2004 INFINITI QX56 display

BRC-60
[VDC/TCS/ABS]
TROUBLE DIAGNOSES FOR SYMPTOMS
Revision: August 20072004 QX56
ABS Warning Lamp Does Not Come On When Ignition Switch Is Turned OnEFS0044Y
1. CHECK ABS ACTUATOR AND ELECTRIC UNIT (CONTROL UNIT) FUSES
Check 30A fusible link h and 40A fusible link i for ABS actuator and electric unit (control unit). For fusible
link layout, refer to PG-4, "
POWER SUPPLY ROUTING CIRCUIT" .
OK or NG
OK >> GO TO 2.
NG >> If fusible link is blown, be sure to eliminate cause of problem before replacing.
2. CHECK ABS ACTUATOR AND ELECTRIC UNIT (CONTROL UNIT) POWER SUPPLY CIRCUITS
1. Disconnect ABS actuator and electric unit (control unit) connec-
tor.
2. Check voltage between ABS actuator and electric unit (control
unit) connector terminal 1 (Y) and ground and terminal 32 (B/Y)
and ground.
Does battery voltage exist?
YES >> GO TO 3.
NO >> Repair harness or connectors between fusible link and
ABS actuator and electric unit (control unit).
3. CHECK ABS ACTUATOR AND ELECTRIC UNIT (CONTROL UNIT) GROUND CIRCUIT
Check continuity between ABS actuator and electric unit (control
unit) connector terminal 16 (B) and ground and terminal 47 (B) and
ground.
Does continuity exist?
YES >> Replace ABS actuator and electric unit (control unit).
Refer to BRC-66, "
Removal and Installation" .
NO >> Repair harness or connectors between ABS actuator
and electric unit (control unit) and ground.
ABS Warning Lamp Stays On When Ignition Switch Is Turned OnEFS0044Z
1. CARRY OUT SELF-DIAGNOSIS
Carry out self-diagnosis. Refer to BRC-29, "
SELF-DIAGNOSIS" .
Are malfunctions detected in self-diagnosis?
YES >> Refer to BRC-30, "Display Item List" .
NO >> Refer to DI-31, "
WARNING LAMPS" .
WFIA0199E
WFIA0196E

TROUBLE DIAGNOSES FOR SYMPTOMS
BRC-61
[VDC/TCS/ABS]
C
D
E
G
H
I
J
K
L
MA
B
BRC
Revision: August 20072004 QX56
Vehicle Jerks During TCS/VDC ActivationEFS00450
1. ABS ACTUATOR AND ELECTRIC UNIT (CONTROL UNIT) SELF-DIAGNOSIS
Perform ABS actuator and electric unit (control unit) self-diagnosis.
Are self-diagnosis result items displayed?
YES >> After checking and repairing the applicable item, perform the ABS actuator and electric unit (con-
trol unit) self-diagnosis again.
NO >> GO TO 2.
2. ENGINE SPEED SIGNAL INSPECTION
Perform data monitor with CONSULT-II for the ABS actuator and electric unit (control unit).
Is the engine speed at idle 400 rpm or higher?
YES >> GO TO 4.
NO >> GO TO 3.
3. ECM SELF-DIAGNOSIS
Perform ECM self-diagnosis.
Are self-diagnosis result items displayed?
YES >> After checking and repairing the applicable item, perform the ECM self-diagnosis again.
NO >> GO TO 4.
4. TCM SELF-DIAGNOSIS
Perform TCM self-diagnosis.
Are self-diagnosis result items displayed?
YES >> After checking and repairing the applicable item, perform the TCM self-diagnosis again.
NO >> GO TO 5.
5. CONNECTOR INSPECTION
Disconnect the ABS actuator and electric unit (control unit) connector and the ECM connectors and check the
terminals for deformation, disconnection, looseness or damage.
OK or NG
OK >> GO TO 6.
NG >> Repair or replace as necessary.
6. CAN COMMUNICATION INSPECTION
Check the CAN communication system. Refer to BRC-54, "
CAN Communication System Inspection" .
OK or NG
OK >> Inspection End.
NG >> Refer to LAN-5, "
CAN COMMUNICATION" .

ON-VEHICLE SERVICE
BRC-63
[VDC/TCS/ABS]
C
D
E
G
H
I
J
K
L
MA
B
BRC
Revision: August 20072004 QX56
4. Touch "START".
CAUTION:
Set vehicle as shown in the display.
5. After approximately 10 seconds, touch "END". (After approxi-
mately 60 seconds, it ends automatically.)
6. Turn ignition switch OFF, then turn it ON again.
CAUTION:
Be sure to carry out above operation
7. Run vehicle with front wheels in straight-ahead position, then
stop.
8. Select "DATA MONITOR", "SELECTION FROM MENU", and
"DECEL G SEN" on CONSULT-II screen. Then check that "DECEL G SEN" is within ±0.08G. If value is
more than specification, repeat steps 3 to 7.
9. Erase memory of ABS actuator and electric unit (control unit) and ECM.
10. Turn ignition switch to OFF.
SF IA116 2E
