key to the vehicle
electronics. A blank key is one which has never been
programmed.
NOTE:When having the Sentry Key System serviced,
bring all vehicle keys to the dealer.
Customer Key Programming
You can program new keys to the system if you have two
valid keys by doing the following:
1. Cut the additional Sentry Key Transponder blank(s) to
match the ignition switch lock cylinder key code.
2. Insert the first valid key into the ignition switch and
turn the ignition switch ON for at least 3 seconds but no
longer than 15 seconds. Turn the ignition switch OFF and
remove the first key.
3. Insert the second valid key and turn the ignition
switch ON within 15 seconds. After ten seconds, a chimewill sound and the SKIS indicator light will begin to
flash. Turn the ignition switch OFF and remove the
second key.
4. Insert a blank Sentry Key into the ignition switch and
turn the ignition switch ON within 60 seconds. After 10
seconds, a single chime will sound. The SKIS indicator
light will stop flashing, turn on for 3 seconds; then turn
off.
The new Sentry Key has been programmed. Repeat this
process to program up to a total of 8 keys.
General Information
The Sentry Key Immobilizer System complies with FCC
rules part 15 and with RSS-210 of Industry Canada.
Operation is subject to the following two conditions:
1. This device may not cause harmful interference.
16 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE
